Unit: MPH, KM/H. A speed signal comes from the motor via controller to the display. The indicated speed depends on the motor signal and the wheel diameter.

When riding the scooter, keep the acceleration handle pressed with the same pressure for 5 seconds to activate the cruise control mode. Use the brake handle to deactivate the cruise control mode.

For safety purposes, all Joyor models except Mbike model are set by default to non-zero start mode, which means the motor will not get started until you start to kick the scooter first so that the speed is above zero:

The display is equipped with a USB port for you to be able to charge your electronic devices. When the device is connected, the USB indicator is lit. In case of problem, the indicator starts to flash, and a safety mode will be automatically activated.

P2:This means the control for your Speed sensor if you doubt that you have an issue with the speed sensor so better to check the default value in your manual.

C5: This parameter is responsible for the maximum operating current & as we mentioned you can use this to reset your controller. please make sure to check your e-bike manual before changing any value.

Possible cause: Undercharged battery.Solution: Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 12 hours after each use. Never charge the battery longer than 30 hours. Check all connections. Make sure the charger port is plugged into the charging port on the scooter and that the charger is plugged into the wall outlet.

Solution: Fully charge the battery. First charge should be 18 hours and up to 12 hours for recharges. Check to ensure that charger is tightly plugged into both the wall outlet and the scooter. Make sure power flow to the wall outlet is on.

Solution: Make sure you do not overload the scooter by allowing more than one rider at a time, exceeding the 120 Ibs (54kg) maximum weight limit, going up steep inclines or towing objects behind the scooter. If the scooter is over loaded, the circuit breaker may trip and shut off power to the motor. Correct the riding condition that caused the over load, wait a few seconds, and then push the reset button to reset the circuit. Avoid overloading the scooter as this will prematurely wear out the batteries and other components.

Solution: Check all wires and connectors to make sure they are connected and tight. The reset button (on the left side of the battery box) will automatically trip and turn off the power if the motor is overloaded. An excessive overload, steep incline or too heavy of a rider could have caused the motor to overheat and tripped the breaker. If this occurs and the scooter suddenly stops running, wait a few seconds and then push the reset button in to reset the circuit. Correct the condition that caused the breaker to trip to avoid repeatedly tripping the breaker.

Note: The value here is based on kilometers. When the unit setting is converted from kilometers to miles, the speed value on the display interface will be automatically converted to the correct mile value, but the speed limit value data set in this menu under the mile interface No conversion, it is inconsistent with the actual displayed mile speed limit value;

Note: Due to the upgrade of the company"s products, the displayed content of the product you get may be different from the manual, but it will not affect your normal use.
