a line of extreme and ultra-narrow bezel LCD displays that provides a video wall solution for demanding requirements of 24x7 mission-critical applications and high ambient light environments

Since 1995 Digital View has been providing LCD controller boards, related accessories and engineering services for video display systems, commercial video monitors and other non-consumer displays systems using LCD panels. Offices in USA, UK and Hong Kong with distribution globally.

Backlit LCDs provide excellent visibility indoors, but require high-brightness backlights to produce enough brightness for for direct sunlight readability - 1000 nits or more, to be exact. All that brightness requires a lot of power to operate, making traditional high-brightness LCD signage costly in multiple ways.

Sun Vision Display panels actually turn sunlight into an asset through their reflective LCD technology.They"re the perfect solution for sunny locations. In fact, as sunlight or ambient light shining on the display increases, so does the brightness of the Sun Vision Display panel"s image - all while consuming almost no power (less than 6 watts). No need to shield the display from the sun!

An LCD video wall is a large visualization surface that is built from multiple LCD displays (also known as ‘tiles’). These individual displays are designed specifically for use in these applications, and differ highly from normal television sets. The biggest differences are the bezel width, the mounting system, and the reliability. Normal television sets are designed to play a few hours per day, these specific panels are expected to play much more. Often even 24/7. And because the environments in which these video walls are deployed are sometimes critical, the uptime needs to be as high as possible.

Especially important for video walls, is a perfect calibration. This is not only restricted to a single panel. More critical, is that the color and brightness settings of the complete wall match. This means that the values of all panels need to be synchronized with the surrounding displays. If not, even the slightest deviation in color or brightness will make the wall seem out of balance.

High brightness: The light output of LCD video walls is generally quite high. Especially compared to LED-lit rear-projection cubes, LCD scores better. This allows the use in most lighting conditions - even in daylight.

Low real estate needs: Rear-projection cubes are quite deep, and (unless front access is available) need a rear maintenance area. As such, they need a lot of real estate space. LCD video walls only take the place on the wall of the panel depth and the wall mounting. This is usually less than 20 cm / 7.9”.

While there are many different manufacturers of LCD monitors, the panels themselves are actually only manufactured by a relatively small selection of companies. The three main manufacturers tend to be Samsung, AU Optronics and LG.Display (previously LG.Philips), but there are also a range of other companies like Innolux and CPT which are used widely in the market. Below is a database of all the current panel modules manufactured in each size. These show the module number along with important information including panel technology and a detailed spec. This should provide a detailed list of panels used, and can give you some insight into what is used in any given LCD display.

Note:These are taken from manufacturer product documentation and panel resource websites. Specs are up to date to the best of our knowledge, and new panels will be added as and when they are produced. Where gaps are present, the detail is unknown or not listed in documentation. The colour depth specs are taken from the manufacturer, and so where they specify FRC and 8-bit etc, this is their listing. Absence of such in the table below does not necessarily mean they aren’t using FRC etc, just that this is how the manufacturer lists the spec on their site.

Today’s vivid, immersive displays rely on layers of Corning glass to provide a stunning viewing experience. Wherever you look for news and entertainment, chances are Corning glass is there, too. We are the science and engineering powerhouse behind revolutionary display inventions, including glass cathode-ray bulbs for the first televisions and the LCD glass that made smartphones and laptop computers commonplace. We set the standard for the industry with Corning® EAGLE XG® Slim Glass substrates, manufacturing over 25 billion square feet — enough to pave the Great Wall of China 25 times, or cover nearly 390,000 football fields — while eliminating the equivalent of 6,000 truckloads of heavy metals from entering the environment. Today, we continue to enable the display industry and emerging technologies with our three-glass portfolio.

New design freedoms are taking shape with Corning LotusTMNXT Glass. Thanks to Corning Lotus NXT Glass, devices with OLED displays that curve, flex, or extend edge-to-edge across a device are all within reach.  Flexible OLED devices use a plastic backplane substrate, which calls for Corning’s high-tech display glass to enable the manufacturing process —to date, it"s enabled more than 2 billion OLED devices. Corning Lotus NXT Glass continues to emerge as the leader most-advantaged glass for rigid and flexible OLED panels – outperforming competitors and enabling the designs and performance that consumers love.

