Many Apple products use liquid crystal displays (LCD). LCD technology uses rows and columns of addressable points (pixels) that render text and images on the screen. Each pixel has three separate subpixels—red, green and blue—that allow an image to render in full color. Each subpixel has a corresponding transistor responsible for turning that subpixel on and off.

Depending on the display size, there can be thousands or millions of subpixels on the LCD panel. For example, the LCD panel used in the iMac (Retina 5K, 27-inch, 2019) has a display resolution of 5120 x 2880, which means there are over 14.7 million pixels. Each pixel is made up of a red, a green, and a blue subpixel, resulting in over 44 million individual picture elements on the 27-inch display. Occasionally, a transistor may not work perfectly, which results in the affected subpixel remaining off (dark) or on (bright). With the millions of subpixels on a display, it is possible to have a low number of such transistors on an LCD. In some cases a small piece of dust or other foreign material may appear to be a pixel anomaly. Apple strives to use the highest quality LCD panels in its products, however pixel anomalies can occur in a small percentage of panels.

In many cases pixel anomalies are caused by a piece of foreign material that is trapped somewhere in the display or on the front surface of the glass panel. Foreign material is typically irregular in shape and is usually most noticeable when viewed against a white background. Foreign material that is on the front surface of the glass panel can be easily removed using a lint free cloth. Foreign material that is trapped within the screen must be removed by an Apple Authorized Service Provider or Apple Retail Store.

If you are concerned about pixel anomalies on your display, take your Apple product in for closer examination at an Apple Store, Apple Authorized Service Provider, or an Independent Repair Provider. There may be a charge for the evaluation. Genuine Apple parts are also available for out-of-warranty repairs through Self Service Repair.*

According to The Elec (via AppleInsider) Apple will be using a hybrid OLED panel for the first iPad it produces with an OLED display, something that the report notes will be a few years from now. Currently, Apple uses an LCD backlit screen on its tablets which it calls a "Liquid Retina" display. The one exception is the latest 12.9-inch iPad Pro which uses a mini-LED backlit screen that Apple calls the "Liquid Retina XDR" display.

Besides being less likely to crumple, Apple might also like that hybrid OLED panels are thinner than rigid panels and should also be cheaper to produce than flexible panels. Apple currently uses flexible OLED panels for the iPhone. The report notes that if the issues (including the propensity of these panels to crumple) can be resolved, Apple could choose to use flexible OLED panels for the iPad instead of hybrid panels.

LG Display and Samsung Display are said to be working on an ultra-thin glass substrate for hybrid OLED panels. Replacing the current 5nm substrate with one measuring 2mm, the two companies are trying to reduce the thickness of hybrid OLED panels. The latest update reveals that the new technology is still at least one year away from being commercialized, but we are sure that Apple is closely monitoring the developments.

The reason why Apple and other phone manufacturers can get away with using flexible OLED panels for their handsets without crumpling issues is because this flaw isn"t as noticeable on smaller screens like the ones used for smartphones. However, the crumpling is noticeable on larger displays like the ones used for the company"s iPad tablets. And that is one of the reasons why Apple would probably choose to use a hybrid OLED panel instead of a flexible one for future iPad models.

Mini-LED backlit screens deliver some of the same features that users receive from OLED displays. The mini-LED displays use smaller LEDs as a backlight. Because of their smaller size, as much as 120 times smaller than the ones employed on traditional LCD screens, these panels have a larger number of LEDs behind the scenes. As a result, instead of the 72 LEDs used on the previous 12.9-inch iPad Pro model, there are 10,000 mini-LEDs used on the current model. They are arranged in four "dimming zones," each with 2,500 mini-LEDs, to provide the super 1,000,000:1 contrast that these screens can offer.

As we just noted, the mini-LED displays offer a high contrast ratio and they are less likely to suffer burn-ins which lead to a permanent image seen on a screen. They also deliver deeper blacks and more true-to-life colors. Last year an Apple executive explained that the mini-LED panel might make the 11-inch iPad Pro too heavy which is why the technology was only used on the larger 12.9-inch variant.

