In the consumer world, hardly anyone remembers what CRT stands for. This is particularly true for the younger generations. However, walking through machine shops and plant floors, you are still likely to come across quite a few CNC machine control panels with CRT monitors, still on active duty.

As the replacement CRT monitor stocks are dwindling down, and the CRT repair costs creeping higher and higher, it makes more sense to replace the CRT monitors with the modern flat panel technology.

LCD Monitor retrofits are a perfect solution to replace the ancient CRT technology. Offering dramatically improved image quality, increased power efficiency and reliability, LCD panels are finding their way into old but trusted lathes, mills, and other industrial machines.

Our clients have long since seen this trend. They requested us to develop the solution. We carefully researched machine brand specific monitor requirements, connector types, environmental conditions, and came up with a series of the LCD retrofits for various control/machine brands.

Are you too looking for an LCD panel upgrade? Please contact us at 847-465-9060 or via repair@precisionzone.com with any questions and for the detailed information about supported CNC controls.

Industrial-Panels QES1506 Series LCD Industrial Monitoris a 5.7 inch open frame monitor designed to be a 6 Inch CRT Replacement Monitor. These Industrial Monitors are rugged, high performance 5.7-inch Active Matrix COLOR TFT LCD monitors, designed as a drop-in replacement for many industrial 6inch open frame monitors. It’s rugged steel chassis is designed to drop into the mounting holes of the original industrial 6-inch CRT, making it unnecessary to replace the original chassis. Its multi-frequency plug & play capability enables this RGB LCD monitor to interface with a wide variety of video formats for easy replacement of your legacy CRT display.

With 15KHz through 68Khz operation, optional TTL video capability, contrast ratios of 800:1 and brightness levels of 700 cd/m2, the QES1506 Series color LCD TFT display is an excellent choice for many legacy industrial display needs. Standard features such multi-language on-screen display, DDC1/2B Plug and Play, and wide viewing angle capability making this a versatile LCD display. This Open-Frame chassis drops directly into Yasnac CNC / JANCD GSP10 DF6101675 and is a direct replacement of Matsushita TR-6DA1.

Our engineers understand, no matter how thoughtful our designs are, there are always things you need to modify from this base design. That is the reason our open frame monitor is very flexible to modify into your project requirements. Call us today at 800.793.6862or email us at sales-IP@dynamicdisplay.com

Industrial Panels understands that technology needs to be replaced in order to keep your organization running efficiently. That"s why we offer durable and high-quality replacement monitors. Industrial Panels has slow scan process control displaysand direct OEM replacements.These replacements are compatible with LCD monitors that are designed to:

This replacement monitor compatibility is made possible by DDI"s proprietary A/D converter and our extensive library of industrial video signal formats, compiled during our many years of manufacturing CRT displays for some of industries largest OEMs. A short list of the OEM systems that we support include:

The Industrial Panels QES1500 series of industrial LCDs are available in screen sizes that range from 5.6" to 24". You can choose from a variety of our monitor configurations such as:

Other chassis versions are available as direct CRT replacements. These clever designs replace open frame console mount CRT displays by attachment to the old CRT chassis after the CRT has been removed.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

Also, setup and key adjustments are more complicated with LCDs—and much more necessary—than they are with CRTs. To be sure, all displays can benefit from proper tuning and adjustment. But LCDs are more likely to experience clarity or viewability issues if they"re not tuned and tweaked to optimum conditions.

In this Recipe, we"ll tackle the system-building differences between LCDs and CRTs. We"ll also describe the kinds of usage situations best suited to one kind of display over the other. Finally, we"ll describe some important tools you can use to make sure your customers get the most from their LCD choices.

We"ll start with the pros and cons of CRT displays, and then do likewise for LCDs. After that, we"ll make some comparisons and explain which type of display is best-suited for specific, identifiable usage scenarios.

