pcap tft display in stock

This 12.3" full HD IPS Bar TFT LCD/ Letterbox Displaymodule features LVDS interface, an exceptional clarity in a unique aspect ratio of 21:9. It provides outstanding high contrast imagethat can be easily viewed over a wide angleeven in bright sunlight and unfavourable conditions. Its wide operating temperature range and long lifetimemake it ideal forindustrial, automotive, transportation, retail signage systems and marine applications. Also suitable for outdoor applications.

All our displays can be customised by our in-house engineering team to meet your application requirements, from optical enhancements, antimicrobial coating, touch optimisation to hardware, software and mechanical integration. Discover all our design services here.

If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.

Take your product to the next level with a capacitive touch screen LCD by Displaytech. Our PCAP (projected capacitive) touch screen technology is a premium alternative to a resistive touchscreen. We offer capacitive touchscreens for our 2.8-inch, 3.5-inch, 4.3-inch, 5-inch and 7-inch TFT LCD displays.

Smart Display can be used to display the coordinate, status and data information provided by the connected HOST device. Customers can configure the position coordinates they want to display in normal operation mode (Node ID = 0x7B).

The Display is designed to be easily connected to a controller network, and to operate with minimum setup or knowledge of the SDO configuration on the controllers.

Raystar Smart Display CAN series offers an out-of-the-box CANopen development experience that will lower customers" development costs and speed time-to-market expectations.

The Smart Display can use wide-temperature are designed to support control applications in harsh operating conditions, which designed to be connected to a variety of different situation combinations, such as automotive, marine, power generation and oil-and-gas.

The Smart Display comes with standard UI objects to get customers project off the ground quickly. If customers need custom UI objects support, our engineers are here to help. Send over your contents in PNG/JPG format, we will send over a new set of UI objects within 3~5 working days.

The Smart Display is defined as a slave device, which is controlled by master device via CAN bus command to render display content on the display screen and return touch event data with protocol objects.

Any object can be placed, moved and deleted at any time. Fonts can be zoomed and rotated without loss. Selected Windows character sets are stored directly in the display. Thanks to automatic ASCII and Unicode switching, all systems are flexibly supported; Chinese characters included.

Size: 3.5 inch, Standard TFT LCD Module, Model No.: VGG322419-A, Brightness: 350 cd/㎡, LCD Type: TFT, Normally White, Transmissive, Interface: TTL RGB, Touch Panel: optional - EVERVISION 3.5 inch TFT Display, 320x240 TFT LCD, PCAP Optional.

VGG322419-A is available for Touch Screen optional, as well as high brightness option for this model. It is suitable for industrial equipment, handheld devices, embedded system, medical equipment, etc. EVERVISION offers the rich diversity of mid-size TFT LCD modules, we are sure to have the perfect fit for your application requirements.

Here at CDS we understand that waiting up to 12 weeks to receive a sample is not always ideal, consequently this is why we have decided to stock our most popular sizes – quick samples, leading to quick approvals, and eventually quick roll outs!Small format bar type LCDs with HDMI driver kits – 8.8″ and 12.3″ (non-touch & PCAP touch)

Any object can be placed, moved and deleted at any time. Fonts can be zoomed and rotated without loss. Selected Windows character sets are stored directly in the display. Thanks to automatic ASCII and Unicode switching, all systems are flexibly supported; Chinese characters included.

Projected capacitive touch screens are usually briefly called PCAP touch screens. They arerobust, can be easily equipped with protective glass and feature multi-touch function for up to 10 fingers, enabling gesture control.

PCAP touch screens are equipped with a network of electrodes (Metal Mesh, Silver Nanowire, ITO) that project an electromagnetic field that also passes through a thick protective glass. If this field changes at one point due to a touching finger or a stylus, the touch position is calculated and forwarded to the controller. Drag & drop, zoom, rotate or scroll via gesture control is possible.

Due to the glass surface, the PCAP touch screens are particularly scratch-resistant and can be cleaned with all cleaning agents - an important advantage in hygienically sensitive areas.

With special protective glasses, the touch screens are vandal-proof and can be used in public areas. However, the number of touch points may vary depending on the strength of the protective glass used. PCAP touch screens are perfect for modern True Flat designs, as known from smartphones or tablet PCs, and thus ensure an appealing device design. We can offer the touchscreens also optically bonded as a unit with a protective glass and / or a TFT display.

3.5" EA TFT035-34AITC IPS display with PCAP touch panel, 480x320x3 dots with SPI or 8-/16-bit data bus or 16-bit RGB interface. AACS Technology with IPS. In-Plane-Switching (IPS) technology widens the viewing angle compared to conventional TFT displays. Onboard display controller ST7789V. Long-term availability. recommended for new designs. Only 1 FPC cable with all signals, pitch 0.3mm. The wide operating temperature ranges is -20..+70°C. Extreme bright white LED backlight integrated at 850 cd/m2. Incl. pure glass touch panel (PCAP) optically bonded with I²C bus controller GT911. This display is also available without touch panel EA TFT035-34ATNN.
