This note will discuss the considerations made when choosing a microcontroller that will work for your display. A few requirements need to be met depending on the display’s features, interface, and size. These can also be determined by the embedded IC in the display. An overview of the considerations when choosing a microcontroller can be seen below. It should be noted that these items are separated for definition but may serve the same purpose and be interconnected in the ecosystem of the controller.

Availability of resources for programming and debugging the microcontroller. Online resources andexampleprograms to leverage from can a lot of save time. Compatibility with a familiarprogramming environment isadditionally beneficial.

The available memory of a microcontroller often becomes a highlighted issue when determining which microcontroller to select. The microcontroller needs a minimum amount of RAM to hold the frame buffer of the display. Even small displays require more RAM than a typical microcontroller possess. To verify that your microcontroller will have enough memory, it is important to calculate the frame buffer.

The minimum RAM required for the frame buffer in this example would then be 768kB. It is important to note that external RAM can be provided for the frame buffer if the microcontroller does not provide it internally. Clocking speed should be verified if using external RAM as the microcontroller cannot access external RAM as quickly. The clock frequency constrained by external RAM sometimes does not meet the minimum requirements of some very high-speed interfaces (ex. DSI-MIPI). Additionally, the display can contain some form of RAM depending on the IC controller inside the display. This can be verified on the specification sheet of the IC.

The speed of the microcontroller is heavily dependent on the interface used in the application. The minimum and maximum of the clock frequency is specified in the datasheet of the display and in the specification sheet of the display’s controller IC. The frame rate is typically around 50-60Hz, which is the median oscillation frequency to refresh the display to maintain an image. The display will often provide an internal high frequency clock that can be initialized to certain frequencies.

It is important to verify in the controller data sheet which resources are provided by the internal IC of the display. Some key information to look for would be: Does the display have sufficient RAM or does this need to be provided? Does the display have an internal oscillator for clock generation for the interface chosen? An additional graphics controller can be used to interface the display with the microcontroller to meet these requirements. Features like these can be utilized to avoid additional cost, space, and memory of your application.

After a brief consideration of intended application and interface of the display you can get some idea of which microcontroller processor and architecture you will need. There are a few different microcontroller processors to choose from. The main choices are ARM, AVR, PIC, and 8051. The difference between them is the bit size of the processor, 8-bit, 16-bit, 32-bit or 64-bit data . The data bit width is the amount of data that can be sent at a time. This determines the speed of data transfer and thus compatible applications and interfaces.

The AVR has an 8-bit processor and is a RISC type microcontroller. This type of processor is compatible with low speed interfaces (SPI, I2C) and smaller displays. A common AVR microcontroller board is the Arduino which has the embedded 8-bit ATMEL RISC processors. These processors are widely popular which provide the benefit of numerous online resources and availability. The Arduino processors (ATmega/SAM3X) are typically available in most microcontroller programming environments. Additionally, Arduino offers 32-bit AVR development boards which function closely to the ARM processors.

The AVR microcontrollers are constrained by the low frequency, internal memory availability and power costs. AVR’s cannot use external program memory but some may allow expansion of external SRAM. These microcontrollers alone would be incompatible for high frequency applications such as video, large displays, or capacitive touch panels.

The ARM microprocessors have a RISC architecture. They offer 32-bit or 64-bit processors and are great options for high speed interfaces (Parallel, LVDS, MIPI, HDMI) and high-resolution displays. Common ARM processors can be found from STMicroelectronics and Raspberry Pi. The most common version of the ARM processors is the “Microcontroller” Arm-M group which include the Cortex-M0 and Cortex-M4 series.

The ARM processors are compatible with most displays and connection interfaces. These microcontrollers have become increasingly popular, so the cost has become comparable between the ARM and the AVR types. These processors provide the speed, but it is recommended to verify the available RAM as these boards vary widely on included features.

The PIC architecture consists of 8, 16, and 32-bit processors developed by Microchip. The PIC 32-bit series of microcontrollers have been geared toward graphical embedded applications and there are a lot of resources online for these devices. There is a huge variety of PIC controllers which make them easily available. These microcontrollers are known for being low cost and are comparable to the ARM processors. The drawback of the PIC controllers is using Microchips programming environment, but this is based on preference.

