Monitor and optimize light levels, reduce the energy burden of buildings by significantly increasing the efficiency of the lighting system with a light meter.

Fluorescent Lamp Tester takes the guess work out of troubleshooting fluorescent light fixtures, saving you time and money. These 3-in-1 tool tests the light bulb, pins, and voltage so you can tell whether fluorescent light bulbs are working before you install or remove them. The intuitive one-button operation, 48" removable and retractable antenna, Helps detect Voltage Non Contact and the ultra-compact design, makes Fluorescent light Tester is the right tool for the right job, in electrical and facilities maintenance applications.

Need help to select the “right tool for the right job”? Our Experienced, Friendly Staff is available to take your Call – 503-406-4373, or fill out the contact us form, and one of our Sales Engineers will call you back to discuss your application needs.

Perform five essential lighting tests in under 30 seconds to pinpoint problems and verify operation when done. Survives on-the-job handling, and is drop-tested to survive from a 6" (2 m) ladder.

Perform five essential lighting tests in under 30 seconds to pinpoint problems and verify operation when done. Survives on-the-job handling, and is drop-tested to survive from a 6" (2 m) ladder.

This digital light meter can be used with multiple light sources, including those that are incandescent and fluorescent. A battery and case are included.

Responsible for performing installations and repairs (motors, starters, fuses, electrical power to machine etc.) for industrial equipment and machines in order to support the achievement of Nelson-Miller’s business goals and objectives:

• Perform highly diversified duties to install and maintain electrical apparatus on production machines and any other facility equipment (Screen Print, Punch Press, Steel Rule Die, Automated Machines, Turret, Laser Cutting Machines, etc.).

• Provide electrical emergency/unscheduled diagnostics, repairs of production equipment during production and performs scheduled electrical maintenance repairs of production equipment during machine service.

The Lighting Facts label gives shoppers the information they need to buy the most energy-efficient bulb to meet their lighting needs. The label includes a bulb’s brightness, energy cost, life, light appearance, and wattage. In addition, the principal display panel on the front of packaging focuses on lumens, a measure of brightness, rather than on watts, a measure of the amount of energy used, and includes the estimated yearly energy cost for each bulb. Bulbs themselves also feature lumens, and in the case of CFLs, a mercury disclosure.

The FTC enforces the Energy Labeling Rule. To help you comply with the labeling and reporting requirements for common household light bulbs, FTC staff have prepared answers to some common questions we’ve been asked.

The FTC Lighting Facts label and principal display panel information must appear on packaging for most general service “lamps” with medium screw bases, including most incandescent, compact fluorescent (CFL) and light-emitting diode (LED) light bulbs. The Energy Labeling Rule has several exceptions for various lamp types, so it’s a good idea to review specific definitions for answers about coverage. See 16 CFR § 305.2 and § 305.5.

the correlated color temperature of each lamp included in the package, measured in degrees Kelvin, expressed as “Light Appearance” and by a number and a marker placed proportionately on a scale ranging from 2,600 K on the left to 6,600 K on the right

the ENERGY STAR logo for qualified products, if you wish. Manufacturers who have a signed Memorandum of Understanding with the Department of Energy or the Environmental Protection Agency may add the ENERGY STAR logo to labels on qualifying covered products that are covered by the Memorandum of Understanding

the lamp"s average initial lumens, expressed as a number rounded to the nearest five, next to the word “lumens,” both in minimum eight point font, and

If the total surface area of the product package available for labeling is less than 24 square inches, and the package shape or size cannot accommodate the standard label, you may provide the information using asmaller linear label. See 16 CFR § 305.15.

Specialty consumer lamps include most lamps with a medium screw, candelabra screw, a GU-10, or GU-24 base and a lumen range between 310 lumens and no more than 2,600 lumens, or a rated wattage between 30 and 199. The term does not cover any lamp that qualifies as a general service lamp. The Energy Labeling Rule has several exceptions for various lamp types, so it’s a good idea to review specific definitions for answers about coverage. See sections305.5and305.23of the Rule for details about the coverage.

Manufacturers may use the Lighting Facts label required for general service lamps or the smaller version of the Lighting Facts label for most specialty consumer lamps, as long as it appears on the principal display panel. However, a specialty consumer lamp that is a vibration-service lamp, rough service lamp, appliance lamp or shatter resistant lamp must use the Lighting Facts labels (and follow all other requirements) applicable for general service lamps.

