Smart Display can be used to display the coordinate, status and data information provided by the connected HOST device. Customers can configure the position coordinates they want to display in normal operation mode (Node ID = 0x7B).

The Display is designed to be easily connected to a controller network, and to operate with minimum setup or knowledge of the SDO configuration on the controllers.

Raystar Smart Display CAN series offers an out-of-the-box CANopen development experience that will lower customers" development costs and speed time-to-market expectations.

The Smart Display can use wide-temperature are designed to support control applications in harsh operating conditions, which designed to be connected to a variety of different situation combinations, such as automotive, marine, power generation and oil-and-gas.

The Smart Display comes with standard UI objects to get customers project off the ground quickly. If customers need custom UI objects support, our engineers are here to help. Send over your contents in PNG/JPG format, we will send over a new set of UI objects within 3~5 working days.

The Smart Display is defined as a slave device, which is controlled by master device via CAN bus command to render display content on the display screen and return touch event data with protocol objects.

If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.

This type of PCAP touch UI utilizes predefined touch areas distributed over the screen. Within these touch areas are icons that display on the screen, often in varying menu screens. Gestures such as swiping or scrolling are not supported. The corresponding sensors only require a single layer of ITO with a predefined button layout and a simple button-type controller with limited input pins depending on the number of buttons.

With this type of PCAP touch UI, single touches can be sensed anywhere on the screen, not just on predefined areas. It’s suitable for devices which typically don’t display pictures that require a zoom feature, but still need single touch gesture support for scrolling or swiping. This type of interface is commonly found in industrial and household applications, remote controls, and consumer medical devices. Here, the sensor can also be realized by a single layer of ITO, typically employing a triangle or backgammon pattern. Reliable gesture recognition is supported by this pattern only in one direction, i.e. either vertically or horizontally. It requires a simple capacitive touch controller with the number of inputs depending on the screen size. Typically, these types of sensors are limited to approximately 4” diagonal.

This is a common PCAP touch user interface found on devices designed for very specific purposes, such as navigation devices, industrial, and professional medical devices. These typically feature pictures or maps that need to be zoomed but are not used for fancy games and applications. The sensor that supports such a UI typically exhibits a pattern of conductive rows and columns perpendicular to each other that are applied on a single substrate often referred to as a “caterpillar pattern”. This requires an elaborate layout where the rows and columns do not intersect on the visible part of the screen. The disadvantage of this pattern is the relatively low resolution it provides. It can be applied on sensors up to 5” diagonal.

This is the most common PCAP touch user interface found on consumer devices such as mobile phones, tablets, laptops, and automotive applications. As mentioned above, the feature of “multi-touch” is not indispensable for everyday use, but sensors designed for higher resolution and larger screens practically provide this feature for free. Both high resolution and large size sensors require an ITO pattern on two different layers separated by a dielectric. This could be realized by laminating two substrates together (GG or FF), having the layers on opposite sides of the same substrate (DITO) or on the same side of a single substrate (SITO) where only the crossovers of the rows and columns of the sensing pattern are separated by an insulation layer. This 2-layer technology is the biggest cost factor that makes this sensor more expensive than the others. The only component specific to multi-touch is a controller that supports mutual capacitive sensing technology whereas a self-capacitive sensing touch controller would be sufficient for all the previously mentioned designs. However, such a controller does not contribute significantly to cost.

Different displays have different characteristics, just tell Panox Display your application, and operating environment, Panox Display will suggest a suitable display for you.

But Panox Display is not a school, if customers don`t know the basic knowledge to design circuit boards, we suggest using our controller board to drive the display.

First, you need to check whether this display has On-cell or In-cell touch panel, if has, it only needs to add a cover glass on it. If not, it needs an external touch panel.

If you don`t know or don`t want to write a display program on Raspberry Pi, it`s better to get an HDMI controller board from us, and Panox Display will send a config.txt file for reference.