The Intel MCS-51, more commonly known as the 8051 microcontrollers have a CISC architecture and an 8-bit processor. These processors differ in architecture from the previous and are programmed using a combination of C and assembly languages. The program memory is read only and does not have an on-board ISP. A special programming device is needed to rewrite the EEPROM or flash memory. These processors are typically small, low cost and low powered. This can make them favorable for battery powered devices. These processors are commonly used to initialize TFT displays and are combined with a graphics controller to provide the required resources such as RAM and clock frequency.

Development environments and online resources become considerably valuable when creating an application for your display. A brand new or uncommon microcontroller will have very few resources for reference. Even knowledgeable engineers can find frustrations with the manufacturers programming environments. There are many microcontroller choices that will support your display with similar and overlapping features. Choosing a microcontroller with an available FAQ, application notes or is accessible on a familiar programming platform can save a lot of time.

Buyers and others who are developing systems that incorporate FocusLCDs products (collectively, “Designers”) understand and agree that Designers remain responsible for using their independent analysis, evaluation and judgment in designing their applications and that Designers have full and exclusive responsibility to assure the safety of Designers" applications and compliance of their applications (and of all FocusLCDs products used in or for Designers’ applications) with all applicable regulations, laws and other applicable requirements.

Designer agrees that prior to using or distributing any applications that include FocusLCDs products, Designer will thoroughly test such applications and the functionality of such FocusLCDs products as used in such applications.

Using the serial enabled controller, it is easy to connect to any microcontroller that has a serial UART port such as an Arduino, AVR, PIC, etc. The SerLCD supports 16 and 20 character-wide screens with 2 or 4 lines of display.

Depending on your LCD"s specs, the input voltage may be 3.3V or 5V. For the LCDs listed below, the input voltage for the backpack must be 3.3V even though the silkscreen says 5V. The logic levels will be the same as the input voltage.

The LCDs listed below require an input voltage of 5V. Higher than 5.5V will cause damage to the PIC, LCD, and backlight (if attached). At 5V, the SerLCD uses 3mA with the backlight turned off and ~60mA with the backlight activated. The following LCDs do not have a SerLCD backpack.

The SerLCD and built-in serial LCDs comes equipped with a 10k potentiometer to control the contrast of the LCD. This is set during assembly and testing but may need correcting for your specific LCD module. Temperature and supply voltage can affect the contrast of the LCD. While powered, simply adjust the potentiometer with a screw driver.

The SerLCD v2.5 uses a general purpose, 1000mA NPN transistor to control the LCDs backlight. If you purchased the SerLCD module, you may use this pin as a general purpose, high power control pin. If you issue the backlight on/off command to the SerLCD or built-in serial LCD, the BL pin on the board can also be used to power / control other circuits with a maximum current of 1000 mA. This is usually the last pin on the top row of the LCD. Check your datasheet for proper pin outs.

A lot goes into the design of quality electronics regardless of the intended application. Akey componentof embedded systems in electronics is the microcontroller. While diverse, an electronic designer needs to settle for a microcontroller type that suits their electronic needs. PIC microcontrollers are one such type.

PIC microcontrollersare programmable and the world’s tiniest. It is capable of carrying out a diverse task range. Therefore, you will find them in alarm systems, computer control systems, phones, alarm systems, etc. Understanding the diverse types of PIC microcontrollers informs the design process and programming of PIC microcontrollers. Want to learn more? Continue reading.

PIC microcontrollers, alternatively inferred asprogrammable interface controllers, came to the fore in 1993. Primarily designed and developed to support PDP computers in controlling their auxiliary devices, it currently has an expanded scope.

The PIC microcontrollers are based on Harvard architecture, which makes them popular. It stems from the ease in which it can get programmed,low cost, wide availability, and a simple interfacing capability with other auxiliary components. Additionally, it possesses a huge user base besides capacity for serial programming.

As anintegrated chip, a PIC microcontroller consists of a ROM, RAM, timers, CPU, and counters that support protocols like CAN, UART, and SPI for interfacing purposes. It also has flash memory, I/O ports, EEPROM, UART, SSP, ADC, and PSP besides ICSPand LCD. Such components form a fundamental aspect of the PIC microcontroller architecture.

The architecture of the PIC microcontroller defines its functionality. Besides considering the four classifications of the PIC microcontroller that rely on the internal architecture, understanding the different PIC microcontrollers’ types becomes ideal before the design process. Classifications include baseline PIC, enhanced mid-range PIC, mid-range PIC, and PIC18.

