lcd touch screen pic microcontroller manufacturer

Microchip"s LCD PIC microcontroller family is a Flash-based, power managed family of LCD-enabled microcontrollers. Microchips LCD PIC microcontroller family meets low power design requirements including driving the LCD display in sleep mode while maintaining desired functional features. With the ability to select from an array of available LCD PIC microcontrollers, a designer can provide additional value by creating scalable designs and products. This gives the designer flexibility to offer different solutions based on the demand of varying market segments all from a single design.

Superior optics for use in high ambient light conditions and high accuracy are important characteristics of touch screens used in the medical industry. It is also important that these units are properly sealed to protect against ingress of water, saline, gels, cleaning solutions and other liquids the unit may be exposed to in the healthcare environment. Learn more about the benefits of DawarTouch solutions for the medical industry.

Excessive vibration and high temperatures are just a few of the extreme environmental conditions touch screens used in the military and aerospace industry experience. A ruggedized and durable product is a must in these industries alongside sunlight readability, low reflections and a robust seal to protect against dust, dirt, debris and liquids. Learn more about the benefits of DawarTouch solutions for the military and aerospace industry.

Touch screens used in Instrumentation and industrial type applications need to be reliable, accurate and highly responsive to touch with a bare finger, stylus or a thick work type glove. Durability and impact resistance is also an important feature as often times these applications are in factory or laboratory type environments and experience heavy use. Learn more about the benefits of DawarTouch solutions for the instrumentation/industrial industry.

In-vehicle control touch screens are used in numerous industries from emergency response vehicles to agricultural, construction and warehouse equipment. Many times these environments require a durable, impact resistant, lightweight or portable solution that can be used with finger, thick work glove or stylus. Durability and protection against shock and vibration is also an important feature for this industry. Learn more about the benefits of DawarTouch solutions for the in-vehicle controls industry.

Touch screens used in the POS/Kiosk market need to offer long life expectancy and high endurance for excessive public use. Sunlight readability, quick response and accuracy are other important features often required with these types of applications. Learn more about solutions for the POS/Kiosk industry.

Touch screens used in the marine environment often require custom tuning to eliminate false touch occurrences from contact with salt water. A cover lens, film enhancement or optical bonding process may also be required for improved sunlight readability in these outdoor applications. Learn more about solutions for the marine industry

The new line of 3.5” TFT displays with IPS technology is now available! Three touchscreen options are available: capacitive, resistive, or without a touchscreen.

PIC is a family of microcontroller products made by Microchip Technology. The acronym PIC microcontroller stands for Programmable Interface Controller and more recently Programmable Intelligent Computer. Modern controllers were derived from the PIC1650 which was originally created by General Instruments Microelectronics Division. It was created to offload the I/O (Input/Output) traffic from the CP1600, a 16-bit Central Processing Unit. While it was a decent CPU at the time it had poor performance in handling I/O traffic. From its new product conception and first public availability in 1976 to today an astounding 12 billion units have been sold!

The early models of PIC used ROM which stands for Read Only Memory. This type of memory was used for field-programmable EPROM and could be used for program storage. Some had provisions for erasing memory as well.

Today’s models use Flash memory for program storage. This enables the newer models to reprogram itself if the application calls for it. Newer enhancements including separating program and data memory. Data memory can be utilized as 8, 16 and in the newest models 32 or 64 bit wide. In contrast to the data memory, the program instructions vary by family of PIC and can be 12, 14, 16 or 24 bits long.

The PIC microcontroller hardware spans from 8-pin DIP type chips up to 100-pin SMD. New offerings can have discrete I/O, ADC and DAC along with communication ports such as CAN, UART, USB and I2C.

Many software developers have written tools to support PICs. Among the programmer/debugger hardware tools are MPLAB and PICkit. Most development suites utilize C/C++ compilers. Open source code and development are also available to use.

Many entry level circuits and programming classes in today’s public university and junior college levels utilize the PIC microcontroller as a means for hands on development in both hardware and software projects. They are preferred my teachers in these classes due to low cost, reliability, a large user base and extensive collection of application notes.

The computer you are using now, whether it’s a laptop or a desktop PC, is essentially ran by a microprocessor. A pic microcontroller is similar but on a much smaller scale. While the desktop computer is a “generic purpose computer” capable of running thousands of programs, the pic microcontroller is more of a “special purpose computer”.

PIC Microcontrollers usually have direct contact with the consumer. For a microwave the display’s information is directed to the microcontroller which then turns on the microwave to cook and starts a timer for the timer function. For a TV, the user interacts with the remote control. The microcontroller then receives this data and will adjust the gain for the volume control, video features such as brightness, color, aspect ratio, etc. For the microcontroller, the remote control is the input device and the TV screen is the output device. Another use for a microcontroller is in the engine of your car. It will take information from sensors and use it to adjust fuel mixture and spark plug timing.

A microcontroller is usually embedded. Meaning it is within the device or consumer product being used. This has led to another term for the microcontroller – “embedded controller”. They usually run one program which is stored in ROM and does not change. They are extremely low power as compared to a microprocessor type device. A desktop may consume 50 Watts vs a battery-operated microcontroller which may consume 50 milliwatts or less! Imagine replacing your power bill to 1/1000th!

The architecture of a microcontroller is complex and may contain the following:A CPU(ranging from a 4-bit processor in more simple applications to a newer architecture 64-bit processor for much more complex applications.)

It used to be the choices of microcontrollers were very limited. Hobbyists and professionals picking one for a project had a limited list. Now the choices available have grown exponentially to well over thousands on Allied Electronicsalone.

Currently a hobbyist should choose a current microcontroller which uses flash or EEPROM memory. These can be programmed then erased and programmed again many times. The cost advantage of one-time-only programmable units have decreased considerably. While external memory options are available, they are usually pricey and can add complexity.

Make a list of the peripherals your microcontroller will be required to support. Some of the options supported are: UART, SPI, I2C, USB, Ethernet and CAN are some of the current examples. Finding an option which supports every peripheral narrows the list considerably. Also is this a low power and relatively simple 4 bit application, or will it support 32 or 64 bit instructions?

Memory can range from as little as 256 instructions and 16 bytes of RAM to as much as 8k of instructions. RAM memory in general is scarce in microcontrollers but a lot can be accomplished with 8k of instructions!

Need help with the design of your custom LCD or resistive touch screen? Contact a technical support person at Focus Displays now by filling out the form on the right-hand side of the screen or call us at 480-503-4295.

