This LCD is a 240x320 resolution IPS TFT display. The IPS technology delivers exceptional image quality with superior color representation and contrast ratio at any angle. This 8-bit/16-bit parallel interface Liquid Crystal Display is RoHS compliant and has a 4-wire resistive touchscreen.

Enhance your user experience with capacitive or resistive touch screen technology. We’ll adjust the glass thickness or shape of the touch panel so it’s a perfect fit for your design.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

Equip your display with a custom cut cover glass to improve durability. Choose from a variety of cover glass thicknesses and get optical bonding to protect against moisture and debris.

ER-TFT028-4 is 240x320 dots 2.8" color tft lcd module display with ILI9341 controller and optional capacitive touch panel and 4-wire resistive touch panel,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports 8080 8-bit,9-bit,16-bit,18-bit parallel,3-wire,4-wire serial spi interface. FPC with zif connector is easily to assemble or remove.Lanscape mode is also available.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 2.8"TFT Touch Shield with Libraries, Examples.Schematic Diagram for Arduino Due,Mega 2560 and Uno . For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.

ER-TFTM028-4 is 240x320 dots 2.8" color tft lcd module display with ILI9341 controller board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

It supports 8080 8-bit /9-bit/16-bit /18-bit parallel ,3-wire,4-wire serial spi interface.Built-in optional microSD card slot, 2.8" 4-wire resistive touch panel with controller XPT2046 and 2.8" capacitive touch panel with controller FT6206. It"s optional for font chip, flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested. Lanscape mode is also available.

Of course, we wouldn"t just leave you with a datasheet and a "good luck!".Here is the link for 2.8"TFT Touch Shield with Libraries, EXxamples.Schematic Diagram for Arduino Due,Mega 2560 and Uno . For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and development kit at the bottom of this page.

This is a 2.8” TFT Resistive Touchscreen Display. The module, with a resolution of 320x240, adopts ILI9341 as driver IC and SPI (4-line) communication mode. The board integrates touch chip XPT2046, which converts the touch data collected by the AD to SPI data. The module also integrates an SD card slot allowing you to easily read the full-color bitmap. There are two modes of wiring supplied, normal pin header wiring and GDI. The latter one requires to work with a main controller board with a GDI interface (e.g. FireBeetle-M0). You can use it with only one FPC line plugging in, which reduces the complexity of the wiring. Furthermore, it features high resolution, wide viewing angle, and simple wiring, which can be used in all sorts of display applications, such as, IoT controlling device, game console, desktop event notifier, touch interface, etc.

Backlight. The backlight is set to the default value, and the user can light up without connecting the backlight pin; in addition, when the backlight pin is connected, input high level (1) to adjust the backlight brightness to the maximum, input low level (0) to turn off the backlight

This product is Breakout module with SPI communication mode and GDI interface, which reduces the wiring complexity and makes it easy to display what was read from the SD card.

The provided display driver example code is designed to work with Microchip, however it is generic enough to work with other micro-controllers. The code includes display reset sequence, initialization and example PutPixel() function.

Please see the DT028CTFT for reference designs. The schematics between the A and the C are the same with the exception that the A does not have the IPS interface.

The provided display driver example code is designed to work with Microchip, however it is generic enough to work with other micro-controllers. The code includes display reset sequence, initialization and example PutPixel() function.

Please see the DT028CTFT for reference designs. The schematics between the B and the C are the same with the exception that the B does not have the IPS interface.

With four bright white LED backlight and 240 x 320 pixels with individual RGB pixel control, this colour 2.8in. TFT display features a resistive touchscreen for fingertip detection across the entire screen surface. The workload is lifted from the microcontroller by a built-in controller equipped with RAM buffering, and the display board has two modes: 8-bit and SPI.

1st generation: with flat display area and flat touch area, the border can be curved. Orient Display uses glass touch sensor and IML (In-Mold Lamination) technology to produce the products.

2nd generation: with flat display area and flat touch area, the border area can be flat or cuver in the middle. Orient Display still uses glass touch sensor and cold bending lens to produce this kind of products.

3rd generation: with flat display area and curve touch area, the border area can be flat or cuver in the middle. Orient Display uses glass or film touch sensor and hot bending lens to produce this kind of products.

4th generation: with curve display area and curve touch area, the border area can be flat. Orient Display uses flexible touch sensor to produce this kind of products.