If the required disclosures (i.e., either the abbreviated specialty bulb disclosure or the standard general service lamp label) would not be legible on the front of a single-card blister package due to its size, you may use a smaller label on the principal display panel that says “See Back for Lighting Facts,” and include the full Lighting Facts label on the back of the package.

You must ensure that you enter the correct data for your products. If you have signed a Memorandum of Understanding with the Department of Energy or the Environmental Protection Agency, you may use labels with the ENERGY STAR logo, but only on certified models listed on the ENERGY STAR website. SeeEnergystar.govfor more information.

You must use Department of Energy (DOE) test procedures for any lamps (e.g., general service lamps), covered by those procedures. You may find themhere. See 10 CFR Part 430, 10 CFR Part 431, and 10 CFR § 429.11.

If a lamp is not covered by DOE tests, you must have competent and reliable scientific evidence to support the representations you make on the required label. See 16 CFR § 305.8.

Here is asample of a bilingual label. All the required information must appear in both languages, but you don’t need to repeat numeric characters that are identical in both languages. The amendments don’t allow a trilingual label. See 16 CFR § 305.23.

No. The Rule doesn’t require you to get FTC approval before you label and sell the products. However, you must meet the FTC reporting requirements before you distribute products that are covered by the Rule. You also must comply with the Rule’s testing requirements. See the previous question: What test procedures must I use to support the content of my Lighting Facts label?

If you are a manufacturer of general service lamps or specialty consumer lamps covered by the labeling requirements, you must post images of the Lighting Facts labels for the products on a publicly available website so website retailers can hyperlink to the labels or download them. The label for each model must remain on the website for six months after production of that model ends. See 16 CFR § 305.6.

A manufacturer, distributor, retailer, or private labeler who advertises a general service lamp on a website or in a print catalog that contains the terms of sale, retail price, and ordering instructions for consumers, must disclose clearly and conspicuously, on the page listing the lamp, an image of the Lighting Facts label.

The labels must be clear and conspicuous, and appear in close proximity to the lamp’s price on each page that contains a detailed description of the lamp.

The Rule requires reports for general service incandescent lamps and CFLs. It does not require reports for general service light-emitting diode (LED or OLED) lamps or specialty consumer lamps. See 16 CFR § 305.8.

You can submit the reports required by the FTC through the Department of Energy’s Compliance Certification Management System (CCMS) atregulations.doe.gov/ccms. The reports must contain the same content the Department of Energy requires under its certification rules. See 16 CFR § 305.8 and 10 CFR Part 429.

Yes. You have the option to use the Lighting Facts label on lamps that do not meet the definition of general service lamp or specialty consumer lamp, as long as you comply with all the Rule’s requirements for specialty consumer lamps.

Due to aggressive automated scraping of FederalRegister.gov and eCFR.gov, programmatic access to these sites is limited to access to our extensive developer APIs.

If you are human user receiving this message, we can add your IP address to a set of IPs that can access FederalRegister.gov & eCFR.gov; complete the CAPTCHA (bot test) below and click "Request Access". This should only be necessary once for each IP address you access the site from.

If you want to request a wider IP range, first request access for your current IP, and then use the "Site Feedback" button found in the lower left-hand side to make the request.

We are an on-demand lighting specialty distributor. We do not have brands or items we try to sell you on, we simply listen to customers and then stock the items and brands they have requested. We have been online since 2007 and have over 75 years of lighting knowledge between our 2 head tech support managers. If it’s an item in one of our categories of items we sell we will be able to get it or suggest an alternative.

Replacing your fluorescent tube lights with LED retrofits can be a confusing and daunting process. We"ve put together this guide to demystify all of the ins and outs of replacing your fluorescent tubes with LED tube lights.

Because fluorescent fixtures are often mounted into ceilings and connected directly to mains electricity, they are relatively expensive and difficult to replace completely.

As a result, it oftentimes makes the most economical sense to simply use the same fluorescent fixture, but replace the fluorescent tube with an LED tube light.

Therefore, it is important to understand the types of fluorescent tubes that were developed, so that the correct LED tube light can be retrofitted in place.

T12 4-ft: Four-foot T12 fluorescent lamps are less efficient compared to T8 lamps. They are the same length as T8 lamps, but have a larger 1.5 inch lamp diameter.