Touch screens offer ease of use, speed, accuracy, and negate the need to become proficient with a handheld device. General Digital offers the option of equipping your LCD monitor with a variety of touch technologies, such as:

In 1977, we created the world’s first touch responsive industrial terminal, the VuePoint™. It didn’t have a true touch screen; rather, the VuePoint was equipped with a circuit board onto which infrared LEDs were mounted. The LEDs were arranged to form a 12 x 40 grid and when the screen was touched, the infrared beams were broken, indicating the touch location to the terminal. Thus, an operator could control a system right at the terminal.

As touch screen technology evolved (along with monitor technology), we incorporated various touch panels into our LCD monitors, starting with our SlimLine™ series of flip-up LCD monitors. Over time and based on demand, our Saber RackMount, PanelMount and Standalone Series became the next logical candidates for touch integration. This was due to increased use of flat panel technology in human-machine interface applications.

Featuring pure glass construction, Surface Acoustic Wave (SAW) touch screens will almost never physically “wear out” due to a superior scratch-resistant coating. Excellent light transmission ensures that the image clarity of the display remains sharp and vibrant. The stable, “drift-free” operation means that the touch response is always accurate. They work well with a finger, gloved hand or a soft stylus. And SAW touch screens have a sensitive touch response—they recognize the touch location and the amount of pressure applied.

Being an all-glass design, light transmission of surface capacitive touch screens is improved, when compared to resistive touch screens. This improves display viewability and reduces eye fatigue. Featuring a scratch-resistant top coat, durability in heavy-use environments is easily maintained. This type of touch screen is ideally suited for rugged, industrial or military applications.

Infrared touch technology doesn’t rely on an overlay or a substrate to register a touch, so it cannot physically “wear out,” thus ensuring a long product life cycle. Possessing superior optical performance and excellent gasket-sealing properties, an infrared touch screen is ideal for harsh industrial environments and outdoor kiosks. They work with a finger, gloved hand, stylus, and most any object wider than 1/10". They adjust to changing light conditions, even direct sunlight. And they benefit from stable, no-drift calibration performance.

Working in tandem, two optical sensors track the movement of an object close to the surface by detecting the interruption of the touch screen’s infrared light source, which is emitted in a plane across the display surface and can be either active (infrared LED) or passive (special reflective surfaces).

Optical touch screens use a controller board that receives signals from the optical sensors, then compensates for optical distortions and triangulates the position of the touching object with extreme accuracy.

The infrared light source and optical sensors of the touch screen are synchronized using a sophisticated algorithm that also reduces the effect of ambient light, thus creating a very clear, accurate touch selection.

Developed specifically for interactive digital signage applications, Dispersive Signal Technology determines a touch point by measuring the mechanical energy (bending waves) within a substrate created by the pressure of a finger or stylus. As these bending waves radiate away from the touch location, the signal spreads out over time due to the phenomena of dispersion. The “smeared” signals are then interpreted by a complex set of algorithms to precisely pinpoint the exact touch location on the screen.

DST is a passive technology, waiting for a signal created by a touch impact. Therefore, contaminants such as dirt, grease, and other solids can accumulate on the surface and edges of the display screen without significantly affecting touch responsiveness. In addition, surface damage, such as scratches, has no significant impact on touch performance.

The sophisticated and optimized controller that continuously monitors for a touch impact is the fastest and most responsive technology available for large format displays, offering greater than 99% touch location accuracy.

Digital View’s SVX-1920v3 is a full featured LCD controller that is a suitable fit for an extensive range of professional display applications. This is an advanced LCD controller that is ideal for use with high resolution

Digital View"s ALR-1400v2 is a multi-purpose LCD controller that was designed for industrial LCD monitors and can be used for a number of industrial and commercial display applications. Features: ∙ Compact Design ∙

Digital View’s ALR-1920-120 is a multi-purpose LCD controller board with a comprehensive selection of built-in features and control options. This solution is compatible with 120Hz panels with up to 1920x1200 resolution.

Digital View’s SVH-1920v2 LCD controller is the updated replacement for the SVH-1920. This newer version includes the same signal inputs and mountings as the original with the addition of an eDP panel connection and increased

Digital View’s HE-1920v2 is the replacement for the HE-1920. It is a harsh environment LCD controller with ceramic capacitors and unmatched durability. The HE-1920v2 has a conformal coating layer that preserves the components

The HLR-1920 by Digital View is a compact, wide temperature LCD controller great for general purpose solutions. It is compatible with LCD panels up to 1920x1200 resolution. The HLR-1920 features low signal latency from input

Digital View’s SVX-2560 is an advanced LVDS and eDP panel LCD controller. It works with LCD panel resolutions up to 2560x1600 and 1920x1920 and is compatible with video signals up to 2560x1600. Features: ∙ LCD

Digital View"s SVX-4096 is an advanced LCD controller ideal for 4K LCDs. It is compatible with LCD and OLED panel resolutions up to 4096x2160 and video signals up to 4096x2160. Because it is a 4K LCD controller, it is an ideal

The Digital View HX-4096 is a harsh environment 4k LCD controller. It supports video signals up to 4096 x 2160 and LCD panel resolutions up to 4096 x 2160. Because of its conformal coating and extended temperature range,

Digital View’s HSP-1920 is the durable, harsh environment version of the SP-1920 LCD controller. It is supports input and panel activity for video signals up to 1920x1200. The built-in H.246 failover media player makes

Digital View’s ALT-1920 is a compact, general solution LCD controller that covers three popular input formats including HDMI, Analog RGB (VGA), and DisplayPort. It is equipped with ceramic capacitors for improved reliability

The Digital View SP-4096 is an easy-to-use controller board for 4k LCDs. It supports LCD panels and video output of up to 4096 x 2160 resolution. Because of its high resolution and excellent reliability, this 4k LCD controller

The Digital View HSP-4096 is the harsh environment version of the SP-4096 and includes a conformal coating that provides increased resistance to the elements. It supports video signals up to 4096 x 2160 and LCD panel resolutions

The Digital View SVX-4096-120 is an advanced controller board that can support both LCD and OLED panels up to 4096 x 2160 resolution. Because of its super high resolution, this 4k controller board is ideal for commercial

The Digital View DT-4096 is a compact and easy-to-use controller board that supports LCD panels up to 4096 x 2160 resolution. Because of its extensive image control options and super high resolution, this 4k controller

A lot goes into the design of quality electronics regardless of the intended application. Akey componentof embedded systems in electronics is the microcontroller. While diverse, an electronic designer needs to settle for a microcontroller type that suits their electronic needs. PIC microcontrollers are one such type.

