Single-chip LCD controllers featuring built-in display memory allowing for low power consumption, low noise, and space-saving ability. These products have more features than Simple LCD Controllers which makes them ideal for display control of mobile terminals and operation panels.

Single-chip LCD controllers with built-in display memory and a simplified function set. These products are ideal for a wide variety of applications that require simple LCD display.

LCD controllers providing support for a wide range of small to large size panels. The external memory option allows the memory size to be cutomized based on the target application. These products are most suitable for display control of OA or FA equipment operation panels, as well as some automotive (in-vehicle) devices.

LCD Controllers incorporating a camera interface which allows the LCD controllers to display camera images on the panel without placing a load on the CPU. These products are excellent choices for display control of a wide variety of applications such as mobile terminals and security devices.

LCD Controller allowing for reception of display data and transmission of touch-screen coordinate data at high speed via USB2.0-HS. This product is most suitable for applications on OA equipment such as multi-functional printers with long lengths of cabling between the host CPU and LCD panel. It is also ideal for in-vehicle devices such as rear entertainment displays.

EPSON LCDC integrates various graphic functions, shcu as PIP, Rotation, and Scaling, into one chip. With simple command, EPSON LCDC helps customer to achieve friendly GUI. EPSON LCDC supports TFT LCD panels from QVGA up to WVGA resolution, and is suitable for factory automation (FA) controller, medical instrument, measuring equipment, and office automation (OA) applications.

GRAPHICS S1D13517 S1D13517 External SDRAM LCD Controller March 2009 The S1D13517 is a color LCD graphics controller which uses an external SDRAM display buffer. The S1D13517 supports an 8/16-bit indirect host interface while providing high performance bandwidth to external SDRAM, allowing for fast screen updates. The S1D13517 supports displays up to 960x540 (QHD) 24 bpp or 800x600 (SVGA) 24bpp, controlling a main the window and up to two Picture-in-Picture windows. Additionally, the S1D13517 is designed with a 2D Graphics Engine with Alpha Blending. The S1D13517 uses a double-buffer architecture to prevent any visual tearing during streaming video screen updates. FEATURES Easy to use, Easy to connect Main Display Window with two Picture-in-Picture windows External 16M-bit, 64M-bit or 128M-bit SDRAM 180 hardware rotation and mirror of display image High performance SDRAM controller Double-Buffer available to prevent image tearing 8/16-bit asynchronous indirect parallel interface during streaming input (used for display or register data) PWM output for LCD backlight control Input data formats: RGB 8:8:8, RGB 5:6:5 Internal programmable PLL Active Matrix TFT interface: 18/24-bit interface SS (Spread spectrum) clock available Supports resolutions up to 960x540 or 800x600 General Purpose Output pins Software Power Save mode SYSTEM BLOCK DIAGRAM SDRAM (16-bit) Host Data and 13517 Control Signals CPU (8/16-bit) Active Matrix TFT Display (18/24-bit) S1D13517 Includes: Two Picture-in-Picture windows Double-Buffering PWM output Alpha Blending acceleration X92A-C-001-01 1 Revision 1.0GRAPHICS S1D13517 DESCRIPTION Frame Buffer Display Features External 16M-bit, 64M-bit or 128M-bit SDRAM 24 bit-per-pixel (bpp) color depths memory support Display window Maximum 90MHz SDRAM clock Two Picture-in-Picture windows 16-bit bus width 2D graphics engine (Alpha blending, Copy) Maximum 16-Buffer separation available 180 hardware rotation and mirror of display image. Host Interface Double-Buffer available to prevent image tearing dur- 8/16-bit asynchronous parallel interface (used for ing streaming input display or register data) Software Multi-Buffer available for simple animation Indirect addressing Intel80 interface TE (Tearing Effect) output Burst and rectangular write available for memory Clock Source Input Data Format Internal programmable PLL (Maximum 180MHz) RGB 8:8:8, RGB 5:6:5 Spread Spectrum clock available for PCLK and SDCLK Display Support (note: frequency: 31MHz to 80MHz) LCD pixel clock (Maximum PCLK = 45MHz) Active Matrix TFT SDRAM clock (Maximum SDCLK = 90MHz 18/24-bit interface Supports resolution up to 960x560 (QHD) Miscellaneous HVGA, VGA, WVGA, SVGA PWM output for LCD backlight control Power Software Power Save mode COREVDD 2.5 volts, PLLVDD 2.5 volts and IOVDD General Purpose Output pins are available (GPO 3:0 ) 3.3 volts QFP15 128-pin package (16mm x 16mm x 1.7mm) CONTACT YOUR SALES REPRESENTATIVE FOR COMPREHENSIVE DESIGN TOOLS S1D13517 Technical CPU Independent S1D13517 Evaluation Royalty Free source level Documentation Software Utilities Boards driver code Japan North America China Taiwan Seiko Epson Corporation Epson Electronics America, Inc. Epson (China) Co., Ltd. Epson Taiwan Technology & Trading Ltd. IC International Sales Group 2580 Orchard Parkway 7F, Jinbao Bldg. 14F, No. 7 421-8, Hino, Hino-shi San Jose, CA 95131, USA No. 89 Jinbao St. Song Ren Road Tokyo 191-8501, Japan Tel: +1-800-228-3964 Dongcheng District Taipei 110, Taiwan Tel: +81-42-587-5814 Fax: +1-408-922-0238 Beijing 100005, China Tel: +886-2-8786-6688 Fax: +81-42-587-5117 Tel: +86-10-6410-6555 Fax: +886-2-8786-6660 Fax: +86-10-6410-7320 Hong Kong Europe Singapore Korea Epson Hong Kong Ltd. Epson Europe Electronics GmbH Epson Singapore Pte., Ltd. Seiko Epson Corp. 20/F, Harbour Centre Riesstrasse 15 1 HarbourFront Place Korea Office 25 Harbour Road 80992 Munich, Germany 03-02 HarbourFront Tower One 50F, LKI 63 Bldg. Wanchai, Hong Kong Tel: +49-89-14005-0 Singapore 098633 60 Yoido-dong, Youngdeungpo-Ku, Tel: +852-2585-4600 Fax: +49-89-14005-110 Tel: +65-6586-5500 Seoul, 150-763, Korea Fax: +852-2827-4346 Fax: +65-6271-3182 Tel: +82-2-784-6027 Fax: +82-2-767-3677 SEIKO EPSON CORPORATION 2008-2009. All rights reserved. Information in this document is subject to change without notice. You may download and use this document, but only for your own use in evaluating Seiko Epson/EPSON products. You may not modify the document. Epson Research and Development, Inc. disclaims any representation that the contents of this document are accurate or current. The Programs/Technologies described in this document may contain material protected under U.S. and/or International Patent laws. EPSON is a registered trademark of Seiko Epson Corporation. All other trademarks are the property of their respective owners. 2 X92A-C-001-01 Revision 1.0

