The Main Display interface is the primary user interface in the EST3 Life Safety System. The main display interface focuses on the emergency user by putting information important to the user up front. Hands free, the first highest priority event is shown. The display always gives the last highest priority event. Arriving at the panel and without opening the door the first and last alarm is given. Simple to understand lights and switches help the emergency user execute system commands with confidence.

Ensuring information clarity the 3-LCDXL uses a backlit high contrast super-twist display. 24 lines of 40 characters provide the room needed to convey emergency information in a useful format.

The 3-LCDXL always displays the last highest priority event even when the user is viewing other message queues. Further message flexibility is provided with EST3’s message routing ability. Messages from a node can display at every node on the network or messages can route to specific nodes only. Routing can be initiated at a specific time/shift change. There is no need to have messages display in areas that are not affected by an event.

The EST3 system configures for Local or Proprietary operation in compliance with U.S. or Canadian marketplace requirements. The mode of operation is selected through the System Definition Utility (SDU) which may adjust the following operations slightly to fit the system operation selected.

Established in 2003, JKFire commands an unflinching corporate trust in the field of fire, safety and security systems. JK works under the fundamental principle of providing effective systems that preempts any eventuality and defuses potential dangers.

Maintaining independence and editorial freedom is essential to our mission of empowering investor success. We provide a platform for our authors to report on investments fairly, accurately, and from the investor’s point of view. We also respect individual opinions––they represent the unvarnished thinking of our people and exacting analysis of our research processes. Our authors can publish views that we may or may not agree with, but they show their work, distinguish facts from opinions, and make sure their analysis is clear and in no way misleading or deceptive.

EST3X represents the latest generation of life safety control panels for mid to large sized applications. With large multi-message displays and innovative controls, intuitive interfaces, and bold colored cabinets — these systems capture the imagination, and catch the eye. But behind the LCD display is where they really shine.

New microprocessors and chipsets take full advantage of the latest advances in computing technology, leading to smarter, faster, higher-capacity processing and more efficient designs. EST3X’s patented Voltage Boost™ technology, for example, delivers consistent voltage – even at low battery power – resulting in lighter cable requirements and/or longer runs. That saves time and money.

High performance processing also leads to powerful networking features and versatile digital audio functionality. The wide range of EST3X configurations include standalone operation, networking with up to 64 nodes, or integration with an EST3 network comprising as many as 64 nodes — complete with EST3-Sixty mass notification capabilities and display of security events.

EST3X sets a new standard in front-panel life safety control interfaces. Its exclusive SpeedTouch™ rotary control offers nimble forward and back scrolling through events and options, while a mere tap of the control selects items with an unprecedented fluidity of motion. Its extra-large backlit display reveals up to eight concurrent messages, and switch/LED strips provide ample space for meaningful custom labels. And for end users, large tactile control buttons instill confidence and promote quick response when time is of the essence.

The 3-LCDXL1 module mounts to the 3-CPU and extends over the first four local rail module slots. The 3-LCDXL1 module is optional in any network node. EST3 networks can support any combination of 3-LCDXL1 and 3-LCD display modules. Ensuring information clarity the 3-LCDXL1 uses a backlit high contrast supertwist display. 24 lines of 40 characters provide the room needed to convey emergency information in a useful format. The 3-LCDXL1 always displays the last highest priority event even when the user is viewing other message queues. Further message flexibility is provided with EST3’s message routing ability. Messages from a node can display at every node on the network or messages can route to specific nodes only. Routing can be initiated at a specific time/shift change. There is no need to have messages display in areas that are not affected by an event. The 3-LCDXL1 can display system messages in either English, French or Spanish. The EST3 system configures for Local or Proprietary operation in compliance with U.S. or Canadian marketplace requirements. The mode of operation is selected through the System Definition Utility (SDU) which may adjust the following operations slightly to fit the system operation selected.

