Apple has shown interest in creating a new iPad with a hybrid display that could dynamically switch all or just part of the full-color screen to low-power black-and-white e-ink for text and other static content.

The new dynamic, hybrid system described by Apple could have sections of the screen operate as a traditional LCD screen for displaying video, while other parts with static content would be served up in e-ink. Rather than depending on the user to switch between e-ink and LCD, Apple"s system would handle the work and provide content in the ideal context.

Apple"s interest in the technology was revealed this week in a new patent application filed with the U.S. Patent and Trademark Office, and first discovered by AppleInsider. The filing, entitled "Systems and Methods for Switching Between an Electronic Paper Display and a Video Display," describes hardware that can selectively switch between the two types of screens.

E-ink displays, or "electronic paper" as Apple refers to it throughout the filing, are advantageous because they do not require a backlight to operate, and they can be read more easily in direct sunlight. E-reader devices focused on delivering books, like the Amazon Kindle, use e-ink displays.

Of course, Apple is also involved in the sale of digital books through its own iBookstore. The iBooks application is available for the iPad, iPhone and iPod touch, but it cannot be utilized on a device with an e-ink display.

Apple"s patent application notes that display types on a device are typically based on an assumption about the visual content that will most often be displayed on the screen. An LCD or OLED display is ideal for high-resolution content with colors, while e-ink is ideal for static black-and-white content, like text.

The solution is to offer a screen with "multiple composite display regions," where content could be shown in both the "electronic paper" mode and "video display" format at the same time. Such a screen would also include independently activated backlights, illuminating panels when necessary.

Apple could accomplish this by having a translucent e-ink display that would be placed on top of the traditional LCD or OLED screen on an iPad. The top screen would allow users to see past it, so that video content in full color could be displayed on the screen below. And of course, atop all that would be a touch panel, allowing users to interact with the device.

The patent application, made public this week, was first filed by Apple in October of 2009. The proposed invention is credited to Gloria Lin and Andrew Hodge.

Popular Science article about a startup coming out with a new ebook+ screen tech called "3Qi" (though much of the article is a human-interest piece about the founder):
http://www.popsci.com/gadgets/...y-kill-paper-forever

Excerpts:

quote:

Turn on the store-bought tablet PC that Jepsen’s prototype screen sits in—she removed the old screen with a screwdriver and swapped hers in—and it looks and acts like any LCD screen, because it is an LCD, only better. LCDs display color and video, but they kill battery life. Electronic ink is more energy-efficient and paper-like, but it’s black and white and is frustratingly slow to load a new page. Jepsen’s screen combines the best of both technologies. Flick a switch, and the bulb that makes the screen glow will dim. But instead of going dark, only the colors will fade. That’s because in Jepsen’s screen, ambient light can substitute for backlight, bouncing off the mirror-like material that Jepsen has added to each pixel to reflect shades of black and white. With the lamp completely off, the screen, called 3Qi (pronounced “three chee,” as in qi, the Chinese word for “spirit,” and a geeky pun on the 3G wireless network), displays letters as crisp and readable as those on Amazon’s Kindle. In this mode, 3Qi uses about one fifth the power of a normal computer screen, Jepsen says. And unlike the E Ink–based Kindle or any other widely available e-reader, it still does everything a regular LCD does, including play videos.

quote:

And this could be the year the leaders in the display race pull away from the pack. The cellphone-chip giant Qualcomm; the current e-reader display leader, E Ink; and at least one other major player are set to release next-generation e-reader screens by 2011. But Jepsen’s hybrid screen is likely to be the first and the least expensive of the bunch. Her company, Pixel Qi, which is based in both Silicon Valley and Taipei, will, by the time you read this, have started a run of millions of screens. Although Jepsen won"t name brands, she says these will soon appear in netbooks, tablet computers and dedicated e-readers.

At CES 2023, we interviewed the Assistant Vice President of E Ink, Tim O’Malley. The company is well-known in the tech world and produces e-ink displays that are used in e-readers, laptops, wearables, phones, and many other products.

Mr. O’Malley revealed a lot during the interview, including details about E Ink’s cooperation with BMW, its plans for expanding to other industries, and much more. You can read a brief overview of the interview below or check out the whole thing in the video above.

Q: Can you tell us a little more about your collaboration with BMW? Also, what challenges did you have to overcome to make it possible for BMW to put your color-changing material on their car?

A: A big announcement happened at the keynote, with BMW introducing its concept electric car. The car has a color-changing surface all over it, and we at E Ink are thrilled that we were able to work with BMW and supply them with the material they needed.

They really care about the lines and curves of the car at BMW in order to get the design they want. Some of these lines and curves are not the friendliest to work with, so we had to bend the material and build in ways to relieve the stress on it. There’s a big team at BMW we worked with to figure all this out.

A: The concept car uses 32 colors and can switch between them on any of its panels. However, the product we’re coming out with first will only use eight colors.

A: There are quite a few. We came out with the Gallery 3 product last year that brings full color to the e-reader platform. There are seven companies that are already interested in using it.

We also brought saturated full-color to retail, and we’re continuing to make progress in this area. I’m also really thrilled about some of the wearables like the Fossil Hybrid watch announced earlier this week. It combines fashion with the elements of great design and the use of our display.

Then there’s also the recently announced Lenovo ThinkBook Plus Twist, which spins to reveal an OLED display on one side and an e-ink display on the other.

A: Yes, we have. The energy efficiency has a lot to do with the fact that our products are relatively low voltage. There’s no power being used when a display is showing an image. We use power to update the display, and once that’s done, the display is not drawing power anymore. So a lot of the demos we carry around show full images, but we don’t actually have any power cords with us.

So a lot of the applications our products are a great fit for have a lower use cycle. Think of a retail store that only updates its prices on e-ink displays every now and then.

A: We have a product line called JustTint at E Ink, which can switch from transparent to mostly opaque. We’re continuing to advance the technology and are working with partners to bring it to market. We’ve discussed using it for automotive sunroofs, for example, which is really exciting.

So if you look at electric cars, it can get really hot when you open the sunroof, but if you then turn on the AC, you can’t drive as far because the battery life takes a hit. So with our products, you won’t have to make those tradeoffs.

A: We generally say it’s paper. We’re trying to bring additional functionality to places where people usually use paper. These include reading, note-taking, smart city signage, and retail shelf tags. These started as paper applications. We know that in some devices people choose LCD displays if they make sense for their use case, but e-ink displays can also be used in many cases and are better for our eyes.

