Projected capacitive touch screens are usually briefly called PCAP touch screens. They arerobust, can be easily equipped with protective glass and feature multi-touch function for up to 10 fingers, enabling gesture control.

PCAP touch screens are equipped with a network of electrodes (Metal Mesh, Silver Nanowire, ITO) that project an electromagnetic field that also passes through a thick protective glass. If this field changes at one point due to a touching finger or a stylus, the touch position is calculated and forwarded to the controller. Drag & drop, zoom, rotate or scroll via gesture control is possible.

Due to the glass surface, the PCAP touch screens are particularly scratch-resistant and can be cleaned with all cleaning agents - an important advantage in hygienically sensitive areas.

With special protective glasses, the touch screens are vandal-proof and can be used in public areas. However, the number of touch points may vary depending on the strength of the protective glass used. PCAP touch screens are perfect for modern True Flat designs, as known from smartphones or tablet PCs, and thus ensure an appealing device design. We can offer the touchscreens also optically bonded as a unit with a protective glass and / or a TFT display.

Projected capacitive (PCAP) touch screens are the latest iteration of a long history of touch sensor technologies dating back decades. The usage of PCAP touch screens has risen in conjunction with the proliferation of consumer electronics, medical device advancements and more sophisticated automotive applications, creating breakthrough specializations and use cases.

A PCAP screen’s conductive grid picks up changes in capacitance, which is the mechanism behind registering a touch. Paired with different bonding techniques, surface treatments and touch controller tunings, the ability to customize PCAP touch screens has led to endless permutations of highly successful touch display products.

PCAP screens use two layers of electrodes (X and Y) that form a capacitive electromagnetic field around them. When a finger, stylus or other conductive object hovers or touches the screen, it results in an electric charge that enables the processing system to identify, register and respond to the signal. A finger, for example, penetrates the electromagnetic field, creating a change in capacitance.

PCAP sensors have almost completely replaced resistive touch sensors over the years due to their numerous advantages. They can support multi-touch, gestures and 3D proximity sensing, and provide superior reliability and durability. This makes them ideal for automotive, consumer, medical, and industrial applications that require more functionality than buttons and single points of contact can offer.

PCAP technology is highly customizable and can be designed to individual customer needs. Engineers can tune PCAP touch sensors for application-specific sensitivity and accuracy, using custom touch controller algorithms. These capabilities make PCAP touch sensors an ideal solution for applications with rigorous requirements.

New Vision Display has decades of experience engineering high performance standards into integrated display products. Backed by its renowned PRECI-Touch® sensors, NVD is a leading designer of PCAP touch screen solutions for some of the world’s largest original equipment manufacturers (OEMs).

This is one of the most effective PCAP stack-ups, as it offers a high degree of accuracy as well as more control of charge time and sensitivity. SITO touch panels are the preferred solution for instrument clusters in automobiles, yacht navigation controls, and other applications requiring high sensitivity and control. They are also more accurate for rugged environments, water and salt-water immunity, and use with glove or stylus.

A 2-layer glass touch panel stack has X and Y electrodes patterned on two different glass layers, bonded together using OCA. The Y electrodes are patterned on the top glass layer, and the X electrodes are patterned on the bottom glass layer. This stack is customizable with additional protective cover lens optically bonded to the sensor, with optional back printing. This was the initial structure used for PCAP stack-ups.

One final point of differentiation among PCAP touch panel designs is how and where the chip is mounted. Two methods can be used:COF (Chip-on-flex:) The controller and supporting electronics are on a flexible substrate. This is the primary chip integration method used for touch sensors due to it being slim and flexible, but may not be possible for sensors larger than 15 inches.

Bonding of touch sensor and display:Optical bonding: Using an optically clear adhesive (OCA) or liquid glue to bond the touch and display components together, called optical bonding, is the optimal solution for many applications. In an optical bonding stack, air gaps are eliminated, creating a moisture and dust barrier and near-perfect optical transmission with low reflectance. This process also offers greater resistance to impacts, meaning greater overall durability.

Air gap bonding: Another option for touch and display bonding is to use a double-sided tape around the perimeter of the display. Though lower in cost than optical bonding methods, this solution has lower optical performance, higher chance of dust and moisture penetration, and reduced shock and vibration resistance. There are ways to reduce system reflectance within an air bonded module by using anti-reflective (AR) films or coatings on the air gap surfaces and/or applying display polarizers.

NVD is one of the most trusted PCAP touch sensor manufacturers with decades of experience serving major OEMs across all markets. Our PRECI-Touch® solutions are known for their performance in some of the most challenging applications and can be customized to your unique application requirements. We also provide full integration with custom LCD/OLED displays, cover lenses, and peripherals.