PIC microcontrollersare programmable and the world’s tiniest. It is capable of carrying out a diverse task range. Therefore, you will find them in alarm systems, computer control systems, phones, alarm systems, etc. Understanding the diverse types of PIC microcontrollers informs the design process and programming of PIC microcontrollers. Want to learn more? Continue reading.

PIC microcontrollers, alternatively inferred asprogrammable interface controllers, came to the fore in 1993. Primarily designed and developed to support PDP computers in controlling their auxiliary devices, it currently has an expanded scope.

The PIC microcontrollers are based on Harvard architecture, which makes them popular. It stems from the ease in which it can get programmed,low cost, wide availability, and a simple interfacing capability with other auxiliary components. Additionally, it possesses a huge user base besides capacity for serial programming.

As anintegrated chip, a PIC microcontroller consists of a ROM, RAM, timers, CPU, and counters that support protocols like CAN, UART, and SPI for interfacing purposes. It also has flash memory, I/O ports, EEPROM, UART, SSP, ADC, and PSP besides ICSPand LCD. Such components form a fundamental aspect of the PIC microcontroller architecture.

The architecture of the PIC microcontroller defines its functionality. Besides considering the four classifications of the PIC microcontroller that rely on the internal architecture, understanding the different PIC microcontrollers’ types becomes ideal before the design process. Classifications include baseline PIC, enhanced mid-range PIC, mid-range PIC, and PIC18.

PIC microcontrollers also need programming to tailor them to their specific applications. As a designer, you need to factor in the PIC microcontroller programming software to deploy before development. It allows for its proper functioning upon completion. In most instances, the typical programming language often features the embedded C language. Let us now look into the architecture and programming process of the PIC microcontroller.

It only becomes possible to design and program a PIC microcontroller after understanding its architecture. The architecture entails I/O ports, CPU, A/D converter, interrupts, oscillator, counters/timers, memory organization CPP module, and serial communication.

It is similar to other microcontroller CPUs. It has a CU, AC, ALU, accumulator, and MU, among other components. Every aspect has its use. For instance, a control unit (CU) controls everything connected to the CPU. An arithmeticlogic unit (ALU) carries out arithmetic operations besides undertaking logical decisions. A memory unit (MU) stores instructions, etc.

The MU or memory organization module consists of ROM, RAM, and STACK. RAM comes unstable and stores data momentarily in its registers. RAM registers get classified either as general-purpose (GPR) or special function registers (SFR). On the other hand, ROM stores data permanently and, for a microcontroller case, the program. It all functions through the execution of instructions by the CPU. EEPROM allows for programming of the ROM numerous times instead of what happens in a typicalread-only memory (ROM). Flash memory is also PROM and thus can write, read, and erase programs multiple times. Lastly, STACK stores and executes the information from the completion of the interrupt execution.

All PIC16 contain five ports, including Port A, B, C, D, and E. Port A is a 16-bit port for output and input based on the TRISA register. The next is Port B, which comes as an 8-bit port for output or input functions, while Port C is similar to Port B but with its operation specified by the TRISC register. Port D acts as the slave port for Bus connection, while Port E comes as a 3-bit port that controls the digital or analog converter signals.

PIC microcontrollers have four counters/timers, whereas the 8-bit timer or the rest can accommodate eight or sixteen-bit mode, depending on your choice. It generates accuracy actions such as particular time delays among two operations.

PIC microcontrollers always require a PIC programmer, especially when building a PIC microcontroller project. Programming comes by way of an embedded C language, and as such, a designer needs to familiarizing with all these aspects before building their PIC controller project. But what does it all entail?

Before getting started on the PIC microcontroller programming front, it is crucial to understand how a standard microcontroller gets developed. However, the underlying considerations entail picking an ideal project for the microcontroller program, such as an LED flash system. Designing the circuit also becomes vital. Here, aspects such as circuit components, diagrams, and connections come into consideration.

The programming of PIC microcontrollers often gets carried out through the “MP-Lab” software. It requires installation before proceeding to install the compiler. Compilers include GCC compiler, CCS compiler, etc. After completion of the installation process, all you need is to follow the process below.

Pick a suitable compiler based on your needs besides your project’s location path. You can pick the CCS or the GCC compiler depending on your PIC microcontroller needs. After that, choose the browse option then the “ccsloader” within the PICC folder from the program files. At this point, a source group folder gets created in the intended folder.

At this stage, it becomes vital to assign the appropriate name to your project before clicking “Next” to save the project. Within the target folder, a source group folder gets created, which you select the file menu and pick the new file from the drop-down list.

After coming up with the PIC microcontroller code, you have to load it into the microcontroller in a process inferred as dumping. Microcontrollers solely comprehend the machine-level language featuring 0’s and 1’s. As such, the dumping process requires specific code loading software.

It is crucial to select and install your preferred software program from many options in the market. Additionally, the PIC programmer kit will come complete with a hardware kit. Plug the PIC microcontroller into the hardware kit and follow the process below to dump the code into the PIC microcontroller.

Plenty of PIC microcontrollers exist in the market. It is, therefore, always difficult to settle on the correct PIC microcontroller type and size when talking to your PCB or circuit assembly company. However, based on your need, we at RayMing PCB and Assembly will advise you accordingly. What’s more? You will get top-rate quality assembly services for your PIC microcontroller at reasonable prices.

The PIC16f877a/PIC16f877 has a simple programming process besides convenience when it comes to using. Because of this, it proves a popular microcontroller option within the industry. It comes either 8-bit or 16-bit and has a flash memory tech allowing for numerous write-erase processes. While ideal because the total amount of pins (40 in total and 33 for output and input) mainly applies in digital electronic circuits and PIC microcontroller projects. It is instrumental in home automation devices and systems, industrial instruments, remote sensors, and safety and security devices.

It comes as an 8-bit CMOS microcontroller developed on high-performance RISC architecture. The PIC12f675 is small in size and cost-effective, thus proves popular among engineers and hobbyists. The design is perfect for low-end systems and applications because of its 2Kbytesflash memory. It also contains 6 GPIO pins that can handle not more than 25mA of current, meeting the threshold of many sensors and peripheral devices.