T5 4-ft: Four-foot T5 fluorescent lamps are typically the most efficient, and some of the newest types of lamps introduced in the 2000"s in the USA. They are commonly designated T5HO (high output) and provide more brightness than their T8 counterparts. They are slightly shorter than four feet (45.8 inches). T5 lamps come in a variety of lengths such as 1-ft, 2-ft and 3-ft versions and are commonly used in non-ceiling fixtures such as table lamps.

All fluorescent tube lights use a device called a ballast to regulate the lamp"s brightness as it warms up. These devices are necessary for fluorescent lamps, and differ from incandescent lamps which can be connected directly to mains electrical circuits.

Fluorescent lamp fixtures typically house the ballast inside the fixture, and is not accessible without removing the fixture from the ceiling. Alterations to the fluorescent lamp ballast should be done only by those comfortable and knowledgeable with electrical work.

LED lamps, on the other hand, operate differently from fluorescent lamps, and do not utilize a ballast (but do utilize electronic components that make up the LED driver).

Early LED tube lights required removing or bypassing the fluorescent ballast. Now, many LED tube lights are designed to be compatible with fluorescent ballasts, allowing for a simple replacement of the fluorescent tube, without re-wiring the fixture. Below, we discuss the common terms used for each of these configurations.

Commonly designed "UL Type A" - these LED tube lights are designed to be compatible with fluorescent ballasts. They are the most straightforward to implement, since it does not require rewiring the fluorescent fixture.

Ideal for: Consumers not comfortable with or preferring to avoid electrical wiring work, lighting installations where electrician labor costs are high

Disadvantages: Fluorescent ballasts can fail, requiring continued maintenance and eventual replacement or bypass of the ballast; potential issues with fluorescent ballast compatibility; lower overall electrical efficiency due to ballast.

LED tube lights that have  a "UL Type B" specification are not compatible with fluorescent ballasts. They cannot be used with the fluorescent ballast, and must be connected directly to mains electricity. The LED driver, however, is integrated into the LED tube itself.

In a single-ended configuration, only the two pins on one end of the tube are used (one pin = live; one pin = neutral), and the two pins on the other end are not electrically functional, and only used for holding the lamp in place.

For single-ended configurations, the direction in which a lamp is installed is important - incorrect configurations can lead to a lamp that does not illuminate, or a potentially hazardous fire risk. Single-ended configurations will typically have a sticker label on one end of the tube with the words "AC INPUT" or similar. Some single-ended configurations can accept power from either end.

In a double-ended configuration, the two pins on each side of the tube are the same polarity. Therefore, the lampholders on one end of the tube must be connected to [neutral], while the other must be connected to [positive].

UL Type C LED tubes are relatively uncommon, but offer the most flexibility and efficiency for a lighting system. Unlike a UL Type B LED tube, these do not have the LED driver integrated into the LED tube, and therefore requires a separate LED driver device to be connected between the LED tube and mains electricity.

Ideal for: lowest maintenance costs as LED drivers can be replaced without replacing the whole LED tube; more LED driver options such as 0-10V dimming and other IoT connectivity.

Tombstones are the "sockets" or lampholders that the LED tube lights will be installed into, providing both the mechanical support as well as electrical current.

Scenario ii) is called non-shunted, while scenario iii) is called shunted. "Shunting" refers to the joining of two separate circuits into one. The result of shunting is that both tombstone contacts connect to the same electrical polarity.

In general, fluorescent fixtures that have never been altered for LED or instant-start ballasts have non-shunted tombstones, while those that have been altered for LED or instant-start ballast may have shunted tombstones.

Sometimes, tombstones are externally shunted, as shown in the photo above, where the wire inputs are only open on one side. In some cases, however, tombstones can be internally shunted, where the wire inputs on both sides are open, but are connected inside the tombstone.

Since some tombstones are internally shunted, visually checking the tombstones does not provide a conclusive result. We strongly recommend testing the two tombstone contacts with a voltmeter to determine whether a closed or open circuit exists. A closed circuit will indicate shunted tombstones.

If your LED tube light is single-ended, it is NOT compatible with shunted tombstones. This is because each of the two contacts in the tombstone must be opposite polarity for a single-ended LED tube light to work. In a shunted tombstone, however, this is not possible as there will be an internal short circuit.

If you have shunted tombstones, you will need to rewire or replace them and connect them to match the single-ended LED tube light manufacturers" wiring diagram.

