This can be "cheated" to just use one pin and timed-length pulse. An RC network is used to provide a time delay for the DAT line to change. Very short pulses mean that a 1 bit is shifted in. With a long enough pulse the DAT voltage drops low enough so that a 0 bit is shifted in when the CLK line goes / again.

Currently I have a 2 wire system with a SN164 that works well so I am not in a hurry to do an LCD on 1 pin, but I may give it a try for use with an attiny850

One-Wire LCD displays are fairly difficult to find. When you are debugging or using one-wire devices it is often handy to have a way to display the actual data. Although this device doesn"t read one-wire sensors you can send characters to its one-wire address and see the data you are interested in.

This is a 3.3V (5V tolerant) display and it will not run on parasite power, so a separate power supply needs to be supplied, in addition to the one-wire and ground wire.

The one wire LCD interface has been around on the internet for some time already and made popular by Roman Black, although he claims he is not the inventor of the principle. His article is mainly PIC processor oriented, but it gives a good explanation of the principle. Myke Predko is also a name that  should not be unmentioned as pioneer in 1 wire LCD driving. Also this article about  one wire driving of a shift register is very informative

The ShiftRegLCD123 website from Raron used to give a lot of information as well, along with circuits, but that (the Wiki) seems to have disappeared. But his library is in codebender.

In brief, the One Wire interface uses a latched shift register in which the clock and the latch are taken from the data signal through two RC networks that produce the necessary delay. Circuits are a plenty on the interweb, but finding the proper driver for it can be confusing sometimes.

Although the interface on the data, clock and latch lines is rather standard, the connection between the shift register and the LCD has thre major variants that for now i will just call the Roman Black, the LCD3Wire circuit (yes, it is 1 wire) and the ShiftRegLCD123 circuit. Also Elektor has published a 1 wire interface (Detlef Hanemann)(Published in issue 9/2015 on page 92) with yet again a different shift register to LCD connection. Their setup is said to have several advantages over the setup used by Roman Black, it uses the Q7′ direct output of the shift register to trigger the output latch register to carry over automatically the shifted data to the output pins. But for that it requires a monoflop built around a BS170 FET to generate the E-pulse. The setup to be used in Francisco Malpartida’s LCD library is yet again different from the other 3 and uses a diode to create an AND gate

Driving these OneWireLCD’s thus differs per configuration. The ShiftRegLCD123 library can do both the ShiftRegLCD and the LCD3Wire protocol. The Liquid Crystal Library of Francisco Malpartida  does have a One Wire protocol but make sure you have the latest version. However, it relies on connections different from the others mentioned:

I needed an LCD-display for a project, but only 1 pin was available for driving it. No problem; there are examples from Elektor and others for such an interface. Most of these use a shift register, which was not available in my private store. Therefore the same function will be realised in software using a small microcontroller.

I used a 14-pin PIC microcontroller 16F1825, but the cheaper 16F1823 will also work. Most pins are needed for the display, but still 1 pin is available for a new function (or 2 if low voltage programming is disabled). Two serial inputs are available for the interface: an rs232 compatible one, which for instance can be connected to a PC (I used this one to test the firmware) and a direct connection to the PIC, which can be used to connect the circuit to another microcontroller. In the latter case Q2 and surrounding components can be omitted.

The first idea was to realise the display as a small VT52 or VT100 terminal, but this was too much effort for such a simple device. The final version therefore does not contain much intelligence.

Initially the program simply sends the 4 LSB"s of any received character to the LCD, using bit 4 to control the RS-input. Using ASCII-characters 0x20 to 0x3f (" " to "?", see examples) the display can be fully controlled.

Later I added the possibility to switch on and off the backlight and to send 8 bit control and data. Sending a string for instance now can simply be done by putting the LCD in 8 bit data mode by sending a code followed by the string as ASCII-characters. Sending an Escape-character returns to 4 bit mode. Using 8 bit control is less usefull, because in many cases not more efficient than 4 bit control.

