[1] The present invention relates to a cutting method of a large size TFT-LCD panel and a liquid crystal display unit to enhance a simplicity of process facility and a speediness through solving a problem of an increase of facilities due to manufacturing TFT-LCD panels of respective sizes and reducing a subsequently increased cost by enabling a mass production of a various size of TFT-LCD panels in one manufacturing line through using a TFT-LCD panel cut in a desired size that is manufactured in large size. Background Art

[5] Most of all as an outline, one pixel (composed of R. G. B. three sub-pixels) in the thin film transistor (TFT) - LCD is approximately as fine as 0.3 mm wide.

[6] Of course, the TFT included in the pixel is smaller than the pixel. Moreover, in order to meet a resolution of 1600x1200, 1,920,000 pixels are required and 5,760,000 TFTs are necessary if the sub-pixels are considered. Therefore, an overall process is very precise and demands a level of semiconductor process.

TFT process, a color filter (CF) process, a cell process and a module process. The cell process makes one panel with two glasses undergone the TFT process and the CF process. Then, the module process completes the manufacturing process by mounting the one TFT-LCD panel undergone the cell process in a real monitor or TV.

[8] First, the TFT process is the most basic core process for forming the most basic electrodes that provides an electrode for each cell. The process includes five process steps in order of forming a gate electrode, an insulating film, a semiconductor film, a data electrode, a protective film, and a pixel electrode that requires one or more pattern processes for each process step. Not only this pattern process that may be called a core

process in the processes of manufacturing the TFT-LCD panel is necessary in the TFT process but also a similar pattern process is necessary in the CF process.

TFT-LCD panel formed as hereinabove, the TFT-LCD panel is completed by providing a polarized plate on a surface of the TFT substrate and the CF substrate.

[11] The TFT-LCD panel of size demanded by a user may be produced in a large amount but the other TFT-LCD panel of less demand may be produced in only a limited amount since various sizes of the TFT-LCD panels completed as hereinabove require a difference in production line and in each process of the production line dependent on the sizes of the TFT-LCD panels. Disclosure of Invention Technical Problem

[13] The cutting method of a large size TFT-LCD panel of the present invention, provided to solve the hereinabove problems, has an object of enhancing a simplicity of process facility and speediness through solving a problem of an increase of facilities due to manufacturing TFT-LCD panels of different sizes and reducing a subsequently increased cost by enabling a mass production of a various size of TFT-LCD panels in one manufacturing line through using a TFT-LCD panel cut in a desired size that is manufactured in large size.

[14] The cutting method of a large size TFT-LCD panel formed as hereinabove can devise a simplicity in process and a profitability through solving a spatial enlargement and other costs increase due to an increase of facilities by equipping a facility"s process dependent on a size according to a production of TFT-LCD panels in various sizes, having an advantage of possibly producing a various size of the TFT-LCD panel asked by a user purpose or a user taste in a simple and convenient way, and solving an abandonment and reduction of the facilities due to a change in consumption dependent

[18] FIG. 4 illustrates a state of a scribe line set into a mid-depth of a color filter substrate and a thin film transistor substrate by diamond wheel in the cutting method of a large size TFT-LCD panel of the present invention.

[20] FIG. 6 illustrates a state completed after processing sealing a cut portion in the cutting method of a large size TFT-LCD panel of the present invention.

[27] In a completed large size TFT-LCD panel formed in a sequentially coupled configuration of a polarized plate, a color filter (CF) substrate, a liquid crystal layer, a thin film transistor (TFT) substrate and a polarized plate below the TFT substrate, a polarized plate stripping step that removes a portion of a predetermined width to be cut from the each polarized plate provided on a surface and an opposite surface of the large size TFT-LCD panel, a cutting location setting step that sets a portion not damaging a gate line and a data line of the TFT substrate through investigating a portion stripped in the polarized plate stripping step by microscope, a scribe line setting step that sets a first scribe line cutting the CF substrate into its mid-depth along the portion set in the cutting location setting step using a diamond wheel, a turning