PIC microcontrollers also need programming to tailor them to their specific applications. As a designer, you need to factor in the PIC microcontroller programming software to deploy before development. It allows for its proper functioning upon completion. In most instances, the typical programming language often features the embedded C language. Let us now look into the architecture and programming process of the PIC microcontroller.

It only becomes possible to design and program a PIC microcontroller after understanding its architecture. The architecture entails I/O ports, CPU, A/D converter, interrupts, oscillator, counters/timers, memory organization CPP module, and serial communication.

It is similar to other microcontroller CPUs. It has a CU, AC, ALU, accumulator, and MU, among other components. Every aspect has its use. For instance, a control unit (CU) controls everything connected to the CPU. An arithmeticlogic unit (ALU) carries out arithmetic operations besides undertaking logical decisions. A memory unit (MU) stores instructions, etc.

The MU or memory organization module consists of ROM, RAM, and STACK. RAM comes unstable and stores data momentarily in its registers. RAM registers get classified either as general-purpose (GPR) or special function registers (SFR). On the other hand, ROM stores data permanently and, for a microcontroller case, the program. It all functions through the execution of instructions by the CPU. EEPROM allows for programming of the ROM numerous times instead of what happens in a typicalread-only memory (ROM). Flash memory is also PROM and thus can write, read, and erase programs multiple times. Lastly, STACK stores and executes the information from the completion of the interrupt execution.

All PIC16 contain five ports, including Port A, B, C, D, and E. Port A is a 16-bit port for output and input based on the TRISA register. The next is Port B, which comes as an 8-bit port for output or input functions, while Port C is similar to Port B but with its operation specified by the TRISC register. Port D acts as the slave port for Bus connection, while Port E comes as a 3-bit port that controls the digital or analog converter signals.

PIC microcontrollers have four counters/timers, whereas the 8-bit timer or the rest can accommodate eight or sixteen-bit mode, depending on your choice. It generates accuracy actions such as particular time delays among two operations.

PIC microcontrollers always require a PIC programmer, especially when building a PIC microcontroller project. Programming comes by way of an embedded C language, and as such, a designer needs to familiarizing with all these aspects before building their PIC controller project. But what does it all entail?

Before getting started on the PIC microcontroller programming front, it is crucial to understand how a standard microcontroller gets developed. However, the underlying considerations entail picking an ideal project for the microcontroller program, such as an LED flash system. Designing the circuit also becomes vital. Here, aspects such as circuit components, diagrams, and connections come into consideration.

The programming of PIC microcontrollers often gets carried out through the “MP-Lab” software. It requires installation before proceeding to install the compiler. Compilers include GCC compiler, CCS compiler, etc. After completion of the installation process, all you need is to follow the process below.

Pick a suitable compiler based on your needs besides your project’s location path. You can pick the CCS or the GCC compiler depending on your PIC microcontroller needs. After that, choose the browse option then the “ccsloader” within the PICC folder from the program files. At this point, a source group folder gets created in the intended folder.

At this stage, it becomes vital to assign the appropriate name to your project before clicking “Next” to save the project. Within the target folder, a source group folder gets created, which you select the file menu and pick the new file from the drop-down list.

After coming up with the PIC microcontroller code, you have to load it into the microcontroller in a process inferred as dumping. Microcontrollers solely comprehend the machine-level language featuring 0’s and 1’s. As such, the dumping process requires specific code loading software.

It is crucial to select and install your preferred software program from many options in the market. Additionally, the PIC programmer kit will come complete with a hardware kit. Plug the PIC microcontroller into the hardware kit and follow the process below to dump the code into the PIC microcontroller.

Plenty of PIC microcontrollers exist in the market. It is, therefore, always difficult to settle on the correct PIC microcontroller type and size when talking to your PCB or circuit assembly company. However, based on your need, we at RayMing PCB and Assembly will advise you accordingly. What’s more? You will get top-rate quality assembly services for your PIC microcontroller at reasonable prices.

The PIC16f877a/PIC16f877 has a simple programming process besides convenience when it comes to using. Because of this, it proves a popular microcontroller option within the industry. It comes either 8-bit or 16-bit and has a flash memory tech allowing for numerous write-erase processes. While ideal because the total amount of pins (40 in total and 33 for output and input) mainly applies in digital electronic circuits and PIC microcontroller projects. It is instrumental in home automation devices and systems, industrial instruments, remote sensors, and safety and security devices.

