This is the classic example of an LCD that has power but has not been initialized correctly. Lack of initialization can be caused by faulty connections as mentioned above or by incorrect code.

I don"t doubt that you have done all this - but if you did it correctly then the display would be working. This is where the forum can help you, but only if you provide us with more information. A copy of your code and a photo of your setup come to mind.

The Liquid Crystal tutorial at http://arduino.cc/en/Tutorial/LiquidCrystal has been updated. If you connect your display as shown there and cut and paste the code your display should work.

It has to do with the way the LCD glass is laid out. Essentially the display is the right and left halves of a 40×2 mapped to the top and bottom of a 20×4.

If you have any questions about initialization code or how to power up any of our LCD displays, please contact our knowledgeable and friendly support staff by email, phone, or chat.

lcd.display(image[, x=0[, y=0[, x_scale=1.0[, y_scale=1.0[, roi=None[, rgb_channel=-1[, alpha=256[, color_palette=None[, alpha_palette=None[, hint=0[, x_size=None[, y_size=None]]]]]]]]]]]])¶

In this project, we will have brief discussion on how to interface 16×2 LCD module to AT89C51, which is an 8051 family microcontroller. We use LCD display for the displaying messages in a more interactive way to operate the system or displaying error messages etc. Interfacing 16×2 LCD with 8051 microcontroller is very easy if you understanding the working of LCD.

16×2 Liquid Crystal Display which will display the 32 characters at a time in two rows (16 characters in one row). Each character in the display is of size 5×7 pixel matrix. This matrix differs for different 16×2 LCD modules, if you take JHD162A, this matrix goes to 5×8. There are 16 pins in the LCD module, the pin configuration us given below

4RSRS is the register select pin used to write display data to the LCD (characters), this pin has to be high when writing the data to the LCD. During the initializing sequence and other commands this pin should low.

So by reading the above table you can get a brief idea how to display a character. For displaying a character you should enable the enable pin (pin 6) by giving a pulse of 450ns, after enabling the pin6 you should select the register select pin (pin4) in write mode. To select the register select pin in write mode you have to make this pin high (RS=1), after selecting the register select you have to configure the R/W to write mode that is R/W should be low (R/W=0).

Commands:There are some preset commands which will do a specific task in the LCD. These commands are very important for displaying data in LCD. The list of commands given below:

RST Pin is pulled-LOW with the help of a 10KΩ Resistor. With the help of a 10μF Capacitor and a Push Button, you can reset the 8051 Microcontroller. EA is pulled-HIGH with the help of a 10KΩ resistor.

The data pins of the LCD are connected to PORT0 (first, the PORT0 pins must be pulled-HIGH with the help of a 1KΩ Resistor Pack). RS and E are connected to PORT2 pins P2.0 and P2.1.

The programs given below will use above functions and display the complete string which is given by the programmer to display the data. We have provided two demo codes working properly and easy to understand.

Edit: The problem is now solved, I edited the above code to a working model. Although some command seem to fail, I am getting character "a" at the first digit position of the first line, which it should be.

To me it seems that for some reason the LCD module is not initialized correctly as after the MCU and LCD have both been powered up I only see one (first) line full of full-dotted characters (0xFF) and second line is blank although the screen should be cleared during initialization and cursor should be visible.

In this guide we’re going to show you how you can use the 1.8 TFT display with the Arduino. You’ll learn how to wire the display, write text, draw shapes and display images on the screen.

The 1.8 TFT is a colorful display with 128 x 160 color pixels. The display can load images from an SD card – it has an SD card slot at the back. The following figure shows the screen front and back view.

This module uses SPI communication – see the wiring below . To control the display we’ll use the TFT library, which is already included with Arduino IDE 1.0.5 and later.

The 1.8 TFT display can load images from the SD card. To read from the SD card you use the SD library, already included in the Arduino IDE software. Follow the next steps to display an image on the display:

Note: some people find issues with this display when trying to read from the SD card. We don’t know why that happens. In fact, we tested a couple of times and it worked well, and then, when we were about to record to show you the final result, the display didn’t recognized the SD card anymore – we’re not sure if it’s a problem with the SD card holder that doesn’t establish a proper connection with the SD card. However, we are sure these instructions work, because we’ve tested them.

In this guide we’ve shown you how to use the 1.8 TFT display with the Arduino: display text, draw shapes and display images. You can easily add a nice visual interface to your projects using this display.

This tutorial shows how to use the I2C LCD (Liquid Crystal Display) with the ESP32 using Arduino IDE. We’ll show you how to wire the display, install the library and try sample code to write text on the LCD: static text, and scroll long messages. You can also use this guide with the ESP8266.

Additionally, it comes with a built-in potentiometer you can use to adjust the contrast between the background and the characters on the LCD. On a “regular” LCD you need to add a potentiometer to the circuit to adjust the contrast.

Before displaying text on the LCD, you need to find the LCD I2C address. With the LCD properly wired to the ESP32, upload the following I2C Scanner sketch.

After uploading the code, open the Serial Monitor at a baud rate of 115200. Press the ESP32 EN button. The I2C address should be displayed in the Serial Monitor.

Displaying static text on the LCD is very simple. All you have to do is select where you want the characters to be displayed on the screen, and then send the message to the display.

The next two lines set the number of columns and rows of your LCD display. If you’re using a display with another size, you should modify those variables.

Then, you need to set the display address, the number of columns and number of rows. You should use the display address you’ve found in the previous step.

To display a message on the screen, first you need to set the cursor to where you want your message to be written. The following line sets the cursor to the first column, first row.

Scrolling text on the LCD is specially useful when you want to display messages longer than 16 characters. The library comes with built-in functions that allows you to scroll text. However, many people experience problems with those functions because:

After reading the previous section, you should be familiar on how this sketch works, so we’ll just take a look at the newly created function: scrollText()

delayTime: delay between each character shifting. Higher delay times will result in slower text shifting, and lower delay times will result in faster text shifting.

In a 16×2 LCD there are 32 blocks where you can display characters. Each block is made out of 5×8 tiny pixels. You can display custom characters by defining the state of each tiny pixel. For that, you can create a byte variable to hold  the state of each pixel.

In summary, in this tutorial we’ve shown you how to use an I2C LCD display with the ESP32/ESP8266 with Arduino IDE: how to display static text, scrolling text and custom characters. This tutorial also works with the Arduino board, you just need to change the pin assignment to use the Arduino I2C pins.

Then after some research I discovered that, the Arduino SD library is just a colorful wrapper for the SDfatlib, and the actual library has much more options and can be used to debug properly. When I tested the quick start sketch form the newly installed library, I got this error message,

I read in some forum posts that the resistive network introduces a latency in the SPI bus and could be the reason for the problem. So I decided to buy a low cost W5100 Ethernet shield which has an SD card slot (Image of which is featured in the heading of this post).

Most of the Ethernet shields have SD card slot, it would be pointless buying one without it. But again the problem was not solved. It took me a while to find out the solution.

The solution to this problem, is that you have to let digital Pin 10 as output (for the SD library to work) and put out a logic HIGH by adding “digitalWrite(10,HIGH);”. For Arduino Mega you have to do exactly the same ignore pin 53 completely though the comment asks you to change it to 53.

Good news is that you can add this line to all the code and it works perfectly fine (atleast for me). I hope this solves the “SD Card Initialization Failed” problem. If you notice any other problem please leave a comment and I will get back to you.
