That annoying dead pixel on your TFT, OLED, or LCD screen might just be stuck and easy to fix. We"ll show you how to do it. You can still return your monitor if this doesn"t work; nothing we recommend here will void your warranty.

Yes, you should test any new monitor for bad pixels. You can simply run your screen through a palette of basic colors, as well as black and white in full-screen mode using a tool like EIZO Monitor Test.

EIZO Monitor Test is an online tool that lets you find and eventually fix stuck pixels. It packs many options into a single test window, but it"s easy to use once you have an overview.

To test your screen, check all the boxes you want to include in your test. We recommend the default setting of having all boxes checked. If you"re testing multiple monitors, you can open the test on an additional monitor. When you"re ready, click Start test to launch the full-screen test window.

Below you see the first test pattern. Each screen has an explainer in the bottom right detailing what you should look for. Next, you"ll see a menu that lets you go from one test to the next on the left. Move through the black and white screens and all the solid colors (green, blue, and red) and check our screen. To exit, press the ESC key or the exit symbol in the top right.

This is a very thorough test not only meant to identify bad pixels but also powerful enough to test the quality of your monitor. Unfortunately, with Flash no longer supported by most browsers, you"ll probably have to use the executable version to make it work.

Move the mouse to the top of the test window, and a menu will appear. There is an info window that you can turn off with a button in the top right corner of the menu. Then click on the Homogenuity test point and move through the three colors as well as black and white.

Fingers crossed, you won"t discover anything out of the ordinary. In the unfortunate case that you do, let"s see whether it"s a stuck or a dead pixel and what you can do about it.

A stuck pixel, sometimes wrongfully referred to as a hot pixel, is defective because it receives incomplete information. Hence, it appears in one of the colors that its three sub-pixels can form, i.e., red, green, or blue. Strictly speaking, hot pixels only appear in digital cameras when electrical charges leak into the camera"s sensor wells. Sometimes, stuck pixels fix themselves.

In a dead pixel, all sub-pixels are permanently off, which will make the pixel appear black. The cause could be a broken transistor. In rare cases, however, even a black pixel may just be stuck.

Unfortunately, you can"t fix a dead pixel. You can, however, fix a stuck pixel. As I explained above, it"s hard to tell the two apart. Either way, these are the methods you can try:

Finally, you can try a manual method that involves rubbing the stuck pixel with a damp cloth or a pointy but soft item, like the rubber/eraser at the end of a pencil.

The tool will load a black browser window with a square of flashing pixels. Press the green button in the bottom right to go full-screen. Drag the flashing square to where you found the stuck pixel and leave it there for at least 10 minutes.

UDPixel, also known as UndeadPixel, is a Windows tool. It can help you identify and fix pixels using a single tool. The program requires the Microsoft .NET Framework. If you"re not on Windows or don"t want to install any software, scroll down for the online tools below.

Should you spot a suspicious pixel, switch to the Undead pixel side of things, create sufficient amounts of flash windows (one per stuck pixel), and hit Start. You can drag the tiny flashing windows to where you found odd pixels.

The PixelHealer lets you flash a combination of black, white, all basic colors, and a custom color in a draggable window with customizable size. You can even change the flashing interval and set a timer to close the app automatically.

Let it run through all colors in Auto mode to spot whether you have any weird pixels on your screen. If you do, start the fix, which will rapidly flash your entire screen with black, white, and basic color pixels.

Should none of these tools resolve your stuck or dead pixel issue, here is one last chance. You can combine any of the tools detailed above and the magic power of your own hands. There is a very good description of all available techniques on wikiHow. Another great step-by-step guide can be found on Instructables.

This works because, in a stuck pixel, the liquid in one or more of its sub-pixels has not spread equally. When your screen"s backlight turns on, different amounts of liquid pass through the pixel to create different colors. When you apply pressure, you"re forcing the liquid out, and when you release the pressure, chances are the liquid will push in, spreading around evenly as it should.

When all attempts to revive your bad pixel fail, the next best thing you can do is to make peace with it. One ugly pixel won"t break your screen, and eventually, you"ll forget about it. If the defect affects more than a single pixel, however, or just bothers you a lot, you can always replace your monitor.

First, check the warranty. The manufacturer or the marketplace where you purchased the monitor might cover dead pixels. Note that most manufacturers define a maximum number of allowable bad pixels for specific resolutions, and the warranty won"t apply until your monitor crosses that threshold.