Keep in mind that mini-LED panels are considered the next step in LCD display technology. So even if Apple were to use it for all of its iPad models, the company would probably continue working toward the ultimate goal of offering OLED-screened iPad models. Due to cost though, we"d expect Apple to offer such a feature first on the pricier 12.9-inch iPad Pro just like it is doing with mini-LED.

Only the original home button assembly from your iPad 2 will be capable of using the Touch ID functionality. Installing a new home button will only restore ordinary home button functions, not the Touch ID features.

The new mini-LED display technology validates LCD technology can still move forward and compete with the OLED displays. Mini-LEDs are physically smaller than backlight LEDs used in the typical LCD. The mini-LED size allows more LEDs (in theory almost 5x more) to be used in a display design, delivering better colors. And even though there are more LEDs in a mini-LED display, mini-LED displays will have better power efficiency than the same LCD.

Wearables like Apple & Samsung watches often don"t have visible LDIs. Check for moisture under the display screen, as well as corrosion, discoloration, and fuzzy growth on the charging connection.

Apple’s iPad remains one of the best tablets on the market. Apple has sold well over 350 million worldwide, and there are currently a number of different models to choose from. While these tablets are certainly well-engineered pieces of digital machinery, they are not immune to a few snags and glitches. We"ve taken a look at some of the most prevalent iPad problems in an attempt to find workable solutions for them. Sometimes it will take more than a simple reset to get your iPad back in working order.

It can be frustrating if a pixel isn’t working on your iPad. You’ll first notice this as an unresponsive dot on the display that doesn’t change, or stays black no matter what happens. Sometimes there may be more than one pixel like this.

If the pixel still lights up but is simply stuck or never goes to the right color, you can try manually fixing it yourself. Wrap your thumb in a clean cloth and apply gentle, firm pressure to the area of the display with the pixel, slowly moving your thumb as you do so. Sometimes this can help fix any issues the panel is experiencing.

If the pixel is permanently dark no matter what you do, it’s dead. You cannot fix a dead pixel. If it’s a minor issue and not distracting, you can leave it. But it’s a good idea to take your iPad into an Apple Store and ask about a display replacement.

Eager to get the latest iOS/iPadOS updates and all the new features offered? You may discover that your iPad is obstinately refusing to download the update, even if it says it will or if it was scheduled to update at a specific time. Fortunately, this is usually due to not meeting specific requirements needed to update, not a permanent flaw on your iPad.

Double check to make sure your iPad is compatible with the latest versions of iPadOS. Check out our list of iPadOS 15 compatible devices and iPadOS 16 compatible devices.

Make sure you are not using a cellular data connection for your internet. The iPad will not start such a big download when on a data connection to avoid using up cell data.

You may find from time to time that your iPad screen freezes and remains unresponsive to your touch. It’s a common complaint at Apple’s support forum. The most likely culprit is a specific app, but it’s not always easy to identify which one. If it happens repeatedly, take note of what you have running and try uninstalling it to see if that solves the problem permanently. Whatever the cause, your immediate solutions to a frozen iPad screen are the same.

If the screen isn’t responding, you might need to force restart the device in which case you should press and hold the Power button and the Home button at the same time for around 10 seconds. You’ll know it worked when the Apple logo appears. For newer iPads without the Home button, press and quickly release the Volume Up button, press and quickly release the Volume Down button, and then press and hold the Power button until the device restarts.

If it stubbornly refuses to react to a restart or reset, then you’ll need to try a restore. Plug it into your computer using the cable provided. Load up iTunes on the computer, select your iPad, choose the Summary tab, and hit the Restore iPad button. This will erase your content, so you may prefer to choose Restore Backup on the Summary tab. Bear in mind that you’ll lose anything you haven’t backed up.

Try holding down the Power button and the Home button together until you see the Apple logo. For newer iPads without the Home button, press and quickly release the Volume up button, press and quickly release the Volume down button, and then press and hold the Power button until the device restarts.

Maybe the battery is just empty. Plug the iPad into the wall charger using the original cable and charger that came in the box and wait an hour before trying the first step again.