If your LED tube light is double-ended, it is likely compatible with both shunted and non-shunted tombstones. The reason is that the two pins on each end of the LED tube light expect the same polarity, so whether or not they are shunted should have no influence on the final resulting circuit.

Keep in mind this section discusses whether or not the tombstone itself is shunted vs non-shunted - be sure to connect the wires into the tombstone correctly to match the manufacturers" wiring diagram to ensure safe installation.

We recommend looking for LED tubes that are compatible with any of the potential electrical configurations in a fluorescent fixture - for example, Waveform Lighting"s T8 3-in-1 LED tubes.

Commonly characterized as the core photoelectric specifications, it"s also important that the emitted light qualities are similar or exceed your current fluorescent tube lighting.

Most fluorescent tube lights have a correlated color temperature (CCT) of 4000K or 5000K, as they have been considered to be most suitable for retail and office environments, respectively. Many fluorescent lamp phosphor developments over the years, however, have enabled a wide range of color temperatures.

Similarly, LED tube lights are also available in a wide range of color temperatures. Generally, the color appearance will be similar between an LED tube light and fluorescent tube light with the same color temperature rating.

Luminous flux, measured in lumens, measures the total amount of light emitted from a lamp, and is the best measure to determine the brightness of a lamp.

The best way to make an apples-to-apples comparison is to compare the luminous flux value of the fluorescent lamp with the LED tube light. Generally, a 35W T8 fluorescent lamp emits about 2500 lumens.

One thing to note about LED tube lights is that they tend to direct light downward, rather than a full 360 degrees in a fluorescent lamp. Therefore, when installed in a ceiling fixture, an LED tube light may provide more useful lumens, since the light is directed downwards rather than back into the fixture as in a fluorescent lamp.

CRI measures the extent to which objects" color appear true and accurate under a light source. Most fluorescent lamps have a CRI rating of 80 or so, and the majority of LED tube lights also come in at around 80 CRI as well. 80 CRI is acceptable for most applications, but for enhanced color quality and environments where color perception is important, look for a higher CRI rating in an LED tube light.

Finally, we"ll talk a bit about the cost considerations for making an LED tube light purchase. In recent years, LED tube lights have come down in price to a level that competes with fluorescent lamps, so the purchase price of the lamps makes LED tube lights a very appealing option.

If, however, the LED tube light you selected is not a UL Type A lamp, you will incur electrical rewiring labor costs. For a large or commercial installation, these costs may be significant depending on the complexity of the rewiring necessary for the fluorescent fixture. Typically, it can take a trained electrician 15-25 minutes per 4-lamp fluorescent fixture.

If we assume it takes an hour for an electrician charging $100 per hour to complete the rewiring of 3x 4-lamp fluorescent fixtures, we can calculate a labor cost of more than $8 per lamp. You can see how labor costs quickly add to the initial costs of the project - adding to the appeal of UL Type A compatible LED tube lights.

Calculate the amount of electricity and maintenance costs that LED tube lights will save, and determine the payback period. Generally, the shorter the better!

Also, consider the warranty terms of the manufacturer. Ideally, the payback period is shorter than the warranty, as that way, you are insured against any premature product failures that jeopardize the cost savings of going with LED tube lights.

The Bulb Eater® 3 is the next generation of Bulb Eater® Lamp Crusher which crushes spent fluorescent lamps of any length into 100% recyclable material while capturing over 99.99% of the vapors released. The system, which is mounted onto a 55-gallon container, can hold up to 1350 4-foot fluorescent lamps

The Bulb Eater® 3 lamp crusher unit is equipped with a side-mounted dust filter unit containing the highest quality HEPA filter available. This works in conjunction with an activated carbon filter located in a steel canister. The activated carbon filter actively captures and neutralized the mercury vapor released from the lamps during crushing. A recent study showed non-detectable levels of escaped mercury vapor even after crushing 1500 lamps (Bulb Eater® 3 Air Emissions Report). The Bulb Eater® 3 features a new 5 stage filter system, a digital control with LCD display, self-diagnostic fault codes, and a higher motor speed for increased lamp waste per drum.

In addition to providing OSHA and ACGIH compliance, the Bulb Eater® 3 lamp crusher frees up valuable storage space normally filled with boxes of spent whole lamps, reduces handling and related labor costs, and typically cutsrecyclingcosts by 50% or more.