Q: What do you see for the future? If we look 15 or 20 years down the line, do you think it will still be possible to improve your products and technology substantially?

A: Absolutely. We’re working on transparent films, which aren’t even full products yet, and we’ve just started our journey when it comes to color displays. I recently heard a quote by Bill Gates that I really liked. He said, “We overestimate what we can do in two years and underestimate what we can do in 10 years.”

We want to expand our business to cars, billboards, and more. The application of low-power full-color technology in this space is what the world needs right now.

This is just a quick overview of the conversation we had with Tim O’Malley from E Ink. If you want to learn more, check out the video at the top of the page.

Got a netbook? Specifically, got a Samsung N130 or a Lenovo S10-2? Even more specifically, do you use it in and outdoors, but find it hard to read in the sun? We have good news! The Maker Shed will sell you one of Pixel Qi"s dual-mode displays as a straight swap-in for your existing LCD-panel.

The 10.1-inch screen runs in one of two modes. When indoors, or watching video, you use the regular LCD display, which will look pretty much the same as the one you already have. When you"re in to mood for some reading, or you are outside in bright sunlight, or you"re just running low on battery power, you can switch to the e-ink mode.

This disables the backlight and shows you hi-res, grayscale pixels, much like you"d see on the screen of the Amazon Kindle. Because it only uses power when updating the screen, it sips power.

There is also a hybrid mode, which lets the sun reflect off the back of the display assembly and back out through the color LCD. This both saves battery power and lets you view a normal color display outdoors.

The panel will cost you $275, which puts it out of the "merely curious" bracket but is still cheap enough for people who do a lot of outdoor computing. The Maker Shed store page also says that the panel will likely work in any netbook: the Lenovo and the Samsung are just the only ones so far tested and guaranteed.

And according to the Pixel Qi blog, which first described the plan to sell these panels separately from the company"s own notebooks, the swap-operation (swaperation?) is easy:It’s only slightly more difficult than changing a lightbulb: it’s basically 6 screws, pulling off a bezel, unconnecting [sic] the old screen and plugging this one in. That’s it. It’s a 5 minute operation.

Liquid crystal display (LCD) is a flat panel display that uses the light modulating properties of liquid crystals. Liquid crystals do not produce light directly, instead using a backlight or reflector to produce images in colour or monochrome.

There are two main types of eReader display technology: E-Ink (electronic ink) and LCD (liquid crystal display). In general, E-Ink readers are considered to be easier to read, with higher contrast, no glare and a more natural reading experience. LCD screens, on the other hand,are both more dynamic and more affordable. Each display technology has its own inherent pros and cons which should be considered before investing in an electronic reader.

E-Ink, or electronic ink, is used in the Amazon Kindle. E-Ink screens use a special type of electronic paper where characters and images are created by arranging pixels on a screen. The mechanism is similar to that of an Etch-a-Sketch. In this way, power is only needed to arrange the pixels. The image remains on the screen even if the unit is powered down.

In terms of reading, E-Ink screens are more like physical books printed on paper. They are not backlit, thus they need a light source to be read, just like a book. The benefits of this is that it produces less strain on the eyes and is a more natural reading experience. Furthermore, you won’t experience glare in bright lights and direct sunlight. E-Ink also holds its charge for a very long time.

The drawbacks of E-Ink is that it cannot display moving images, such as video or cursors, nor can it display color. E-Ink, for now, can only be displayed in shades of grey.

An LCD screen is on an eReader is the same as the screen on your laptop computer, flat screen TV or smartphone. The screen is backlit, thus requiring more battery power. Furthermore, the glass screen creates a glare. LCD screens are also notoriously difficult to read in direct sunlight. Viewing an LCD screen over long periods of time is also less enjoyable than reading a book or an E-Ink screen.

The pros of an LCD screen is that it can display full color and video. LCD screens are also very affordable and can be outfitted with touchscreens for easy navigation. In fact, many smartphones and tablets double as eReaders, such as the iPod Touch, iPad and BlackBerry Storm.

When deciding which type of eReader screen is best for you, there are two things you should consider: your usage and your needs. If you plan on reading outdoors or in brightly lit areas or for long periods of time, an E-Ink eReader makes sense because of its lack of a glare and its long battery life. But if you’d like to read in the dark—such as in bed or on a red eye flight—an LCD screen may be better. Furthermore, eReaders with LCD screens can offer other functionality, such as video or web browsing, bringing it closer to a smartphone experience.

Bottom-line: For those who intend to use your eReader strictly for books and strictly in well-lit areas, the E-Ink models are likely the best for you. If you are looking for an eReader that can do a bit more than simply read books and magazines, and LCD smartphone, tablet or reader could give you more bang for your buck.

The Chinese gadget maker Boyue is now showing a concept design for a hybrid 8″ ereader on its website. They haven’t released any specs and I’m not entirely sure it will ever see the light of day, but I still want to laud Boyue for for being either bold enough or crazy enough to come up with this:

The Boyue D81 features an 8″ IPS display on its front and an 8″ E-ink display on the back, and if it is ever built it will run Android 4.2 Jelly Bean on a quad-core CPU. It will probably also cost a lot of money, somewhere in the neighborhood of $300 (by my guesstimate).

I don’t know that Boyue has worked on a dual screen design before, but they have developed a couple Android tablet as well as a couple ereaders which run Android. So even though this device presents twice as many technical issues as a single screen tablet, it’s entirely possible that they could pull it off.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

Electronic paper, AKA E Ink, displays are amazing devices, capable of holding an image in place without the application of power. Unfortunately, their refresh rate tends to be quite low, and they are typically limited to showing shades of black and white, so their applications tend to be somewhat niche.

One place where such a display is really useful if when showing text that changes only intermittently, such as price data at a store, or as Hamed Taha demonstrates in hisE Ink Pen Holderproject, for revealing a quote of the day. His build embeds a 3.7" E Ink screen inside of a pen holder made with epoxy resin, along with an ESP32 module for control. The result, so far, is a pen holder that can be updated using a cell phone and a wireless charger/receiver, and something that can hopefully be enhanced software-wise in the future

It’s a neat idea, and a concept that others may be able to take and “mold” to their own purposes. Of course, one hazard of working with such a permanent structure is that you can’t really fix things once the epoxy has cured. Taha went through several iterations, losing display and control hardware in the process, before producing a functional device.

