Pixel, also called Picture Element, A pixel is the smallest unit of a digital image or graphic that can be displayed and represented on a digital display device. A pixel is the basic logical unit in digital graphics. Pixels are combined to form a complete image, video, text, or any visible thing on a computer display

LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

HD TV has 1280×720 = 921,600 pixels; Full HD has 1920x 1080=2,073,600 pixels; 8K TV has 7,680×4,320=33,177,600 pixels. he “K” in 8K stands for Kilo (1000), meaning a TV that has achieved a horizonal resolution of about 8,000 pixels.

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

DPI stands for dots per inch and refers to the resolution of a printer. It describes the density of ink dots placed on a sheet of paper (or another photographic medium) by a printer to create a physical print.

PPI stands for number of pixels per inch. It is kind of pixel density. PPI describes the resolution of a digital image, not a print. PPI is used to resize images in preparation for printing

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

Special names by individual companies: Apple Macbook Pro Retina 6K display, Acer Nitro, ASUS Pro Art , ViewSonic Elite, ASUS TUF ,Samsung edge Infinity-O Display etc.

The display panels used in LCD displays have a fixed, predefined pixel format over a set area. For example, if the panel has a predefined area of 1,024 x 768, there are exactly 1,024 pixels in each horizontal line and 768 pixels in each vertical line or 786,432 total pixels.

Native resolution or optimal resolution occurs when the screen resolution in the display settings is the same as the predefined area of the display panel. Native resolution is typically the maximum display resolution, and HP recommends using LCD displays at the native resolution.

Fixed matrix display uses the number of pixels required for a certain resolution exclusively and typically results in a border or framing effect, but the image size remains unchanged. The fixed matrix display method prevents users from taking full advantage of the display screen size.

Scaling uses an expansion technique known as an interpolated algorithm to widen the resolution to fit the entire viewable area of the screen. Scaling requires the manipulation of pixels adjacent to the text to give individual letters a smoother look. The image remains equivalently sized, but the image might appear blurry due to the dithering and loss of data, color, or information. Scaling is the most common method to make full use of the entire screen when operating in a resolution lower than the native resolution.

Find Display resolution, and then choose an option. It"s usually best to stick with the one that"s marked (Recommended). Monitors can support resolutions that are lower than their native resolutions, but text won"t look as sharp and the display might be small, centered on the screen, edged with black, or stretched.

Note:If you see unexpected changes in your screen resolution, your graphics driver might need to be updated. To see and install available updates, select Start >Settings > Update & Security > Windows Update.

We must verify whether the problem is the display screen of the laptop, video card (GPU), or video settings on the computer. A straightforward way to identify this is to connect the laptop to an external monitor or TV.

If the issue persists on the external monitor, it may be an issue with the video card (GPU) or video settings and not the laptop LCD panel. Go to verify display or video issues in Windows Safe Mode. Otherwise, go to the next step.

Performance issues may occur if there is any damage to the LCD screen. The display may stop working, work intermittently, flicker, display horizontal or vertical lines, and so on, if there is damage to the display screen.

Dell laptops have integrated diagnostic tools that can determine if the screen abnormality is an inherent problem with the LCD screen of the Dell laptop or with the video card (GPU) and computer settings.

When you notice screen abnormalities like flickering, distortion, clarity issues, fuzzy or blurry images, horizontal or vertical lines, color fade, running a diagnostic test on the LCD helps identify if the issue is with the LCD panel.

Press and hold the D key and turn on the computer to enter the LCD built-in self-test (BIST) mode. Continue to hold the D key until you see the entire screen change colors.

If you do not detect any screen abnormalities in the integrated self-test mode, the LCD panel of the laptop is functioning properly. Go to the Update the video card (GPU) driver, monitor driver, and BIOS section.

If you notice any abnormalities in the LCD built-in self-test mode, contact Dell Technical Support to learn more about repair options that are available in your region.

Display settings like brightness, refresh rate, resolution, and power management may affect the performance of the LCD screen on your Dell laptop. Changing or adjusting the display settings can help resolve several types of video issues.

If the diagnostic tests on the LCD panel and the video card (GPU) passed, it is most definitely an issue that is related to software that is installed on the computer. If the above troubleshooting steps did not resolve the issue, you may try to restore the computer to factory default settings as a last resort.

