Think that iPad"s Retina display is sharp? Ortustech would argue that it"s old hat. The company"s new LCD occupies a similar dimension at 9.6 inches, but it also carries an extremely dense 3,840 x 2,160 resolution -- making it the world"s smallest 4K display at a time when most everyone else is struggling to produce the giant variety. Like with the Japanese firm"s earlier 4.8-inch record-setter, the trick rests in a Hyper Amorphous Silicon TFT (HAST) that lets in more light per pixel and prevents that virtually seamless 458PPI image from becoming unusably dim. Test samples are rolling off the factory lines in November, although we"re not expecting to see Ortustech displays in our tablets anytime soon: sheer performance demands aside, the narrower 160-degree viewing angles and lower 72 percent color gamut better suit the 4K screen to pro video cameras and medical monitors that thrive on sharpness over anything else.

Tokyo, October 23, 2012 - ORTUS TECHNOLOGY CO., LTD (ORTUSTECH, HQ in Tokyo, Hino, President Mr.Ichiro Ohno) announced today that it has developed 9.6-inch color liquid crystal display, which is the world"s smallest size screen＊ realizes 4K2K full-pixels (3840x2160), and start sample delivery from November 2012.

4K2K display market is expected to grow rapidly as the next generation standard of high-quality display. Along with ORTUSTECH original HAST® technology (Hyper Amorphous Silicon TFT) which enables high-resolution display at high-aperture ratio, fine-pitch assemble technology, liquid crystal alignment technology, TFT drive technology which makes panel performance maximize, contribute to realize 4K2K full-pixels (3840x2160) image on 9.6-inch small size panel.

The natural and three-dimensional expression is realized by achieving overwhelming higher resolution (458ppi), which exceed discrimination limit of human eyes. 9.6-inch 4K2K display will be well suited to professional video equipment and medical equipment where clear and high resolution is demanded, such as broadcasting 4K2K camera monitor.

4K is all the rage as product manufacturers, broadcasters, and content producers anticipate adoption of UltraHD as a viable consumer platform. More pixels means greater resolution and larger average screen sizes, right?

Ortustech first gained notoriety in 2010 by packing a 1920x1080 HD into a 4.8 inch screen. Building on its mission to create small form factor high resolution displays, the company has announced a 4K2K (3840x2160) screen that’s only 9.6 inches!

According to Ortustech’s press release, “the natural and three-dimensional expression is realized by achieving overwhelming higher resolution (458ppi), which exceed discrimination limit of human eyes. 9.6-inch 4K2K display will be well suited to professional video equipment and medical equipment where clear and high resolution is demanded, such as broadcasting 4K2K camera monitor.”