Wow, just wow. We were about three months away from putting Pixel Qion a temporary vaporware watch, and now we couldn"t be happier about shoving this crow down our throats. The outfit"s so-called 3qi display technology -- which seamlessly integrates e-ink with LCD -- was on display this week at Computex, and there"s a beautiful video just after the break that shows it off. Put simply, we"ve never seen a laptop display look as good in broad daylight as Pixel Qi"s display, and even though there"s no striking colors in the black-and-white e-ink mode, at least you can see the thing (clearly, at that) without squinting. Seriously, hop on past the break and mash play.

Many e-readers, devices meant to replace traditional books, utilize electronic paper for their displays in order to further resemble paper books; one such example is the Kindle series by Amazon.

Electronic paper, also sometimes electronic ink, e-ink or electrophoretic display, are display devices that mimic the appearance of ordinary ink on paper.flat panel displays that emit light, an electronic paper display reflects ambient light like paper. This may make them more comfortable to read, and provide a wider viewing angle than most light-emitting displays. The contrast ratio in electronic displays available as of 2008 approaches newspaper, and newly (2008) developed displays are slightly better.

Many electronic paper technologies hold static text and images indefinitely without electricity. Flexible electronic paper uses plastic substrates and plastic electronics for the display backplane. Applications of electronic visual displays include electronic shelf labels and digital signage,smartphone displays, and e-readers able to display digital versions of books and magazines.

Electronic paper was first developed in the 1970s by Nick Sheridon at Xerox"s Palo Alto Research Center.Gyricon, consisted of polyethylene spheres between 75 and 106 micrometers across. Each sphere is a Janus particle composed of negatively charged black plastic on one side and positively charged white plastic on the other (each bead is thus a dipole).polyvinylidene fluoride (PVDF) as the material for the spheres, dramatically improving the video speed and decreasing the control voltage needed.

In the simplest implementation of an electrophoretic display, titanium dioxide (titania) particles approximately one micrometer in diameter are dispersed in a hydrocarbon oil. A dark-colored dye is also added to the oil, along with surfactants and charging agents that cause the particles to take on an electric charge. This mixture is placed between two parallel, conductive plates separated by a gap of 10 to 100 micrometres. When a voltage is applied across the two plates, the particles migrate electrophoretically to the plate that bears the opposite charge from that on the particles. When the particles are located at the front (viewing) side of the display, it appears white, because the light is scattered back to the viewer by the high-indexpixels), then an image can be formed by applying the appropriate voltage to each region of the display to create a pattern of reflecting and absorbing regions.

An electrophoretic display - also known as an EPD - are typically addressed using MOSFET-based thin-film transistor (TFT) technology. TFTs are requiredactive matrix displays used in the Amazon Kindle, Barnes & Noble Nook, Sony Reader, Kobo eReader, and iRex iLiad e-readers. These displays are constructed from an electrophoretic imaging film manufactured by E Ink Corporation. A mobile phone that used the technology is the Motorola Fone.

Electrophoretic Display technology has also been developed by SiPix and Bridgestone/Delta. SiPix is now part of E Ink Corporation. The SiPix design uses a flexible 0.15 mm Microcup architecture, instead of E Ink"s 0.04 mm diameter microcapsules.Bridgestone Corp."s Advanced Materials Division cooperated with Delta Optoelectronics Inc. in developing Quick Response Liquid Powder Display technology.

Electrophoretic displays can be manufactured using the Electronics on Plastic by Laser Release (EPLaR) process developed by Philips Research to enable existing AM-LCD manufacturing plants to create flexible plastic displays.

In the 1990s another type of electronic ink based on a microencapsulated electrophoretic display was conceived and prototyped by a team of undergraduates at MITBarrett Comiskey, Joseph Jacobson, Jeremy Rubin and Russ Wilcox co-founded E Ink Corporation in 1997 to commercialize the technology. E ink subsequently formed a partnership with Philips Components two years later to develop and market the technology. In 2005, Philips sold the electronic paper business as well as its related patents to Prime View International."It has for many years been an ambition of researchers in display media to create a flexible low-cost system that is the electronic analog of paper. In this context, microparticle-based displays have long intrigued researchers. Switchable contrast in such displays is achieved by the electromigration of highly scattering or absorbing microparticles (in the size range 0.1–5 μm), quite distinct from the molecular-scale properties that govern the behavior of the more familiar liquid-crystal displays. Micro-particle-based displays possess intrinsic bistability, exhibit extremely low power d.c. field addressing and have demonstrated high contrast and reflectivity. These features, combined with a near-lambertian viewing characteristic, result in an "ink on paper" look. But such displays have to date suffered from short lifetimes and difficulty in manufacture. Here we report the synthesis of an electrophoretic ink based on the microencapsulation of an electrophoretic dispersion. The use of a microencapsulated electrophoretic medium solves the lifetime issues and permits the fabrication of a bistable electronic display solely by means of printing. This system may satisfy the practical requirements of electronic paper."

This used tiny microcapsules filled with electrically charged white particles suspended in a colored oil.circuitry controlled whether the white particles were at the top of the capsule (so it looked white to the viewer) or at the bottom of the capsule (so the viewer saw the color of the oil). This was essentially a reintroduction of the well-known electrophoretic display technology, but microcapsules meant the display could be made on flexible plastic sheets instead of glass.

One early version of the electronic paper consists of a sheet of very small transparent capsules, each about 40 micrometers across. Each capsule contains an oily solution containing black dye (the electronic ink), with numerous white titanium dioxide particles suspended within. The particles are slightly negatively charged, and each one is naturally white.liquid polymer, sandwiched between two arrays of electrodes, the upper of which is transparent. The two arrays are aligned to divide the sheet into pixels, and each pixel corresponds to a pair of electrodes situated on either side of the sheet. The sheet is laminated with transparent plastic for protection, resulting in an overall thickness of 80 micrometers, or twice that of ordinary paper.

The network of electrodes connects to display circuitry, which turns the electronic ink "on" and "off" at specific pixels by applying a voltage to specific electrode pairs. A negative charge to the surface electrode repels the particles to the bottom of local capsules, forcing the black dye to the surface and turning the pixel black. Reversing the voltage has the opposite effect. It forces the particles to the surface, turning the pixel white. A more recent implementation of this concept requires only one layer of electrodes beneath the microcapsules.

