This module is engineered for high volume production. It uses a "TAB" (tape automated bonding) or "COF" (chip on flex) style flex tail mated with a "COG" (chip on glass) display. The TAB connector is soldered directly to corresponding pads on your PCB using a hot-bar soldering machine. High volume contract manufacturers will be familiar with this type of construction and its assembly methods. Hot-bar soldering machines designed for prototype, rework or repair of TAB connections are available from equipment suppliers at reasonable cost.

This is an extremely low-power 128x64 graphic LCD display module. It has an integrated white LED backlight that illuminates the display easily in low-light conditions. This display is perfectly suited for hand-held or any application requiring low-power or a very a thin display. It has an integrated controller and the FFC tail is designed to mate with standard 18-conductor 0.5mm pitch ZIF connectors (typical would be Omron XF2L18351A/ DigiKey P/N OR754CT-ND).

Reason: Controller IC ST7565R used on dislay ERC12864FS-1 is hard to source because of the global chip shortage.We now use the compatible IC ST7567S as replacement. The part number is updated to ERC12864FS-1-S7.

ERC12864FS-1-S7 is 1.4 inch white background with 128x64 monochrome black pixels cog(chip on glass) lcd module,ST7565S controller,compact size,high contrast,wide operating temperature,wide view angle,white led backlight,fstn lcd,fpc connection,optional zif connector and led backlight connector.It supports 6800 8-bit,8080 8-bit parallel and 4-wire serial spi interface.

You may wish ERC12864SBS-1 could come with frame backlight without backlight wires ,The part number ERC12864SBSF03-1 should meet this requirment. Except the backlight structure,the other spec is the totally same with ERC12864SBS-1.

ERC12864SBSF03-1 is still not our general product ,we don"t have enough stock .You have to email ([email protected]) our sales to buy samples or orders. Besides the minimum order quantity is no lesss than 1000pcs per order.The production lead time is 5-6 weeks.