If your iPad turns on but gets stuck during startup, then plug it into your computer with iTunes running and repeat step one, except this time, don"t let go of the buttons when you see the Apple logo, keep holding them until you see the recovery mode screen. You should get the option to Restore or Update. Choose Update and it will try to reinstall iOS without wiping your data.

Some people have reported issues with plugging the iPad into the computer and booting up iTunes only to find that the iPad isn’t there. If iTunes or Finder isn’t recognizing your iPad then you can try a few things to solve the problem.

Check the battery icon on the iPad when you plug it into your computer. If it has a lightning bolt on it to denote charging or it says Not charging next to it then you know the port and the cable are working and you can move to the next solution. If it doesn’t, then try another port. If that doesn’t work, then try another cable.

(If you are running MacOS Catalina you can skip this as you"ll be using Finder to interface with your iPad.) Make sure you have the latest version of iTunes. If it’s on a PC then go to Help and then select Check for updates. If it’s on a Mac then hit the iTunes tab and select Check for updates. If you have the latest version or updating makes no difference, try the next solution.

Turn the iPad off. Turn the computer off. Turn them both back on again and plug the iPad back in. If you see a Trust this computer alert, unlock your device and tap Trust.

If you find that your iPad won’t charge when you plug it into a power adapter, there are a couple of possible reasons. If it doesn’t charge when you plug it into the computer, it may just be the port you are using, try the power adapter instead. You can see whether the USB port on your computer is charging it or not by looking at the battery icon on the iPad. If it is charging, you’ll see the lightning symbol; if not, it will say Not charging next to it. Some computer ports can’t provide enough juice to charge the iPad, and it will always charge more slowly via the computer, even if it does work.

If the cable or power adapter is not the problem and nothing else has worked, then there could be a fault with the iPad and you’ll need to contact Apple, contact the retailer where you bought it, go into an Apple Store, or take it to a third party repair shop as the culprit could be a damaged battery, or a damaged charge port, both of which are repairable.

A lot of people have trouble connecting to Wi-Fi networks with their iPads. Before you start serious troubleshooting, you should check Settings > Wi-Fi on the iPad and make sure that it is turned on. It’s also worth making sure that Wi-Fi is accessible on another device.

There’s a reason IT departments the world over tell everyone to turn a device off and on again as a first troubleshooting step — because it so often works. Try turning off your iPad and router and then turn them both on again and wait a few seconds before trying to reconnect.

Try telling the iPad to forget the network in Settings by tapping the network name and selecting forget. Turn the iPad off and on again and then reconnect to the network and re-enter the details as necessary. You can also try Settings > General > Reset > Reset network settings.

Make sure you have the latest iOS software by going to Settings > General > Software update. You should plug your iPad into the power adapter before updating. Older iPads can be updated via iTunes on the Summary tab via the Check for update option.

If your iPad still won’t connect then it’s worth checking with your ISP for help or advice. The problem could be related to your specific router. You might want to update the firmware or change the channel.

If nothing so far has worked, then you may consider trying to connect to a different Wi-Fi network with your iPad just to test if it works. If not, then it"s time to contact Apple for further help.

If you find that your iPad is not its usual zippy self and you are experiencing some lag when you navigate, you can try a couple of fixes. You may just have too many things running.

Double-tap the Home button and swipe up on each open app or game to close it. If you have a newer iPad without the Home button, then swipe up from the bottom of the Home screen and pause slightly in the middle of the screen to open the recently used apps list.

You could also just reset the iPad by holding down the Power button and the Home button simultaneously for 10 seconds. For newer iPads without the Home button, press and quickly release the Volume up button, press and quickly release the Volume down button, and then press and hold the Power button until the device restarts.

You really need at least 2GB of free space for smooth operation, so take a look in Settings > General > iPad storage and check. You may need to delete some files or uninstall some apps. Some apps take up more and more space over time, so it can even be worth uninstalling and then reinstalling an app to clear it. You may also consider going to Settings > Safari and tapping Clear history and Website data, then Clear history and Data to clear out your cache, but this will also log you out of websites you"ve signed into.