Electrowetting display (EWD) is based on controlling the shape of a confined water/oil interface by an applied voltage. With no voltage applied, the (colored) oil forms a flat film between the water and a hydrophobic (water-repellent) insulating coating of an electrode, resulting in a colored pixel. When a voltage is applied between the electrode and the water, the interfacial tension between the water and the coating changes. As a result, the stacked state is no longer stable, causing the water to move the oil aside. This makes a partly transparent pixel, or, if a reflective white surface is under the switchable element, a white pixel. Because of the small pixel size, the user only experiences the average reflection, which provides a high-brightness, high-contrast switchable element.

Displays based on electrowetting provide several attractive features. The switching between white and colored reflection is fast enough to display video content.

This results in the availability of two-thirds of the display area to reflect light in any desired color. This is achieved by building up a pixel with a stack of two independently controllable colored oil films plus a color filter.

The colors are cyan, magenta, and yellow, which is a subtractive system, comparable to the principle used in inkjet printing. Compared to LCD, brightness is gained because no polarisers are required.

Electrofluidic display is a variation of an electrowetting display. Electrofluidic displays place an aqueous pigment dispersion inside a tiny reservoir. The reservoir comprises <5-10% of the viewable pixel area and therefore the pigment is substantially hidden from view.

The core technology was invented at the Novel Devices Laboratory at the University of Cincinnati. The technology is currently being commercialized by Gamma Dynamics.

The technology used in electronic visual displays that can create various colors via interference of reflected light. The color is selected with an electrically switched light modulator comprising a microscopic cavity that is switched on and off using driver integrated circuits similar to those used to address liquid-crystal displays (LCD).

Other research efforts into e-paper have involved using organic transistors embedded into flexible substrates,triads, typically consisting of the standard cyan, magenta and yellow, in the same way as CRT monitors (although using subtractive primary colors as opposed to additive primary colors). The display is then controlled like any other electronic color display.

E Ink Corporation of E Ink Holdings Inc. released the first colored E Ink displays to be used in a marketed product. The Ectaco Jetbook Color was released in 2012 as the first colored electronic ink device, which used E Ink"s Triton display technology.

Several companies are simultaneously developing electronic paper and ink. While the technologies used by each company provide many of the same features, each has its own distinct technological advantages. All electronic paper technologies face the following general challenges:

Electronic ink can be applied to flexible or rigid materials. For flexible displays, the base requires a thin, flexible material tough enough to withstand considerable wear, such as extremely thin plastic. The method of how the inks are encapsulated and then applied to the substrate is what distinguishes each company from others. These processes are complex and are carefully guarded industry secrets. Nevertheless, making electronic paper is less complex and costly than LCDs.

There are many approaches to electronic paper, with many companies developing technology in this area. Other technologies being applied to electronic paper include modifications of liquid-crystal displays, electrochromic displays, and the electronic equivalent of an Etch A Sketch at Kyushu University. Advantages of electronic paper include low power usage (power is only drawn when the display is updated), flexibility and better readability than most displays. Electronic ink can be printed on any surface, including walls, billboards, product labels and T-shirts. The ink"s flexibility would also make it possible to develop rollable displays for electronic devices.

In December 2005, Seiko released the first electronic ink based watch called the Spectrum SVRD001 wristwatch, which has a flexible electrophoretic displayPebble smart watch (2013) uses a low-power memory LCD manufactured by Sharp for its e-paper display.

In 2019, Fossil launched a hybrid smartwatch called the Hybrid HR, integrating an always on electronic ink display with physical hands and dial to simulate the look of a traditional analog watch.

In 2004, Sony released the Librié in Japan, the first e-book reader with an electronic paper E Ink display.Sony Reader e-book reader in the USA. On October 2, 2007, Sony announced the PRS-505, an updated version of the Reader. In November 2008, Sony released the PRS-700BC, which incorporated a backlight and a touchscreen.

In late 2007, Amazon began producing and marketing the Amazon Kindle, an e-book reader with an e-paper display. In February 2009, Amazon released the Kindle 2 and in May 2009 the larger Kindle DX was announced. In July 2010 the third-generation Kindle was announced, with notable design changes.

In 2020, Onyx released the first frontlit 13.3 inch electronic paper Android tablet, the Boox Max Lumi. At the end of the same year, Bigme released the first 10.3 inch color electronic paper Android tablet, the Bigme B1 Pro. This was also the first large electronic paper tablet to support 4g cellular data.

The French daily iRex iLiad. Two different processing platforms were used to deliver readable information of the daily, one based on the newly developed GPP electronic ink platform from

Flexible display cards enable financial payment cardholders to generate a one-time password to reduce online banking and transaction fraud. Electronic paper offers a flat and thin alternative to existing key fob tokens for data security. The world"s first ISO compliant smart card with an embedded display was developed by Innovative Card Technologies and nCryptone in 2005. The cards were manufactured by Nagra ID.

The Samsung Alias 2 mobile phone incorporates electronic ink from E Ink into the keypad, which allows the keypad to change character sets and orientation while in different display modes.

On December 12, 2012, Yota Devices announced the first "YotaPhone" prototype and was later released in December 2013, a unique double-display smartphone. It has a 4.3-inch, HD LCD on the front and an electronic ink display on the back.

On May and June 2020, Hisense released the hisense A5c and A5 pro cc, the first color electronic ink smartphones. With a single color display, with toggable front light running android 9 and Android 10.

E-paper based electronic shelf labels (ESL) are used to digitally display the prices of goods at retail stores. Electronic-paper-based labels are updated via two-way infrared or radio technology and powered by a rechargeable coin cell.

E-paper displays at bus or trams stops can be remotely updated. Compared to LED or liquid-crystal displays (LCDs), they consume lower energy and the text or graphics stays visible during a power failure. Compared to LCDs, it is well visible also under full sunshine.

Typically, e-paper electronic Tags integrate e-ink technology with wireless interfaces like NFC or UHF. They are most commonly used as employees" ID cards or as production labels to track manufacturing changes and status. E-Paper Tags are also increasingly being used as shipping labels, especially in the case of reusable boxes.

An interesting feature provided by some e-paper Tags manufacturers is batteryless design. This means that the power needed for a display"s content update is provided wirelessly and the module itself doesn"t contain any battery.

Other proposed applications include clothes, digital photo frames, information boards, and keyboards. Keyboards with dynamically changeable keys are useful for less represented languages, non-standard keyboard layouts such as Dvorak, or for special non-alphabetical applications such as video editing or games.

