There are many transmitter options available for mini quads. While many would recommend a high end transmitter, beginners might choose to save a bit of cash on selecting a TX. This is completely understandable when you don’t know if the hobby is really for you, and this is where the FlySky range comes in.

Disclaimer: this is NOT a sponsored post, we did not and will not get paid by Flysky for writing this guide. This article was created purely for the benefit of the FPV community, and with the hope that some people who have the passion but with a small budget can find a more affordable way to fly. A radio transmitter is often referred to as a TX, or radio controller. Make sure to check out our tutorial to learn the basics of radio transmitter and receiver.

FlySky provides the market with some of the most affordable radio control solutions available. The range is most suitable for people who are incapable of comprehending the addictive power of flying FPV mini quad… Sorry, I mean people who just want to ‘try it out’, and don’t require all the bells and whistles of something more expensive.

There are 4-channel transmitters available from FlySky, but while a 4-channel TX is fine for simple RC cars, boats and basic planes, we really need 6 or more channels to operate a mini quad.

Different TX and RX might be capable of different protocols. In this section we will give you some basic understanding of the protocols used by Flysky transmitters and receivers..

Below is our pick of the transmitters available from FlySky, those prefaced with a letter ‘i’ are the newer options, the number denotes how many PWM and PPM channels each supports. FS-TH9X

The Nirvana NV14 is developed together by Flysky and UndergroundFPV (UFPV). This is the latest offering in the Flysky radio lineup, featuring a gmaing pad style housing and a colour touch screen. It also supports external JR module and compatible with TBS Crossfire and Frsky R9M modules.

The Palatin is the latest offering in the Flysky premium lineup. It has many of the new features in the Nirvana but in a much more traditional style shell. It also supports the latest AFHDS 3 air protocol.

I have included the older FS-TH9X here because it’s worth mentioning that it is capable of running OpenTX. OpenTX is open source TX firmware, which is a powerful transmitter operating system. It allows you to change menu displays, welcome screens and various other options on your TX via LUA scripts.

The layout of the X could have done with a touch from the design team of the S but as they have stuck with the original form factor of the i6, this means that there are some design flaws that have re-emerged. The inclusion of the USB port on the S was great, but it has been frustratingly excluded here, this means that you will need to purchase a dedicated simulator adapter to use with your PC simulators.

The FS-i8 is the newest TX on the list from FlySky, and as the name suggests it offers 8 native channels, serving to fill the gap between the i6 range and the i10.

Borrowing heavily from the design of the i10, the FS-i8 isn’t the best looking TX available, (some will say that’s a gross understatement) but that can be put, in-part, down to the large TFT colour touch-screen.

I think the size of the screen may be useful if you don’t have great eyesight, but TFT screens of this size can be even more difficult to make out in bright sunlight than a backlit black and white LCD. I also think the touchscreen is more gimmick than actual functionality at this stage, though I’m sure we can expect to see more touch-screens providing a real improvement to user friendliness in future.

The FS-i10 is the top of the range offering from FlySky and provides 10 native channels with all the (5) knobs and (7) switches to make full use of them all. Like the i8, the i10 also utilizes a rechargeable LiPo battery and a USB port for charging, connectivity for sims and trainer functions.

The appearance of the i10 is a bit more classy than the red plastic of the i8, but again its face is marred by the massive touch-screen! The i10 and i8 both weigh in at 720g, almost double the weight of the i6S at 410g.

Thanks to Loopyroberts for his comment below confirming that the i10 does support the original AFHDS system, so you will be able to bind with older FlySky RX.

One point that has me worried about the i10 (and the i8 as well) is that there is no mention of how long the supplied rechargeable battery lasts. While using a LiPo to power the TX is a good idea (IMO), I think that the large screen might burn through the battery quite quickly.

The Turnigy Evo is not a Flysky TX, but we’d like to include it in this list because it uses the same TX protocol as Flysky TX’s, and it’s compatible with Flysky’s RX as well.

Receivers are where FlySky would most benefit from adding a few more solutions to their range, they are lagging behind the market leaders when it comes to full featured micro RX options.

So much in this hobby is a balancing act, “motor KV” vs. “prop size”, “battery weight” vs. “flight time”, and FlySky receivers are no different. You will be required to do a bit of ‘balancing’ to ensure that you get the features you are expecting from your RX…

The older models in the FlySky RX range are prefaced with the letters ‘iA‘ and are relatively large and heavy, weighing between 15 and 20 grams! As keeping weight down is critical in a mini quad, I have excluded the bulky options to focus on these lighter weight solutions.