Based on the above five types of touch panel technology, Orient Display can also add different kinds of features like different material glove or stylus or pencil touch, water environment touch, salt water environment touch, hover touch, force (3 dimensional) touch, haptic touch etc. Orient Display can also provide from very low-cost fixed area button touch, single (one) finger touch, double finger (finger+ gesture) touch, 5 finger touch, 10 points touch or even 16 points touch.

Considering the different shapes of the touch surface requirements, Orient Display can produce different shapes of 2D touch panel (rectangle, round, octagon etc.), or 2.5D touch screen (round edge and flat surface to create edge-less impression) or 3D (totally curved surface) touch panel.

Considering different strength requirements, Orient Display can provide low-cost chemical tampered soda-lime glass, Asahi (AGC) Dragontrail glass and Corning highest generation Gorilla glass. With different thickness requirement, Orient Display can provide the thinnest 0.5mm OGS touch panel, to thickness more than 10mm tempered glass to prevent vandalizing, or different kinds of plastic touch panel to provide glass piece free (fear) or flexible substrates need.

Orient Display can also provide full customized or part customized solutions for our customers to enhance the viewing experience. Orient Display can provide all the different kinds of surface treatments, such as AR (Anti-reflection); AG (Anti-glare), AF (Anti-finger print or Anti-smudge); AS (Anti-smashing); AM (Anti-microbial), IMITO (Index Matching Indium Tin Oxide), Anti Sparkling etc.

Orient Display can also provide both dry bonding (OCA, Optical Clear Adhesive), or wet bonding (OCR, Optical Clear Resin and OCG, Optical Clear Glue) to get rid of light reflective in air bonding products to produce high end touch screen monitor much more readable under sunlight and much more robust as well.

Touch panels have been a much better human machine interface which become widely popular. Orient Display has been investing heavy for capacitive touch screen sensor manufacturing capacity and LCD module production ability. With Orient huge production capacity, top notch quality, and competitive pricing, Orient has been working with top LCD panel manufacturers ,AUO, BOE, LG, Innolux and top touch controller manufacturers , Atmel (Microchip, Cypress, Synaptics, Elan, NXP, Goodix, Sharp, Hydis etc. to provide the best touch display technology in the market, such as IPS, MVA, in-cell, on-cell, automotive grade etc.

It is a new technology replace ink printing cover plate with visual area and black border area are integrated with seamless black design using AG/AR surface treatment. Non ink printing AR/AR seamless black optical cover plate can be customized to match touch display module to achieve the best integrated seamless black solution.

With high transmittance rate of over 90% low optical delay, no interference and Moore fringe phenomenon, low square resistance ITO of lower than 20 ohms , white and clear with yellow index Yi around 1, bending resistance which can last 200,000 times with bending radius R6.5.

With high transmittance rate of over 90% low optical delay, no interference and Moore fringe phenomenon, low square resistance ITO of lower than 20 ohms, white and clear with yellow index Yi around 1, bending resistance which can last 200,000 times with bending radius R6.5.

Orient Display developed a special smoke film which is very low cost but gives the customer a optical bonding performance. Smoke film uses optical interference to reduce the glass-air interface reflection for air (perimeter) bonding between LCD and touch screen.

Found in 2007, SAEF TECH is an experienced LCD/LCM manufacturer. With good quality, professional service, and competitive price, we have been qualified by many wellknown companies around the world. Our strategic customers include LG in Korea(white goods & remote controller), Uniden in Japan(scanner), Cisco in USA(conference phone), Jabil in UK(industrial meter & instrument), Vtech in HK(IP phone in conference room), Ametek in Germany(bulldozer dash board), AML in USA(banking system), Spectrum mfg in Canada(meter), etc.

Raystar ‘s Resistive Touch Screen TFT Display uses 4- wire type of resistive touch screen with advantages of low-power consumption, fast response time and stable quality. With full ranges from small to medium sizes, we set low MOQ in standard products. Comparing to TFT Capacitive Touch screen Display, the Resistive Touch Screen TFT is more competitive.

The resistive structure is sensed by pressure so there is no limitation of contacting forms. Resistive touch screens work smoothly even using a pen or with gloves. TFT display with resistive touch screen can be used on consumer electrical products, such as POS system, security system, control monitors and GPS devices.