Heikenfeld (2011). "A critical review of the present and future prospects for electronic paper". J. Soc. Inf. Display. 19 (2): 129. doi:10.1889/JSID19.2.129. S2CID 18340648.

Crowley, Joseph M.; Sheridon, Nicholas K.; Romano, Linda (2002). "Dipole moments of gyricon balls". Journal of Electrostatics. 55 (3–4): 247–259. doi:10.1016/S0304-3886(01)00208-X.

"53.4: Ultra-Thin Flexible OLED Device". SID Symposium Digest of Technical Papers -- May 2007 -- Volume 38, Issue 1, pp. 1599-1602. Retrieved 2007-12-03.

Journal, Alec Klein Staff Reporter of The Wall Street. "A New Printing Technology Sets Off a High-Stakes Race". Wall Street Journal. ISSN 0099-9660. Retrieved 2015-11-27.

Comiskey, B.; Albert, J. D.; Yoshizawa, H.; Jacobson, J. (1998). "An electrophoretic ink for all-printed reflective electronic displays". Nature. 394 (6690): 253–255. Bibcode:1998Natur.394..253C. doi:10.1038/28349. S2CID 204998708.

Comiskey, Barrett; Albert, J. D.; Yoshizawa, Hidekazu; Jacobson, Joseph (1998-07-16). "An electrophoretic ink for all-printed reflective electronic displays". Nature. 394 (6690): 253–255. Bibcode:1998Natur.394..253C. doi:10.1038/28349. ISSN 0028-0836. S2CID 204998708.

Rogers, John A; Bao, Zhenan; Baldwin, Kirk; Dodabalapur, Ananth; Crone, Brian; Raju, V R; Kuck, Valerie; Katz, Howard; Amundson, Karl; Ewing, Jay; Drzaic, Paul (24 April 2001). "Paper-like electronic displays: Large-area rubber-stamped plastic sheets of electronics and microencapsulated electrophoretic inks". PNAS. 98 (9): 4835–4840. doi:PMC PMID 11320233.

Xiong, Kunli; Emilsson, Gustav; Maziz, Ali. "Plasmonic Metasurfaces with Conjugated Polymers for Flexible Electronic Paper in Color"Advanced Materials: sid. n/a–n/a. doi:10.1002/adma.201603358. ISSN 1521-4095. 28 October 2016.

Huitema, H. E. A.; Gelinck, G. H.; van der Putten, J. B. P. H.; Kuijk, K. E.; Hart, C. M.; Cantatore, E.; Herwig, P. T.; van Breemen, A. J. J. M.; de Leeuw, D. M. (2001). "Plastic transistors in active-matrix displays". Nature. 414 (6864): 599. Bibcode:2001Natur.414..599H. doi:PMID 11740546. S2CID 4420748.

Gelinck, G. H.; et al. (2004). "Flexible active-matrix displays and shift registers based on solution-processed organic transistors". Nature Materials. 3 (2): 106–110. Bibcode:2004NatMa...3..106G. doi:10.1038/nmat1061. PMID 14743215. S2CID 7679602.

Andersson, P.; Nilsson, D.; Svensson, P. O.; Chen, M.; Malmström, A.; Remonen, T.; Kugler, T.; Berggren, M. (2002). "Active Matrix Displays Based on All-Organic Electrochemical Smart Pixels Printed on Paper". Adv Mater. 14 (20): 1460–1464. doi:10.1002/1521-4095(20021016)14:20<1460::aid-adma1460>3.0.co;2-s. Archived from the original on 2011-03-09.

A thin-film-transistor liquid-crystal display (TFT LCD) is a variant of a liquid-crystal display that uses thin-film-transistor technologyactive matrix LCD, in contrast to passive matrix LCDs or simple, direct-driven (i.e. with segments directly connected to electronics outside the LCD) LCDs with a few segments.

In February 1957, John Wallmark of RCA filed a patent for a thin film MOSFET. Paul K. Weimer, also of RCA implemented Wallmark"s ideas and developed the thin-film transistor (TFT) in 1962, a type of MOSFET distinct from the standard bulk MOSFET. It was made with thin films of cadmium selenide and cadmium sulfide. The idea of a TFT-based liquid-crystal display (LCD) was conceived by Bernard Lechner of RCA Laboratories in 1968. In 1971, Lechner, F. J. Marlowe, E. O. Nester and J. Tults demonstrated a 2-by-18 matrix display driven by a hybrid circuit using the dynamic scattering mode of LCDs.T. Peter Brody, J. A. Asars and G. D. Dixon at Westinghouse Research Laboratories developed a CdSe (cadmium selenide) TFT, which they used to demonstrate the first CdSe thin-film-transistor liquid-crystal display (TFT LCD).active-matrix liquid-crystal display (AM LCD) using CdSe TFTs in 1974, and then Brody coined the term "active matrix" in 1975.high-resolution and high-quality electronic visual display devices use TFT-based active matrix displays.

The liquid crystal displays used in calculators and other devices with similarly simple displays have direct-driven image elements, and therefore a voltage can be easily applied across just one segment of these types of displays without interfering with the other segments. This would be impractical for a large display, because it would have a large number of (color) picture elements (pixels), and thus it would require millions of connections, both top and bottom for each one of the three colors (red, green and blue) of every pixel. To avoid this issue, the pixels are addressed in rows and columns, reducing the connection count from millions down to thousands. The column and row wires attach to transistor switches, one for each pixel. The one-way current passing characteristic of the transistor prevents the charge that is being applied to each pixel from being drained between refreshes to a display"s image. Each pixel is a small capacitor with a layer of insulating liquid crystal sandwiched between transparent conductive ITO layers.

The circuit layout process of a TFT-LCD is very similar to that of semiconductor products. However, rather than fabricating the transistors from silicon, that is formed into a crystalline silicon wafer, they are made from a thin film of amorphous silicon that is deposited on a glass panel. The silicon layer for TFT-LCDs is typically deposited using the PECVD process.

Polycrystalline silicon is sometimes used in displays requiring higher TFT performance. Examples include small high-resolution displays such as those found in projectors or viewfinders. Amorphous silicon-based TFTs are by far the most common, due to their lower production cost, whereas polycrystalline silicon TFTs are more costly and much more difficult to produce.