Looking beyond incumbent LCD and OLED display technology, Corning"s display portfolio is finding new opportunities in emerging technology applications, including Quantum Dot, Micro LED and Mini LED. With our proven track record of successfully navigating the display technology roadmap, our proprietary fusion manufacturing platform and reliable supply network, our commitment to our customers and innovation, and our innovative portfolio, we are excited to support the next generation of displays.

They filed a Swiss patent for the idea on Dec. 4, 1970. Though it attracted scant attention at the time, the milestone now stands as the birthdate of the liquid crystal display (LCD) – the technological platform which has transformed consumer electronics and presented a brilliant new way to view the world.

Early LCD developers took a few years to figure out that specialty glass, not plastic, was the best stable substrate for the delicate LCD circuitry and the color backplane component. Once they did, they turned increasingly to Corning to supply them with extraordinarily stable, flat, fusion-formed glass, able to preserve the critical properties of the liquid crystal and withstand high processing temperatures.

And LCDs rapidly transformed from “passive matrix” models, mostly used in pocket calculators and digital watches, to “active matrix” LCDs in which each sub-pixel was controlled with an isolated thin-film transistor. AMLCDs enabled wide viewing angles; brilliant, fast-moving images; and high-resolution images that had never been possible before.

Corning Incorporated was a critical player in this development, and eventually became the world’s leading supplier of LCD glass substrates. And Corning® EAGLE XG® Glass, the world’s first LCD substrate with no arsenic or other heavy metals, went on to exceed sales of 25 billion square feet, making it one of the most successful products in Corning’s history.

Different displays use different types of TCONs. In this article we will be talking about TCONs for the IT market: LCD (Liquid Crystal Display) notebook PCs and monitors.

An LCD panel has millions of Red, Green, and Blue (RGB) liquid crystals that are used to block a white backlight when electrical voltage is applied to them. High voltage signals to each individual pixel control how much of the backlight to block. A white display means nothing is being blocked. A black display means all three colors are blocked at maximum effort.

TCONS direct the high voltage driver chips that move the color filters and are usually found on a circuit board that sits below the glass panel (Fig. 1).

eDP connections are fast, use few wires, and are flexible for size, bandwidth and adding features eDP provides all panel connections in one plug, including power, data, and control signals. This is Analogix’s specialty.

While the GPU is responsible for transforming mathematical equations into individual pixels and frames, a TCON takes the individual frames generated by the GPU, corrects for color and brightness, then sends out parts of the image to each individual driver at the panel’s specific timing.

The human eye has an incredible dynamic range.  That means we can see both very dark images and very bright images, at the same time. However, neither camera sensors nor display panels can display that range. Your camera generates HDR images by using images from multiple exposures to combine the brightest and darkest parts of the picture. This increases the contrast (dynamic range) between light and dark, pulling out details from darkened or washed out areas.

HDR accurately maps real world color and luminance to a display panel. VESA DisplayHDR™ standard specifies HDR quality, including luminance, color gamut, bit depth, and rise time.

Display panels have difficulty displaying a wide range of brightness. Normal sunlight can reach 10,000 nits, but the backlight on most notebooks today is around 250 nits

VESA DisplayHDR requires the panel to meet minimum brightness, contrast, and color. No panel can reach 10,000nits of natural light. The brightest a 250nit notebook panel can produce is 250nits and any image above 250nits is washed out.  Also, no details from 250 nits to 10,000nits can be seen.

The HDR400 specifications require a dimmable backlight which helps with both producing darker blacks and lowering the power consumption. Tone mapping is used to map the whole range of 10,000 nits down to what the panel can handle, so the details can be seen. Tone mapping does not increase the brightness of the panel; it only makes the details visible.

VESA DisplayHDR600 Requires local dimming. No LCD panel can reach the VESA DisplayHDR600 requirement of 6000:1 contrast ratio. However, this can be overcome with local dimming.