As a last resort, you might try a factory reset. This will wipe everything though, so make sure you back up first. If you do a factory reset, test the iPad without restoring a backup just to see if it runs any better. If you subsequently restore a backup and it slows down again, then you"ll know the issue is with something in the backup.

Quite a few iPad owners have been complaining about cellular data connections dropping frequently. Obviously, this will be seriously influenced by how good the coverage is in your area. If you have good coverage on the same network with your phone, but the iPad is struggling, you could try a couple of things. First, check in Settings > General > Cellular and make sure it’s on. You could also try a restart. If it continues to be a problem, go through the steps below.

A lot of iPad owners suffer from random crashes where an app spontaneously closes or the iPad suddenly restarts. You might find that this is a bigger issue on older iPads. You can try a few different things to alleviate the problem. It is quite likely to be related to specific apps, so take note of what you were doing when it crashes and see if a pattern emerges over time.

Press and hold the Power button and then slide to power off. Press and hold the button to turn it on again. You could also reset by pressing and holding the Power button and the Home button at the same time for 10 seconds. For newer iPads without Home buttons, press and quickly release the Volume up button, press and quickly release the Volume down button, and then press and hold the Power button until the device restarts. Neither of these solutions is liable to affect a permanent fix, but it may offer some relief.

Connect to Wi-Fi and go to Settings > General > Software update to ensure that your iPad has the latest software. If there’s an update available then download it and install it.

When everything is running as it usually should, your iPad should take about three hours to recharge. If you own an older model, it still would only take about four hours, at a maximum. That said, many users report that it takes much longer for their iPad to recharge fully. We have a couple of tips to try and speed up the charging process.

Make sure your iPad is updated. Infamously, iPadOS 13 caused these types of battery charging issues for many users. If it"s an issue with iPadOS, you can"t do much except live with it until Apple improves the software and releases a new version.

Check your ports and connectors. Look for any signs of damage, grime that"s blocking ports, or anything else that may be interrupting the connection. If you aren"t sure, try to find another compatible charging cable and switch it out to see if this makes a difference. Do not use an off-brand cable or charger to charge your iPad! If you are using one, stop right away and switch to a version straight from Apple.

Make sure your iPad isn"t trying to do a lot when you are charging it. Disconnect from Wi-Fi and Bluetooth or put it into Airplane mode first. Don"t use your iPad when it"s charging, and see how much this helps.

Always remember to make sure that your iPad isn"t put in a particularly hot or cold place. This can damage the battery and cause long-term problems that can"t really be fixed without a full replacement.

We completely understand how frustrating this issue can be, mainly because you likely bought the Pencil to pair specifically with your iPad. We have several solutions to try out to get the two working together again.

Make sure you have the right Apple Pencil and iPad. Compatibility issues do exist. We have a full Apple Pencil compatibility guide, and certain Apple Pencil and iPad combinations simply won"t work. Also, if you have an iPad Air 2 or earlier model, the Pencil won"t be able to work with your screen at all, although some third-party stylus models could work for you. We know, it"s confusing. But it"s important to find out what Pencil and iPad model you have to see if they can work together.

Restart your iPad and try again. When you restart, take a look at Settings and Bluetooth to make sure your Bluetooth is turned on. If you already see the Pencil as a recognized device in the Bluetooth settings, then select the information icon, and choose Forget this Device. Then try reconnecting.

A bootloop is when your device gets stuck in a cycle of turning off and turning back on; The iPad continues repeating that over and over again on a seemingly endless loop. We’ve found that these frustrating cycles tend to result from a bug in whatever app you were last trying to use. That said, there could also be a couple of other factors causing the bootloop. We have several recommendations to try out to stop the looping before you take your iPad to the Apple Store for help.

* Wait for an update. Unfortunately, bootloops are often caused by bugs in specific apps or the iPad’s current operating system. In that situation, you just need to wait for an app or OS update to be released. A recent example of this happened in June 2020, when a version of iPad iOS caused iPads to bootloop unexpectedly while working, usually around a minute or so after starting up. Apple doesn’t waste a second when it comes to releasing patches for these problems. Just keep an eye out for new updates.