Bright or dark sub-pixels can occur during the production of the LCD Monitor panel but does not affect the LCD Monitor functionality. The customer may notice the bright or dark spots if the film of the liquid crystal does not perform as expected while customers uses the LCD monitor. However, this is not considered a defect unless the number of bright and dark subpixels exceeds the maximum allowable threshold (...)

On a monitor with over 12 million pixels (Wide QXGA+, 2560x1600 pixels), for example, LG"s pixel policy says that 12 bright or dark sub-pixels is the maximum you have to tolerate.

Should all of these approaches fail to fix your dead pixel warrior, at least you"ll now know it"s not simple to fix, and, you might actually have to replace the screen.

In a TFT LCD (thin-film-transistor liquid-crystal display), each pixel has three sub-pixels: a red, green and blue. Each of these sub-pixels has its own transistor which allows the individual pixel to be turned on or off. These pixels and transistors are contained within a layer of insulating liquid between other transparent layers. Pixel size defects on the display can result from malfunctioning transistors or uneven distribution of this insulating liquid inside the display.

There are two main pixel level defects with LCDs -- dead pixels and stuck pixels. These are actually two separate issues, but the words are often used interchangeably. Dead pixels usually occur because the pixel transistor is defective and permanently stuck in an "off" state. The problematic pixel will usually be completely black. Unfortunately, a transistor issue is not fixable but still worth addressing because it"s hard to identify and may actually be a fluid distribution issue. The manufacturer may have an acceptable limit for dead pixels, above which they will replace the monitor, bu these policies vary depending on manufacturer. Stuck pixels, on the other hand, can be due either to poor insulating liquid distribution, or transistors stuck in an "on" state on a particular color. Liquid distribution issues are often fixable, but transistor issues are not.

Stuck pixels due to uneven insulating fluid distribution can often be fixed by applying pressure to the area of the pixel. First turn off the monitor, then get a soft cloth and a pen or eraser with a dull and rounded end. Fold the cloth in two, put it on the monitor in the problem pixel area, then apply some slight pressure onto the cloth with the pen or eraser. Continue applying pressure while you turn the monitor on and see if the pixel color has reset. You could also simply use a pencil eraser and softly rub it directly onto the problem pixel. Try your finger or other methods to create a pressure point and attempt to massage the display.

An alternate method to fix a stuck pixel is by tapping. Keep the monitor on and use a screensaver or blanker to display a black screen or window. First find an item with a dull and rounded end, such as a pencil eraser end, pen end, or a sharpie with the cap on. Items used in the previous method will work just fine. The difference here is that you"ll tap the pixel location on the screen directly with this item, and without using any cloth. Apply enough pressure so you see a small, white glow when you press on the screen. Do this a couple of times and then switch to a white screen or window and see if the pixel is unstuck.

If the previous methods did not work, you can try software designed to locate or fix dead or stuck pixels. DeadPixelTester runs various display tests to help you locate problem pixels but does not attempt flashing colors to try and fix them. UDPixel and PixelRepairer both help to find dead or stuck pixels and can attempt to fix these issues by rapidly flashing colors onto sections of the screen. These software suggestions are all Windows-based freeware. Note that the display of rapidly flashing screens may trigger seizures and epileptic attacks, so use these with care.

Michael Martinez has been working with computers since 1993. He fondly remembers the launch of Windows 95 and the original Pentium processors. Martinez has a Bachelor of Science in computer science.

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller"s listing for full details.See all condition definitionsopens in a new window or tab

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller"s listing for full details.See all condition definitionsopens in a new window or tab

By continuing to use AliExpress you accept our use of cookies (view more on our Privacy Policy). You can adjust your Cookie Preferences at the bottom of this page.

By continuing to use AliExpress you accept our use of cookies (view more on our Privacy Policy). You can adjust your Cookie Preferences at the bottom of this page.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

As of August 2018 the State of California has changed the requirements of the �Prop 65� law. We now must list on our website any possible chemicals the can cause cancer, birth defects or reproductive problem.

To put it simply we are a small company and do not have the resources to test every single part, so we list every thing as hazardous. Please recycle all electronic parts responsibly and under no circumstance eat, drink or smoke these parts and wash your hands after touching!

This image is a public domain image, which means either that copyright has expired in the image or the copyright holder has waived their copyright. Alamy charges you a fee for access to the high resolution copy of the image.

In chapter 7, we made use of the segmented LCD display on the Wonder Gecko Starter Kit through the use of a pre-built LCD library and driver when designing the user interface for the sprinkler timer. That made things easy for us, and we didn’t really need to dwell on how the driver worked. In this chapter, we will dig into some of those details so that we can connect the EFM32 to any kind of display we choose.