The FS-RX2A, can be considered an updated A8S and is one of the smallest RX made by FlySky at the moment. It weighs in at 1g, and measures only 12mm x 15mm to gift the market with a true micro FlySky RX. The

Another compact and light weight receiver option and with AFHDS2 protocol support. No telemetry, but supports both PPM and iBUS protocols. Compatible with popular radios such as the Turnigy Evolution, FlySky i6S. It also supports failsafe in iBUS. Protocols : PPM, iBUS

The Eachine Minicube Flysky RX is a great option for outdoor models between 100mm and 180mm due to its 20x20mm mounting pattern, and pre-installed buzzer.

This receiver was designed together with UndergroundFPV for Flysky Nirvana NV-14. It has diversity antennas and works in AFHDS 2A protocol. Outputs PPM / i-Bus / S-Bus signals. Protocols : SBUS PPM iBUS

I think that for FlySky, telemetry has been a bit of an afterthought, and when most newer FCs come with an integrated OSD, who can blame them if they are focussing sales towards the FPV market? In reality though telemetry can be considered one of the ‘bells and whistles’ I referenced earlier, and for the beginner is not a necessity by any means.

As you can see, when using a FlySky RX there can be some sacrifices that must be made to ensure you have an operational failsafe. Failsafe is probably not as critical to an indoor model or a micro that you use in the garden, but it is far more important than telemetry. For some reason the most suitable RX FlySky make for larger models (the FS-X6B) only provides a failsafe on the older PWM protocol, which is nonsensical in my view.

The selection of RX that I have detailed above are the cream of what Flysky currently have to offer for mini quad and micro quads, but there are pro’s and con’s to each.

On the other hand, I honestly have to say that out of all the Flysky TX we’ve seen so far, the Flysky i6X is the one I would choose for flying a mini quad. The FS-i6X is inexpensive, provides 10 channels, and can operate on both AFHDS and AFHDS-2A systems. It’s compatible with iBUS/SBUS receivers as well as the older PWM and PPM receivers.

My next pick would be the Turnigy Evolution, and the Flysky i6S is also a pretty good choice if you don’t mind the missing physical trim buttons and lack of support for older AFHDS receivers.

The i8 and i10 offer more native channels and are well provisioned with switches, however despite the attempt to integrate the updated technology of a touchscreen, I feel that these 2 fail to provide much actual improvement over the i6X.

It makes sense for FlySky to include these options in their range, however they are catering for the affordable end of the market. Since the introduction of the FrSky Taranis QX7 at a similar price point to the FS-i8, there is now some stiff competition at the $100 market level.

Other options for those that are unsure about committing to a single RC system are starting to hit the market now. There are multi-protocol TX and external modules to support a bind with FlySky, FrSky, Futaba and Devo RX as well as many toy grade quadcopters out there.

I wish Flysky would support OpenTX with their radios, as it allows for more freedom of customization and settings. Another super useful feature that is missing is the LUA script that has been popular with the Frsky Taranis, which allows the pilot to conveniently change PID, rates even VTX settings from the radio. Author: Tom Allport (IntoFPV ID: Tom BD Bad)

Turnigy TGY-i6S Transmitter Specs:Channels: 10 (PPM) or 6 (PWM)RF range: 2.408 ~ 2.475 GHzBandwidth: 500 KHzRF channel: 135RF power: Less than 20 dBm2.4GHz system: AFHDS 2AModulation type: GFSKStick resolution: 4096Low voltage alarm: Yes (lower than 4.2V)DSC port: Micro USB /PPMPower input: 4.2V – 6.0VAntenna length: 26mm x 2Size (Length x Width x Height): 179 x 81 x 161mmWeight: 410gCertificate: CE0678, FCC ID:N4ZI6S00, RCM

Specification Channels: 4Model Type: Car / BoatRF Range: 2.4055 - 2.475GHzRF Power: Less than 20dBmBand: 140Bandwidth: 500KHz2.4GHz System: AFHDS 2A Code Type: GFSKSensitivity: 1024Low Voltage Warning: Yes (Less than 3.7V)DSC port: Yes ( USB,...