For more information on our PCAP technology capabilities, or to discuss your project with our experienced sales and engineering staff, contact New Vision Display today.

These wide viewing angle Small Format TFT LCDs with optional touch are industrial grade and cost competitive. Therefore these products are a popular display choice to integrate in many projects.

Using only high-tech factories that we partner with, we provide clients with the service of designing liquid crystal display panel (LCD) and liquid crystal display module(LCM), and is committed to the customized service, R&D, sales, after-sales service of display products. Our factories have hundreds of engineers focusing on creating the highest quality displays including monochrome LCD (TN, STN), colour LCD (CSTN and TFT), Custom LCD’s, LCD module (both COG* and COB*) which are widely used in mobile phones and many other applications.

Our state of the art factory produces High Resolution TFT glass panel cells, has TN, HTN, STN and TFT technologies for LCD panels. The Factory has class 1000 clean rooms, high accuracy bonding, pre bonding and heat seal machinery, many production lines specifically for TFT production, OCA and OCF bonding machines,  In-House LCD glass cleansing process, output thousands of pieces per month.

Touchscreen overlay cover glass only available (so you do not have to purchase the display)These displays can come with: touchscreen components, touchscreen overlays, industrial touch screen,Wide LCDs, LED TFTs, and TFT Colour displays.

Other options are: LCD drivers, LVDS Touchscreen displays, automotive LCD Display, TFT high resolution screens, TFT LCD capacitive touchscreens, TFT capacitive touchscreens, high brightness LCDs, Letterbox Displays, small VGA Displays, LCD panel without backlights,Variations of our Small Format TFT LCDs include: TFT Display touchscreens, TFT IPS Display, monochrome displays, TFT or LCD, embedded components, LCD components, TFT Drivers, industrial range of Displays,

CDS also offers industrial TFT LCDs,Our displays are used in: touch screen vending machines, automotive touch screen displays, vending machine display panel, Touch screen vending, TFT Automotive, LCD Dislay panel kits, Touch screen TFT monitors, LCD Display components, LCD Screen components,  and POS LCD Displays.As you can see from the tables above we have sizes including:  8.8 inches, 4.3 inch LCD Display, 10.1″ TFT LCD,  3.5 inch LCD Display, 4.3 inch display, 3.5 inch TFT LCD Display, 4.3″ screen, 7 inch LCD panel, 3 inch LCD Displays, and 4.3″ TFT LCDs as well as other small LCD Display screens.We have options on and equivalents to the following displays and TFT panel manufacturers:  Raystar, Kingtech LCD, Digital View, OLED modules, OLED products, Powertip LCD Displays, Data Vision LCD, LG TFT Display, Tianma NLT, Powertip Displays, Mitsubishi LCD Displays, DMC components, Kyocera LCDs, NLT Technologies Ltd, Sharp LCD TFT modules, LCD manufacturers in the USA, PMOLED Displays, innolux display corp, Industrial touchscreens, A Grade TFT LCD Displays, Panoramic TFT Displays, Samsung TFT Displays, Touchscreen components, Transparent TFT Displays, Touchscreen components,  TFT LCD controllers, as well as other TFT LCD manufacturers and Liquid crystal Display manufacturers.

CDS offers the widest range of displays and touchscreens including Abon touchscreens, Ampire LCD distributor, alternative Prisma interface baord supplier including Prisma iiia, Solomon Goldentek, Panasonic TFT, Winmate display, USB IO, and Apollo monitors

Our range includes AMOLED, circular displays, circular monitors, circular screens, circular TFT screens, round displays, Round TFT LCD displays, TFT AMOLEDs, TFT and IPS, TFT display interface microcontroller, TFT LCD or AMOLED, TFT LCD super AMOLED, WXGA TFT Displays, and WXGA TFT screens

As well as large format displays CDS also offers DSI TFT Display, large monochrome LCD displays, mono displays, mono OLEDC displays, mono TFT LCDs, monochrome displays, PCT Touchscreens, projected capacitive touch PCT technology, sq monitors and squid IDS.

CDS added a number of additional controller boards nd accessories which include TFT adaptor boards, TFT boards, TFT display controller boards, USB c LCD controller, USB touch kit, resistive touch screen, TFT accessories com, LCD controller board, LCD controller board USB c, LCD controller board, HDMI to MiPi DSI board, HDMI to MiPi DSI bridge, HDMI to MiPi LCD controller board, EDP adaptor bard, elite C microcontroller, Displaylink DL 3000 .

