The EA 9707-V24S interface allows dot-matrix LCDs to be programmed easily and quickly. The interface can be soldered directly onto almost all dot-matrix modules. It is connected to a standard RS-232C interface.

The data transmission rate can be set to 300, 1200, 2400 or 9600 bps. Umlauts (ä, ö, ü, ß, Ä, Ö, Ü) are interpreted as extended IBM code and recoded. If the display is full, it scrolls upward automatically. CR ($0D,13d) and LF ($0A,10d) are identified and executed. This automatic function can be switched off for individual cursor positioning. The supply voltage is +5V/typ. 1mA. The interface can also be supplied with an RS-422 interface (EA 9707 OPT-RS-422).

WH2402A is 24 characters by 2 lines LCD 24x2 display module which is built in with ST7066 controller IC; its default interface is 6800 4/8-bit parallel. This LCD display 24x2 model WH2402A is available for without backlight or with LED backlight options. This display LCD 24x 2 modules is available in various LCD panel colors including gray, yellow/green and blue LCD options. The LEDs can be driven by pin 1, pin 2, or pin 15 pin 16 or A/K. There are different character fonts/texts available for ST7066 IC including English/Japanese, English/West European, English/Scandinavian European, or English/Cyrillic (Russian) as options.

Newhaven 24x2 character Liquid Crystal Display shows characters with dark pixels on a bright white background when powered on. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0224BZ1-FSW-FBW display has an optimal view of 6:00. This display operates at 5V supply voltage and is RoHS compliant.

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

A 2 x 24 LCD display has 2 x 40 addresses. That means that if you want to wrap to the second line after 22 characters, you need to do one of the following:

Go to my web site www.mjbc.ch and download the free program VIPpanel. It includes an LCD simulator (several different types) and allows all possible commands to be tested, including creating your own characters in a user friendly dialog. Command - View | LCD Control Panel - It includes detailed user documentation and can also be used to establish a connection to an Internet enabled LCD in my lab, which you can also control to be sure that the commands are really accurate... See the LCD at the web cam http://212.254.22.36:8080 and configure VIPpanel to communicate withe the IP address 212.254.22.36 Port 1923.

The VIPpanel also allows complete front panels to be designed (with upto 256 keys and 256 LEDs and an LCD of choce). It can then be used as virtual front panel (hence the name VIPpanel = VIrtual Prototyping Panel) and controlled either via the COM port or via a TCP/IP socket connection - all details are in the user manual.
