The T-57152GD042H-LW-AAN and the T-55923GD050J-LW-ABN, small-format TFT LCD modules designed for use in harsh environments, have been introduced by Kyocera.

The T-57152GD042H-LW-AAN, which measures 4.2”, features a resolution of 480x272px, a brightness of 700cd/m², a digital 18-bit RGB interface, a contrast ratio of 1200:1, and horizontal and vertical viewing angles of 160° each. The design is based on automotive requirements and boasts an expanded operating temperature range of -30 to +85°C and a storage temperature range of -40 to +95°C. In addition, the anti-glare surface treatment improves readability in bright surroundings.

Measuring 5.0”, the T-55923GD050J-LW-ABN is a portrait-mode display that features a resolution of 480x640px. Optical characteristics include 800cd/m² brightness and a 500:1 contrast ratio. The viewing angle amounts to 140º horizontally and 110° vertically. This module comes with a 24-bit digital RGB interface and has a wide operating temperature range of -30 to +80°C.

“Portable outdoor devices are liable to fall down and are exposed to low temperatures, heat and humidity. Even in these conditions, they should always work reliably, and our components are designed for that purpose,” says Eberhard Schill, Manager Distribution and Marketing, Kyocera Display Europe.

Active Matrix TFT Colour LCD Display is becoming more pervasive for indoor or outdoor applications, especially the demand in wide temperature TFT LCD is growing in many fields. Winstar Display offers a full range of wide temperature TFT LCD modules; available in various sizes from 3.5" to 12.3". These TFT modules can be operating at Wide Temperature Range from -30℃ to 80℃ or up to 85℃.

ASI-T-17711A1SPN/D is a 1.77 inch transflective TFT with a resolution of 160 x 128, SPI interface and with a brightness of 110 Nits; viewable in direct sunlight.

ASI-T-240DA10SMN/AQ is a 2.4 inch high brightness TFT with a resolution of 240 x 320, SPI & MCU interface, IPS all-angle view and with a brightness of 1000 Nits; viewable in direct sunlight. It also features an extra wide operating temperatures of -30 to +80C; perfect for extreme environmental applications.

ASI-T-350EA8RCY6/A is a 3.5 inch high brightness TFT with a resolution of 320 x 240, 24-bit Parallel RGB/Serial RGB/CCIR/YUV interface and with a brightness of 850 Nits; viewable in direct sunlight with Capacitive Touch Panel

ASI-T-350EA10SRN/A is a 3.5 inch TFT with a resolution of 320 x 240, SPI & RGB interface and with a high brightness of 1,000 Nits and wide temperature range of -30 - +85 C.

ASI-T-430FA2F6/AY is a 4.3 inch IPS TFT with a resolution of 480 x 272, RGB interface, a brightness of 220 nits, wide operating temperature and a capacitive touch panel.

ASI-T-430MA10FN/A is a 4.3 inch TFT with a resolution of 800 x 480, IPS all view, RGB interface, a brightness of 1000 Nits with an ultra wide temperature operating and storage range.

ASI-T-430MA8F6/A is a 4.3 inch TFT with a resolution of 800 x 480, IPS all view, RGB interface, a brightness of 850 Nits, capacitive touch panel with an ultra wide temperature operating and storage range.

ASI-T-700MAKFN/A is an industrial grade, high reliability, 7 inch TFT with a resolution of 800 x 480, 24-bit RGB interface, wide temperature range, IPS all view and with a high brightness of 1000 Nits; viewable in direct sunlight.

ASI-T-10251248AKLN/D is a 10.25 inch wide TFT, with a resolution of 1280 x 480, LVDS interface, IPS all view, with wide temperature operation and storage and a high brightness of 1,000 Nits.

ASI-T-1040GA6TN/D is a 10.4 inch wide TFT, with a wide operating temperature and a resolution of 640 x 480, All View display, RGB interface and a brightness of 500 Nits.

ASI-T-1040HB4LN/D is a 10.4 inch wide TFT, with a wide operating temperature and a resolution of 800 x 600, LVDS interface and a brightness of 400 Nits.

ASI-T-1210HB4LN/D is a 12.1 inch wide TFT, with a wide operating temperature, a resolution of 800 x 600, all view display, LVDS interface and a brightness of 450 Nits.

US Micro Products manufactures a wide selection of TFT LCD (Active Matrix LCDs) displays to accommodate the needs of OEMs across many different industries, including medical, industrial, gaming, military and many more.