Whether it be bar type LCDs or any of CDS display solutions or many TFT displays we can help with comparing mipi dsi vs lvds interfces or mipi to edp wch can include use on pos shelf displays and rgb epaper for example.

IVO industrial TFT LCDs – IVO are a Chinese TFT manufacturer, offering very competitively priced panels. They have a small line up, focused on industrial applications but are looking to expand their range in the near future. TFT panel driver boards for IVO industrial TFT LCDs are available – VGA, DVI and video input cards to drive a wide range of TFT panels. IVO is an innovative and renowned manufacturer of high-quality TFT LCD panels and displays, which CDS has  added to our product range. Our IVO TFTs in sizes from 7″ to 27″ (17.78 to 68.59 cm) are characterized by their wide, symmetrical viewing angles and a high resolution, which ensures a very detailed image reproduction.

IVO provide an excellent price performance ratio and CDS offers long-term available industrial TFTs with integrated LED converter in the sizes listed, plus for easy installation CDS offers these TFTs as a complete VIDEO/HDMI/VGA/DP kit solutions. For the MIPI TFT displays. Plus CDS also has matching resistive analog and PCAP (I²C or USB) touch screens, including customised touchscreen solutions. For other manufacturers we have Public Information Displays (PID) for advertising and infotainment which are available in sizes from 29″ (72.64 cm) to 85″ (215.9 cm), with various brightness levels up to 4500cd/m² and can be used in 24/7 permanent operation. The displays provide excellent value for money and long-term availability.

1st generation: with flat display area and flat touch area, the border can be curved. Orient Display uses glass touch sensor and IML (In-Mold Lamination) technology to produce the products.

2nd generation: with flat display area and flat touch area, the border area can be flat or cuver in the middle. Orient Display still uses glass touch sensor and cold bending lens to produce this kind of products.

3rd generation: with flat display area and curve touch area, the border area can be flat or cuver in the middle. Orient Display uses glass or film touch sensor and hot bending lens to produce this kind of products.

4th generation: with curve display area and curve touch area, the border area can be flat. Orient Display uses flexible touch sensor to produce this kind of products.

Based on the above five types of touch panel technology, Orient Display can also add different kinds of features like different material glove or stylus or pencil touch, water environment touch, salt water environment touch, hover touch, force (3 dimensional) touch, haptic touch etc. Orient Display can also provide from very low-cost fixed area button touch, single (one) finger touch, double finger (finger+ gesture) touch, 5 finger touch, 10 points touch or even 16 points touch.

Considering the different shapes of the touch surface requirements, Orient Display can produce different shapes of 2D touch panel (rectangle, round, octagon etc.), or 2.5D touch screen (round edge and flat surface to create edge-less impression) or 3D (totally curved surface) touch panel.

Considering different strength requirements, Orient Display can provide low-cost chemical tampered soda-lime glass, Asahi (AGC) Dragontrail glass and Corning highest generation Gorilla glass. With different thickness requirement, Orient Display can provide the thinnest 0.5mm OGS touch panel, to thickness more than 10mm tempered glass to prevent vandalizing, or different kinds of plastic touch panel to provide glass piece free (fear) or flexible substrates need.

Orient Display can also provide full customized or part customized solutions for our customers to enhance the viewing experience. Orient Display can provide all the different kinds of surface treatments, such as AR (Anti-reflection); AG (Anti-glare), AF (Anti-finger print or Anti-smudge); AS (Anti-smashing); AM (Anti-microbial), IMITO (Index Matching Indium Tin Oxide), Anti Sparkling etc.

Orient Display can also provide both dry bonding (OCA, Optical Clear Adhesive), or wet bonding (OCR, Optical Clear Resin and OCG, Optical Clear Glue) to get rid of light reflective in air bonding products to produce high end touch screen monitor much more readable under sunlight and much more robust as well.

Touch panels have been a much better human machine interface which become widely popular. Orient Display has been investing heavy for capacitive touch screen sensor manufacturing capacity and LCD module production ability. With Orient huge production capacity, top notch quality, and competitive pricing, Orient has been working with top LCD panel manufacturers ,AUO, BOE, LG, Innolux and top touch controller manufacturers , Atmel (Microchip, Cypress, Synaptics, Elan, NXP, Goodix, Sharp, Hydis etc. to provide the best touch display technology in the market, such as IPS, MVA, in-cell, on-cell, automotive grade etc.

It is a new technology replace ink printing cover plate with visual area and black border area are integrated with seamless black design using AG/AR surface treatment. Non ink printing AR/AR seamless black optical cover plate can be customized to match touch display module to achieve the best integrated seamless black solution.