Our comparison of the pros, cons, and differences between CRT and LCD displays hinges on the differences between analog and digital technologies. CRTs are analog; therefore, they support continuous values, smooth scaling, and arbitrarily high resolutions (within reason or the limits of technology). LCDs are digital and therefore work like an array of individual, discrete pixels with individual, discrete color and gray-scale values, and a fixed, native resolution. In mathematical terms, it"s the difference between a continuous integral versus a stair-step function. Here"s how they line up:

Motion artifacts: The faster images move on a display, the more past display values can affect current display contents; these leftovers are called motion artifacts. CRTs offer fast response times with no motion artifacts. For this reason, CRTs are the best choice for fast-moving or ever-changing images.

Resolution: CRTs operate at any resolution, geometry, and aspect ratio with no need to rescale images shown. CRTs also run at the highest resolutions graphics cards support.

Emissions: CRTs emit electrical, magnetic, and electromagnetic fields, where magnetic fields are often believed to pose health hazards (although no available scientific evidence supports this belief).

Geometric distortion: CRTs are subject to geometric distortion and generally include adjustments to counter same. But they may also be affected by magnetic fields from other devices.

Interference: CRTs produce visual distortions known as Moire patterns. While many monitors offer Moire reduction, this doesn"t entirely eliminate this problem.

Sharpness: CRTs use electron beams to activate pixels on their screens. This results in softer images than an LCD operating at its native resolution. (But a CRT is usually sharper than an LCD not operating at its native resolutions.)

Size, weight, and power consumption: CRTs are big and bulky. They consume more power—and give off more heat—than most other display technologies.

Size, weight, and power consumption:LCDs are thin-profile devices that are generally lighter than CRTs. LCDs also consume less electricity—and give off less heat—than CRTs.

Aspect ratio: Any LCD has a fixed resolution and aspect ratio. For panels with a resolution of 1280 x 1024 (common for 17- and 19-inch models), the aspect ratio is 5:4 or 1.25, smaller than the 4:3 or 1.33 ratio common for other displays. This may require letterboxing to a 1280 x 960 resolution to get a standard 4:3 ratio.

Bad pixels and screen uniformity: LCDs may include malfunctioning pixels that are weak, or stuck in on or off modes. They are also subject to variations in backlighting, owing to the use of light sources at the top or bottom edges of the display.

Black-level, contract, color saturation: LCDs are poor at producing deep blacks and dark grays. This results in lower contrast and reduced color saturation for low intensity colors, which makes LCDs a poor choice for dimly lit or dark environments.

Color and gray scale accuracy: Internal gamma and gray-scale on an LCD varies by location on the display surface. LCDs normally produce only a limited number—fewer than 256—of discrete intensity levels. This leads to image-accuracy issues with black level, gray-scale, and gamma, and it isn"t suitable for professional color balancing.

Interference: LCDs using analog input require painstaking adjustment of pixel tracking and phase to minimize digital noise in image display. Automatic controls seldom produce optimum outputs, and it may be impossible to eliminate all digital noise completely.

Motion artifacts: The slower an LCD"s pixel refresh rate—often called response time, though this term is more appropriate for CRTs—the more likely it is that motion artifacts will appear. For continuous or very fast motion, some artifacts are inevitable on an LCD.

Resolution: Native resolution is set by the manufacturer and cannot be altered. All other resolutions require re-scaling and leads to image degradation, especially where fine text and graphics are concerned.

White saturation: White levels on LCDs are easily overloaded, and maximum brightness occurs before gray-scale values peak. This phenomenon is best managed by careful contrast-setting adjustments.

When it comes to picking one kind of display over the other, here"s what you should advise your customers on a number of criteria, including needs, pocketbooks, and working environments:

Color or gray-scale accuracy: Users who need or want higher color or gray-scale accuracy, and more viewable deep blacks or dark grays, will be better served by CRTs. Professional color balancing demands a high-quality CRT.

Contrast: CRTs produce the brightest contrast levels available, LCDs fare somewhat more poorly, especially with black and dark colors. Contrast ratio numbers published for LCD displays cannot always be taken literally.

Environmental concerns:CRTs, especially the picture tube itself, are chock-full of heavy metals of several varieties and pose more challenges for recycling than do LCDs. Also, smaller size and weight means less waste to manage. Also, LCDs emit less heat and other forms of energy—electrical, electromagnetic and magnetic—than do CRTs.