An array of available interfaces, brightness levels, and temperature ranges ensure that our TFT LCDs work well with your design and in the environment of your choice

A full color 240xRGBx320 pixel TFT display module with 2.2" diagonal active area. Very small text and images look sharp on this graphic display, with its dense pixel pitch of 0.141 x 0.141 millimeters. The TFT"s 6:00 o" clock viewing direction works well for devices that must be easy to read above eye level without fading, such as signal analyzers or other benchtop laboratory equipment.

With a built-in Sitronix ST7789V or compatible display controller, the logic voltage range of 2.5v to 3.3v allows direct connection to 3.3v processors.

Buy with confidence. Our Logistics department is experienced at sending products anywhere in the world where permitted. This TFT display module has a limited 1-year warranty and free technical support.

GDT250T2080 is a 2.5 inch color TFT-LCD display panel, 320x240 resolution, wide operating temp. -30℃~85℃, suitable for outdoor or cold environment, 4:3 contrast, 6 o"clock viewing angle, surface anti-glare treatment, 18-bit RGB (with T-CON) + 4-wire SPI interface, superior display quality, wide range of applications.

GDT250T2080 is a 2.5 inch color TFT-LCD display panel, 320x240 resolution, wide operating temp. -30℃~85℃, suitable for outdoor or cold environment, 4:3 contrast, 6 o"clock viewing angle, surface anti-glare treatment, 18-bit RGB (with T-CON) + 4-wire SPI interface, superior display quality, wide range of applications, it can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.

{"specs":[],"skus":[{"id":4697,"useViewType":false,"productId":373,"templateId":1,"code":"","name":"2.5 inch TFT LCD Display Panel, Wide Operating Temperature, GDT250T2080","stock":0,"price":0.00,"retailPrice":0.00,"weight":0.00,"status":"1","isDefault":"1","createDate":"2022-03-08 11:33:57","updateDate":"2022-03-08 11:33:57","productSkuSpecs":[],"moq":1,"skuId":0,"chargedWeight":0.00}],"specConfs":[]}

RFF700A9-AWW-DNN is a 7-inch wide temperature TFT LCD display with aspect ratio: 15:9, resolution 800x480 dots. This TFT module uses IPS screen which allows users to see the display clearly at wider angles. The brightness is 500 cd/m2 with contrast ratio 1,000:1. With the help of a anti-glare display surface, the screen doesn’t reflect light and preserves better image quality.

This wide temperature LCD module uses HX8249-A + HX8678-C IC which supports 24 bit R.G.B interface. VCC voltage of RFF700A9-AWW-DNN ranges from 2.7V to 3.6V; typical value is 3.3V. The module works within wide temperature range from -30℃ to +80℃; storage temperature is -40℃ to +85℃. In this RFF700A9 series, there are resistive touch screen (RTP) and capacitive touch screen (PCAP) options available. We also provide a high brightness version.

Pacer offers an extensive range of colour TFT LCD panels from 1.8″ through the popular 3.5″ and 5.7″ sizes to 82″. Our range includes sunlight readable panels from 5.6″ to 70″, bar cut panels, and SMART TFT displays with built-in control. We offer TFT displays with high brightness, high contrast ratio, wide viewing angle, wide temperature operation, longer lamp life, and lower power consumption.

TFT displays are used extensively in many industrial, commercial and scientific applications, including ATMs, POS terminals, kiosks, security systems, lottery and gambling gaming machines, medical equipment, factory automation, digital advertisement signage, transportation information, and marine equipment.

TFT technology is being used to replace Mono LCD in many applications, and Raystar Optronics now offers a 5.2″ TFT module designed specifically to fit the footprint of the industry standard RG24064-series 240×64 mono graphic STN LCD. The RFS520A can replace traditional STN displays of 8×2 or 16×2 format as it shares the same 16 pin footprint.

Our TFT modules are fully supported with a variety of options including wide operating temperatures, high brightness and contrast, built-in DC-DC and temperature compensation circuitry and most with white LED backlights. Resistive Touchscreens and Projected Capacitive Touchscreens are available for most models. Many panels can be configured as a kit – see our Interface Kits page for more details.

IMPORTANT ANNOUNCEMENT – Mitsubishi has decided to end production of TFT-LCD modules, as the company is no longer able to maintain the products’ competitiveness after significant price falls in the global market. Production of TFT-LCD modules is scheduled to end in June 2022 with a Last Time Buy date of June 2021. Please contact us as soon as possible to discuss last time buy or identification of suitable alternative displays.