Marine displays & panel PCs from CDS are internationally recognised and certified with a proven track record of satisfying all types of scenarios, applications and environments for maritime professionals and organisations.

In order to enlarge the display product line in the medical industry, the company decided to release a TFT that could fit the application like the Syringe Infusion Pump. Some main features are listed as follows.

We adopt a thinner touch structure in this case: G+FF(Cover glass + Film sensor*2), the total thickness of the PCAP is 1.53mm (1.10mm Coverlens + 0.43mm Film sensor), including the bonding adhesive.

The EMI shielding Film will be adopted in this display and help to reduce EMI. Many electronic devices that utilizing flexible circuits and rigid-flex PCB are sensitive to either absorbing or emitting EMI. If EMI is left uncontrolled, it can negatively impact the performance of the design and in extreme cases completely prevent it from functioning.

The pictures in this video were displayed in landscape mode after modification (originally are in portrait mode), the real sample shall prevail in this case due to the poor video resolution here.

In order to enlarge the display product line in the medical industry, the company decided to release a TFT that could fit the application like the Syringe Infusion Pump. Some main features are listed as follows.

We adopt a thinner touch structure in this case: G+FF(Cover glass + Film sensor*2), the total thickness of the PCAP is 1.53mm (1.10mm Coverlens + 0.43mm Film sensor), including the bonding adhesive.

The EMI shielding Film will be adopted in this display and help to reduce EMI. Many electronic devices that utilizing flexible circuits and rigid-flex PCB are sensitive to either absorbing or emitting EMI. If EMI is left uncontrolled, it can negatively impact the performance of the design and in extreme cases completely prevent it from functioning.

The pictures in this video were displayed in landscape mode after modification (originally are in portrait mode), the real sample shall prevail in this case due to the poor video resolution here.

PCAPs are suitable for multi-touch screens. Gesture recognition is given and multiple contact points are possible (up to 10). The suitability depends largely on the support of the operating system used.

I have seen a PCAP at another dealer, where the optical properties were insufficient. There were wires in the touch field that reminded me of the rear window heater in my car. When can we expect an optical improvement with this technology - or does it already exist?

There have been projective capacitive touchscreens with excellent optical properties for quite some time, and the wires running in the touch field are hardly noticeable (see iPhone). Some PCAPs are actually operated with visible wires. These have a different operating principle, which is optically less favorable. At HY-LINE you get only high quality PCAPs, whose optical properties are very good.

Projective capacitive touchscreens consist of several layers. Depending on the purpose for which a PCAP is used and in which environment, different material compositions of the layers are available (layers made of glass or different plastics).

The cover glass is separate from the actual touch sensor. Thus, a cover glass can also be larger than the actual touch sensor. A PCAP thus offers a design freedom that other touch technologies cannot provide.

This is a special process for bonding two surfaces (display and touchscreen) together - in a high-quality manner and covering the entire surface - without significantly changing the optical properties. One challenge here is to minimize internal reflections. This highly technical process is carried out in a clean room so that no dust particles affect the bonding process.

EVE3 3.5" SPI 320x240 Graphic TFT Display HMI Oversize Mountable Capacitive Touch Screen utilizes the FTDI/Bridgetek BT815 EVE (Embedded Video Engine) to create fast and economical HMI systems.

The Matrix Orbital EVE3 SPI TFT utilizes the FTDI/Bridgetek BT815 EVE (Embedded Video Engine) to create fast and economical HMI systems. With built in graphics operations, sound synthesizer, digital filter and support for multiple widgets you can create your own stunning screens and interfaces with the EVE Screen Designer software.

Stylish smart touch displays with an input voltage of 12-24V DC make the HG2J HMI a leading choice for applications across a variety of industries, including industrial, solar, and vehicle applications.

Offered in a popular size form factor, HG2J delivers a technologically advanced display with projected-capacitive (PCAP) technology to provide a slimmer and sleeker appearance, small installation footprint, improved performance, and longer life.
