ICT test device mainly tests the performance of all components. The aim is to check if there are problems or defects for boards in production. The test object is a semi-finished product, but the FCT fixture test object is a PCBAfunctional test. FCT fixture mainly to simulate the product working environment to verify the function of boards during working conditions. ICT test device and FCT fixture both are online tests.

FCT refers to the functional test in which PCBA connects the power. It includes voltage, current, power, power factors, frequency, duty ratio, position determination, LED lighting, LED color, sound recognition, temperature measurement and control, pressure measurement and control, precision micro motion control, FLASH, and EEPROM online programming. It refers to the operating environment (excitation and load) that provides simulation against the UUT.

The earliest function tests are mainly automatic and semi-automatic. In order to simplify the design and reduce production costs, manual and semi-automatic are still used. With the technology development, to save production costs and improve production efficiency, most of the functional tests are fully automated.

You can request full PCB manufacturing Price that Rayming provide PCB,assembly, electronic components and testing, Also you can ask partial PCBA quote that you will provide some components by yourself, Our pcb assembly services is flexbile

System control center:The main parts of the full test system composed of PC, MCU, ARM, central processing. The primary functions are to control all test processes, record the contents and results of each step test, and create a final test result.

Control executive:Control executive is composed mainly of I/O. It is the execution of logical actions during the testing process. The system builds various testing environments based on the testing function.Measurement part: The measurement part is mainly composed of a special measurement board and instrument. It mainly completes the collection of various analog or digital during the test process. It is also called data collection.Data processing and output: The purpose of the final test result is to figureout how to store and output the results data. It will be advantageous for us to control thePCBA quality effectively. This is the responsibility of data processing and output.

In the PCBA batch process, it is impossible to achieve 100% running status on the equipment and human operators. PCBA are good,so it requests all kinds of test equipment and test tools at the end of production. This leads to the other types of testing, such as ICT, AOI,X-Ray, Boundary Scan, to make sure all the circuit boards according to the design of various specifications and parameters.

FCT means providing a simulated running environment (excitation and load) to a UUT, making it functional in different design situations. Then, getting a range of different design situations to improve the UUT function. In short, it is suitable to load to the UUT, and the UUT output shows whether or not the board fits the design; it is called the PCBA functional test. FCT fixture is a fixture that simulates the finished PCBA.

ICT only tests if the PCBA is connected,short-circuited, LCP value, wrong orientation diode, and other semiconductor connections. The principle is to isolate other components then test a single or series-parallel group of components individually.

FCT is different; it is a functional test. It tests PCBA key componentsor output waveform through the relevant voltage or signal and determines if the values are within the acceptable range. Do not test against components. If the component fails, the functionality will be affected.

fiberboard. They are then applied to the computer main board, LED lamp main board, LCD TV main board, communication equipment main board, and other electronic products.

According to the test board and test requirements, select relay control, embedded microcontroller control mode, PC control mode, and PLC control mode. Then select the corresponding components after the mode is determined.

11.Function, lifetime, maneuverability, esthetic should be considered when design work. To achieve stable test and long service life, Beautiful appearance and humanized operation

This part contains PC, MCU, PLC, and other central processor components. Its main role is to control the whole test process and each step of the test content for evaluation and test results. It is the brain of the whole test system.

The control execution part comprises I/O components, induction, and execution mechanism of logical actions in the test process. The system builds a variety of testing environments to achieve the testing functions.

The measurement part is mainly composed of board instruments. It mainly completes the collection of various analog or digital data in the testing process.

5.3.3. Each assembly step should be followed carefully and correctly to ensure the parallelism of the press board to the load board vertical board. This is to ensure the accuracy of the test fixture.

5.3.4. Select the correct test probe, test point normally is Pin ,Component pin using claw needle, if customers have special requirements can use other types of probe (round class). Probe contact 3.5mm-4.0mm, more test points can reduce the contact travel accordingly.

5.3.6. Press bar to choose anti-static black steel bar, choose the flat press bar in the case of not hamper testing and collision, small position can be processed into a cone type

Check the network is correctand check for open short circuits before connecting the device. If any special TP point should be connected during the test, the software should detect the short circuit.

Test for few goods or bad onesunder the test debugging system model. Verify the test results are consistent with the actual product and revise the test standard if necessary.