It is a renowned and the most utilized PIC microcontroller type based on its pioneering stature. The PIC16f84 comes as an 8-bit mid-range microcontroller with a 1024 word program memory. It also has a RAM of 68bytes and a lasting EPROM storage of 64bytes. The striking factor about PIC 16f84 is that it can get reprogrammed using thein-circuit ICSP.

It is an 8-bit flash-based CMOS microcontroller that is simple to program. The PIC microcontroller packs the powerful PIC® MCU architecture within the 8-pin package. It has various features that make it popular, such as the one-channel comparator besides the 128byte EEPROM. It is ideal for application in industrial, automotive, and consumer electronics.

It is a powerful and simple-to-program PIC microcontroller that is based on the CMOS flash-based 8-bit PIC microcontroller. Additionally, it packs the PIC® architecture within the 28-pin package. PIC16f886 possesses a 256byte EEPROM, is self-programming, and has two comparators, among other vital features. It makes it a popular choice for applications in sectors like industrial, automotive, consumer and appliances.

The popular PIC microcontroller mainly gets deployed in embeddedand automation systems. It comes as either TQFP, PDIP, or QFN. The PDIP has 40 pins, while the rest contains a 44-pin interface. It contains a 10-bit ADC, a 256byte EEPROM data memory, and a RAM of 1536 bytes.

It comes as a popular 8-bit PIC microcontroller and comes with an improved NanoWatt technology and flash processor. The PIC microcontroller has three distinctive packages in SSOP, PDIP, and QFN. The SSOP has a 20 pin package, while the PDIP and QFN have 18 pin and 28 pin packages, respectively.

It is a powerful and simple-to-program CMOS and flash-based 8-bit PIC microcontroller. The PIC16f676 packs the powerful PIC® MCU architecture within the 14-pin package. It is a 10-bit A/D converter complete with eight channels, a single comparator, besides an EEPROM data memory. It has applications in industrial, automotive, consumer, and appliance entry-level products, especially those requiring field re-programmability.

The 8-pin flash-based CMOS PIC microcontroller comes with a nanoWatt tech. It offers benefits associated with the mid-range x14 architecture, including standardized features. Such features make it a popular PIC microcontroller option for automotive and industrial applications.

The popular and powerful PIC microcontroller comes as an 8-bit CMPS FLASH-based microcontroller type. It contains 34 I/O pins and comes with one 16-bit and 8-bit timer, 10-bit A/D converter, SPI, I2C, and USART peripherals.

It is a popular and relatively new PIC microcontroller type that cannot work on older device models. The PIC16f628 is based on the FLASH program memory of 3.5, 2 comparators, and a single CCP. What makes it an excellent option entails low voltage programming, programmable BOR, on-chip voltage reference, and other features.

The 8-bit PIC microcontroller from Microchip comes with a 20-pin interface. It incorporates the high-performance RISC CPU that assists in the execution of instructions. The microprocessor also has a crystal oscillator of 20MHz for interfacing purposes and the creation of clock pulses.

The popular PIC microcontroller comes with a FLASH memory of 32KB and proves compatible with PIC17 and PIC16 instruction sets. It uses advanced CAN technology and applies to the automotive and industrial sectors.

The PIC microcontroller comes optimized and equipped with the RISC architecture. It operates on flash memory and has a CPU speed of 10 DMIPS/MIPS, making it a toast for some people. Its maximum ADC is 10 bits with a CCP of 1.

The popular PIC microcontroller comes as a high-performance, low-cost, and 8-bit static microcontroller. It uses flash CMO technology with a total of 8 pins. It also possesses a DRT (device reset timer) that eliminates any requirement for external reset circuitry.

It is always vital to understand everything about PIC microcontrollers, including the diverse types, program them, etc. Such information becomes useful in designing integrated circuits and electronics as a whole. Therefore, consider all insights about the intricacies of the diverse PIC microcontrollers to stay ahead of your design game.

Glass substrate with ITO electrodes. The shapes of these electrodes will determine the shapes that will appear when the LCD is switched ON. Vertical ridges etched on the surface are smooth.

A liquid-crystal display (LCD) is a flat-panel display or other electronically modulated optical device that uses the light-modulating properties of liquid crystals combined with polarizers. Liquid crystals do not emit light directlybacklight or reflector to produce images in color or monochrome.seven-segment displays, as in a digital clock, are all good examples of devices with these displays. They use the same basic technology, except that arbitrary images are made from a matrix of small pixels, while other displays have larger elements. LCDs can either be normally on (positive) or off (negative), depending on the polarizer arrangement. For example, a character positive LCD with a backlight will have black lettering on a background that is the color of the backlight, and a character negative LCD will have a black background with the letters being of the same color as the backlight. Optical filters are added to white on blue LCDs to give them their characteristic appearance.

LCDs are used in a wide range of applications, including LCD televisions, computer monitors, instrument panels, aircraft cockpit displays, and indoor and outdoor signage. Small LCD screens are common in LCD projectors and portable consumer devices such as digital cameras, watches, digital clocks, calculators, and mobile telephones, including smartphones. LCD screens are also used on consumer electronics products such as DVD players, video game devices and clocks. LCD screens have replaced heavy, bulky cathode-ray tube (CRT) displays in nearly all applications. LCD screens are available in a wider range of screen sizes than CRT and plasma displays, with LCD screens available in sizes ranging from tiny digital watches to very large television receivers. LCDs are slowly being replaced by OLEDs, which can be easily made into different shapes, and have a lower response time, wider color gamut, virtually infinite color contrast and viewing angles, lower weight for a given display size and a slimmer profile (because OLEDs use a single glass or plastic panel whereas LCDs use two glass panels; the thickness of the panels increases with size but the increase is more noticeable on LCDs) and potentially lower power consumption (as the display is only "on" where needed and there is no backlight). OLEDs, however, are more expensive for a given display size due to the very expensive electroluminescent materials or phosphors that they use. Also due to the use of phosphors, OLEDs suffer from screen burn-in and there is currently no way to recycle OLED displays, whereas LCD panels can be recycled, although the technology required to recycle LCDs is not yet widespread. Attempts to maintain the competitiveness of LCDs are quantum dot displays, marketed as SUHD, QLED or Triluminos, which are displays with blue LED backlighting and a Quantum-dot enhancement film (QDEF) that converts part of the blue light into red and green, offering similar performance to an OLED display at a lower price, but the quantum dot layer that gives these displays their characteristics can not yet be recycled.