over step that turns over the large size TFT-LCD panel to a side opposite from a side where a portion of the first scribe line is set after chucking one end of the large size TFT-LCD panel, a scribe line setting step that sets a second scribe line cutting the TFT substrate into its mid-depth in the stripped polarized plate portion along the portion set in the cutting location setting step which precisely corresponds with the set first scribe line using a diamond wheel after turning over the large size TFT-LCD panel, a tempering step that tempers for 30 minutes to form a natural crack in the scribe lines formed on the CF substrate and the TFT substrate of the large size TFT-LCD panel, a cutting step that cuts the CF substrate and the TFT substrate naturally cracked after the 30 minutes tempering step, and a sealing process step that sealing a cut portion formed in the cutting step, and

[28] In a completed large size TFT-LCD panel formed in a sequentially coupled configuration of a polarized plate, a color filter (CF) substrate, a liquid crystal layer, a thin film transistor (TFT) substrate and a polarized plate, a cutting location setting step that sets a portion to be cut, a scribe line setting step that sets a first scribe line cutting the CF substrate into its mid-depth along the portion set in the cutting location setting step using a diamond wheel, a turning over step that turns over the large size TFT-LCD panel to a side opposite from a side where a portion of the first scribe line is set after chucking one end of the large size TFT-LCD panel, a scribe line setting step that sets a second scribe line cutting the TFT substrate into its mid-depth along the portion set in the cutting line setting step which precisely corresponds with the set first scribe line, using a diamond wheel after turning over the large size TFT-LCD panel, a tempering step that tempers for 30 minutes to form a natural crack in the scribe lines formed on the CF substrate and the TFT substrate of the large size TFT-LCD panel, a cutting step that cuts the CF substrate and the TFT substrate naturally cracked after the 30 minutes tempering step, and a sealing process step that sealing a cut portion formed in the cutting step may accomplish the present invention object.

[29] Further, the present invention comprises a scribe line setting step that sets scribe lines simultaneously cutting the CF substrate and the TFT substrate into their mid-depths along the portions set in the cutting location setting step using a diamond wheel.

[30] The cutting method of a large size TFT-LCD panel further comprises a blocking off a light illuminated from a backlight through attaching a light blocking tape along a cut portion selected between the CF substrate and the TFT substrate or the both substrates or between the polarized plates located above the CF substrate and below the TFT substrate or the both polarized plates.

LCD panel 100 is formed in structure sequentially coupled of, a polarized plate 10, a color filter (CF) substrate 11, a liquid crystal layer 12, a thin film transistor (TFT) substrate 13 and a polarized plate 14.

[36] In order to cut the large size TFT-LCD panel 100 completed as hereinabove, a polarized plate stripping step is initially performed that removes a portion of a predetermined width to be cut from the each polarized plate 10 provided on a surface above the CF substrate 11 and an opposite surface below the TFT substrate 13.

[38] The TFT substrate 13 is exposed if the polarized plates 10 and 14 around the cutting portion are removed by its lengthwise direction. Since gate lines transferring a scanning signal and data line transferring a screen image signal are configured by innumerably crossing with each other and difficult to perceive by naked eyes, a cutting location setting step sets a portion not damaging the gate line and the data line of the TFT substrate through investigating a portion stripped on the polarized plate stripping step by microscope.

[43] To process a side opposite from a side where a portion of the first scribe line is set, the present step turns over the large size TFT-LCD panel 100 after chucking one end of the large size TFT-LCD panel 100.

[45] The present step sets a 2nd scribe line setting step cutting the TFT substrate 13 into its mid-depth in the portion of the stripped polarized plate 14 bonded with the TFT substrate 13 below along the portion set in the cutting location setting step which

precisely corresponds with the set first scribe line, using a diamond wheel after turning over the large size TFT-LCD panel 100. This step is also difficult and requires a skill of high precision to correspond with the set first scribe line.

[48] A natural crack is made if tempered for 30 minutes to form a natural crack in the scribe lines formed on the CF substrate 11 and the TFT substrate 13 of the large size TFT-LCD panel 100. Then, the air flows into a liquid crystal layer 12. If there is the air flow into the liquid crystal layer 12, the liquid crystal layer 12 is temporarily restricted from flowing out by the flowed in air.