4.5. Check fixture stability and protection, especially special parts, such as external optical fiber, MIC, automatic card insertion device, adapter plate fixing module, pressing plate needle module, and other special switching devices.

4.13. The tightness of the casing is moderate, without any loosening phenomenon, and  the casing height is correct or not (down test compression is 2/3, up-test compression is 1/3~1/2)

4.16. Whether spare parts meet requirements and prepare the document according to the product list：Customized functional test system (including tester and fixture).

Check whether the air pressure in the appropriate range (4-6kg/cm2), the test program and fixture are correct, and the fixture arrangement is connected in order.

5. When inserting any test periphery, be sure to turn off the test fixture power to avoid damage to the test periphery. Use both hands to hold the two sides of the CPU. Align the CPU slot and insert the CPU’s golden finger from top to bottom. On the contrary, in selecting the application of both hands from the bottom up the CPU out.

8. Please pay attention to the display during the VFA test and make sure it is the correct paint and color. Also, please pay attention to whether the sound emitted by the buzzer on the board is normal.

PCB assembly testing methods are an integral part of the manufacturing process. Reputable electronics contract manufacturers (ECMs) offer a variety of PCB testing methods, but the seven main types include:

In-circuit testing (ICT) is the most robust type of PCB testing in existence. The high price reflects that -- tens of thousands of dollars, though the cost will depend on board and fixture size, among other factors.

An ICT, also known as a bed-of-nails test, powers up and actuates the individual circuitry on the board. In most cases, the test is designed for 100% coverage, but you’ll get closer to 85-90% coverage. The nice thing about ICT is that the 85-90% you get is totally free of human error.

This test involves using fixed probes laid out in a way that matches the design of the PCB. The probes checks the integrity of the solder connection. The bed of nails tester simply pushes the board down on the bed of probes to start the test. There areaccess points predesigned in the board that allows the ICT testing probes to make connections with the circuit. They put a certain amount of pressure on the connection to make sure it stays intact.

This test is for a “mature” product with very few revisions expected. If you don’t have design-for-manufacturing as part of your goal, with the proper pads on the board, you may not be able to use an in-circuit test. Unfortunately, you can’t change your mind and move to an ICT strategy halfway through production.

The test works through the use of needles attached to a probe on an x-y grid obtained from basic CAD. Your ECM programs coordinates to match the circuit board and then runs the program.

In some cases, ICT makes it unnecessary to use flying probe testing, but the PCB has to be designed to fit with the test fixture -- which means a higher initial cost. ICT can be faster and less error-prone than flying probe testing, so you might find the extra cost is worth it. While flying probe testing can be cheaper initially, it may actually be less cost-effective for large orders.

As the name suggests, burn-in testing is a more intense type of testing for PCBs. It’s designed to detect early failures and establish load capacity. Because of its intensity, burn-in testing can be destructive to the parts being tested.

Burn-in testing pushes power through your electronics, usually at its maximum-specified capacity. The power is run through the board continuously for 48 to 168 hours. If a board fails, it is known as an infant mortality. For military or medical applications, boards with high infant mortality are clearly not ideal.

Burn-in testing isn’t for every project, but there are some cases where it makes a lot of sense. It can prevent embarrassing or dangerous product launches before they reach customers.

Just remember that burn-in testing can shorten the product’s lifespan, especially if the test puts your board under more stress than it’s rated for. If few or no defects are found, it"s possible to reduce the testing limit after a shorter period to avoid over-stressing your PCBs.

X-ray testing can check elements that are usually hidden from view, such as connections and ball grid array packages with solder joints underneath the chip package. While this check can be very useful, it does require trained, experienced operators.

It does take time. If you want to get your product out the door quickly, this may not be your best choice. But from a quality and longevity standpoint, functional testing can save face and save money.

A PCB functional test verifies a PCB’s behavior in the product’s end-use environment. The requirements of a functional test, its development, and procedures can vary greatly by PCB and end product.

Figuring out what PCB testing is right for you can be a challenge; there are certainly a lot of methods! Your ECM will know which tests are right for your specific needs, so consult with them often.

And don’t forget about PCB prototyping. This essential element of product launches acts as a test in its own right, allowing you to see the real thing before your market does.
