You can get 40 pin tft lcd display with an operation range that suits your specific application, choosing from a wide selection of suppliers. Source wholesale 40 pin tft lcd display on Alibaba.com for your business and enjoy a wide variety and great deals.

40 pin tft lcd display (Liquid crystal display) are made of liquid crystals that form digital images made visible through ambient light or through LED backlight. LCDs are used in the place of other displays that are less efficient such as cathode ray tubes (CRTs) and have become the most popular display type on the market.

Explore the extensive selection of wholesale 40 pin tft lcd display LCD displays, TFT, and HMI that can be used across a range of industries, including domestic, medical, industrial, automotive, and many others. You can choose from a number of standard industry sizes and find the 40pin tft Lcd display that are applicable to your required use. If you would like options that allow a smaller environmental footprint due to low power consumption, you can browse the Chip-on-Glass (COG) LCDs. COGs are designed without PCBs so have a slimmer profile.

This breakout board is designed to work in conjunction with our TFT displays to give you a faster, more flexible development process. This development tool will jumpstart your workflow by providing an all-in-one solution to run your hardware application and act as an intermediate PCB. With a compact design that allows for easy placement in your application, breakout boards make it easier than ever to connect with any MCU and see your design in action. This particular breakout board has a 40-pin FFC connector, 2.54mm pitch, and is breadboard friendly. It has a configurable LED driver with PWM, a power LED indicator, and open-source hardware.

Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

This 7.0" TFT screen has lots of pixels, 800x480 to be exact, an LED backlight and a resistive touchscreen overlay. Its great for when you need a lot of space for graphics or a user interface. These screens are commonly seen in consumer electronics, such as miniature TV"s, GPS"s, handheld games car displays, etc. A 40-pin connector has 8 red, 8 green, and 8 blue parallel pins, for 24 bit color capability.

For that reason,we are carrying it as a companion to the Adafruit RA8875 driver board in the store, which is a chip that can handle the huge video RAM and timing requirements, all in the background. That"s the best way to interface this display to just about any microcontroller(including Arduino & friends)If you want to control with from an HDMI or DVI output, check out our TFP401 driver board.

This 5.0" TFT screen has lots of pixels, 800x480 to be exact, an LED backlight and a resistive touchscreen overlay. Its great for when you need a lot of space for graphics or a user interface. These screens are commonly seen in consumer electronics, such as miniature TV"s, GPS"s, handheld games car displays, etc. A 40-pin connector has 8 red, 8 green, and 8 blue parallel pins, for 24 bit color capability.

As of October 21, 2022we"ve changed TFT suppliers - the new TFT has the exact same functionality and dimensions. The color and brightness are comparable or better.

The Toradex module provides LCD interface(18/24-bit) which can be used to connect most of the RGB LCDs available in the market. On Apalis/Colibri Evaluation boards or Iris/Ixora/Viola carrier boards, a Unified Display Interface is provided to connect the RGB LCD to the EDT.

We have found the following 40 pin interface which many LCD manufacturers support (pin-outs mentioned below in the table), so we thought of doing an example display adapter board to make it easy for our customers.

NOTE: Generic Display Adapter Board design is just an example, not fully optimized for production. Toradex do not manufacture these boards, but we have given all design data.Also change the over-voltage and current resistors on the display adapter board according to the backlight power requirements of the LCD to connect.

NOTE: Please note that this version of the Generic Display Adapter is only compatible with displays supporting 40 pin standard interface pinout, in which resistivetouch screen signals are also available on the same connector.

Touch section is not compatible to adapter board LCD side 40 Pin connector(X7) due to touch signals not coming to 40 Pin flex cable, but via another four wire flex cable. We have for the same reason given another connector(X10) on adapter board which routes touch signals.