Seiko Epson Corporation (“Epson”) has begun shipping samples of the S1D13709, a new display controller IC with built-in memory that is capable of easily controlling the display of both text and graphics on color TFT[1] and STN[2] LCD panels. This display controller is ideal for control panels used on factory automation equipment and office equipment such as printers and multifunction units.

STN panels are often used as control panels on factory automation systems and office equipment, but demand for color TFT panels in these applications has been growing in recent years because of their good visibility and greater powers of expression. The new S1D13709, with built-in CGROM[3], can enable such popular features as mixed text and graphics, overlays, and smooth scrolling (vertical and horizontal) on both STN and TFT LCD panels. In addition, since memory for the display is built-in, no external memory is needed. This saves space and design work for users. The software of the new S1D13709 is compatible with that of the S1D13700, Epson’s previous display controller IC for monochrome STN LCD panels. This makes it easy for S1D13700 users to migrate to color TFT LCD panels.

Going forward, Epson intends to leverage its unique set of compact, energy-saving, and high-precision technologies to help enrich society by providing products and services that solve real issues for customers.

Users of the S1D13700, Epson’s previous display controller IC for monochrome STN display panels, can use the new S1D13709 with their existing software to control color TFT LCDs (some restrictions apply).

Hantronix TFT LCDs will deliver a vibrant, high contrast user interface to any application. Our TFT displays are available in a wide range of sizes, and are easy to incorporate into any design. We offer the most popular and cost-effective Amorphous Silicon Thin Film Transistor or a-SiTFT panels. This application note discusses how to drive a TFT LCD using widely available microprocessors.

Note that some small, lower end panels may not have all of the electronics included with them because of size or cost restraints. Some panels have a simple row and column interface. Some may need an external timing controller. Some have a processor bus type Interface.