The display we will be using for this chapter is the Adafruit 2.8” 240x320 TFT LCD Capacitive Touch screen, shown below. We will interface with it over SPI for transferring image data and I2C for reading the touch interface. We will learn how to interface with it with our own drivers and build our own simple graphics libraries, as well.

Segmented Display: We have already worked with the segmented LCD display in chapter 7, also known as a character display. In such a display, there are a fixed matrix of LCD segments that are preconfigured in hardware to convey specific information. They are not flexible enough to display an image, but they don’t require many pins on the MCU and are easier to program. For example, the number “9” can be formed on such a display with as few as 6 signals.

Graphics Display: A graphics display has a matrix of pixels, each of which are individually addressable. Therefore, in order to display the number “9”, it can require many more pixels than the segmented display. The benefit of a graphic display is that the letter “9” can be in any font we choose, and better yet, we can display any shapes we choose. The drawback to a graphical display is that it takes an enormous number of signals to drive all of those pixels. For the display used in this chapter, which has a resolution of 240 pixels wide by 320 pixels tall, there are 76,800 individually-addressable pixels, and each of those are made up of red, green, and blue components for each pixel.

In order to cut down on the number of signals required to drive such a display, each pixel is driven one at a time in a column-and-row scan technique. This scanning only requires 240 + 320 wires for our chosen display, which are toggled on or off many times per second, even for a static image. The pixels do not hold their color information for very long, and therefore they require periodic refreshes.

Note that a new “Memory LCD” described in Silicon Labs application note AN0048 couples a memory device within each pixel so that constant refreshing is not necessary, reducing power consumption as well.

Graphical display screens have many different technologies, from passive-matrix Liquid Crystal Display (LCD) or active-matrix Thin Film Transistor (TFT) LCD, Light Emitting Diode (LED), or Organic LED (OLED). Display technology is not the focus of this chapter. No matter which technology you choose, you will still need to understand the topics of this chapter in order to display your images.

A display is a layered device, with each part customizable by the manufacturer. The display is constructed on top of a circuit board which houses the connector and any controller chips that are necessary. The backlight is located on top of the circuit board, with the pixel matrix sitting on top of the backlight. The touch sensor is optional and is located at the top of the stackup.

The LCD pixel matrix is the heart of the display. This part is responsible for displaying the image and, in the case of LCD displays, it will either allow or prevent light from a backlight to pass through. In the case of LED displays, the pixel matrix produces the light and forms the image in one step. No matter the process, the pixel matrix is comprised of an array of pixels in height and width of a certain color depth that make up the display. For the display used in this chapter, the color depth is 18 bits, consisting of 6 bits each for the red/blue/green components of a pixel. That means that the information required to paint the screen one time is 240 bits wide x 320 bits tall x 18 bits of color = 172,800 bytes. That’s a lot of data, and it is more data than we can hold in the RAM of the Wonder Gecko MCU. Therefore, it will require some intelligent code to drive the display or an external memory buffer to store the image data.

The backlight is necessary for TFT LCD displays to allow the display to be seen. Without a backlight, a color TFT LCD will show no image. A monochrome LCD is a little different, since the segments can be seen if they are in the “on” state. The brightness of an LCD screen is sometimes controlled by applying a Pulse Width Modulated (PWM) signal to a pin (or pins) that controls the LED backlight. This is exactly what we have already done in the last chapter to dim an LED.

A display driver chip is used to drive 76,800 signals by rotating through all horizontal and vertical scan lines many times per second. This component is an optional component of the display, and if it is present, it dramatically reduces work for the MCU to display (and continue to display) an image on the screen.

A frame buffer is a block of RAM that holds all of the color information for every pixel (172 kB for this display) that is used to paint a single image (or “frame”) to the display. This buffer is required to exist somewhere in the system because it is used by the display driver chip to refresh the LCD image many times per second.

A touch interface is an optional component and will often have its own control chip or control signals that are separate from the display driver chip.

A resistive touch screen is pressure sensitive. It requires that your finger (or stylus) makes contact with the screen and causes a tiny grid of precisely controlled resistance wires to touch each other, and then measures the resistance to calculate the position. The resistive touch screen requires four signals to interface the MCU, two of which must be fed into an Analog to Digital Comparator (ADC) in order to read the touches. The Wonder Gecko has several ADC inputs that can be used for this purpose. Resistive touch screens may require calibration by the user to perform accurately.