* Force a manual restart, or “soft reset,” and see if it solve the problem. A manual reset is a powerful troubleshooting tool. To start the reboot, hold the Power and Home buttons down for about 10 seconds simultaneously. You don’t have to count it down; you’ll see when the reboot has started because the Apple logo will appear on the screen. Some newer iPads don’t have a Home button. For those devices, press and quickly release the Volume up button, press and quickly release the Volume down button, and then press and hold the Power button until the device restarts. If this doesn’t work, you may need to force a factory reset, unfortunately. Before resetting anything, though, may sure you back up all of your important data.

* Go into recovery mode. This feature prevents bootloops and opens the door for your iPad to fully update if your device is stuck in an infinite bootloop. Apple has a full guide, but to explain it briefly — connect your iPad to a computer; then press and release the Volume up button, the Volume down button, the Top button, and then hold the Top button as your iPad restarts. If this is completed correctly, your iPad will reboot into recovery mode. If your device has a Home button, hold the Home and Top buttons simultaneously. Continue holding them until you see that recovery screen.

Retina Display is a brand name used by Apple for its series of IPS LCD and OLED displays that have a higher pixel density than traditional Apple displays.trademark with regard to computers and mobile devices with the United States Patent and Trademark Office and Canadian Intellectual Property Office.

The Retina display debuted in 2010 with the iPhone 4 and the iPod Touch (4th Generation), and later the iPad (3rd generation) where each screen pixel of the iPhone 3GS, iPod touch (3rd generation), iPad 2 was replaced by four smaller pixels, and the user interface scaled up to fill in the extra pixels. Apple calls this mode HiDPI mode. In simpler words, it is one logical pixel = four physical pixels. The scale factor is tripled for devices with even higher pixel densities, such as the iPhone 6 Plus and iPhone X.

The Retina display has since expanded to most Apple product lines, such as Apple Watch, iPhone, iPod Touch, iPad, iPad Mini, iPad Air, iPad Pro, MacBook, MacBook Air, MacBook Pro, iMac, and Pro Display XDR, some of which have never had a comparable non-Retina display.marketing terms to differentiate between its LCD and OLED displays having various resolutions, contrast levels, color reproduction, or refresh rates. It is known as Liquid Retina display for the iPhone XR, iPad Air 4th Generation, iPad Mini 6th Generation, iPad Pro 3rd Generation and later versions,Retina 4.5K display for the iMac.

Apple"s Retina displays are not an absolute standard for display sharpness, but vary depending on the size of the display on the device, and at what distance the user would typically be viewing the screen. Where on smaller devices with smaller displays users would view the screen at a closer distance to their eyes, the displays have more PPI (Pixels Per Inch), while on larger devices with larger displays where the user views the screen further away, the screen uses a lower PPI value. Later device versions have had additional improvements, whether an increase in the screen size (the iPhone 12 Pro Max), contrast ratio (the 12.9” iPad Pro 5th Generation, and iMac with Retina 4.5K display), and/or, more recently, PPI count (OLED iPhones); as a result, Apple uses the names “Retina HD display", "Retina 4K/5K display", “Retina 4.5K display", "Super Retina HD display", “Super Retina XDR display”, and "Liquid Retina display" for each successive version.

When introducing the iPhone 4, Steve Jobs said the number of pixels needed for a Retina display is about 300 PPI for a device held 10 to 12 inches from the eye.skinny triangle with a height equal to the viewing distance and a top angle of one degree will have a base on the device"s screen that covers 57 pixels. Any display"s viewing quality (from phone displays to huge projectors) can be described with this size-independent universal parameter. Note that the PPD parameter is not an intrinsic parameter of the display itself, unlike absolute pixel resolution (e.g. 1920×1080 pixels) or relative pixel density (e.g. 401 PPI), but is dependent on the distance between the display and the eye of the person (or lens of the device) viewing the display; moving the eye closer to the display reduces the PPD, and moving away from it increases the PPD in proportion to the distance.