Lighting: Users who work in bright light are bound to prefer an LCD. Users who work in lower-light conditions will increasingly prefer a CRT as ambient light decreases.

Motion and artifacts: Users who need or want to work with fast or constantly moving images are best served by CRTs. But this also limits diagonal sizes to no more than 24 inches.

Operating costs: Those concerned about energy consumption will favor LCDs, as these monitors consume at least 40 percent less electricity than CRTs with the same rated diagonal measurements. (And standby mode savings are about 40 percent.) In theory, users can also get away with less office space by using LCDs, translating into lower rent.

Purchase cost: Those with smaller budgets should consider CRTs, as they cost 50 percent or less than LCDs with the same reported diagonal measurements.

Resolution: If a user doesn"t like an LCD at its native resolution, this spells trouble. Native resolution for an LCD is equivalent to maximum resolution on a CRT; it represents the upper limit of picture quality for a given model. So if a user needs a monitor to run at multiple resolutions, especially if they also need fine text and graphics for all resolutions, this virtually mandates a CRT.

With more customers switching to LCDs, system builders should understand how to set up these monitors and configure them properly once they"re in place. A system builder should also know how to get the best-looking text on the screen. To help, we"ll now describe some great tools for system builders working with LCD displays.

ClearType is a Microsoft technology specifically designed to improve text readability on LCD screens, including laptop screens, mobile device displays, and flat-panel monitors. ClearType technology can access individual color elements in each pixel on an LCD display. Prior to its introduction, the level of detail operated at the pixel level. But with ClearType running on an LCD monitor, features of text as small as a fraction of a pixel in width can be displayed, according to Microsoft. This leads to a visible improvement in the sharpness of tiny text details. It not only improves readability, but also is easier on the eyes, especially over extended periods of time.

ClearType is included with Windows XP. But to tweak text settings on individual LCD displays, you must download a Windows PowerToy called ClearType Tuner.

Once downloaded and installed, ClearType Tuner appears as a control panel widget named ClearType Tuning. Its users work with a wizard that asks them to select among multiple on-screen displays that look the best, in much the same way an optometrist works with patients to help determine a new prescription for corrective lenses.

Using the ClearType Tuning widget is fast and easy, and a bit of practice makes working with it a snap. You"ll also see noticeable improvements to text on LCD screens as a consequence of its use, as toggling the check box for "Turn on ClearType" in the widget itself will show.

DisplayMate Technologies is a small and highly-regarded company that offers a family of powerful tools of great interest to system builders and consultants. The company offers a $89 (download only) or $99 (CD and manual shipped to buyer) product called DisplayMate for Windows Video Edition, which we highly recommend. It not only supports both CRT and LCD displays, but also other display types, including liquid crystal on silicon (LCoS), digital light processing (DLP), TV, HDTV, Plasma, and multi-media displays. Though this product aims primarily at end-users and consumers, system builders and consultants on a tight budget can get plenty of value from this product.

System builders who work with lots of displays and really want to get the most out of them will probably prefer the higher end DisplayMate Multimedia Edition, which sells for $495. It not only handles the same kinds of displays as the aforementioned Windows Video Edition, but also includes many more test patterns and command scripts to perform customized display testing and tuning.

This scaffolding around the consumer-level DisplayMate for Windows program provides users with a set of detailed descriptive text screens that precede each of the monitor test sequences under two general headings: Set-Up Program and Tune-Up Program.

The Set-Up program helps familiarize users with graphics and display capabilities on the systems under test, and to establish initial configuration. The Tune-Up Program provides quick checks on specific display capabilities, with opportunities to tweak and tune them for optimal display output.

Introduction: A lead-in screen for the program that briefly describes its capabilities and (more important) provides the option to toggle the Novice Option on or off. Beginners will appreciate its information and instructions, while experienced users can ignore this.

