We constantly think and practice corresponding to the change of circumstance, and grow up. We aim at the achievement of a richer mind and body along with the living for Tft Display Resolution, Color Lcd Display Module, Touch Screen Monitor With Stylus, Outdoor Lcd Display,Active Matrix Monitor. Our company eagerly looks ahead to setting up long-term and pleasant small business partner associations with customers and businessmen from everywhere in the entire world. The product will supply to all over the world, such as Europe, America, Australia,Israel, Armenia,Chile, Austria.In order to carry out our goal of "customer first and mutual benefit" in the cooperation, we establish a specialist engineering team and a sales team to supply the best service to satisfy our customers" requirements. Welcome you to cooperate with us and join us. We have been your best choice.

TFT displays are full color LCDs providing bright, vivid colors with the ability to show quick animations, complex graphics, and custom fonts with different touchscreen options. Available in industry standard sizes and resolutions. These displays come as standard, premium MVA, sunlight readable, or IPS display types with a variety of interface options including HDMI, SPI and LVDS. Our line of TFT modules include a custom PCB that support HDMI interface, audio support or HMI solutions with on-board FTDI Embedded Video Engine (EVE2).

Looking for a specific TFT resolution? We offer LCD TFTs varying in resolution from 128x160 pixels to 800x480 pixels. Many of our TFT LCDs also have carrier boards to make integrating them into your product as simple as possible. All of our TFT LCDs offer full color RGB. If you"re not finding the correct TFT LCD for your product or project, please contact our support team to see if they can help you find an appropriate TFT display module for you.

The provided display driver example code is designed to work with Microchip, however it is generic enough to work with other micro-controllers. The code includes display reset sequence, initialization and example PutPixel() function.

If driving the backlight of the C version display with 12 Volts and a series resistor, substituting a D version display will not work since the four LEDs need more than 12 Volts to get the same current flowing.

The DT022BTFT uses the same connections as the DT022CTFT, with the exception of the backlight (which has connections shown in the Displaytech datasheet).

The provided display driver example code is designed to work with Microchip, however it is generic enough to work with other micro-controllers. The code includes display reset sequence, initialization and example PutPixel() function. Keep the default values for all registers in the ILI9341, unless changed by the example code provided.

Note that the WR pin becomes the D/CX signal in serial mode. CS is used to initiate a data transfer by pulling it low. At the end of the data transfer, pull the CS pin high to complete the transaction. The timing diagram indicates that you can pull the CS pin high in between the command byte and data bytes within a transfer, but it is unlikely needed if the display is the only device on the SPI bus. To keep things simple, we suggest to leave it low during the entire transaction.

WF43VTIAEDNN0 is a color TFT LCD with WQVGA 480x272 resolution, diagonal size 4.3 inch. This TFT model is built in with ST7282 driver IC. WF43VTIAEDNN0 supports 24-bit RGB interface; it’s available for Resistive Touch Screen (RTP) and Projected Capacitive Touch Screen (CTP) optional, as well as high brightness option for this model. WF43VTIAEDNN0 is an alternative item to replace WF43HTIAEDNNB which adopted CPT (Chunghwa Picture Tubes Ltd) TFT panel.

Pixel, also called Picture Element, A pixel is the smallest unit of a digital image or graphic that can be displayed and represented on a digital display device. A pixel is the basic logical unit in digital graphics. Pixels are combined to form a complete image, video, text, or any visible thing on a computer display

LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

HD TV has 1280×720 = 921,600 pixels; Full HD has 1920x 1080=2,073,600 pixels; 8K TV has 7,680×4,320=33,177,600 pixels. he “K” in 8K stands for Kilo (1000), meaning a TV that has achieved a horizonal resolution of about 8,000 pixels.

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

DPI stands for dots per inch and refers to the resolution of a printer. It describes the density of ink dots placed on a sheet of paper (or another photographic medium) by a printer to create a physical print.

PPI stands for number of pixels per inch. It is kind of pixel density. PPI describes the resolution of a digital image, not a print. PPI is used to resize images in preparation for printing

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

Special names by individual companies: Apple Macbook Pro Retina 6K display, Acer Nitro, ASUS Pro Art , ViewSonic Elite, ASUS TUF ,Samsung edge Infinity-O Display etc.

ER-TFT050-3 is 800x480 dots 5" color tft lcd module display with ILI6122 driver IC,optional 5 points capacitive multi-touch panel with controller GSL1680 and optional 4-wire resistive touch panel screen,superior display quality,super wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry PI.

It can be used in any embedded systems,car,mp4,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.

RFK101VL-1YH-LHS is a 10.1-inch TFT display with resistive touch screen (USB interface), supporting HDMI connector (only DVI signal) interface. The resolution of this 10.1” display module is 1280x800 dots. The brightness is 750 cd/m2 with contrast ratio 800:1. LCM voltage ranges from 4.9V-5.1V, typical value is 5V. Operating temperature covers from -20~+70℃, storage temperature range is from -20~+70℃.

★RFK101VL-1YH-LHS 1280x800 resolution TFT Display with a 40-pin header connector on board, supports Raspberry Pi 3B+ (including Pi 4B) version. If customers choose this display to support Raspberry Pi 4, please note that the interface is only compatible with micro HDMI. Customers need to use “Micro HDMI to HDMI” cable for this TFT series.

The Eyoyo mini HDMI multi-port monitor, provide Professional factory color calibrated Native resolution HD 800 * 480 high resolution Precise Color. It supports VGA, HDMI, BNC and AV inputs so you can easily extend the enjoyment from many devices on Full HD display. what"s more, this monitor supports USB charge and 12V DC power supply charge.

Support five channel video input mode, TV compatible, video, as well as professional VGA, also customized monitoring mode, can be done as a liquid crystal display, PC display, while supporting the HDMI input. Application in the optical industry, medical industry, security industry, video industry, Photographed，Education and training ，product marketing ，military industry, electronics manufacturing, industrial manufacturing, etc..