For example, a 750:1 contrast panel requires 8 different backlight power settings to reach 6000:1 contrast ratio. However, unless there are thousands of separate regions, local dimming always produces halos around the bright areas. In order to reduce the halos, the following are recommended:

Monitors can use a direct backlight with many regions. An extra layer of liquid crystal can be used to dim the backlight at a specific location but this often results in a panel that is too thick for a notebook.

Notebook backlights use LEDs on the edge of the panel to reduce panel thickness. These can be on 1 side, 2 sides, or all 4 sides. Each edge adds to cost and bezel size.

Global Dimming Power Savings - Figure 6 shows a 15.6” UHD panel with 400nit maximum brightness. Figure 7 shows a comparison of backlight power consumption values between 400nit, 50nit and, respectively 5nit.

The primary goal of color management is to obtain a good match across color devices; for example, the colors of one frame of a video should appear the same on a computer LCD monitor, on a TV screen, and as a printed poster. Color management helps to achieve the same appearance on all of these devices, provided the devices are capable of delivering the needed color intensities. Color management cannot guarantee identical color reproduction, as this is rarely possible, but it can at least give more control over any changes which may occur.

A PC in HDR and SDR modes use different color gamut but the same screen. Dual-panel phones and notebooks need the color of the two sides to match perfectly. Graphic artists for web sites, movies, video games, etc., need to know what they are creating looks the same on their screen as on their customers’ screens.

As panels improve, the color space of new panels may exceed the color space from Windows.  This results in displays which look oversaturated. There is a trend towards low blue light or “night shift” panels, while still retaining color accuracy for the other colors. Today, low blue light panels are created by measuring each individual panel, then hoping that the yield is high enough.

Analogix’s Advanced Color Blocking (ACB) technology is used to create consistent image quality across different panels and change color space for different usage modes (Fig. 8). It allows for 3D color gamut rotation in the optical color domain rather than the RGB domain and color space change on the fly, such as color mapping of BT.2020 source to sRGB or DCI-P3 panels. It includes LUT shadow registers and hardware transition calculations (to smooth changes).

Color conversion in the TCON can dynamically and continuously adjust the incoming signal from the GPU for a low blue light color space. This way, no individual panel measurement is needed and yields should increase. While this can also be done by the GPU itself, that takes GPU bandwidth and 500x more power.

Panel Self-Refresh (PSR) – frame buffer in a TCON can maintain a display image without receiving video data from the CPU. For a still image, this allows the GPU to enter a low-power state and the eDP main link to turn off. Allowing the GPU to power down between display updates will save significant power and extend battery life.

Panel Self-Refresh with Selective Update (PSR2) is a superset of the panel self-refresh feature and it allows the transmission of modified areas within a video frame with obvious benefits when watching a movie or playing a game. PSR2 identifies when only a portion of the screen is static, which is a selective update. In PSR2, when the full screen is static, the refresh rate can be lowered for further power savings as done by Intel Low Refresh Rate (LRR). Intel LRR lowers the refresh rate by changing pixel clock or by changing vertical blank depending on the scenario such as idle, playing video, browsing, etc. All Analogix TCONs support Intel LRR.

In-Cell Touch embeds the touch function in the display itself, the panel including all the touch sensors, controllers, and needed processing. This simplifies the production process and reduces weight and reflection by removing the cover glass. It also allows for thinner bezels as there is no need for daughter cards and no separate wires for touch, as well as lighter devices as the cover glass is removed.

Analogix has pioneered the in-cell touch notebook panel TCONs. About 15% of notebooks support touch and we expect the touch attach rate to increase as more active pen support is introduced.