Since LCD screens do not use phosphors, they rarely suffer image burn-in when a static image is displayed on a screen for a long time, e.g., the table frame for an airline flight schedule on an indoor sign. LCDs are, however, susceptible to image persistence.battery-powered electronic equipment more efficiently than a CRT can be. By 2008, annual sales of televisions with LCD screens exceeded sales of CRT units worldwide, and the CRT became obsolete for most purposes.

Each pixel of an LCD typically consists of a layer of molecules aligned between two transparent electrodes, often made of Indium-Tin oxide (ITO) and two polarizing filters (parallel and perpendicular polarizers), the axes of transmission of which are (in most of the cases) perpendicular to each other. Without the liquid crystal between the polarizing filters, light passing through the first filter would be blocked by the second (crossed) polarizer. Before an electric field is applied, the orientation of the liquid-crystal molecules is determined by the alignment at the surfaces of electrodes. In a twisted nematic (TN) device, the surface alignment directions at the two electrodes are perpendicular to each other, and so the molecules arrange themselves in a helical structure, or twist. This induces the rotation of the polarization of the incident light, and the device appears gray. If the applied voltage is large enough, the liquid crystal molecules in the center of the layer are almost completely untwisted and the polarization of the incident light is not rotated as it passes through the liquid crystal layer. This light will then be mainly polarized perpendicular to the second filter, and thus be blocked and the pixel will appear black. By controlling the voltage applied across the liquid crystal layer in each pixel, light can be allowed to pass through in varying amounts thus constituting different levels of gray.

The chemical formula of the liquid crystals used in LCDs may vary. Formulas may be patented.Sharp Corporation. The patent that covered that specific mixture expired.

Most color LCD systems use the same technique, with color filters used to generate red, green, and blue subpixels. The LCD color filters are made with a photolithography process on large glass sheets that are later glued with other glass sheets containing a TFT array, spacers and liquid crystal, creating several color LCDs that are then cut from one another and laminated with polarizer sheets. Red, green, blue and black photoresists (resists) are used. All resists contain a finely ground powdered pigment, with particles being just 40 nanometers across. The black resist is the first to be applied; this will create a black grid (known in the industry as a black matrix) that will separate red, green and blue subpixels from one another, increasing contrast ratios and preventing light from leaking from one subpixel onto other surrounding subpixels.Super-twisted nematic LCD, where the variable twist between tighter-spaced plates causes a varying double refraction birefringence, thus changing the hue.

LCD in a Texas Instruments calculator with top polarizer removed from device and placed on top, such that the top and bottom polarizers are perpendicular. As a result, the colors are inverted.

The optical effect of a TN device in the voltage-on state is far less dependent on variations in the device thickness than that in the voltage-off state. Because of this, TN displays with low information content and no backlighting are usually operated between crossed polarizers such that they appear bright with no voltage (the eye is much more sensitive to variations in the dark state than the bright state). As most of 2010-era LCDs are used in television sets, monitors and smartphones, they have high-resolution matrix arrays of pixels to display arbitrary images using backlighting with a dark background. When no image is displayed, different arrangements are used. For this purpose, TN LCDs are operated between parallel polarizers, whereas IPS LCDs feature crossed polarizers. In many applications IPS LCDs have replaced TN LCDs, particularly in smartphones. Both the liquid crystal material and the alignment layer material contain ionic compounds. If an electric field of one particular polarity is applied for a long period of time, this ionic material is attracted to the surfaces and degrades the device performance. This is avoided either by applying an alternating current or by reversing the polarity of the electric field as the device is addressed (the response of the liquid crystal layer is identical, regardless of the polarity of the applied field).

Displays for a small number of individual digits or fixed symbols (as in digital watches and pocket calculators) can be implemented with independent electrodes for each segment.alphanumeric or variable graphics displays are usually implemented with pixels arranged as a matrix consisting of electrically connected rows on one side of the LC layer and columns on the other side, which makes it possible to address each pixel at the intersections. The general method of matrix addressing consists of sequentially addressing one side of the matrix, for example by selecting the rows one-by-one and applying the picture information on the other side at the columns row-by-row. For details on the various matrix addressing schemes see passive-matrix and active-matrix addressed LCDs.

LCDs, along with OLED displays, are manufactured in cleanrooms borrowing techniques from semiconductor manufacturing and using large sheets of glass whose size has increased over time. Several displays are manufactured at the same time, and then cut from the sheet of glass, also known as the mother glass or LCD glass substrate. The increase in size allows more displays or larger displays to be made, just like with increasing wafer sizes in semiconductor manufacturing. The glass sizes are as follows:

Until Gen 8, manufacturers would not agree on a single mother glass size and as a result, different manufacturers would use slightly different glass sizes for the same generation. Some manufacturers have adopted Gen 8.6 mother glass sheets which are only slightly larger than Gen 8.5, allowing for more 50 and 58 inch LCDs to be made per mother glass, specially 58 inch LCDs, in which case 6 can be produced on a Gen 8.6 mother glass vs only 3 on a Gen 8.5 mother glass, significantly reducing waste.AGC Inc., Corning Inc., and Nippon Electric Glass.

In 1922, Georges Friedel described the structure and properties of liquid crystals and classified them in three types (nematics, smectics and cholesterics). In 1927, Vsevolod Frederiks devised the electrically switched light valve, called the Fréedericksz transition, the essential effect of all LCD technology. In 1936, the Marconi Wireless Telegraph company patented the first practical application of the technology, "The Liquid Crystal Light Valve". In 1962, the first major English language publication Molecular Structure and Properties of Liquid Crystals was published by Dr. George W. Gray.RCA found that liquid crystals had some interesting electro-optic characteristics and he realized an electro-optical effect by generating stripe-patterns in a thin layer of liquid crystal material by the application of a voltage. This effect is based on an electro-hydrodynamic instability forming what are now called "Williams domains" inside the liquid crystal.

In 1964, George H. Heilmeier, then working at the RCA laboratories on the effect discovered by Williams achieved the switching of colors by field-induced realignment of dichroic dyes in a homeotropically oriented liquid crystal. Practical problems with this new electro-optical effect made Heilmeier continue to work on scattering effects in liquid crystals and finally the achievement of the first operational liquid-crystal display based on what he called the George H. Heilmeier was inducted in the National Inventors Hall of FameIEEE Milestone.

In the late 1960s, pioneering work on liquid crystals was undertaken by the UK"s Royal Radar Establishment at Malvern, England. The team at RRE supported ongoing work by George William Gray and his team at the University of Hull who ultimately discovered the cyanobiphenyl liquid crystals, which had correct stability and temperature properties for application in LCDs.