Set-Up Display: A stepwise procedure that leads users through all available user controls on their display and graphics card, each of which is associated with a test pattern and an explanation of how to use its appearance on screen to achieve settings that are visually optimal. First, an initial explanation appears on screen. Then, users click through a sequence of 22 test-pattern screens that include checks on brightness and contrast, intensity range, black-level, and gray scale checks, numerous standard test patterns and color gauges, and numerous geometry checks. The whole sequence takes at least 30 minutes to traverse the first few times through, especially if you read all the preliminary text that precedes each individual test (and if our experience is any guide, you definitely should).

Video Obstacle Course: A set of demanding and difficult images designed to stress test displays and show settings in need of adjustment or improvement. The software also provides information about what users will see during these 24 tests, and how to remedy any potential problems or issues they may expose. About a third of the tests repeat from the previous Set-Up Display sequence, but others deal with important checks related to Moire patterns, color registration, screen and local display regulation, and more. Expect to spend at least 30 minutes working through this series of test patterns and checks.

Master Test Pattern: As the name suggests, this one has a little bit of everything: Geometry, focus and resolution checks, gray-scale and color levels and saturation, and more. You"ll learn to use this to take a quick look at a display and see if it needs some (or more) work.

Video System Information: Shows what information from your display and graphics card DisplayMate can read, including native resolution, screen colors, gray levels, screen and pixel aspect ratios, pixel shape (square or not), color depth, palette, and planes, as well as system font and display driver information. Useful to make sure everything is as it should be.

The DisplayMate Tune-Up Program includes the following elements, whose organization indicates that this tool takes a functional view of the various activities involved in display tuning and tweaking:

Screen Pixel Resolution: Shows a series of 15 visually interesting test patterns to check screen resolution, fineness of detail, and accuracy in a series of complex line and pattern traces. This is some of the coolest looking stuff in the program.

Miscellaneous Effects: A series of 14 tests and checks that let you fool around with colors and gray scales on the display. Be sure to toggle through color selections where you can; click the right mouse button to toggle through such options where available.

In our test lab, we have a number of LCD screens ranging in size from 17 inches (diagonal) to 30 inches. We found the DisplayMate program"s ability to help us properly set brightness, contrast, and pixel timing to be of greatest use. Those are the aspects of our LCDs that suffer the most when left at factory-default settings. System builders and consultants will find these tools useful in making sure that their customers and users have the best possible experiences when they upgrade or switch to LCD displays.

ED TITTEL is a freelance writer and trainer in Austin, TX, who specializes in Windows topics and tools, especially networking and security related matters. JUSTIN KORELC is a long-time Linux hacker and Windows maven who concentrates on hardware and software security topics. Ed and Justin are also co-authors of Build the Ultimate Home Theater PC (John Wiley, 2005).

Drawing on over 20 years experience of manufacturing rugged displays for the OEM industrial market place, Dynamic Displays has developed LCD display solutions for a wide range of CNC Machine Tools, Factory Automation, Process Controls and other legacy manufacturing systems.  Our rugged, industrial-grade QES1510-025 open frame display employs a high resolution Active 10.4" Matrix color LCD with a viewable screen area comparable with any 12" CRT. No matter how old, or complicated, the CRT monitor in your CNC machine might seem to you, we assure you that we have a worry-free replacement LCD monitor.

In our QES1510-025 10" Color LCD, we’ve incorporated the latest microprocessor controlled A/D boards with a HEX file specifically programmed to ensure compatibility with the Allen Bradley 8400MP system video signals. The painstaking effort to correctly match our LCD monitor model to the Allen Bradley OEM video signal results in a bright, sharp, crisp image for your CNC control system.

Now, Dynamic Displays, Inc. offers an economical 10.4" LCD monitor replacement for the obsolete Toshiba D12CX73 12" CRT monitor in the Allen Bradley 8400MP Control.

Our model QES1510-025 LCD monitor has a rugged steel chassis designed to drop into the mounting holes of the original 12 inch Toshiba D12CX73 Color CRT monitor. This new 10.4" LCD monitor has mating video and power input connections and with circuitry and firmware engineered specifically to work in your legacy Allen Bradley 8400MPcontrol.