This statistic shows the TFT LCD automotive display panel market share worldwide in 2017, by supplier. Japan Display lead the automotive display panel market in 2017, with a market share of 17.9 percent.Read moreTFT LCD automotive display panel market share worldwide in 2017, by brandCharacteristicMarket share--

IHS Markit. (April 4, 2018). TFT LCD automotive display panel market share worldwide in 2017, by brand [Graph]. In Statista. Retrieved January 18, 2023, from https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/

IHS Markit. "TFT LCD automotive display panel market share worldwide in 2017, by brand." Chart. April 4, 2018. Statista. Accessed January 18, 2023. https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/

IHS Markit. (2018). TFT LCD automotive display panel market share worldwide in 2017, by brand. Statista. Statista Inc.. Accessed: January 18, 2023. https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/

IHS Markit. "Tft Lcd Automotive Display Panel Market Share Worldwide in 2017, by Brand." Statista, Statista Inc., 4 Apr 2018, https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/

IHS Markit, TFT LCD automotive display panel market share worldwide in 2017, by brand Statista, https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/ (last visited January 18, 2023)

TFT LCD automotive display panel market share worldwide in 2017, by brand [Graph], IHS Markit, April 4, 2018. [Online]. Available: https://www.statista.com/statistics/929819/worldwide-automotive-display-panel-market-share-supplier/

When the health of your business depends on delivering a quality product and keeping your customers happy, you can’t afford to deal with supplier problems. In fact, your relationship with your LCD supplier is a key business partnership that can impact every area of your business more than you might realize. In order to keep your company running ...

The purchasing process for LCD displays can be quite complex. And as a procurement manager, you’re ultimately accountable for ensuring your end users receive the displays they need, when and where they need them....

It may have been years since you last switched to a new LCD display supplier. And chances are, that original vetting process may not have been very thorough if done at all, which may be why this is why you"re re-evaluating today. Asking the right questions during this process clarifies what you need for a successful partnership with your display ...

If you are in the market of color TFT LCD displays and you haven’t already been affected by the recent changes in the global market, then it’s just a matter of time. If you have recently asked, ‘What is going on with TFT-LCD panel prices lately?’, you are not alone. Here at Phoenix Display we have had a lot of questions regarding the TFT-LCD panel ...

You’ve been there before: Customer commitments you’ve made have been missed. Your production facility is line-down, effectively bringing it to a complete halt. And all parts are sitting idle waiting for the longest lead-time component — the LCD display — which is now extremely late. Maybe this is a onetime occurrence, or perhaps it’s systematic, ...

The company strives to expand its automotive display business as it represents a strong future growth engine and key contributor to its Order-to-Order business. LG Display will unveil a wide range of revolutionary automotive displays featuring key proprietary technologies such as P-OLED and LTPS (Low-Temperature Polycrystalline Silicon) LCD, innovations which enable larger, higher-resolution displays and more distinctive, practical designs.

The company’s LTPS LCD-based Head-Up Display (HUD), which achieves up to 5,000 nits, meets the driver’s needs while maintaining premium picture quality. Another innovation, glasses-free 3D display panel, maximizes the display’s 3D effect by utilizing cutting-edge eye-tracking technology to give viewers a level of visual satisfaction they have never experienced before.

The company will also showcase its Thin Actuator Sound Solution, a new technology designed to take the infotainment user experience to the next level. LG Display’s film-type exciter technology allows the device to vibrate off display panels or interior materials for a richer, 3D-immersive sound experience. This Thin Actuator Sound Solution even received a CES® 2023 Innovation Award (‘In-Vehicle Entertainment & Safety’ category) for its excellence in space efficiency, design innovation, sound experience innovation and eco-friendliness.

In the North Hall, LG Display will also unveil its third-generation OLED TV panel that achieves the most advanced picture resolution to date by applying ‘Meta Technology’.

LG Display will present its comprehensive OLED line-up, from the largest 97-inch OLED display to 77-, 65-, 45-, 42-, 27-inch OLED TV panels and ultra-small 0.42-inch OLEDoS.

OLED Glow is a 27-inch OLED concept that is not only height and angle adjustable, but also comes with convenient touch technology. BeFit Trolly, which combines a wheeled storage design frame with a 48-inch OLED panel boasting CSO (Cinematic Sound OLED) technology that creates sound directly from the display without additional speakers, maximizes functionality, mobility, convenience and interior designs.

Starting this month, the company will mass produce the gaming OLED panels to be featured in premium gaming monitors by global tech companies such as LG Electronics, Asus, and Corsair.