A vacuum fluorescent display (VFD) is a display device once commonly used on consumer electronics equipment such as video cassette recorders, car radios, and microwave ovens.

A VFD operates on the principle of cathodoluminescence, roughly similar to a cathode ray tube, but operating at much lower voltages. Each tube in a VFD has a phosphor-coated carbon anode that is bombarded by electrons emitted from the cathode filament.triode vacuum tube because it also has a mesh control grid.

Unlike liquid crystal displays, a VFD emits very bright light with high contrast and can support display elements of various colors. Standard illumination figures for VFDs are around 640 cd/m2 with high-brightness VFDs operating at 4,000 cd/m2, and experimental units as high as 35,000 cd/m2 depending on the drive voltage and its timing.Cadmium was commonly used in the phosphors of VFDs in the past, but the current RoHS-compliant VFDs have eliminated this metal from their construction, using instead phosphors consisting of a matrix of alkaline earth and very small amounts of group III metals, doped with very small amounts of rare earth metals.

VFDs can display seven-segment numerals, multi-segment alpha-numeric characters or can be made in a dot-matrix to display different alphanumeric characters and symbols. In practice, there is little limit to the shape of the image that can be displayed: it depends solely on the shape of phosphor on the anode(s).

The device consists of a hot cathode (filaments), grids and anodes (phosphor) encased in a glass envelope under a high vacuum condition. The cathode is made up of fine tungsten wires, coated by alkaline earth metal oxides (barium,electrons when heated to 650 °Cdiffused by the grids (made using Photochemical machining), which are made up of thin (50 micron thick) stainless steel.fluoresce, emitting light. Unlike the orange-glowing cathodes of traditional vacuum tubes, VFD cathodes are efficient emitters at much lower temperatures, and are therefore essentially invisible.graphite, which in turn is coated with phosphor. This transfers energy from the trace to the segment. The shape of the phosphor will determine the shape of the VFD"s segments. The most widely used phosphor is Zinc-doped copper-activated Zinc oxide,

The cathode wire to which the oxides are applied is made of tungsten or ruthenium-tungsten alloy. The oxides in the cathodes are not stable in air, so they are applied to the cathode as carbonates, the cathodes are assembled into the VFD, and the cathodes are heated by passing a current through them while inside the vacuum of the VFD to convert the carbonates into oxides.

The principle of operation is identical to that of a vacuum tube triode. Electrons can only reach (and "illuminate") a given plate element if both the grid and the plate are at a positive potential with respect to the cathode.multiplexed displays where the multiple grids and plates form a matrix, minimizing the number of signal pins required. In the example of the VCR display shown to the right, the grids are arranged so that only one digit is illuminated at a time. All of the similar plates in all of the digits (for example, all of the lower-left plates in all of the digits) are connected in parallel. One by one, the microprocessor driving the display enables a digit by placing a positive voltage on that digit"s grid and then placing a positive voltage on the appropriate plates. Electrons flow through that digit"s grid and strike those plates that are at a positive potential. The microprocessor cycles through illuminating the digits in this way at a rate high enough to create the illusion of all digits glowing at once via persistence of vision.

The extra indicators (in our example, "VCR", "Hi-Fi", "STEREO", "SAP", etc.) are arranged as if they were segments of an additional digit or two or extra segments of existing digits and are scanned using the same multiplexed strategy as the real digits. Some of these extra indicators may use a phosphor that emits a different color of light, for example, orange.

The light emitted by most VFDs contains many colors and can often be filtered to enhance the color saturation providing a deep green or deep blue, depending on the whims of the product"s designers. Phosphors used in VFDs are different from those in cathode-ray displays since they must emit acceptable brightness with only around 50 volts of electron energy, compared to several thousand volts in a CRT.

Besides brightness, VFDs have the advantages of being rugged, inexpensive, and easily configured to display a wide variety of customized messages, and unlike LCDs, VFDs are not limited by the response time of rearranging liquid crystals and are thus able to function normally in cold, even sub-zero, temperatures, making them ideal for outdoor devices in cold climates. Early on, the main disadvantage of such displays was their use of significantly more power (0.2 watts) than a simple LCD. This was considered a significant drawback for battery-operated equipment like calculators, so VFDs ended up being used mainly in equipment powered by an AC supply or heavy-duty rechargeable batteries.