The idea of a TFT-based liquid-crystal display (LCD) was conceived by Bernard Lechner of RCA Laboratories in 1968.dynamic scattering mode (DSM) LCD that used standard discrete MOSFETs.

On December 4, 1970, the twisted nematic field effect (TN) in liquid crystals was filed for patent by Hoffmann-LaRoche in Switzerland, (Swiss patent No. 532 261) with Wolfgang Helfrich and Martin Schadt (then working for the Central Research Laboratories) listed as inventors.Brown, Boveri & Cie, its joint venture partner at that time, which produced TN displays for wristwatches and other applications during the 1970s for the international markets including the Japanese electronics industry, which soon produced the first digital quartz wristwatches with TN-LCDs and numerous other products. James Fergason, while working with Sardari Arora and Alfred Saupe at Kent State University Liquid Crystal Institute, filed an identical patent in the United States on April 22, 1971.ILIXCO (now LXD Incorporated), produced LCDs based on the TN-effect, which soon superseded the poor-quality DSM types due to improvements of lower operating voltages and lower power consumption. Tetsuro Hama and Izuhiko Nishimura of Seiko received a US patent dated February 1971, for an electronic wristwatch incorporating a TN-LCD.

In 1972, the concept of the active-matrix thin-film transistor (TFT) liquid-crystal display panel was prototyped in the United States by T. Peter Brody"s team at Westinghouse, in Pittsburgh, Pennsylvania.Westinghouse Research Laboratories demonstrated the first thin-film-transistor liquid-crystal display (TFT LCD).high-resolution and high-quality electronic visual display devices use TFT-based active matrix displays.active-matrix liquid-crystal display (AM LCD) in 1974, and then Brody coined the term "active matrix" in 1975.

In 1972 North American Rockwell Microelectronics Corp introduced the use of DSM LCDs for calculators for marketing by Lloyds Electronics Inc, though these required an internal light source for illumination.Sharp Corporation followed with DSM LCDs for pocket-sized calculators in 1973Seiko and its first 6-digit TN-LCD quartz wristwatch, and Casio"s "Casiotron". Color LCDs based on Guest-Host interaction were invented by a team at RCA in 1968.TFT LCDs similar to the prototypes developed by a Westinghouse team in 1972 were patented in 1976 by a team at Sharp consisting of Fumiaki Funada, Masataka Matsuura, and Tomio Wada,

In 1983, researchers at Brown, Boveri & Cie (BBC) Research Center, Switzerland, invented the passive matrix-addressed LCDs. H. Amstutz et al. were listed as inventors in the corresponding patent applications filed in Switzerland on July 7, 1983, and October 28, 1983. Patents were granted in Switzerland CH 665491, Europe EP 0131216,

The first color LCD televisions were developed as handheld televisions in Japan. In 1980, Hattori Seiko"s R&D group began development on color LCD pocket televisions.Seiko Epson released the first LCD television, the Epson TV Watch, a wristwatch equipped with a small active-matrix LCD television.dot matrix TN-LCD in 1983.Citizen Watch,TFT LCD.computer monitors and LCD televisions.3LCD projection technology in the 1980s, and licensed it for use in projectors in 1988.compact, full-color LCD projector.

In 1990, under different titles, inventors conceived electro optical effects as alternatives to twisted nematic field effect LCDs (TN- and STN- LCDs). One approach was to use interdigital electrodes on one glass substrate only to produce an electric field essentially parallel to the glass substrates.Germany by Guenter Baur et al. and patented in various countries.Hitachi work out various practical details of the IPS technology to interconnect the thin-film transistor array as a matrix and to avoid undesirable stray fields in between pixels.

Hitachi also improved the viewing angle dependence further by optimizing the shape of the electrodes (Super IPS). NEC and Hitachi become early manufacturers of active-matrix addressed LCDs based on the IPS technology. This is a milestone for implementing large-screen LCDs having acceptable visual performance for flat-panel computer monitors and television screens. In 1996, Samsung developed the optical patterning technique that enables multi-domain LCD. Multi-domain and In Plane Switching subsequently remain the dominant LCD designs through 2006.South Korea and Taiwan,

In 2007 the image quality of LCD televisions surpassed the image quality of cathode-ray-tube-based (CRT) TVs.LCD TVs were projected to account 50% of the 200 million TVs to be shipped globally in 2006, according to Displaybank.Toshiba announced 2560 × 1600 pixels on a 6.1-inch (155 mm) LCD panel, suitable for use in a tablet computer,transparent and flexible, but they cannot emit light without a backlight like OLED and microLED, which are other technologies that can also be made flexible and transparent.

In 2016, Panasonic developed IPS LCDs with a contrast ratio of 1,000,000:1, rivaling OLEDs. This technology was later put into mass production as dual layer, dual panel or LMCL (Light Modulating Cell Layer) LCDs. The technology uses 2 liquid crystal layers instead of one, and may be used along with a mini-LED backlight and quantum dot sheets.

Since LCDs produce no light of their own, they require external light to produce a visible image.backlight. Active-matrix LCDs are almost always backlit.Transflective LCDs combine the features of a backlit transmissive display and a reflective display.

CCFL: The LCD panel is lit either by two cold cathode fluorescent lamps placed at opposite edges of the display or an array of parallel CCFLs behind larger displays. A diffuser (made of PMMA acrylic plastic, also known as a wave or light guide/guiding plateinverter to convert whatever DC voltage the device uses (usually 5 or 12 V) to ≈1000 V needed to light a CCFL.

EL-WLED: The LCD panel is lit by a row of white LEDs placed at one or more edges of the screen. A light diffuser (light guide plate, LGP) is then used to spread the light evenly across the whole display, similarly to edge-lit CCFL LCD backlights. The diffuser is made out of either PMMA plastic or special glass, PMMA is used in most cases because it is rugged, while special glass is used when the thickness of the LCD is of primary concern, because it doesn"t expand as much when heated or exposed to moisture, which allows LCDs to be just 5mm thick. Quantum dots may be placed on top of the diffuser as a quantum dot enhancement film (QDEF, in which case they need a layer to be protected from heat and humidity) or on the color filter of the LCD, replacing the resists that are normally used.