Many LCD controllers, including those integrated into microcontrollers, will directly drive the signals shown in Figure 1. This means that the biggest obstacle to quickly getting an image on the screen is generating the appropriate signal timing. The LCD controller is responsible for generating the timing; however software must be written to correctly program the controller for the specific LCD model.

An LCD panel comprises a matrix of pixels (picture elements), divided into red, green, and blue "sub-pix-els". Each sub-pixel is driven by a small transistor. Typically, LCD panels have internal row and column drivers, much like DRAM. A row is selected by the row driver, then the column driver sequences through each of the columns. After each of the columns has been written, the row driver selects the next row and the process repeats. The VSYNC signal resets both row and column drivers to the upper left pixel. The HSYNC causes the row driver to step to the new row. The clock sequences the column driver through each of the pixels, with each clock edge latching data values for the red, green, and blue sub-pixels. These values drive a form of D/A converter to store an electrical charge in a capacitor in each sub-pixel which controls the drive of the transistor; this in turn controls the brightness of the sub-pixel. A red-green-blue color mask is used to filter the light from each sub-pixel to form its corresponding color.

Like a DRAM, an LCD panel must be constantly refreshed or the image will fade. Most TFT LCD panels work when refreshed around 60 Hz. The imagedata is usually held in a section of main memory called a frame Buffer.

Each location in the frame buffer corresponds to a pixel on the LCD. The value in the location determines the color displayed for that pixel. See Figure 2. The size of the frame buffer depends on two things: the number of locations needed, and the size of each location.

TFT panels typically have an input of at least 6 bits of red data, 6 bits of green data, and 6 bits of blue data. A panel with 6 red, 6 green, and 6 blue data lines is termed a 6-bit panel. If the processor or LCD controller doesn"t drive as many data lines as the panel requires, use the data line configuration shown in Figure 3 or Figure 5.

Seiko Epson Corporation announced that it will in September start supplying its latest display controller IC reference design compatible with the Arduino Due including the Atmel SAM3X8E 32-bit microcontroller based on ARM"s Cortex-M3 open source hardware platform. This new reference design will support the development of products using small- and medium-sized TFT LCD panels, providing significantly shorter development times and a lower cost evaluation environment. The reference design includes an evaluation board with an integrated S1D13781 LCD controller IC manufactured by Epson and a software library providing simple graphics functions.

The S1D13781 Shield TFT evaluation board is compatible with Arduino Due. Both this evaluation board and the software library were developed to be compatible with the Arduino Due environment, providing a simple hardware connection that allows the evaluation board to be powered by Arduino Due, and with simple software installation and usage. The evaluation board includes two FPC (Flexible printed circuits: It"s possible to easily change the shape of these flexible circuits without affecting their electrical characteristics) connectors (40-pin and 54-pin) that can be used to connect to separately available WQVGA (400x240 dot) or QVGA (320x240 dot) TFT panels.

The S1D13781 Shield TFT evaluation board can also be used to evaluate the low cost S1D13L01 LCD controller that shares the same features as the S1D13781, except for BitBLT functionality (A function that transfers bitmap images used on the display from the main memory to the graphics memory). The evaluation board will be available for purchase from online shops in September. To be made available on Epson"s website from September 2015.

If the controller is on the back of the LCD, then you are in luck. If it"s not, then you will have to find an equivalent LCD controller and design a PCB with a microcontroller on it.

The first thing to do is find the datasheet for the LCD controller chip, without this you have a real uphill battle. If you know the manufacturer and find the package this might help you reverse engineer your module. Some companies only provide datasheets on request, some you have to have an agreement with them.

If what you have salvaged is an LCD module that is manufactured, this will be easier to interface to as the manufacturer will in all likely hood have the datasheet and drivers.

Once you have found the datasheet, you can then figure out how to interface to it. The LCD controller will either be a parallel (for the bigger screens with a faster update) or a serial (smaller screens with a slower update). Some of the serial screens use SPI. The parallel ones will have data and address lines and control lines similar to writing to memory.

Then connect your microprocessor to the data (and or address lines) and see if you can access a register and read and write data to the LCD (preferably control registers to test communication).

Remember that to implement one interface to an LCD can take man months of time to implement for a product, a project like this can really help you appreciate economies of scale.