During the 1980s, this display began to be used in automobiles, especially where car makers were experimenting with digital displays for vehicle instruments such as speedometers and odometers. A good example of these were the high-end Subaru cars made in the early 1980s (referred to by Subaru enthusiasts as a digi-dash, or digital dashboard). The brightness of VFDs makes them well suited for use in cars. The Renault Espace and older models of Scenic used VFD panels to show all functions on the dashboard including the radio and multi message panel. They are bright enough to read in full sunlight as well as dimmable for use at night. This panel uses four colors; the usual blue/green as well as deep blue, red and yellow/orange.

This technology was also used from 1979 to the mid-1980s in portable electronic game units. These games featured bright, clear displays but the size of the largest vacuum tubes that could be manufactured inexpensively kept the size of the displays quite small, often requiring the use of magnifying Fresnel lenses.LCD games could be manufactured for a fraction of the price, did not require frequent changes of batteries (or AC adapters) and were much more portable. Since the late 1990s, backlit color active-matrix LCD displays have been able to cheaply reproduce arbitrary images in any color, a marked advantage over fixed-color, fixed-character VFDs. This is one of the main reasons for the decline in popularity of VFDs, although they continue to be made. Many low-cost DVD players still feature VFDs.

From the mid-1980s onwards, VFDs were used for applications requiring smaller displays with high brightness specifications, though now the adoption of high-brightness organic light-emitting diodes (OLEDs) is pushing VFDs out of these markets.

Vacuum fluorescent displays were once commonly used as floor indicators for elevators by Otis Elevator Company worldwide and Montgomery Elevator Company in North America (the former from the early 1980s to the mid-2000s in the form of (usually two) 16-segment displays, and the latter from the mid 1980s to the mid 1990s in the form of (usually 3) 10x14 dot-matrix displays).

In addition to the widely used fixed character VFD, a graphic type made of an array of individually addressable pixels is also available. These more sophisticated displays offer the flexibility of displaying arbitrary images, and may still be a useful choice for some types of consumer equipment.

Several radio amateurs have experimented with the possibilities of using VFDs as triode amplifiers.Korg released the Nutube, an analogue audio amplifier component based on VFD technology. The Nutube is used in applications such as guitar amplifiers from Vox

Fading is sometimes a problem with VFDs. Light output drops over time due to falling emission and reduction of phosphor efficiency. How quickly and how far this falls depends on the construction and operation of the VFD. In some equipment, loss of VFD output can render the equipment inoperable. Fading can be slowed by using a display driver chip to lower the voltages necessary to drive a VFD. Fading can also occur due to evaporation and contamination of the cathode. Phosphors that contain sulfur are more susceptible to fading.

Emission may usually be restored by raising filament voltage. Thirty-three percent voltage boost can rectify moderate fade, and 66% boost severe fade.

Of the three prevalent display technologies – VFD, LCD, and LED – the VFD was the first to be developed. It was used in early handheld calculators. LED displays displaced VFDs in this use as the very small LEDs used required less power, thereby extending battery life, though early LED displays had problems achieving uniform brightness levels across all display segments. Later, LCDs displaced LEDs, offering even lower power requirements.

The first VFD was the single indication DM160 by Philips in 1959. It could easily be driven by transistors, so was aimed at computer applications as it was easier to drive than a neon and had longer life than a light bulb. The 1967 Japanese single digit seven segment display in terms of anode was more like the Philips DM70 / DM71 Magic Eye as the DM160 has a spiral wire anode. The Japanese seven segment VFD meant that no patent royalties needed to be paid on desk calculator displays as would have been the case using Nixies or Panaplex neon digits. In the UK the Philips designs were made and marketed by Mullard (almost wholly owned by Philips even before WWII).

The Russian IV-15 VFD tube is very similar to the DM160. The DM160, DM70/DM71 and Russian IV-15 can (like a VFD panel) be used as triodes. The DM160 is thus the smallest VFD and smallest triode valve. The IV-15 is slightly different shape (see photo of DM160 and IV-15 for comparison).

Joseph A. Castellano (ed), Handbook of display technology, Gulf Professional Publishing, 1992 ISBN 0-12-163420-5 Chapter 7 Vacuum Fluorescent Displays pp. 163 and following

N9WOS (29 July 2005). "VFD as an audio/RF amplifier?". Electronics Point forums. Archived from the original on 11 March 2018. Retrieved 11 March 2018.