The FGr4 adopts FlySky"s third-generation automatic frequency hopping digital system, AFHDS 3. It uses a single-antenna, bidirectional transmission system that is uniquely designed to save space and supports standard PPM, and i-Bus signals.

FlySky 2.4 Ghz 4 channel radio system includes a FS-A6 receiver. This radio offers a great alternative to many land based radio systems and it will...

The FS-i6S transmitter and FS-iA6 receiver constitute a 7 channel 2.4GHz AFHDS 2A digital proportional computerized RC System. This system supports quadcopters.

This FlySky FS-iA6B 6ch Receiver works great with the FlySky FS-i6 Controller. This compact 6 channel receiver is great for any model using up to 6 channels and, with a range exceeding 500 meters, it can be considered to be full range for all but the...

The NV14 is an amazing product developed in conjunction with Underground FPV. Moving away from traditional transmitter designs the NV14 has a unique ergonomic design, open source firmware, ports for expandability, a color touch screen display, and most...

FLYSKY FS-G7P SURFACE TRANSMITTERNew from Flysky is the FS-G7P Surface Transmitter. This 7 channel unit was designed to be a large screen transmitter for entry level drivers. Check out these highlights-

Two-channel, digital control equipment for car models and boats flysky GT2. The equipment provides trimmers of both channels, flow adjustment for the first channel and reverses of both channels.SPECIFICATION:Transmitter:Frequency is FM 2.4GHz. AFHDS...

The brand new FS-i10 uses the FLYSKY 2.4GHz AFHDS 2 (AUTOMATIC FREQUENCY HOPPING DIGITAL SYSTEM 2 / or second -generation automatic frequency hopping digital system),

Flysky mini receiver FGr4B for rc car, rc truck, rc boat, compatible with Flysky AFHDS 3 transmitters, noble nb4, noble pro, noble lite and RF modules4 channels single-antenna bidirectional transmission system and is uniquely designed to install and...

Features:• Reliable, interference free 2.4GHz AFHDS 2A signal operation• Ultra light weight design• Dual antennas for most reliable interference free operation

Specialising in transmitters (radio controllers) and receivers FlySky are proud manufacturers of the world"s most popular 2.4ghz transmitter, the FS-GT2. The GT2 is very reliable and affordable, and found in dozens of RTR (ready to run) RC kits across many manufacturers.

FlySky also manufactures a lot of high-end transmitters like the FS-iT4S which features real-time telemetry and a colour touch screen, and the range-topping Noble NB4.

The FGr8B receiver adopts Flysky"s third-generation automatic frequency hopping digital system (AFHDS 3). It uses a single-antenna bidirectional transmission system and is uniquely desi..

OverviewFlySky GT-2 2.4ghz system is an entry level transmitter offering the reliability of 2.4Ghz signal technology with very sensitive 3ch long antenna receiver for RC Car or Boat. Powered by 8 AA t..

The FlySky GT2B features 3 channel operation, interchangeable hand grips, adjustable steering dual-rate, servo reversing and a rechargeable li-ion battery which eliminates the need for buy..

Overview The popular FlySky GT3B AFHDS 2.4ghz 3 Channel radio system!Featuring a large Back-lit LCD, A quick access jog wheel for function selection and programming, 10 Model memory, Steering wheel ex..

Overview The popular FlySky GT3C AFHDS 2.4ghz 3 Channel radio system!Featuring a large LCD display, A quick access jog wheel for function selection and programming, Model memory, 3.7V Li-Ion rechargea..

Specifications Compatible transmitters: all AFHDS 3 transmitters and RF Modules (PL18, Paladin EV, NB4, NB4 Lite, etc.) Model Type: Car/boat etc PWM Channels: 4 RF: 2.4GHz Protocol: AFH..

The FS-G4P 4 channel transmitter uses Flysky’s latest in-house developed 2.4GHz ANT digital auto RF link channel switching protocol complimented with a slick race car design exterior. It als..

OverviewThe Fly Sky FS-GT5 Surface Radio comes with the ever reliable 6 channel 2.4GHz AFHDS 2A (Automatic Frequency Hopping Digital System) to provide the most reliable link between radio and RC Car ..

OverviewThe FS-i6S uses the solid and reliable 2.4GHz Automatic Frequency Hopping Digital System (AFHDS) spread spectrum technology. It is also a superb budget radio for both new and experienced pilot..

Overview The receiver has end-on connectors to enable a neat installation in tight spaces. Built-in connectors allow you to use any of the optional FlySky telemetry sensors. The receiver is capable..