The 3-LCD series of display modules is the primary user interface for the EST3 Life Safety System. Designed specifically to meet the latest Control Panel Standard the 3-LCDXL1 provides 8 simultaneous events to be displayed. Emergency operator information shows the first 7 highest priority events in addition to the most recent event. Simple to understand LEDs and switches help the emergency user to display information and execute system commands with confidence.

Located below the general status LEDs are four, LED / Switch common controls. The versatility of EST3 allows system designers to define the features as affecting a domain (defined group of nodes) or as global (affects all nodes) across the network. This feature is very useful when configuring systems with multiple buildings on one network. As an example, operating the reset in one building may have adverse effect in other buildings. With EST3, having operational differences between buildings on the same network is not a problem.

Pressing Reset starts the system’s reset operation. The yellow LED has three flash rates during reset. The LED flashes fast during the smoke power down phase of reset, flashes slow during the restart phase, and turns on steady for the restoral phase. The Reset LED turns off when the system is normal. Pressing Alarm Silence turns off all Notification Appliance Circuits defined as audible. The yellow LED turns on when silence is active via the Alarm Silence switch or via alarm silence software timers. Pressing Panel Silence turns off the system’s internal audible signal. The yellow LED turns on when panel silence is active.

The “Selected Alarm” window, lines 2, 3, 4 automatically display the first active event of the highest priority if the user has not taken control of the system. Once the emergency user takes control, this window displays user message selections. The system events window of the display shows system event information.

WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.govEDWARDS 3-LCD

Use our “Get an Estimate” tool to review potential costs if you get service directly from Apple. The prices shown here are only for screen repair. If your iPhone needs other service, you’ll pay additional costs.

If you go to another service provider, they can set their own fees, so ask them for an estimate. For service covered by AppleCare+, your fee per incident will be the same regardless of which service provider you choose.

Replacement equipment that Apple provides as part of the repair or replacement service may contain new or previously used genuine Apple parts that have been tested and pass Apple functional requirements.

Edwards has announced that new orders for the EST3 fire alarm panel will halt on December 31, 2023. Edwards will continue to provide parts and supporting materials for all their products to the extent possible.

If you recently installed new EST3 products, know that you will experience a full lifetime of quality performance from your system. And when you’re ready, Edwards and Performance Systems Integration (PSI) are prepared to support your upgrade to the next generation of Edwards panels.

At PSI, our factory-trained and NICET-certified technicians provide comprehensive fire and life safety services—monitoring, testing and inspecting, system maintenance, installations, and code compliance consultations—all under one agreement.

The EST3 Life Safety Platform entered the market in 1996 as one of the most advanced life safety systems available. Edwards then introduced the EST4 as the next-generation life safety system platform in 2019. The EST4 is fully backward compatible and based on the newest, most advanced technology available.

PSI has been an Edwards Strategic Partner since its founding and has provided industry-leading support for the entire Edwards product line. We have embraced the introduction of the EST4 and already have technicians trained with experience accumulated since 2019 in all markets, providing design, installation support, inspection, testing, and maintenance services.

If you currently have an EST3 operating in your facility, rest assured that we can, and will, continue to support your system. Of course, it is always prudent to plan for your system’s inevitable end of life. PSI can help evaluate your facility and provide professional, code-compliant, guidance for planning and budgeting.

Since the EST4 is fully backward compatible with the EST3 product line, we can help develop a plan to systematically upgrade over time so that your budget can be spread out over several years rather than taking an emergency budget hit if the system is compromised.

If you are in the process of installing new EST3 products, know that you will experience a full lifetime of quality performance from your new, PSI-provided, Edwards products. But we understand if you’re a bit nervous about it. PSI stocks Edwards service parts locally, and our history with Edwards gives us confidence that they will continue to provide parts and supporting materials for all their products as much as possible.

Our NICET-certified technicians will continue to provide services considered by our customers to be best in class. Contact us today to service your EST3 panel, or to plan your upgrade to the EST4.