The twisted nematic display is one of the oldest and frequently cheapest kind of LCD display technologies available. TN displays benefit from fast pixel response times and less smearing than other LCD display technology, but suffer from poor color reproduction and limited viewing angles, especially in the vertical direction. Colors will shift, potentially to the point of completely inverting, when viewed at an angle that is not perpendicular to the display. Modern, high end consumer products have developed methods to overcome the technology"s shortcomings, such as RTC (Response Time Compensation / Overdrive) technologies. Modern TN displays can look significantly better than older TN displays from decades earlier, but overall TN has inferior viewing angles and poor color in comparison to other technology.

Most TN panels can represent colors using only six bits per RGB channel, or 18 bit in total, and are unable to display the 16.7 million color shades (24-bit truecolor) that are available using 24-bit color. Instead, these panels display interpolated 24-bit color using a dithering method that combines adjacent pixels to simulate the desired shade. They can also use a form of temporal dithering called Frame Rate Control (FRC), which cycles between different shades with each new frame to simulate an intermediate shade. Such 18 bit panels with dithering are sometimes advertised as having "16.2 million colors". These color simulation methods are noticeable to many people and highly bothersome to some.gamut (often referred to as a percentage of the NTSC 1953 color gamut) are also due to backlighting technology. It is not uncommon for older displays to range from 10% to 26% of the NTSC color gamut, whereas other kind of displays, utilizing more complicated CCFL or LED phosphor formulations or RGB LED backlights, may extend past 100% of the NTSC color gamut, a difference quite perceivable by the human eye.

The transmittance of a pixel of an LCD panel typically does not change linearly with the applied voltage,sRGB standard for computer monitors requires a specific nonlinear dependence of the amount of emitted light as a function of the RGB value.

In-plane switching was developed by Hitachi Ltd. in 1996 to improve on the poor viewing angle and the poor color reproduction of TN panels at that time.

Initial iterations of IPS technology were characterised by slow response time and a low contrast ratio but later revisions have made marked improvements to these shortcomings. Because of its wide viewing angle and accurate color reproduction (with almost no off-angle color shift), IPS is widely employed in high-end monitors aimed at professional graphic artists, although with the recent fall in price it has been seen in the mainstream market as well. IPS technology was sold to Panasonic by Hitachi.

Most panels also support true 8-bit per channel color. These improvements came at the cost of a higher response time, initially about 50 ms. IPS panels were also extremely expensive.

IPS has since been superseded by S-IPS (Super-IPS, Hitachi Ltd. in 1998), which has all the benefits of IPS technology with the addition of improved pixel refresh timing.

In 2004, Hydis Technologies Co., Ltd licensed its AFFS patent to Japan"s Hitachi Displays. Hitachi is using AFFS to manufacture high end panels in their product line. In 2006, Hydis also licensed its AFFS to Sanyo Epson Imaging Devices Corporation.

It achieved pixel response which was fast for its time, wide viewing angles, and high contrast at the cost of brightness and color reproduction.Response Time Compensation) technologies.

Less expensive PVA panels often use dithering and FRC, whereas super-PVA (S-PVA) panels all use at least 8 bits per color component and do not use color simulation methods.BRAVIA LCD TVs offer 10-bit and xvYCC color support, for example, the Bravia X4500 series. S-PVA also offers fast response times using modern RTC technologies.

When the field is on, the liquid crystal molecules start to tilt towards the center of the sub-pixels because of the electric field; as a result, a continuous pinwheel alignment (CPA) is formed; the azimuthal angle rotates 360 degrees continuously resulting in an excellent viewing angle. The ASV mode is also called CPA mode.

A technology developed by Samsung is Super PLS, which bears similarities to IPS panels, has wider viewing angles, better image quality, increased brightness, and lower production costs. PLS technology debuted in the PC display market with the release of the Samsung S27A850 and S24A850 monitors in September 2011.

TFT dual-transistor pixel or cell technology is a reflective-display technology for use in very-low-power-consumption applications such as electronic shelf labels (ESL), digital watches, or metering. DTP involves adding a secondary transistor gate in the single TFT cell to maintain the display of a pixel during a period of 1s without loss of image or without degrading the TFT transistors over time. By slowing the refresh rate of the standard frequency from 60 Hz to 1 Hz, DTP claims to increase the power efficiency by multiple orders of magnitude.

Due to the very high cost of building TFT factories, there are few major OEM panel vendors for large display panels. The glass panel suppliers are as follows:

External consumer display devices like a TFT LCD feature one or more analog VGA, DVI, HDMI, or DisplayPort interface, with many featuring a selection of these interfaces. Inside external display devices there is a controller board that will convert the video signal using color mapping and image scaling usually employing the discrete cosine transform (DCT) in order to convert any video source like CVBS, VGA, DVI, HDMI, etc. into digital RGB at the native resolution of the display panel. In a laptop the graphics chip will directly produce a signal suitable for connection to the built-in TFT display. A control mechanism for the backlight is usually included on the same controller board.

The low level interface of STN, DSTN, or TFT display panels use either single ended TTL 5 V signal for older displays or TTL 3.3 V for slightly newer displays that transmits the pixel clock, horizontal sync, vertical sync, digital red, digital green, digital blue in parallel. Some models (for example the AT070TN92) also feature input/display enable, horizontal scan direction and vertical scan direction signals.

New and large (>15") TFT displays often use LVDS signaling that transmits the same contents as the parallel interface (Hsync, Vsync, RGB) but will put control and RGB bits into a number of serial transmission lines synchronized to a clock whose rate is equal to the pixel rate. LVDS transmits seven bits per clock per data line, with six bits being data and one bit used to signal if the other six bits need to be inverted in order to maintain DC balance. Low-cost TFT displays often have three data lines and therefore only directly support 18 bits per pixel. Upscale displays have four or five data lines to support 24 bits per pixel (truecolor) or 30 bits per pixel respectively. Panel manufacturers are slowly replacing LVDS with Internal DisplayPort and Embedded DisplayPort, which allow sixfold reduction of the number of differential pairs.

Backlight intensity is usually controlled by varying a few volts DC, or generating a PWM signal, or adjusting a potentiometer or simply fixed. This in turn controls a high-voltage (1.3 kV) DC-AC inverter or a matrix of LEDs. The method to control the intensity of LED is to pulse them with PWM which can be source of harmonic flicker.

The bare display panel will only accept a digital video signal at the resolution determined by the panel pixel matrix designed at manufacture. Some screen panels will ignore the LSB bits of the color information to present a consistent interface (8 bit -> 6 bit/color x3).