WLED array: The LCD panel is lit by a full array of white LEDs placed behind a diffuser behind the panel. LCDs that use this implementation will usually have the ability to dim or completely turn off the LEDs in the dark areas of the image being displayed, effectively increasing the contrast ratio of the display. The precision with which this can be done will depend on the number of dimming zones of the display. The more dimming zones, the more precise the dimming, with less obvious blooming artifacts which are visible as dark grey patches surrounded by the unlit areas of the LCD. As of 2012, this design gets most of its use from upscale, larger-screen LCD televisions.

RGB-LED array: Similar to the WLED array, except the panel is lit by a full array of RGB LEDs. While displays lit with white LEDs usually have a poorer color gamut than CCFL lit displays, panels lit with RGB LEDs have very wide color gamuts. This implementation is most popular on professional graphics editing LCDs. As of 2012, LCDs in this category usually cost more than $1000. As of 2016 the cost of this category has drastically reduced and such LCD televisions obtained same price levels as the former 28" (71 cm) CRT based categories.

Monochrome LEDs: such as red, green, yellow or blue LEDs are used in the small passive monochrome LCDs typically used in clocks, watches and small appliances.

Today, most LCD screens are being designed with an LED backlight instead of the traditional CCFL backlight, while that backlight is dynamically controlled with the video information (dynamic backlight control). The combination with the dynamic backlight control, invented by Philips researchers Douglas Stanton, Martinus Stroomer and Adrianus de Vaan, simultaneously increases the dynamic range of the display system (also marketed as HDR, high dynamic range television or FLAD, full-area local area dimming).

The LCD backlight systems are made highly efficient by applying optical films such as prismatic structure (prism sheet) to gain the light into the desired viewer directions and reflective polarizing films that recycle the polarized light that was formerly absorbed by the first polarizer of the LCD (invented by Philips researchers Adrianus de Vaan and Paulus Schaareman),

Due to the LCD layer that generates the desired high resolution images at flashing video speeds using very low power electronics in combination with LED based backlight technologies, LCD technology has become the dominant display technology for products such as televisions, desktop monitors, notebooks, tablets, smartphones and mobile phones. Although competing OLED technology is pushed to the market, such OLED displays do not feature the HDR capabilities like LCDs in combination with 2D LED backlight technologies have, reason why the annual market of such LCD-based products is still growing faster (in volume) than OLED-based products while the efficiency of LCDs (and products like portable computers, mobile phones and televisions) may even be further improved by preventing the light to be absorbed in the colour filters of the LCD.

A pink elastomeric connector mating an LCD panel to circuit board traces, shown next to a centimeter-scale ruler. The conductive and insulating layers in the black stripe are very small.

A standard television receiver screen, a modern LCD panel, has over six million pixels, and they are all individually powered by a wire network embedded in the screen. The fine wires, or pathways, form a grid with vertical wires across the whole screen on one side of the screen and horizontal wires across the whole screen on the other side of the screen. To this grid each pixel has a positive connection on one side and a negative connection on the other side. So the total amount of wires needed for a 1080p display is 3 x 1920 going vertically and 1080 going horizontally for a total of 6840 wires horizontally and vertically. That"s three for red, green and blue and 1920 columns of pixels for each color for a total of 5760 wires going vertically and 1080 rows of wires going horizontally. For a panel that is 28.8 inches (73 centimeters) wide, that means a wire density of 200 wires per inch along the horizontal edge.

The LCD panel is powered by LCD drivers that are carefully matched up with the edge of the LCD panel at the factory level. The drivers may be installed using several methods, the most common of which are COG (Chip-On-Glass) and TAB (Tape-automated bonding) These same principles apply also for smartphone screens that are much smaller than TV screens.anisotropic conductive film or, for lower densities, elastomeric connectors.

Monochrome and later color passive-matrix LCDs were standard in most early laptops (although a few used plasma displaysGame Boyactive-matrix became standard on all laptops. The commercially unsuccessful Macintosh Portable (released in 1989) was one of the first to use an active-matrix display (though still monochrome). Passive-matrix LCDs are still used in the 2010s for applications less demanding than laptop computers and TVs, such as inexpensive calculators. In particular, these are used on portable devices where less information content needs to be displayed, lowest power consumption (no backlight) and low cost are desired or readability in direct sunlight is needed.

A comparison between a blank passive-matrix display (top) and a blank active-matrix display (bottom). A passive-matrix display can be identified when the blank background is more grey in appearance than the crisper active-matrix display, fog appears on all edges of the screen, and while pictures appear to be fading on the screen.

STN LCDs have to be continuously refreshed by alternating pulsed voltages of one polarity during one frame and pulses of opposite polarity during the next frame. Individual pixels are addressed by the corresponding row and column circuits. This type of display is called response times and poor contrast are typical of passive-matrix addressed LCDs with too many pixels and driven according to the "Alt & Pleshko" drive scheme. Welzen and de Vaan also invented a non RMS drive scheme enabling to drive STN displays with video rates and enabling to show smooth moving video images on an STN display.

Bistable LCDs do not require continuous refreshing. Rewriting is only required for picture information changes. In 1984 HA van Sprang and AJSM de Vaan invented an STN type display that could be operated in a bistable mode, enabling extremely high resolution images up to 4000 lines or more using only low voltages.

High-resolution color displays, such as modern LCD computer monitors and televisions, use an active-matrix structure. A matrix of thin-film transistors (TFTs) is added to the electrodes in contact with the LC layer. Each pixel has its own dedicated transistor, allowing each column line to access one pixel. When a row line is selected, all of the column lines are connected to a row of pixels and voltages corresponding to the picture information are driven onto all of the column lines. The row line is then deactivated and the next row line is selected. All of the row lines are selected in sequence during a refresh operation. Active-matrix addressed displays look brighter and sharper than passive-matrix addressed displays of the same size, and generally have quicker response times, producing much better images. Sharp produces bistable reflective LCDs with a 1-bit SRAM cell per pixel that only requires small amounts of power to maintain an image.

Segment LCDs can also have color by using Field Sequential Color (FSC LCD). This kind of displays have a high speed passive segment LCD panel with an RGB backlight. The backlight quickly changes color, making it appear white to the naked eye. The LCD panel is synchronized with the backlight. For example, to make a segment appear red, the segment is only turned ON when the backlight is red, and to make a segment appear magenta, the segment is turned ON when the backlight is blue, and it continues to be ON while the backlight becomes red, and it turns OFF when the backlight becomes green. To make a segment appear black, the segment is always turned ON. An FSC LCD divides a color image into 3 images (one Red, one Green and one Blue) and it displays them in order. Due to persistence of vision, the 3 monochromatic images appear as one color image. An FSC LCD needs an LCD panel with a refresh rate of 180 Hz, and the response time is reduced to just 5 milliseconds when compared with normal STN LCD panels which have a response time of 16 milliseconds.