It comes as an 8-bit CMOS microcontroller developed on high-performance RISC architecture. The PIC12f675 is small in size and cost-effective, thus proves popular among engineers and hobbyists. The design is perfect for low-end systems and applications because of its 2Kbytesflash memory. It also contains 6 GPIO pins that can handle not more than 25mA of current, meeting the threshold of many sensors and peripheral devices.

It is a renowned and the most utilized PIC microcontroller type based on its pioneering stature. The PIC16f84 comes as an 8-bit mid-range microcontroller with a 1024 word program memory. It also has a RAM of 68bytes and a lasting EPROM storage of 64bytes. The striking factor about PIC 16f84 is that it can get reprogrammed using thein-circuit ICSP.

It is an 8-bit flash-based CMOS microcontroller that is simple to program. The PIC microcontroller packs the powerful PIC® MCU architecture within the 8-pin package. It has various features that make it popular, such as the one-channel comparator besides the 128byte EEPROM. It is ideal for application in industrial, automotive, and consumer electronics.

It is a powerful and simple-to-program PIC microcontroller that is based on the CMOS flash-based 8-bit PIC microcontroller. Additionally, it packs the PIC® architecture within the 28-pin package. PIC16f886 possesses a 256byte EEPROM, is self-programming, and has two comparators, among other vital features. It makes it a popular choice for applications in sectors like industrial, automotive, consumer and appliances.

The popular PIC microcontroller mainly gets deployed in embeddedand automation systems. It comes as either TQFP, PDIP, or QFN. The PDIP has 40 pins, while the rest contains a 44-pin interface. It contains a 10-bit ADC, a 256byte EEPROM data memory, and a RAM of 1536 bytes.

It comes as a popular 8-bit PIC microcontroller and comes with an improved NanoWatt technology and flash processor. The PIC microcontroller has three distinctive packages in SSOP, PDIP, and QFN. The SSOP has a 20 pin package, while the PDIP and QFN have 18 pin and 28 pin packages, respectively.

It is a powerful and simple-to-program CMOS and flash-based 8-bit PIC microcontroller. The PIC16f676 packs the powerful PIC® MCU architecture within the 14-pin package. It is a 10-bit A/D converter complete with eight channels, a single comparator, besides an EEPROM data memory. It has applications in industrial, automotive, consumer, and appliance entry-level products, especially those requiring field re-programmability.

The 8-pin flash-based CMOS PIC microcontroller comes with a nanoWatt tech. It offers benefits associated with the mid-range x14 architecture, including standardized features. Such features make it a popular PIC microcontroller option for automotive and industrial applications.

The popular and powerful PIC microcontroller comes as an 8-bit CMPS FLASH-based microcontroller type. It contains 34 I/O pins and comes with one 16-bit and 8-bit timer, 10-bit A/D converter, SPI, I2C, and USART peripherals.

It is a popular and relatively new PIC microcontroller type that cannot work on older device models. The PIC16f628 is based on the FLASH program memory of 3.5, 2 comparators, and a single CCP. What makes it an excellent option entails low voltage programming, programmable BOR, on-chip voltage reference, and other features.

The 8-bit PIC microcontroller from Microchip comes with a 20-pin interface. It incorporates the high-performance RISC CPU that assists in the execution of instructions. The microprocessor also has a crystal oscillator of 20MHz for interfacing purposes and the creation of clock pulses.

The popular PIC microcontroller comes with a FLASH memory of 32KB and proves compatible with PIC17 and PIC16 instruction sets. It uses advanced CAN technology and applies to the automotive and industrial sectors.

The PIC microcontroller comes optimized and equipped with the RISC architecture. It operates on flash memory and has a CPU speed of 10 DMIPS/MIPS, making it a toast for some people. Its maximum ADC is 10 bits with a CCP of 1.

The popular PIC microcontroller comes as a high-performance, low-cost, and 8-bit static microcontroller. It uses flash CMO technology with a total of 8 pins. It also possesses a DRT (device reset timer) that eliminates any requirement for external reset circuitry.

It is always vital to understand everything about PIC microcontrollers, including the diverse types, program them, etc. Such information becomes useful in designing integrated circuits and electronics as a whole. Therefore, consider all insights about the intricacies of the diverse PIC microcontrollers to stay ahead of your design game.