With analogue signals like VGA, the display controller also needs to perform a high speed analog to digital conversion. With digital input signals like DVI or HDMI some simple reordering of the bits is needed before feeding it to the rescaler if the input resolution doesn"t match the display panel resolution.

The statements are applicable to Merck KGaA as well as its competitors JNC Corporation (formerly Chisso Corporation) and DIC (formerly Dainippon Ink & Chemicals). All three manufacturers have agreed not to introduce any acutely toxic or mutagenic liquid crystals to the market. They cover more than 90 percent of the global liquid crystal market. The remaining market share of liquid crystals, produced primarily in China, consists of older, patent-free substances from the three leading world producers and have already been tested for toxicity by them. As a result, they can also be considered non-toxic.

Kawamoto, H. (2012). "The Inventors of TFT Active-Matrix LCD Receive the 2011 IEEE Nishizawa Medal". Journal of Display Technology. 8 (1): 3–4. Bibcode:2012JDisT...8....3K. doi:10.1109/JDT.2011.2177740. ISSN 1551-319X.

Brody, T. Peter; Asars, J. A.; Dixon, G. D. (November 1973). "A 6 × 6 inch 20 lines-per-inch liquid-crystal display panel". 20 (11): 995–1001. Bibcode:1973ITED...20..995B. doi:10.1109/T-ED.1973.17780. ISSN 0018-9383.

Richard Ahrons (2012). "Industrial Research in Microcircuitry at RCA: The Early Years, 1953–1963". 12 (1). IEEE Annals of the History of Computing: 60–73. Cite journal requires |journal= (help)

K. H. Lee; H. Y. Kim; K. H. Park; S. J. Jang; I. C. Park & J. Y. Lee (June 2006). "A Novel Outdoor Readability of Portable TFT-LCD with AFFS Technology". SID Symposium Digest of Technical Papers. AIP. 37 (1): 1079–82. doi:10.1889/1.2433159. S2CID 129569963.

Kim, Sae-Bom; Kim, Woong-Ki; Chounlamany, Vanseng; Seo, Jaehwan; Yoo, Jisu; Jo, Hun-Je; Jung, Jinho (15 August 2012). "Identification of multi-level toxicity of liquid crystal display wastewater toward Daphnia magna and Moina macrocopa". Journal of Hazardous Materials. Seoul, Korea; Laos, Lao. 227–228: 327–333. doi:10.1016/j.jhazmat.2012.05.059. PMID 22677053.

And consumers are fairly satisfied with devices that get charged once every day, and can take a 15 minute quick-charge to add multiple hours of additional usage to them.

As noted, we already have e-ink phones that can do both colour and video[1], while there is some ghosting it"s getting to the point of usable. Just need a big display to match it.

eInk"s primary advantages are power (and only if your idle period is long enough; if you have to update it with any frequence you"re going to lose pretty soon to a memory LCD); and angles/polarity (specially compared to LCD), which some people also claim produces less headaches.

The company also doesn"t exist and only produced 10" 1024x600 screens, which are barely usable. If you know of another usable product, or have anything to back up your claims, please do share.

I also have the Metawatch. These are purely reflective, not transflective. They boast whopping 20:1 contrast ratios -- https://www.sharpsma.com/products?sharpCategory=Memory%20LCD... . Even at its best days (carta) eInk didn"t reach that 15:1 https://wiki.mobileread.com/wiki/E_Ink_Carta , and nowadays it"s more like 10:1.

I"ve owned two devices with them so far, and quite frankly the newer one works just as well (if not better) than E-Ink outdoors but still has a backlight when necessary. Also, it can display color and smooth motion. The minor downside I see is the lack of an ability to display an image with zero battery consumption, such as on E-Ink, but the consumption is still so low that the transflective LCD watches can last weeks with an always-on display.

With the refresh rate of e-ink, wouldn"t the google play store be useless anyway? Most apps would be unbearable (games a non-starter, scrolling a no-no, etc).

Everybody would like a Ferrari/Rolex/etc., but they don"t get cheaper because of it. In fact, high demand combined with a monopoly means you don"t need to lower prices at all. (You lower price to raise demand, but you don"t need to if you have strong demand at your current prices).

Competition does lower prices. And with patents competition is impossible. As if for a competitor to make improvements to the process/technology, while still using parts of it (they would still infringe).

In my experience in the display industry, the main driver of price is cost and the main driver of cost is volume. If a customer puts in a signed escrowed order for a million displays lilke what Apple did, then processes get scaled, factories get built, and per-unit prices go down.

That my understanding of how 6" matrix E-Ink displays went from costing thousands of dollars per display when they were being built in low volumes of hundreds of displays to costing sub-50 when they were being built for Sony, Amazon and others in volumes of hundreds of thousands of displays. The same is true of the LCD industry and the OLED industry. The same is true of the cellphone industry.

I can"t understand what exactly you"re talking about. Is this the E-Ink-is-expensive-because-of-patents trope? I"ve asked before whenever I see this trope on HN, what specific patent are you referring to? Patent thicket? This extraordinary claim requires evidence. I go to SID, never heard anyone claiming this kind of stuff. Tonnes of competition but physics, featureset, costs, volume, customer demand gets in the way. It is why even well funded companies like Liquavista-Amazon and Mirasol-Qualcom didn"t make it.

I"m talking about exactly this: if a company holds patents on a technology, other companies can"t improve the same technology (using parts of the patented tech and improving specific aspects with inventions of their own) without licensing it.

You"re making a claim equivalent to saying Microsoft holds patents on operating system technologies, other companies can"t improve the same technology.

I"m guessing you"re not actually involved in the display industry because you chose not to reply with a clearly defined specific problem that is blocked by patents. I actually work in the display industry so I just see the repetition and self-citation claims (OP"s article refers to yet another HN throwaway post) on HN as being disappointing.

But they can"t make a filesystem that also leverages X, Y, Z (or any combination of them) unless they license, and also can"t make a filesystem with an improved version of X, Y, or Z lest they infringe on the X, Y, Z pattent.

So this isn"t about other companies still being able to make improved eg. OSes in the general sense, but if they can build improved OSes that also leverage the same patented techniques where needed (and they can"t).

> So this isn"t about other companies still being able to make improved eg. OSes in the general sense, but if they can build improved OSes that also leverage the same patented techniques where needed (and they can"t)

I think I"ve explained my point clearly enough. I"ll wait for you to give some factual evidence as to which patent you believe is giving rise to your statement of "they can"t".