In practice, thus far Apple has converted a device"s display to Retina by doubling the number of pixels in each direction, quadrupling the total resolution. This increase creates a sharper interface at the same physical dimensions. The sole exception to this has been the iPhone 6 Plus, 6S Plus, 7 Plus, and 8 Plus, which renders its display at triple the number of pixels in each direction, before down-sampling to a 1080p resolution.

The displays are manufactured worldwide by different suppliers. Currently, the iPad"s display comes from Samsung,LG DisplayJapan Display Inc.twisted nematic (TN) liquid-crystal displays (LCDs) to in-plane switching (IPS) LCDs starting with the iPhone 4 models in June 2010.

Apple markets the following devices as having a Retina display, Retina HD display, Liquid Retina display, Liquid Retina XDR display, Super Retina HD display, Super Retina XDR display or Retina 4K/5K/6K display:

Reviews of Apple devices with Retina displays have generally been positive on technical grounds, with comments describing it as a considerable improvement on earlier screens and praising Apple for driving third-party application support for high-resolution displays more effectively than on Windows.T220 and T221 had been sold in the past, they had seen little take-up due to their cost of around $8400.

That much resolution is stunning. To see it on a mainstream device like the iPad—rather than a $13,000 exotic monitor—is truly amazing, and something I"ve been waiting more than a decade to see. It will set a bar for future resolution that every other manufacturer of devices and PCs will have to jump.

Writer John Gruber suggested that the arrival of Retina displays on computers would trigger a need to redesign interfaces and designs for the new displays:

Raymond Soneira, president of DisplayMate Technologies, has challenged Apple"s claim. He says that the physiology of the human retina is such that there must be at least 477 pixels per inch in a pixelated display for the pixels to become imperceptible to the human eye at a distance of 12 inches (305 mm).Phil Plait notes, however, that, "if you have [better than 20/20] eyesight, then at one foot away the iPhone 4S"s pixels are resolved. The picture will look pixelated. If you have average eyesight [20/20 vision], the picture will look just fine... So in my opinion, what Jobs said was fine. Soneira, while technically correct, was being picky."

Apple fan website CultOfMac hosts an article by John Brownlee"Apple"s Retina Displays are only about 33% of the way there."visual acuity in the population saying "most research suggests that normal vision is actually much better than 20/20" when in truth the majority have worse than 20/20 vision,WHO considers average vision as 20/40.presbyopia

The first smartphone following the iPhone 4 to ship with a display of a comparable pixel density was the Nokia E6, running Symbian Anna, with a resolution of 640 × 480 at a screen size of 62.5mm. This was an isolated case for the platform however, as all other Symbian-based devices had larger displays with lower resolutions. Some older Symbian smartphones, including the Nokia N80 and N90, featured a 2.1 inch display at 259 ppi, which was one of the sharpest at the time. The first Android smartphones with the same display - Meizu M9 was launched a few months later in beginning of 2011. In October of the same year Galaxy Nexus was announced, which had a display with a better resolution. By 2013 the 300+ ppimark was found on midrange phones such as the Moto G.Samsung Galaxy S4 and HTC One (M8) had 1080p (FHD) screens around 5-inches for a 400+ PPI which surpassed the Retina density on the iPhone 5. The second major redesign of the iPhone, the iPhone 6, has a 1334 × 750 resolution on a 4.7-inch screen, while rivals such as the Samsung Galaxy S6 have a QHD display of 2560 × 1440 resolution, close to four times the number of pixels found in the iPhone 6, giving the S6 a 577 PPI that is almost twice that of the iPhone 6"s 326 PPI.

The larger iPhone 6 Plus features a "Retina HD display", which is a 5.5-inch 1080p screen with 401 PPI. Aside from resolution, all generations of iPhone Retina displays receive high ratings for other aspects such as brightness and color accuracy, compared to those of contemporary smartphones, while some Android devices such as the LG G3 have sacrificed screen quality and battery life for high resolution. Ars Technica suggested the "superfluousness of so many flagship phone features—the move from 720p to 1080p to 1440p and beyond...things are all nice to have, but you’d be hard-pressed to argue that any of them are essential".