A second addition was a time-out on the reception of the second nibble in 4 bit mode. If it is not received within 1 second, the controller forgets the first nibble. The time-out can be made smaller by changing parameter MAXTIM and by another prescaler factor for timer 0. The time of 1 second was needed

Because the lack of intelligence, all kind of displays based on HD44780 and compatibles can be used. Information about number of lines and characters are kept on the sending side.

The DT010TFT is a 1 inch TFT LCD module with 80 x 160 RGB resolution. This small LCD screen uses a 4-wire Serial Protocol Interface (SPI) to communicate with the driver IC (Ilitek ILI9163) and has a 6 o"clock viewing angle. The single chip driver IC for this transmissive TFT LCD provides a full color display mode of 262K colors. This TFT LCD is ideal to be used as an indicator or to display simple icons and information. The 1" LCD module includes a color TFT-LCD panel, a driver IC, FPC, and a white LED backlight unit.

As of August 2018 the State of California has changed the requirements of the �Prop 65� law. We now must list on our website any possible chemicals the can cause cancer, birth defects or reproductive problem.

This module works with at least the LiquidCrystal I2C and LiquidCrystal_PCF8574 libraries available in the Arduino library manager. Address 0x3F worked for me since the A0, A1, and A2 jumpers are not shorted.

Recently purchased unit has a different address than the same part number purchased a year ago. It seems that if the small board is marked MH, the address is not going to be 0x27 or 0x20 but 0x3F. With that change of address, this display works and looks great.

Google for LCM1602 and you will find many pages that mention the board - including the pinouts stated above and sample programs using the Arduino library.

Heres the scoop. The library that works with this chip set is available at this link. http://www.play-zone.ch/en/fileuploader/download/download/?d=0&file=custom%2Fupload%2FFile-1345667375.zip

I liked the idea of the 4-wire interface, but I was disappointed that no documentation was available for this part. However after a night of hacking I got it to work with my Arduino Uno. I thought Id pass along the following information to spare others the trouble.

On the software side, you have to download and install a new LiquidCrystal_I2C library for Arduino, which has the capability to talk to the LCD display over the I2C bus. Heres a link to the library. Follow the example code for the DFRobot board, which turns out to have the same configuration as this LCD, and it should fire right up for you. The LCD has white characters on a backlit blue background, and looked great.

In this experiment, we will be building on the previous experiment by adding an LCD screen and writing a script to display the temperature sensor data on it. If you start thinking about how to run this in the background, we have something planned for that too!

The LCD screen is a 16x2 display, meaning it has 2 rows of 16 columns (characters). It has an LED backlight to illuminate the display even in the dark!

These screens are typically controlled by many parallel data lines, usually 11 or so. However, the one in your kit has additional circuitry that implements control of the screen with the I2C protocol, so you only need to use two data lines to control the screen!

I2C (Inter-Integrated Circuit), sometimes called IIC or Two-Wire Interface, is a serial interface used to quickly and easily connect multiple devices to controllers and processors such as the Omega2. Examples of I2C devices include:

To get this experiment up and running, we’ll be using the same temperature sensor circuit from the previous experiment, but we’ll also be connecting the I2C display to the Omega so we can display the temperature on it. The code we write will tie the two together, but the build will borrow heavily from the previous experiment.

The main sensor circuit is exactly the same as the previous experiment. If you’ve already taken it apart, no worries, just wire it back up exactly as before and you’ll be ready for the next step!

Note that this time, we’re using the 5V pin instead of the 3.3V source that we’ve been using previously. This is because the display requires a higher voltage to run.

All done! If everything is connected properly, the LCD should light up with a bright green background and a row of black boxes on the top row. If it doesn’t light up, check that the jumper on the back of the LCD is firmly connected to the LED pins hanging off the side.

If the display lights up but you can’t see any black boxes, you may need to adjust the contrast on the display. There is a small grey screw on the back; use a Philips screwdriver to turn it and adjust it so that the boxes appear. This will define how clear the text will be on the display.