Samsung introduced UFB (Ultra Fine & Bright) displays back in 2002, utilized the super-birefringent effect. It has the luminance, color gamut, and most of the contrast of a TFT-LCD, but only consumes as much power as an STN display, according to Samsung. It was being used in a variety of Samsung cellular-telephone models produced until late 2006, when Samsung stopped producing UFB displays. UFB displays were also used in certain models of LG mobile phones.

In-plane switching is an LCD technology that aligns the liquid crystals in a plane parallel to the glass substrates. In this method, the electrical field is applied through opposite electrodes on the same glass substrate, so that the liquid crystals can be reoriented (switched) essentially in the same plane, although fringe fields inhibit a homogeneous reorientation. This requires two transistors for each pixel instead of the single transistor needed for a standard thin-film transistor (TFT) display. The IPS technology is used in everything from televisions, computer monitors, and even wearable devices, especially almost all LCD smartphone panels are IPS/FFS mode. IPS displays belong to the LCD panel family screen types. The other two types are VA and TN. Before LG Enhanced IPS was introduced in 2001 by Hitachi as 17" monitor in Market, the additional transistors resulted in blocking more transmission area, thus requiring a brighter backlight and consuming more power, making this type of display less desirable for notebook computers. Panasonic Himeji G8.5 was using an enhanced version of IPS, also LGD in Korea, then currently the world biggest LCD panel manufacture BOE in China is also IPS/FFS mode TV panel.

In 2011, LG claimed the smartphone LG Optimus Black (IPS LCD (LCD NOVA)) has the brightness up to 700 nits, while the competitor has only IPS LCD with 518 nits and double an active-matrix OLED (AMOLED) display with 305 nits. LG also claimed the NOVA display to be 50 percent more efficient than regular LCDs and to consume only 50 percent of the power of AMOLED displays when producing white on screen.

This pixel-layout is found in S-IPS LCDs. A chevron shape is used to widen the viewing cone (range of viewing directions with good contrast and low color shift).

Vertical-alignment displays are a form of LCDs in which the liquid crystals naturally align vertically to the glass substrates. When no voltage is applied, the liquid crystals remain perpendicular to the substrate, creating a black display between crossed polarizers. When voltage is applied, the liquid crystals shift to a tilted position, allowing light to pass through and create a gray-scale display depending on the amount of tilt generated by the electric field. It has a deeper-black background, a higher contrast ratio, a wider viewing angle, and better image quality at extreme temperatures than traditional twisted-nematic displays.

Blue phase mode LCDs have been shown as engineering samples early in 2008, but they are not in mass-production. The physics of blue phase mode LCDs suggest that very short switching times (≈1 ms) can be achieved, so time sequential color control can possibly be realized and expensive color filters would be obsolete.

Some LCD panels have defective transistors, causing permanently lit or unlit pixels which are commonly referred to as stuck pixels or dead pixels respectively. Unlike integrated circuits (ICs), LCD panels with a few defective transistors are usually still usable. Manufacturers" policies for the acceptable number of defective pixels vary greatly. At one point, Samsung held a zero-tolerance policy for LCD monitors sold in Korea.ISO 13406-2 standard.

Dead pixel policies are often hotly debated between manufacturers and customers. To regulate the acceptability of defects and to protect the end user, ISO released the ISO 13406-2 standard,ISO 9241, specifically ISO-9241-302, 303, 305, 307:2008 pixel defects. However, not every LCD manufacturer conforms to the ISO standard and the ISO standard is quite often interpreted in different ways. LCD panels are more likely to have defects than most ICs due to their larger size. For example, a 300 mm SVGA LCD has 8 defects and a 150 mm wafer has only 3 defects. However, 134 of the 137 dies on the wafer will be acceptable, whereas rejection of the whole LCD panel would be a 0% yield. In recent years, quality control has been improved. An SVGA LCD panel with 4 defective pixels is usually considered defective and customers can request an exchange for a new one.

Some manufacturers, notably in South Korea where some of the largest LCD panel manufacturers, such as LG, are located, now have a zero-defective-pixel guarantee, which is an extra screening process which can then determine "A"- and "B"-grade panels.clouding (or less commonly mura), which describes the uneven patches of changes in luminance. It is most visible in dark or black areas of displayed scenes.

The zenithal bistable device (ZBD), developed by Qinetiq (formerly DERA), can retain an image without power. The crystals may exist in one of two stable orientations ("black" and "white") and power is only required to change the image. ZBD Displays is a spin-off company from QinetiQ who manufactured both grayscale and color ZBD devices. Kent Displays has also developed a "no-power" display that uses polymer stabilized cholesteric liquid crystal (ChLCD). In 2009 Kent demonstrated the use of a ChLCD to cover the entire surface of a mobile phone, allowing it to change colors, and keep that color even when power is removed.

In 2004, researchers at the University of Oxford demonstrated two new types of zero-power bistable LCDs based on Zenithal bistable techniques.e.g., BiNem technology, are based mainly on the surface properties and need specific weak anchoring materials.

Resolution The resolution of an LCD is expressed by the number of columns and rows of pixels (e.g., 1024×768). Each pixel is usually composed 3 sub-pixels, a red, a green, and a blue one. This had been one of the few features of LCD performance that remained uniform among different designs. However, there are newer designs that share sub-pixels among pixels and add Quattron which attempt to efficiently increase the perceived resolution of a display without increasing the actual resolution, to mixed results.

Spatial performance: For a computer monitor or some other display that is being viewed from a very close distance, resolution is often expressed in terms of dot pitch or pixels per inch, which is consistent with the printing industry. Display density varies per application, with televisions generally having a low density for long-distance viewing and portable devices having a high density for close-range detail. The Viewing Angle of an LCD may be important depending on the display and its usage, the limitations of certain display technologies mean the display only displays accurately at certain angles.

Temporal performance: the temporal resolution of an LCD is how well it can display changing images, or the accuracy and the number of times per second the display draws the data it is being given. LCD pixels do not flash on/off between frames, so LCD monitors exhibit no refresh-induced flicker no matter how low the refresh rate.

Color performance: There are multiple terms to describe different aspects of color performance of a display. Color gamut is the range of colors that can be displayed, and color depth, which is the fineness w