Shenzhen Jingda Display Technology Co.Ltd.is a wholly-owned subsidiary of CNK group(CNK), established in 2014, is adevelopment production and sales of integrated technology-based manufacturers currently the main 3 product lines; 1.TFT COLOR LCD screen. 0.96-10.1-inch color LCD screen,2. Oled, passive, active Oled, 3. Monochrome LCD (Dot Matrix, character code breaking)TNHTN STN,FSTN, VA, hundreds of products for customers to choose product quality is stable and controllable, service customers!

PPD-1110 is a compact LCD display that comes with a small footprint desktop stand. It offers dual functionality served as a main or 2nd display while saving affordable working counter space. PPD-1110 offers multiple interfaces including VGA, DC power jack, DVI-D and audio line-in ports to provide better connectivity. It offers a robust structure with a metal cabinet and well-organized cable management. Elegant, reliable, and user-friendly, PPD-1110 is your best choice for your LCD display solution. Its steady base stand, adjustable angle, and rich I/O ports can fit most application scenarios including retail service, entertainment business, factory automation, and restaurants. FAMETECH, since 1981, is a 9.7-inch LCD Display with resolution 1024 x 768 | POS system manufacturer based in Taiwan. PPD-1110 is a compact LCD display that comes with a small footprint desktop stand. It offers dual functionality served as a main or 2nd display while saving affordable working counter space. PPD-1110 offers multiple interfaces including VGA, DC power jack, DVI-D and audio line-in ports to provide better connectivity. It offers a robust structure with a metal cabinet and well-organized cable management. Elegant, reliable, and user-friendly, PPD-1110 is your best choice for your LCD display solution. Its steady base stand, adjustable angle, and rich I/O ports can fit most application scenarios including retail service, entertainment business, factory automation, and restaurants. The product including: payment terminal, mobile POS, barcode scanner, thermal receipt printer and label printer. ISO-9001 / 9002 certified, total AIDC & POS solutions, fast-responding pre-sale consulting service, technical support, training, after service and customized ODM & OEM service.

Image quality is paramount for creative professionals, and with a 2K QHD (2560 x 1440) resolution panel, images on the ColorPro® VP2756-2K series ensure incredible detail.

Monitor resolution is often automatic and adjusts to fit the screen, but it can default to the wrong view. Another common scenario involves accidentally changing the resolution while working on the settings. When adjusting display settings, it’s possible to change the monitor’s resolution to a point that the screen turns off and you can’t see what you’re doing. In these instances, you can use Windows" built-in recovery modes to get your system up and running in the default settings.

Use the arrow keys on your keyboard to select an option from the nine advanced boot options. Windows has a built-in mode for troubleshooting video problems, called Enable low-resolution video. Press the 3 key or F3 to select this option. Windows will boot using a basic video driver, overriding the resolution settings you changed. When your Desktop loads, its icons will be much larger than normal.

Click on the top-right corner of the Desktop once Windows loads, and type Display. Click Settings and Display to access your computer’s display settings. Click the drop-down arrow beside Resolution to see the available resolutions for your monitor. One of the settings will say Recommended beside it. This is the best resolution your monitor can display as detected by Windows.

Choose the Recommended resolution or any lower resolution, and click “Okay.” The screen flickers while it adjusts to the new setting. Click OK to accept the change and keep these settings. As long as you chose a resolution your monitor could support, Windows will not override it. Reboot the computer to access Windows normally; your newly selected, appropriate resolution will be ready.

The reboot process will reset to the original display settings but you also can simply enter the monitor settings menu and make adjustments as needed. The nice thing about this process is the fact that you only touch the display settings and will not reset any other unrelated settings.

Simply right click on the home screen to retrieve a menu and choose Settings. You can also access this from the menu bar or a general search on Windows 10 and many other programs as well. Click on Display and navigate to your screen resolution settings. You can decrease the resolution within this menu. Test several different settings before settling on the lowest possible option. Your monitor may work with a moderate resolution.

By simply adjusting the monitor resolution settings without a full reboot, you can easily work through each individual option to find the best possible end result.

Windows 10 changed the game somewhat by introducing a scaling resolution model. It functions in the same manner as on a Mac. Luckily, adjusting the settings is straightforward. The resolution sits on a scale that you can access and reduce the scale to fit, as desired.

Click on the gear icon followed by Settings to open a menu. Choose Display and locate the drop down menu labeled Resolution under the Scale and Layout settings header. It will show the recommended monitor resolution percentage setting, but you have the option to adjust this and to reduce the resolution to a lower percentage.

Used on some portable devices, and is a common alternative resolution to QCIF for webcams and other online video streams in low-bandwidth situations, and on video modes of early and later low-end digital cameras.