Wouldn’t it be nice if something could run the script for us every minute to actually update the LCD? We will get there in a bit, but for now, let’s take a look at how the code works.

In the code, we specifically use two main functions of the library: the constructor and i2c.write(). The constructor creates an I2C device object with the given address. The i2c.write() function then writes a list of bytes to the device’s address (without specifying the memory location on the device). The LCD display requires specific commands in order to activate its different write modes which the lcdDriver class wraps up nicely, making our final execution script quite compact.

Here we’re using two objects of different classes to accomplish our goal, TemperatureSensor and Lcd. If we had other devices we wanted to include in this experiment, we can write more class definitions and load them using the import statement.

To briefly explain, the asterisks (*) mean ‘for all instances’. The position of the asterisk corresponds to ‘minute’, ‘hour’, ‘date’, ‘month’, and ‘year’ in order from left to right. The path at the end is the script or command you want to run. Basically, this line tells cron to run the STK09-temperatureLCD.py script once a minute.

When getting started with microcontrollers, you’ll quickly discover just how common it is to run out of available port lines. This is especially true when interfacing to parallel devices such as the common LCD (liquid crystal display). Inexpensive LCDs show up all the time on the surplus market, but these usually require either four or eight data lines in addition to several control lines. Of course, you could always dip into your wallet and spring for more advanced displays featuring I2C or SPI serial inputs, reducing the wiring considerably.

On the other hand, with just a pittance of external parts, it"s easy to reconfigure even the humblest LCD to run well on only two port lines of the microcontroller. This article describes just such a technique you can readily incorporate in your own designs.

Why would you really want to roll your own? There are several very practical reasons. First, as intimated above, parallel LCDs are ridiculously cheap nowadays, and with just a handful of inexpensive components you’ll get the best of two worlds. Then again, not all microcontrollers support the I2C or SPI protocols should you even be tempted to go that more expensive route. This is especially true with eight-pin chips — the very ones you’re likely to need a reduced port line count for anyway.

Even better, we’ll get direct software control over all the neat visual features of the LCD — things like panning, scrolling, various types of cursors, custom characters, blinking, blanking, and lots of other things. Moreover, the methodology used here is important in such diverse applications as communications, electronic music production, data logging, and more, making this an excellent educational experience as well.

One last thing before we dig in: There are lots of designs kicking around that get the serial interface down to three wires. I wanted to go one better and reduce it further. In particular, two wires only are all we need to make the LCD respond reliably. If your curiosity is aroused, carry on and let’s see how it works.

Let’s look at the key features. A single bit (either a zero or a one) is placed on pin 14 — the serial data input. When a low-to-high transition is applied to pin 11, that bit is clocked in to the first stage of the shift register, but only after all other bits are bumped ahead one notch to make room for it. The current contents of the shift register are still “invisible.” If, however, a clock signal is next applied to pin 12, then the presently concealed contents are latched into an external storage register and appear on the associated output pins.

So, the steps are: (a) put a bit on the serial input; (b) strobe the shift register clock; and (c) strobe the storage register clock to make the bits appear on the outputs. By carrying these steps out eight times in a row, an entire byte coming in serially is moved bit-by-bit down the conveyor belt and finally appears on the output pins, QA through QH. If, for some reason, you’d like to clear everything out and start with all zeros again, a high-to-low pulse on pin 10 will accomplish that.

Most of these are set to operate either as eight-bit or four-bit parallel devices, but the latter is more than fast enough for any application I’ve ever come up against. So, we’ll jettison pins 7 through 10 at once simply by grounding them. Anytime we need to send a byte to the device, we’ll do so in halves, transmitting one nibble (four bits) at a time.

LCDs do have the ability to talk back, but that feature is almost never required. So, we’ll also ground pin 5 which is the Read/Write line. This is a one-way street.

It"s possible to send either a command or a character to the LCD. Commands take care of such things as clearing the screen, homing the cursor, and so forth. Characters are indicated by means of the ubiquitous ASCII code set.