[50] After the 30 minutes tempering step, the CF substrate 11 and the TFT substrate 13 are naturally cracked along the first scribe line and the second scribe line and the present step externally applies a certain amount of force in order to cut the large size TFT-LCD panel 100 along the scribe lines.

[52] The present step is the last step that applies a sealant 30 on a cut portion in the large size TFT-LCD panel 100 and the present invention is completed by applying the sealant 30.

[53] Through undergoing the process hereinabove, the large size TFT-LCD panel 100 is possible to be cut into a plural or multiple numbers without a many numbers of equipment and to meet a desired size of a demander or an operator.

[56] That is, in a large size TFT-LCD panel 100 completed of forming sequentially coupled, a polarized plate 10, a color filter (CF) substrate 11, a liquid crystal layer 12, a thin film transistor (TFT) substrate 13 and a polarized plate 14 below the TFT substrate 13, a cutting location setting step that sets a portion to be cut, a scribe line setting step that sets a first scribe line cutting the CF substrate 11 into its mid-depth along the portion set in the cutting location setting step using a diamond wheel, a turning over step that turns over the large size TFT-LCD panel 100 to a side opposite from a side where a portion of the first scribe line is set after chucking one end of the large size TFT-LCD panel 100, a scribe line setting step that sets a second scribe line cutting the TFT substrate 13 into its mid-depth along the portion set in the cutting location setting step corresponds with the set first scribe line, using a diamond wheel after turning over the large size TFT-LCD panel 100, a tempering step that tempers for

30 minutes to form a natural crack in the scribe lines formed on the CF substrate 11 and the TFT substrate 13 of the large size TFT-LCD panel 100, a cutting step that cuts the CF substrate 11 and the TFT 13 substrate naturally cracked after the 30 minutes tempering step, and a sealing process step that sealing a cut portion formed in the cutting step may configure the present invention.

[59] For example, after undergoing the sequentially processed cutting location setting steps of the first or the second exemplary embodiments through the polarized plate stripping step that removes a corresponding portion of a predetermined width to be cut from the polarized plates 10 and 14 provided on a surface of the CF substrate 11 and an opposite surface of the TFT substrate 13 like the first exemplary embodiment or without the polarized plate stripping step like the second exemplary embodiment, a scribe line setting step sets scribe lines simultaneously cutting the CF substrate 11 and the TFT substrate 13 into their mid-depths along the portion set in the cutting location setting step using a diamond wheel.

TFT substrate 13 by applying the same scribe line depth and the like enables not only an abridgement of the operation process but also a precise setting job.

[61] The present exemplary embodiment may or may not include the polarized plate stripping step like the first or second exemplary embodiment, and the subsequent steps may proceed in the same sequence as tempering step for the natural crack, cutting step cutting the CF substrate 11 and the TFT substrate 13 and sealing process step .

[62] Meanwhile, when a light from the backlight unit through the TFT-LCD panel 100 processed by the respective exemplary embodiments is illuminated to display a corresponding image, the image may be displayed with an image quality relatively unclear at a portion corresponding to the cutting portion.

[64] Here, the light blocking tape 20 may be attached in a range covering any cut portions of the CF substrate 11 and the TFT substrate 13 or the both substrates 11 and 13 as shown in FIG. 7.

10 bonded above with the CF substrate 11 or at a periphery of the polarized plate 14 bonded below with the TFT substrate 14 which are removed with the set cutting portion, may maximize a clearness of the screen quality when the light from the back light unit is illuminated on the cut portion of the TFT-LCD panel 100 completed by cutting into a desirable size.

[67] Meanwhile, as shown in FIG. 9 of other exemplary embodiment, a transparent tape is used to cover an outer peripheral edge of the CF substrate 11 and the TFT substrate 13 after sealing the outer peripheral edge with an ultraviolet sealant 31 while the CF substrate 11 and the TFT substrate 13 are in bonded state.

[68] Further, though not shown in the drawings, the peripheries of the CF substrate 11 and the TFT substrate 13 may be covered by tape-processing or may be fixed by clipping and the like.