OverviewThe NB4 is the newest, fastest and most stylish Flysky ground transmitter to date. Not only does it look great with its new sleek design and metal finish, it also features new flexibility and ..

FeaturesChannels: 6Model Type: Fixed-Wing/Glider/HelicopterRF Range: 2.4055-2.475GHzRF power: <20dBmRF Channel: 140Bandwidth: 500KHz2.4GHz system: AFHDSModulation Type: GFSKStick Resolution: 4096Lo..

OverviewThis FlySky FS-iA6B 6ch Receiver works great with the FlySky FS-i6 Controller. This compact 6 channel receiver is great for any model using up to 6 channels and, with a range exceeding 500 met..

OverviewThe NB4 is the newest, fastest and most stylish Flysky ground transmitter to date. Not only does it look great with its new sleek design and metal finish, it also features ..

If you are looking for all the best international brands and genuine quality global products, your search ends here. Most people would love to find all their essential products in one location, whenever they choose to buy anything. Hence, it is very essential and beneficial to find a genuine, reliable and trustworthy online store to buy Flysky products. A good online store is a quintessential stop to discover a galaxy of brands and products to suit every requirement. If you are looking for exclusive Flysky products online in Gaborone, Francistown, Moleplole, Selebi-Phikwe , Maun, Serowe, Kanye, Mogoditshane, Mahalapye, etc; you can find it effortlessly on Ubuy which is a one-stop-shop to explore from over 100 million products and brands from international market. It is also the right place to find products that are not easily available elsewhere.

To find a perfect collection of unique and popular global products from Flysky, Ubuy online shopping can help you to get the right product that suits your specific requirements. You can discover the latest offers on Flysky products and save money each time you decide to purchase. Searching for your preferred products and brands across towns and cities may not be necessary for this modern technological era since your products are just one click away. So, get ready to find and buy all your desirable products from your best-loved brands on Ubuy.

4. Quality issues – What to do if you find a problem with your radio? E.g. damaged switches, buttons, antennas, etc., poor touch response or other screen issues, not booting etc.

If the seller does not want to take any action, please contact Flysky via our email address with the product model number, product problem, product serial number and order information and seller information (product model, product serial number, order information, please provide pictures, provide and records of communication with seller)

6. What should I do if the remote control is damaged? If the potentiometer, button switch, antenna, screen, etc. are damaged during use, the remote control or receiver power supply is connected incorrectly or reversely burned out.

For power problems domestic users can contact Flysky’s after-sales service for factory repair; foreign users are advised to abandon repairs if they do not have overseas service points and cannot repair themselves.

If you need to update, please check the latest firmware of the remote control on the Flysky website. If your firmware version is lower than the official version, please check the “Software Version Update Record” to confirm whether you need to upgrade.

You can download it from the official website product page or download it from github at https://github.com/open-flysky/FLYSKY-ProductInformationDownload.

Please check the surrounding environment for interference. If there is a mobile phone base station, a high-power router, a 2.4GHz high-power wireless device, etc., nearby it is likely to cause some interference.

If you cannot solve the issue please contact the seller to go through the after-sales process; if the seller does not process, please contact Flysky via email with the product model, product problem, product serial number and order information and seller information (product model, product) Please provide the image of the serial number and order information, and provide the communication record of the seller and the seller.)

Different radios have different settings for the failsafe function. Radios that have a screen can be set up on the radio itself. Radios without a screen must be set up with the receiver. The specific method is subject to the manual.

If the gimbal is not operating as expected it may need to be calibrated. If the radio has a screen it can be calibrated via the radio itself in settings. If the radio does not have a screen a key combination will activate calibration mode. Refer to the radio’s user manual for more information.

The receiver has two types of interfaces for outputting PPM signals. Class 1 is a sticker or PCB silk screen labeled PPM interface. This interface only outputs PPM signals; Class 1 is a receiver labeled PPM/CH1 or P/CH1. It is necessary to set the signal type to PPM through in the radio settings to output the PPM signal (generally under the receiver setup menu, refer to the manual).

If you need more information Flysky products such as schematics (limited open source products), component model numbers, certifications, ibus information, etc., you can send us an email with the subject of the message clearly indicating the needs and uses.

In addition to PL18, other Flysky product require the opening of the radio to switch the left and right gimbals. For details, please refer to the products user manual.