A capacitive touch screen requires no physical contact between the user and the sensor. Therefore, the sensor can be placed beneath hardened glass or plastic. A valid touch is formed by the change in capacitance measured on the sensor. A human finger can change the capacitance of this sensor, whereas a plastic stylus will not produce a change in capacitance. The capacitive touch screen used in this chapter uses a controller that communicates via the I2C interface.

The type of architecture used in our display (and system) has a huge impact on how we will write our software code, as well as how well our display will perform. You cannot assume that any model of MCU can sufficiently drive any type of display. You must be aware of the architecture details and MCU pinout so that you can determine the best type of display for your needs.

In a general sense, all display architectures require the above control blocks. The display contains a number of scan lines (depending on the resolution) and an image driver that must continually feed the scan control circuitry with pixel data, even for a static image. The pixel control allows light to pass for an instant, and then the pixel goes dark again. If the scan control circuitry were stopped, the display would turn dark, as all pixels would be turned off. Therefore, the image driver needs a frame buffer of memory somewhere in the system to fetch the pixel data that is needed for every scan. The application fills the frame buffer as new drawing operations change what is to be displayed on the screen.

In the RGB interface mode, the MCU acts as the image driver. This means that it must constantly drive data to the display, refreshing all 320 x 240 pixels many times per second. You can imagine the amount of work that would require of your MCU. If the frame buffer is too big to fit in the MCU RAM, an external memory chip must be used. The frame buffer can be attached to the MCU via serial interfaces such as I2C or SPI for static images such as device menus, but must utilize a parallel interface in order to keep up with the demands of full motion video. The External Bus Interface (EBI) can be used with external memory for maximum speed and ease of use, as long as your particular model of EFM32 supports it. EBI extends the RAM of your EFM32 and allows you to address external memory as if it resides within the RAM address space of the EFM32 itself.

When a display has an integrated device driver chip and frame buffer (such as the Ilitek ILI9341 used in this chapter), the MCU doesn’t have to perform all of the constant refreshing of the display; it only sends data to the driver chip when the image changes. This enables the MCU to offload all of that work to stay focused on the application at hand rather than driving the display.

These driver chips usually offer both parallel and serial interfaces to receive image data from the MCU. Parallel interfaces are required if the display will be used for full-motion video and require 8 or more data interface pins. Serial interfaces can be used for static images like device menus and only require 3 or 4 interface data pins.

There are displays available on the market (such as the EVE series from FTDI) which go well beyond a display driver chip. They contain the ability to create graphical shapes such as lines, rectangles, and circles, as well as device controls such as windows, sliders, and buttons. These displays can even offer an integrated touch controller and audio capabilities. The displays communicate over I2C or SPI, and the data that is sent is similar to a software Application Programming Interface (API). The specs of such displays define the commands that the controller chip accepts, and the application software simply communicates each graphic primitive one-by-one to the display to paint the appropriate picture on the screen. These types of displays can be easier to program, but are not the focus of this chapter.

Since graphic displays are complex devices, the code that runs them should be broken up into parts that deal with only one part of the problem. This is known as a software stack.

At the top of the stack is the application software. Application software is focused on providing a solution to the end user, such as the content of menus, fetching images from flash storage, responding to user input, and generally deciding what to do next. Application software should not have to be bogged down with the simple task of how to write a snippet of text to the screen, or the exact details of how to display an image. These things should be handled further down the stack to keep your application code simple.

In order for your application code to stay focused on its mission, your graphics library should provide useful methods to do common things, such as paint the screen with a color, display text, create lines or shapes, and display graphic images. We will learn how to build a very simple graphics library of our own as part of this chapter.

Depending on the graphics library complexity, it may even create a full windowing capability with sliders or popups and add all of the comforts of a modern computer interface to your embedded application, all within the limited RAM available in an MCU. Silicon Labs provides the Segger emWin graphics library as part of the Simplicity Studio installation. We will introduce the emWin library at the end of this chapter.

At the bottom of the software stack, the device driver is the necessary code that customizes your graphics library for your particular display device architecture and physical hardware connection. (Note that a software device driver is not the same thing as the device driver chip on the physical display.) Graphics libraries are flexible, and can be adapted to many different display architectures, but they need to be configured for your display architecture and MCU. The device driver provides this customization, providing the display’s resolution and color depth, mapping the data bus for the display to GPIO pins on your MCU and setting up the memory for the frame buffer (if applicable).