[70] Further, FIG. 10 and FIG. 11 illustrate an application of the TFT-LCD panel according to the cutting method provided by the present invention. FIG. 10 is a brief exploded perspective view of a liquid crystal display unit. FIG. 11 is a brief cross sectional view of FIG. 10.

[71] As shown in FIG. 10 and FIG. 11, the cut processed TFT-LCD panel 100 equipped with the backlight unit (not shown in drawing) below undergoes a series of course coupling a top sash 2 corresponding to an upper frame with an accommodating frame 3 accommodating the TFT-LCD panel 100 and the backlight unit to be used for the liquid crystal display unit.

[72] Here, when the TFT-LCD panel 100 cut processed in a desired size according to the present invention is received in the top sash 2 and the accommodating frame 3, a realization of a clear screen may be difficult since a slight difference may be produced, not accurately fixing the TFT-LCD panel 100, and producing a flowing phenomena because of the internal difference.

[74] Accordingly, in order to prevent the flowing phenomena, that is the flowing phenomena of the received TFT-LCD panel 100, attaching a plurality of both-faces tape 4 at the outer peripheral edge on the top sash 2 surface and attaching a plurality of both-faces tape 4 at the outer peripheral edge on the accommodating frame 3 surface as well is preferable to completely prevent the flowing phenomena.

[76] Therefore, since a large size TFT-LCD panel may be miniaturized for an application to various video games, monitors or cell phone liquid crystal displays through cut processing the large size TFT-LCD panel without a separate manufacturing line for manufacturing process according to present invention, an industrial applicability expecting an effective reduction of manufacturing facility and its value may be recognized.

FIG. 1 is a schematic view of one pixel unit in the TFT-LCD array substrate according to the first embodiment of the present invention. FIG. 2 is a partial cross-sectional view of the TFT along the line 1b-1b in FIG. FIG. 3 is a partial cross-sectional view of the gate line along line 2b-2b of FIG.

As shown in FIGS. 1, 2, and 3, the TFT-LCD array substrate according to the first embodiment of the present invention includes a substrate (for example, a transparent substrate) 21, a gate line 22a formed on the substrate 21, and a gate line 22a. The gate electrode 22b to be connected (or branched therefrom), the first insulating layer 23 formed in the gate line 22a and the gate electrode 22b, the semiconductor layer 24, and the source / drain region of the semiconductor 24 to expose the channel. The formed ohmic contact layer 25, the gate line 22a and the gate electrode 22b, the first insulating layer 23, and the second gate insulating layer formed on the substrate 21 so as to cover the side walls of the semiconductor layer 24 and the ohmic contact layer 25. 26, and a source electrode via hole 27c and a drain electrode via hole formed above the ohmic contact layer of the source region and the drain region, respectively. 27 d, formed in the second insulating layer 26, formed in the second insulating layer 26, the data line 32 contacting the ohmic contact layer 25 in the source region via the source electrode via hole 27 c and the source electrode 27 a connected thereto. The drain electrode 27b that is in contact with the ohmic contact layer 25 in the drain region through the drain electrode via hole 27d, the passivation layer 28 formed on the data line 32, the source electrode 27a, and the drain electrode 27b, and the second insulating layer 26 And a pixel electrode 31 connected to the drain electrode 27b. Here, the gate line 22a and the data line 32 intersect each other to define a pixel region.

FIGS. 4 to 9 show a manufacturing method for manufacturing the TFT-LCD array substrate according to the first embodiment of the present invention by employing four photolithography processes.

A photoresist layer (for example, a positive photoresist, not shown) is applied to the laminate obtained by the process shown in FIG. 4, and this photoresist layer is exposed with a gray-tone mask to form a photoresist layer. An unexposed region of the photoresist, a partially exposed region of the photoresist (ie, a gray tone region), and a photoresist fully exposed region are obtained. The exposed photoresist layer is developed to obtain a gray tone photoresist pattern (not shown). Here, the photoresist layer in the unexposed region of the photoresist is completely left, and a complete photoresist remaining region corresponding to a portion where the gate line and the gate electrode are to be formed on the array substrate is obtained. The photoresist layer in the photoresist partial exposure region is partially left, and a photoresist partial residual region corresponding to a portion where a TFT channel is to be formed on the array substrate is obtained. The photoresist layer in the completely exposed region of the photoresist is completely removed, resulting in a region without photoresist.