To let the display know what the incoming byte (or more accurately, pair of nibbles) represents, use pin 4 — the Register Select (RS) line. When this is low, the byte stands for a command; when high, it is a character.

The few remaining lines are fairly pedestrian in nature and will be explained once we get to the complete circuit. At this point, you have a basic understanding of the pins of both the 74HC595 and the LCD at your fingertips.

Let’s chase them down. Outputs QA through QD of the 74HC595 connect to data inputs D4 through D7 of the LCD, respectively. Recall that inputs D0 through D3 are grounded and not needed for four-bit operation. Output QE of the chip drives the Register Select input of the LCD. Output QG feeds the Enable input of the LCD, but only after being processed by C1 and R4.

IC1 output QH is first inverted by transistor Q1 and then fed back to IC1 to provide a reset or clear operation. The inversion is necessary since the shift register clear pin expects negative logic. If you already have an uncommitted inverter kicking around in your design, you can use it instead and then eliminate Q1, R2, and R3.

The shift register clock and storage register clock lines (pins 11 and 12) are tied together and simply become the clock input. When configured in this manner, the storage register (the latch outputs, in other words) will always be one step behind what’s happening internally within the shift register.

The serial data input is found at pin 14 of IC1. Pin 8 is ground, while pin 16 is +5V. Pin 13 is also grounded to enable the tri-state outputs of the 74HC595.

Pins 15 and 16 take care of the backlight LED, if any. Some units require a resistor as shown in the schematic (R1), while others need a power rectifier. Use whatever the datasheet for your particular LCD specifies.

Now, don’t panic because the progression displayed there is very linear in nature, as you’d expect in serial-to-parallel conversion. The steps are labeled 0 through 10. Furthermore, each row is split in two, showing what the shift register currently holds and what the storage register (called the latch from now on) is presently outputting to the LCD. Don’t forget that the latch is always one clock pulse behind the shift register. Let’s see what happens.

At the outset (Step 0), both the register and the latch are clear; this is the normal condition during quiescence. In Step 1, a one is input. This will eventually first become the enable pulse in Step 8, and then the reset pulse in Step 9.

Step 3 pumps in the RS bit — either zero for a command or one for a character. By the time we get to Step 8, it will obviously be controlling the RS line going to the LCD.

Now, Step 8 is where the action really occurs. Data lines D0 through D4 are in place, as are the RS and Enable bits. The data is locked in to the LCD here. Then in Step 9, the Enable line goes low once more, followed by a reset a split second after that. The 74HC595 is forced to an all-clear state in Step 10, which is back where we originally started.

Just to show what’s all possible with this rig, I put together a complete software package consisting of a demonstration program along with the necessary drivers. This has been implemented for the popular PIC12F683 microcontroller which is, in fact, an eight-pin device just begging for a two-line LCD.

In the downloads, you"ll find source code for the drivers and a complete program demonstrating just about everything an LCD can do. The code is written in the excellent Great Cow Basic language. The nice thing here is that this language supports parameter passing and program structures like procedures and functions, so all the routines are just lying there ready for you to pluck for your own work.

If you feel the need, you can even port the code over to an existing commercial Basic language like PICBasic PRO, since the syntax is virtually the same. In any event, the drivers contain routines for sending nibbles, and complete commands and characters, along with a set of equates for unlocking all of the other features in an LCD.

The PCB was designed as a double-sided affair which could certainly be sent to a professional etching facility. Since the only top-side traces are straight lines, I actually etched my own single-sided board and simply installed jumper wires on top. It was quick and easy, and works very well.

One final thing before I turn you loose to come up with your own application. I thought it might be handy to have an all-in-one arrangement for the two-wire LCD. To this end, the download package for this article also includes the printed circuit board artwork to make a piggyback affair for most any LCD you bump into.

Note: The backlight in an LCD typically requires something to drop the voltage a bit. In the unit shown here, R1 was specified. Sometimes, however, a rectifier is used. Check the datasheet for whatever LCD you employ.