Raystar is a professional TFT (Thin Film Transistor) module manufacturer. Whether you need a TFT display with control board, high brightness, wide viewing angle, monochrome or bar type, we have TFT active matrix display models for you to choose from.

LITEMAX® Industrial Display solution provide a wide range of reliable displays from 5.7″ to 85″ including LCD panel modules, open frame LCD displays, outdoor displays, and panel mount monitors. LITEMAX have developed and focused on LCD display technologies such as high brightness technology, optical bonding solutions, and color enhancement technology that bring more add-on value to enhance their products.

According to the popularization of display applications, the TFT LCD display have to adapt the Extreme Temperature and Different EnviromentsFIRST Components/ Evervision’s Wide Temperature TFT LCD Series are designed specifically for operation in harsh environments and under changing temperature. Furthermore, we have a solution for low temperature environment. Let’s find out!

The LCD in cold temperatures may cause misreading because of the response time of LC (physical characteristics). It will turn slowly and make the screen overlap. Additionally, it may cause permanent damage to the display if LCD panel left in such conditions for extended periods.

Fortunately, ​there are a number of solution such as specialty liquid crytals (LCs) and other materials for application requiring the use of a display in extreme environmental condition. FIRST Components/ Evervision Wide Temperature TFT LCD Display overcome these challenges through the use of applied heating and cooling solutions.​

At present, the common TFT LCD modules on the market have a wide range of definitions of -20~70 °C. For industrial control, vehicle and outdoor products, this temperature range always can’t meet the needs of such usage.

Fortunately, our Wide Temperature TFT LCD Display can work under extreme environments with operating temperatures ranging from -30°C to +80°C, and the maximum for some models can reach 85°C. These TFT displays are full color LCDs available in industry standard sizes rangingfrom 3.5″ to 15.6” TFT LCD display and widely used in cold or heat condition throughout the world.

In low temperature environment, liquid crystals will be condensed and cause the screen blanked out. In order to prevent the problem, you may need to add a Glass Heater to your TFT LCD Module.

It can optimize the LCD visual clarity and operate normally by heating up to the right temperature. With Glass Heater, displays and touch screens remain usable in cold, high humidity/low dew point environments and locations where ambient temperature can change quickly.

Made for any rugged application this 7.0″ TFT comes with a high resolution of 1280x768dot, super-wide viewing angles, high brightness 1000cd, high contrast 1000:1 and a wide operating temperature range of -40 to +80C. It also manages high vibration and shock for outdoor industrial devices.

Mitsubishi Electric also offers 7.0” / 8.0” / 12.1” / 15.0” and 19” TFT with pcap-touch for rugged applications! In total they have more than 34 TFT-LCD modules with super-wide viewing angles.

Liquid crystal displays (LCD) have become an essential component to the industry of display technology. Involved in a variety of contexts beyond the indoors like LCD TVs and home/office automation devices, the LCD has expanded its usage to many environments, such as cars and digital signage, and, thus, many temperature variations as well.

As with any substance that requires a specific molecular characteristic or behavior, LCDs have an operating temperature range in which the device, if within, can continue to function properly and well. In addition to that, there is also an ideal storage temperature range to preserve the device until used.

This operating temperature range affects the electronic portion within the device, seen as falling outside the range can cause LCD technology to overheat in hot temperatures or slow down in the cold. As for the liquid crystal layer, it can deteriorate if put in high heat, rendering it and the display itself defective.

In order for the LCD panel to avoid defects, a standard commercial LCD’s operation range and storage range should be kept in mind. Without adaptive features, a typical LCD TV has an operating range from its cold limit of 0°C (32°F) to its heat limit of 50°C (122°F) (other LCD devices’ ranges may vary a bit from these numbers).

The storage range is a bit wider, from -20°C (-4°F) to 60°C (140°F). Though these ranges are quite reasonable for many indoor and even outdoor areas, there are also quite a few regions where temperatures can drop below 0°C or rise above 32°C, and in these conditions, LCDs must be adapted to ensure functionality.

Heat, can greatly affect the electronics and liquid crystals under an LCD screen. In consideration of heat, both external heat and internally generated heat must be taken into consideration.