複数ステップのドライエッチングが終わった後、フォトレジストのアッシング工程を行い、フォトレジスト部分的残留領域のフォトレジスト層を除去する。アッシングガスとしては、ＳＦ６、Ｏ２又はＳＦ６／Ｏ２混合ガス等を選択すれば良い。これと同時に、フォトレジスト完全残留領域のフォトレジスト層も部分的に除去されるため、厚さが薄くなる。アッシングが終わった後、図６に示すように、フォトレジスト部分的残留領域におけるフォトレジスト層も除去されることによって、形成しようとするＴＦＴチャンネル中のオーミック接触層２５が露出される。そして、下の半導体層２４を露出させるように、ドライエッチング工程によって露出されたオーミック接触層２５をエッチングして除去し、ＴＦＴのチャンネル４０を形成する。エッチングガスとしては、ＳＦ６／Ｃｌ２、又はＳＦ６／ＨＣｌ等のガスを選択すれば良い。チャンネルにおけるオーミック接触層を完全にエッチング除去するために、一般にオーバーエッチング法を取る。After the multi-step dry etching is completed, a photoresist ashing process is performed to remove the photoresist layer in the photoresist partially remaining region. As the ashing gas, SF 6 , O 2, SF 6 / O 2 mixed gas, or the like may be selected. At the same time, the photoresist layer in the photoresist completely remaining region is also partially removed, so that the thickness is reduced. After the ashing is finished, the ohmic contact layer 25 in the TFT channel to be formed is exposed by removing the photoresist layer in the photoresist partially remaining region as shown in FIG. Then, the ohmic contact layer 25 exposed by the dry etching process is removed by etching so that the lower semiconductor layer 24 is exposed, and the TFT channel 40 is formed. As an etching gas, a gas such as SF 6 / Cl 2 or SF 6 / HCl may be selected. In order to completely etch away the ohmic contact layer in the channel, an over-etching method is generally used.

図７に示すように、ＴＦＴのチャンネルが形成された後、残りのフォトレジストパターンを除去し、ＰＥＣＶＤ法によって基板２１の露出面、オーミック接触層２５及び半導体層２４の露出部分に、厚さが約２５００Åである第２の絶縁層２６を堆積する。第２の絶縁層２６は酸化物、窒化物、又は酸窒化物を含んでも良い。ＰＥＣＶＤにおいて対応する反応ガスはＳｉＨ４、ＮＨ３又はＮ２、或いはＳｉＨ２Ｃｌ２、ＮＨ３又はＮ２であっても良い。第２の絶縁層２６はＴＦＴのチャンネルを直接覆うため、ＴＦＴのチャンネルを保護する作用がある。As shown in FIG. 7, after the TFT channel is formed, the remaining photoresist pattern is removed, and the exposed surface of the substrate 21, the ohmic contact layer 25, and the exposed portion of the semiconductor layer 24 have a thickness by PECVD. A second insulating layer 26, which is about 2500 mm, is deposited. The second insulating layer 26 may include oxide, nitride, or oxynitride. The corresponding reaction gas in PECVD may be SiH 4 , NH 3 or N 2 , or SiH 2 Cl 2 , NH 3 or N 2 . Since the second insulating layer 26 directly covers the TFT channel, the second insulating layer 26 has an effect of protecting the TFT channel.

As shown in FIG. 1, after the passivation layer 28 is etched and patterned, the photoresist in the passivation layer is retained, and a transparent pixel electrode material having a thickness of about 400 mm by sputtering or thermal evaporation on the obtained substrate Layer 29 is deposited (see FIGS. 2 and 3). This pixel electrode material layer may contain indium tin oxide (ITO), indium zinc oxide (IZO), or the like. The photoresist is peeled off with the chemical solution, and the transparent conductive material layer in the photoresist is also peeled off to form the pixel electrode 31 (see FIG. 2), thereby completing the manufacture of the TFT-LCD array substrate.