This website or its third-party tools process personal data (e.g. browsing data or IP addresses) and use cookies or other identifiers, which are necessary for its functioning and required to achieve the purposes illustrated in the cookie policy. To learn more, please refer to the cookie policy. In case of sale of your personal information, you may opt out by sending us an email via our Contact Us page. To find out more about the categories of personal information collected and the purposes for which such information will be used, please refer to our privacy policy. You accept the use of cookies or other identifiers by closing or dismissing this notice, by scrolling this page, by clicking a link or button or by continuing to browse otherwise.

For industrial CRT monitor repair, LCD repair or industrial LED monitor repair, there’s no reason to look any further than Global Electronic Services. Your and monitors are the eyes of your operation, and we can make sure you see

When your monitors come in to us, we immediately evaluate the problem, and as part of our industrial monitor repair services, perform any necessary maintenance. When you get your monitors back, we are confident you’ll be 100 percent satisfied with the results.

Why is Global Electronic Services the name you can trust to come to the rescue when your monitors are down? Our factory-trained technicians know every major brand of industrial monitor completely. We’ve successfully repaired monitors from Allen-Bradley, Xycom, Square D, Fanuc, Quickpanel, Cutler Hammer, Automation Direct and more.

Fast work is the key. You can be sure we’ll do a great job on your monitors and have them working correctly, but that isn’t going to help you if it takes weeks for you to get them back. If you’re going to be stuck without monitors for that long, you might as well buy new ones.

But that won’t be a problem with Global Electronic Services because in most cases, we can get your monitor back to you in one to five days – not weeks. In just a few days and you’re up and running again.

No one can argue that cathode ray tube technology is the wave of the past. LCD displays, LED displays and now HD and Plasma displays have supplanted this old level of technology. The only people who are likely to use this outdated technology are those who have old computers with CRT monitors that still work and people who like to play vintage video games on the screens they were originally intended for.

We can analyze the problems with your CRT monitors and repair them if repair is possible just as easily as a more modern screen. Naturally, LED monitor repair and LCD monitor repair are no problem for us, either.

If you have a lot of CRT monitor machines in your factory and those monitors are causing you problems, we can certainly fix them. However, a better solution might be to retrofit those machines and replace the CRT monitors with LCD monitors. This could give you the best of both worlds. You don’t have to scrub the machines that have been giving you so much loyal service for so many years, and you don’t have to deal with the poor video quality and constant repairs that come with cathode ray tube-based monitors.

LCD monitors are not only able to provide better image quality for your machines, but they will also often be more efficient, saving you on energy costs, and are likely to last longer than your old CRT monitors.

If you have a bad display or another issue with your Allen Bradley Panelview device, just send it over to Global Electronic Services, and we can fix it. Whether you are suffering from poor screen brightness, lack of clarity, touchscreen misalignment, faulty ports, bad seals, cracked screens or any other problems likely to befall this piece of equipment, GES has you covered.

We have the equipment and expert technicians to test the LCD and components to locate the problem and replace or repair as necessary to get your product back in business as it should be again.

Our staff at Global Electronic Services have all the expertise you could ever want when it comes to industrial monitors and industrial monitor repair. Do not hesitate to contact us with your industrial monitor repair issues no matter how old or new your monitor is, no matter what brand you are working with. If it is possible to fix your monitor and have it functioning optimally again, we know how to do it — and we will do it quickly at a reasonable price.

Especially when compared to the cost of buying new monitors, our industrial monitor repair services are extremely budget-friendly. In fact, if you can bring us a lower price from a competitor, we’ll beat it by 10 percent.

Add to that the fact that you’ll get a fair estimate up front, so you won’t have to worry about surprise big charges later, and repairing with Global Electronic Services only make sense.

Without your monitors, you’re working in the dark, and we want to make sure you see the light. For full maintenance and repair of your industrial monitors, Global Electronic Services is your best resource. Call us up now at 877-249-1701, or contact us online for more information on monitor maintenance or repair or for a quick quote on services.