Seen as the liquid crystals are manipulated in a device by altering their orientations and alignments, heat can disrupt this by randomizing what is meant to be controlled. If this happens, the LCD electronics cannot command a certain formation of the liquid crystal layer under a pixel, and the LED backlighting will not pass through as expected, which can often lead to dark spots, if not an entirely dark image. This inevitably disrupts the display’s readability.

Depending on the upper limit of the operation temperature range, LCD device can be permanently damaged by extreme heat. With long exposure to extreme heat, besides the destruction of the liquid crystals, battery life can shorten, hardware can crack or even melt, response time may slow to prevent even more heat generation from the device.

The LED backlight and the internal circuitry, typically TFT-based in the common TFT LCDs, are components that can generate heat that damages the device and its display. To address this concern with overheating, many devices use cooling fans paired with vents.

Some devices that are used in extremely high ambient temperatures may even require air conditioning. With air vents to carry the heat out, the device can expel it into the surroundings.

In the opposite direction is extreme cold. What typically occurs in the cold is “ghosting” (the burning of an image in the screen through discoloration) and the gradual slowing and lagging of response times. Like heat-affected LCD modules, the extreme temperature can affect the liquid crystals. This layer is a medium between the liquid and solid state, so it is still susceptible to freezing.

An LCD device can be left in freezing temperatures because it will likely not be permanently damaged like in the heat, but it is important to understand the device’s limits and how to take precautions when storing the device. The standard and most common lower-bound storage range limit is -20°C, below freezing, but if possible, it would be best to keep it above that limit, or else there is still a risk of permanent damage.

If the device is not adapted for the cold, it would be good to keep it bundled up, trapping the heat within layers. However, this is only a temporary solution. Adapted, rugged devices have advantages such as screen enclosure insulation for heat level preservation and, in more extreme cases, heaters to generate extra heat to raise the internal temperature to a level above the minimum.

When selecting the appropriate module, it is necessary to understand the device’s expected primary application. The application will decide factors such as display type, environmental conditions, whether or not power consumption is a factor, and the balance between performance and cost. These factors can have an effect on the operation and storage temperature ranges for the device.

Display types have a lot of variation. Choices like alphanumeric or graphic LCD, human-machine interactive LCD modules and touchscreen panels capabilities, the width of the viewing angle, level of contrast ratios, types of backlighting, and liquid crystal alignment methods are often considered. For example, the twisted nematic LCD provides for the fastest response time at the lowest cost, but cannot offer the highest contrast ratio or widest viewing angle.

Environment-based factors must consider things besides the obvious temperature like UV exposure and humidity/moisture, as they all are necessary in finding the perfect fit extreme temperature LCD module.

Besides the LCD modules, recent new products have opened doors in wide temperature range displays, such as OLED displays. OLED displays offer better displays in regard to contrast, brightness, response times, viewing angles, and even power consumption in comparison to traditional LCD displays.

These benefits, in addition to its ability to achieve a wide temperature range, provide more options for consumers in search of high quality displays for extreme climates.

| -22 to +185 deg.F) model of a command-controlled touch TFT module designed to facilitate quick embedded GUI development and reduce system costs with powerful built-in commands.

This new display can operate in a wide temperature range -30 to +85 deg C (-22 to +185 deg. F) without any adverse effects. This is perfect for refrigeration and heating applications.

The GTWQ043C3B00PWA is based on Noritake VFD command sets. It has a combination of Noritake’s GU3000 ASCII-based text commands, full color image commands, and scalable-font compatibility. The module can work with a wide range of low and high-end micro-controllers using industry standard serial interfaces (Async., I2C, SPI, and USB).

A number of TFT solutions are offered. Serial TFT, I2C TFT, USB TFT, RS422 TFT, SPI TFT and Parallel 24bit RGB TFT. TFT, or Thin Film Transmissive, display technology uses the same control techniques as an LCD, but permits larger screen sizes by adding transistors to address pixels by row and column rather than individually. Additionally, TFT units offer red, green, and blue elements for each pixel to produce a full range of colour output. The brightness of each colour element is individually controlled by a number of bits, typically between 5 and 8, to produce up to 16 million colours. These units are driven by an LED backlight which requires moderate power input, and can be varied to control brightness, typically up to 600 nits. These units have an operating range similar to LCDs of -20C to 70C, but offer increased contrast performance, typically up to 500:1, and viewing angles of up to 140 degrees. High display resolution and touch overlay options make this technology attractive to higher end HMI applications. TFT is available on GTT, EVE, HTT and Parallel Displays.
