Product Details of 2.8 Inch /2.76 Inch 480(RGB)x480 Pixel TFT LCD Display with MIPI 2lane Interface, ST7701S Driver IC TFT LCD Display for Commercial Display Equipment for Sale

Product Introduction

Headline: 2.8 Inch /2.76 Inch 480(RGB)x480 Pixel TFT LCD Display with MIPI 2lane Interface, ST7701S Driver IC TFT LCD Display for Commercial Display Equipment

1.General Specification

General Information
Item	Standard Value	Units
LCD type	2.76	inch
Display Mode	Normally Black	mm
Resolution	480(RGB)x480	mm
Pixel pitch	0.1461RGB0.1461	pixel
Pixel Arrangement	RGB Vertical Stripe	--
Viewing direction	IPS	--
Module outline dimension	73.03(H)76.48(V)2.34(D)	--
LCD AA	70.13x70.13	--
Colors	16.7M	--
Driver IC	ST7701S	--
Interface	MIPI 2lane	--
Backlight	White LED	--
Operating Temperature	-20~ +70	℃
Storage Temperature	-30~ +80	℃
Luminance	350	CD/m2

2.Drawing