:-) I wouldn"t describe myself as pro-patent. I would say I"m pro-fair play. If Alice spends years in front of a fume hood developing a new ITO coating or polymer that reduces cost and improves manufacturability of a product, then she deserves to be protected from corporate VP Big Bob getting his engineer to just reverse engineer Alice"s work. If you agree that Alice"s work deserves some protection for some period of time, then we both share the same concept of right/wrong. Whether patents are the best way, and how they can be made more effective and less vulnerable to turkeys and vultures, is a discussion we could have in good faith. But at the very least we would need to base the discussion on facts rather than what I see in some other posts (not alleging you have done this) where they"re writing Kiplingesque just-so stories to explain display product pricing while not knowing the difference between ITO and AgNP.

Thanks for having some persecution syndrome or conspiracy theory about "the downvote brigade" and about me having "some other agenda for promoting this story".

In actually, I don"t give a duck about the E-ink industry, but I do dislike the effect patents have in general, and am talking out of general principles about that.

You might be happy with E-ink patents in particular or patens in general. You might also be an E-ink industry insider (wouldn"t that make you the one that is more possible to have an "agenda" ot at least a vested interest?), and have far more information that me, a mere e-ink consumer, about the impact of patents there.

You could still respond (or not respond) on a thread about the impact on patents (on e-ink and in general) without being rude and second-guessing the other person.

I have not read such claims. What I have read are individual small-scale customers approaching base layer producers like E-Ink and being disappointed after expecting assistance in getting their product ideas to market. That"s analogous to a 10,000 unit/month or less customer approaching say a liquid crystal supplier, or AU Optronics and expecting any form of support or assistance. The outcome of such an interaction is pretty much guaranteed. Even the top tier distributors won"t talk to you unless you"re expected to order at least 100,000 units a year. Anything less and you go through the normal OEM development path of which there"s tonnes of partners. You do what everybody else who has a display product idea does, which is go to SID or maybe just CES, and talk to OEM vendors. If you"ve got an E-Ink product idea, probably somebody like Netronix would be your OEM partner but even they probably won"t talk to you unless you"re putting down big NRE. That"s just how it is. Volume drives the products. You can"t have small volume and cheap unless you"re reusing some component that someone else has driven the volume for. That"s just as true in the display industry as it is in any other tech industry, eg: LCDs, OLEDs, CPUs, memory, sensors, even passives like resistors and capacitors!

I don"t follow. I also don"t see how it is different than any other industry be it bricks or CPUs. Buy a few and the per unit price is high. Buy millions and the per unit price is low.

I keep seeing this claim. I believe it is wrong and asked for evidence. In response to which OP has promised to correct the article. https://news.ycombinator.com/item?id=26247268

Which companies / patents did they buy up? I keep seeing this rumor floating around but their Wikipedia article lists exactly one acquisition (https://en.wikipedia.org/wiki/E_Ink#Acquisition) and a casual Google doesn"t show any others.

I am curious if you work in the display industry. Do you know what the pricing for PQi displays actually was? Did you actually use a PixelQi display on a daily basis yourself? To be clear, I"m not attempting to be negative, but I actually work in the display industry and found the PixelQi display on the OLPC-XO-1 to be unusable. My perception of the display was one with very low quality color with backlight; and terrible viewing angle and unreadable contrast levels in bright sunlight. It also had low resolution. The XO-1 display I had access to had lots of pixel defects. If I am not mistaken (as I do not know actual pricing that Quanta got for the PixelQi displays) they were more expensive than LCDs and required additional parts that made managing their supply chain overall difficult. Most experts in my industry that I talked to expressed the opinion that it was a reality-distortion field type charismatic executive who managed to convince people at OLPC to try that idea. It was funded by UN and money from developing countries budgets who were excited by the promise of being able to educate their masses. Sadly it looks as if those countries were taken for a ride, rather than benefiting from a genuinely merit based idea.

So I am very interested to hear what details you will share to back up the "really good" and "clearly affordable" parts of your claim. If your claim is true then it would suggest that my whole industry ought to abandon our current design and architectural roadmaps and switch to Jepsen"s design! :-D I say that in a humourous context because last I heard in 2019 Jepsen abandoned badmouthing the entire display industry and switched to talking about telepathy and VR.

It seems kind of obvious to me that if it was cheaper people would reach for it more often and find cool uses for it. There’s some more circular logic for you.

As I have stated, I was looking for evidence or proof for OP"s claim about patents and did not find it, nor does OP appear to be able or willing to back up his/her claim. My opinion is that display pricing is driven primarily by volume, and secondarily by a lot of other rapidly fluctuating variables related to ITO/TFT manufacturing costs. I"m sure patents has some effect on the industry, but most likely negligible as I"ve never heard companies being impacted by it. At least not in my corner of the industry.

To be frank, I believe OP"s claim about patents is wrong and is just some kind of worldview that for some reason has caught on recently in HN and is getting repeated without being challenged.

The simplest evidence I can give that volume is the main driver of pricing is to compare EPD 6" matrix display pricing between 2007 where it was 100x more expensive than it is today. Patents haven"t changed. Volume has. That was driven by large scale buyers like Sony, Amazon, and others.

Now shipping with all the but the cheapest complete PCs are LCD monitors. Advances in display manufacturing and associated cost reductions with economies of scale have brought LCD monitors into the mainstream, shipping with budget systems that start at just £400. LCD monitors come in all shapes and sizes, have differing resolutions and inputs. The purpose of this HEXUS.help guide is to provide a basic understanding of how LCDs work, delineate their desirable characteristics, and to offer basic buying advice.

LCDs work in a relatively easy method to understand. Firstly, behind each LCD screen, where screens are defined by the number of pixels on a given panel, a light source is shone through from the behind to panel, through two panels of glass sandwiching the LCD, to your eyes. Each pixel on the LCD display has an array of liquid crystals (from whence the name arrives) whose molecules can be charged with a variable amount of voltage from electrodes over each subpixel (where each pixel is divided into red, blue and green filters), resulting in varying levels of light, from the source, passing through. Oversimplifying it somewhat, it"s the combination of subpixel voltage-switching and light source that make up the images you see.

LCD technology encompasses digital watches right up to ultra-high resolution displays. For the latter, each pixel can display one colour to another, activated by the variable voltage-switching from the pixels" transistors, detailed above. Faster switching between opposing colours (usually black-to-white), quoted in milliseconds,