Orient Display developed a special smoke film which is very low cost but gives the customer a optical bonding performance. Smoke film uses optical interference to reduce the glass-air interface reflection for air (perimeter) bonding between LCD and touch screen.

Some companies have individual demands and requirements on their LCD panels and that`s why our liquid crystal displays are so individual. We offer individualised display solutions for nearly every requirement. Kit with LCD modules with controller cards and cable set

The drive electronics, cable sets and display systems, available at distronik, are perfectly adapted to your individual wishes and requirements. These display kits are not only compiled, but also tested. The advantages are clear: easy and quick installation of your industrial display and control electronics. The components of our display kits work perfectly together so you don`t have to matter about it.

The biggest advantage of our display solution is that you only have one supplier. That guarantees operative TFT display kits for your visualisation systems.

RELEC’s standard TFT Displays are available in a wide range of sizes, from small 1.77” up to 31.5”. These cover all industry-standard resolutions, sizes, and interfaces. Standard units are available with brightness levels exceeding 1500 cd/m² and can be supplied with or without resistive or PCAP touch panels.

In addition to supplying standard panels, we also have the ability to offer a range of enhancements to improve the optical, mechanical and environmental performance of your display. These may include:

Our goods are commonly recognized and reliable by consumers and may satisfy continually developing economic and social needs for Pcap Touch Screen Manufacturers, Lcd Frame, Tft Lcd Touch, Large Lcd Display,Graphic Lcd Display Module. We sincerely welcome overseas consumers to consult for your long-term cooperation as well as the mutual advancement.We strongly think that we will do superior and far better. The product will supply to all over the world, such as Europe, America, Australia,Jersey, Paris,Mauritania, Kuwait.Our company offers the full range from pre-sales to after-sales service, from product development to audit the use of maintenance, based on strong technical strength, superior product performance, reasonable prices and perfect service, we will continue to develop, to provide the high-quality products and services, and promote lasting cooperation with our customers, common development and create a better future.

Winstar is a global leading Manufacturer of TFT LCD display based in Taiwan and China. Winstar offers a wide product range of small to medium sizes TFT display modules in sizes ranging such as 2.4" TFT LCD, 2.8" TFT LCD, 3.2" TFT LCD, 3.5" TFT Display, 4.3 inch TFT LCD, 5 TFT LCD, 5.6 TFT LCD, 5.7 inch Display, 7 " TFT LCD, 8" TFT, 9" TFT, 10.1" TFT LCD, 10.2" TFT LCD, 12.1" TFT LCD , 12.3" TFT LCD (diagonal size of the active area) and so on . There are more than 250 TFT standard models listed on this website; furthermore, almost each item is acceptable to derivate from the standard items to meet the customers" requirement.

Winstar TFT displays are qualified under industrial standard including standard TFT-LCD modules, IPS TFT, High brightness TFT LCD (sunlight readable display), TFT panels with controller boards, Bar Type TFT, Wide Temperature TFT LCD, Winstar Clever System TFT and Touch screen display. These displays include landscape or portrait modes. Winstar has Mono TFT displays and full color TFTs in line, these displays are available in various resolutions as well as touch screen optional in resistive and projected capacitive (PCAP touch screen) technology. Many of our TFT display modules have more than one interface available including MCU, RGB, TTL, LVDS and MIPI DSI. Winstar TFT modules are perfect for a number of applications including industrial control, coffee machine, medical equipment, POS system, automation, GPS navigator, white goods, energy control, telecoms, medical equipment and etc.

CDS has recommended the use of thick cover lenses to add extra protection to capacitive touch TFT displays that are being used in harsh environments. These cover lenses can be supplied in thicknesses ranging between 1.1mm through to 11mm and can be added to TFT screen sizes ranging up to 47”!  In cases where the cover lens glass exceeds 4mm thickness, an industrial capacitive IC controller is required.

Tony Large, technical director at CDS, said: “The use of cover lenses on capacitive TFT displays gives OEMs that extra reassurance that the displays are sufficiently robust when used in harsh environments. This solution is ideal for a wide range of different applications, including industrial electronics, Gaming, Medical, automation, fire detection, as well as the oil and gas industry. We are currently using this combination of display combined with a thick cover lens for a Gaming client who loves the solution plus we saved them money!”

As TFTs can be susceptible to reflection and glare from bright lights or direct sunlight, optical bonding may be added to between the display and the cover lens to reduce the level of refraction and improve readability. Optical bonding technology can be used in conjunction with thick cover lenses. An alternative solution is to use anti-glare and anti-reflective coating on the cover lens itself.

If you have a specific requirement or project please email us on info@crystal-display.com and we will support you in every way we can and save you money at the same time.