In my 30 year career in industrial automation repair, I’ve seen countless HMIs or monitors pass through the workshop for repair. Most of these were the CRT (Cathode Ray Tube) type. CRTs were the first technology to allow users to interact with machines carrying out manufacturing functions.

Whilst repairs to CRT monitors can still be carried out, although parts availability is reducing, at Fletcher Moorland we recommend converting from CRT to LCD (Liquid Crystal Display). There are many good commercial and technical reasons to do this including –

4 – Operator Comfort – Screen burn often associated with CRTs are a thing of the past with LCDs, the display is much clearer for the operator to view and will not fade.

5 – Less Knock-On Problems –LCD screens do not operate at such high temperatures and voltages as CRTs so there is less chance of damaging associated components and circuitry.

An important question now, ‘When is the best time to convert?‘ and this is one I can’t really answer. It depends on your production scheduling and shutdown windows. However if you do have an industrial automation monitor or HMI that is already giving you problems of fading, burnt screen, display folding etc. Then it is already failing and will get worse. It maybe prudent to remove it from service before a failure impacts on your production.

Some subscribers prefer to save their log-in information so they do not have to enter their User ID and Password each time they visit the site. To activate this function, check the "Save my User ID and Password" box in the log-in section. This will save the password on the computer you"re using to access the site.

Note: If you choose to use the log-out feature, you will lose your saved information. This means you will be required to log-in the next time you visit our site.

Looking for wholesale 15 inch crt monitor? Look no further than Alibaba.com, one of the largest collections of wholesale shipment suppliers in the world. We have a huge range of lcd computer monitor options and lcd display screen options to choose from. Whether you need a small lcd screen or a large one, we have you covered.

These 15 inch crt monitor products have become the go to display types for computers today. With tft color monitors slowly being phased out, lcd computer monitor displays are the standard in the industry. All customers need a flat screen computer monitor to interact with their personal computers. For ardent gamers that require high refresh rates to minimize lagging and make use of high performance computers there are a range of lcd gaming monitors available.

We also have more specialised products like rack mounted monitors for IT administrators and network administrators working in commercial settings. These monitors are used to oversee large server rooms and network infrastructure. New transparent lcd screen options are also coming on the market that are futuristic and allow for a sleek look to fit modern aesthetics.

So, start ordering your shipment of 15 inch crt monitor today from our suppliers. They are ready and willing to answer any questions you may have about their products and get you started today!

Where can you recycle your old crt or lcd monitor?  Crt monitor recycling and lcd monitor recycling is easy.  By allowing STS Electronic Recycling, Inc., to recycle your old crt monitor or lcd monitor you are helping safeguard against electronic waste polution.  A single crt monitor can contain up to six pounds of lead.  Lcd monitors contain harmful contaminants such as mercury.  Recycle your old or broken lcd and crt monitors.

Hard drive and hard drive data destruction are essential when recycling obsolete/unwanted computers and electronic equipment.  STS Electronic Recycling, Inc., guarantees hard drive data destruction in compliance with NIST hard drive data destruction recomendations.  Protecting personal/business data can save you money and safeguard against improper data destruction and potential data theft.  STS Electronic Recycling offers hard drive destruction tracking and an official certificate of data destruction for clients choosing to recycle their unwanted computers and electronics. Hard drive data destruction processes exceed Department of Defense requirements.

Proper electronics recycling can be achieved with STS Electronic Recycling, Inc.  It is important to use a reputable electronics recycler for disposal of out of date/obsolete computer and electronic equipment.  Making the environement a priority in electronics recycling is important to STS Electronic Recycling.  By practicing a no landfill policy for computers and electronics recycled at the STS Electronic Recycling, Inc., 50,000 sq. ft. facility, we insure a complete compliant recycling process.

Compliant computer, laptop and pc recycling goes further than turning over your obsolete/unwanted electronic equipment to a recycling company.   At STS Electronic Recycling, Inc., we aim to create the most environmentally friendly solution for each piece of electronic equipment recieved.  Recycling or disposing of your old electronic equipment and computers with STS Electronic Recycling assures the best solution for end of life electronics. Contact us at 903 589 3705 for information on recycling/disposing of your electronics.