A common size for LCDs manufactured for small consumer electronics, basic mobile phones and feature phones, typically in a 1.7" to 1.9" diagonal size. This LCD is often used in portrait (128×160) orientation. The unusual 5:4 aspect ratio makes the display slightly different from QQVGA dimensions.

A shared size for older portable video game systems. The nearly-square (but landscape) aspect ratio and coarse pixel resolution gave these games a characteristic visual style. Colour depth ranged from 4 colours (2 bpp) with the original Game Boy, through 16–32 colours (4–5 bpp) with the Atari Lynx and Game Gear, to a maximum of 56 colours (equivalent of 6 bpp) from a wider palette with the Game Boy Color. Also appears as a YouTube resolution option ("144p").

Half the resolution in each dimension as standard VGA. First appeared as a VESA mode (134h=256 color, 135h=Hi-Color) that primarily allowed 80x30 character text with graphics, and should not be confused with CGA (320x200); QVGA is normally used when describing screens on portable devices (PDAs, pocket media players, feature phones, smartphones, etc.). No set colour depth or refresh rate is associated with this standard or those that follow, as it is dependent both on the manufacturing quality of the screen and the capabilities of the attached display driver hardware, and almost always incorporates an LCD panel with no visible line-scanning. However, it would typically be in the 8-to-12 bpp (256–4096 colours) through 18 bpp (262,144 colours) range.

Effectively 1/16 the total resolution (1/4 in each dimension) of "Full HD", but with the height aligned to an 8-pixel "macroblock" boundary. Common in small-screen video applications, including portable DVD players and the Sony PSP.

Various Apple, Atari, Commodore, Sinclair, Acorn, Tandy and other home and small-office computers introduced from 1977 through to the mid-1980s. They used televisions for display output and had a typical usable screen resolution from 102–320 pixels wide and usually 192–256 lines high, in non-interlaced (NI) mode for a more stable image (displaying a full image on each 1/50th / 1/60th-second field, instead of splitting it across each frame). The limited resolution led to displays with a characteristic wide overscan border around the active area. Some more powerful machines were able to display higher horizontal resolutions—either in text-mode alone or in low-colour bitmap graphics, and typically by halving the width of each pixel, rather than physically expanding the display area—but were still confined in the vertical dimension by the relatively slow horizontal scanning rate of a domestic TV set. These same standards—albeit with progressively greater colour depth and upstream graphical processing ability—would see extended use and popularity in TV-connected game consoles right through to the end of the 20th century.

Atari ST line. High resolution monochrome mode using a custom non-interlaced monitor with the slightly lower vertical resolution (in order to be an integer multiple of low and medium resolution and thus utilize the same amount of RAM for the framebuffer) allowing a "flicker free" 71.25 Hz refresh rate, higher even than the highest refresh rate provided by VGA. All machines in the ST series could also use colour or monochrome VGA monitors with a proper cable or physical adapter, and all but the TT could display 640x400 at 71.25 Hz on VGA monitors.

The single fixed-screen mode used in first-generation (128k and 512k) Apple Mac computers, launched in 1984, with a monochrome 9" CRT integrated into the body of the computer. Used to display one of the first mass-market full-time GUIs, and one of the earliest non-interlaced default displays with more than 256 lines of vertical resolution. (Early models used a 384×256 screen; both standards are cut down from the 720×364 of the preceding Lisa model)

Very nearly 3:2 (to within 0.2%); 256:171 exact. Displayed with square pixels on a moderately wide-screen monitor (equivalent to 16:10.67 in modern terms).

The second-generation Macintosh, launched in 1987, came with colour (and greyscale) capability as standard, at two levels, depending on monitor size—512×384 (1/4 of the later XGA standard) on a 12" (4:3) colour or greyscale (monochrome) monitor; 640×480 with a larger (13" or 14") high-resolution monitor (superficially similar to VGA, but at a higher 67 Hz refresh rate)—with 8-bit colour/256 grey shades at the lower resolution, and either 4-bit or 8-bit colour (16/256 grey) in high resolution depending on installed memory (256 or 512 kB), all out of a full 24-bit master palette. The result was equivalent to VGA or even PGC—but with a wide palette—at a point simultaneous with the IBM launch of VGA.

Later, larger monitors (15" and 16") allowed use of an SVGA-like binary-half-megapixel 832×624 resolution (at 75 Hz) that was eventually used as the default setting for the original, late-1990s iMac. Even larger 17" and 19" monitors could attain higher resolutions still, when connected to a suitably capable computer, but apart from the 1152×870 "XGA+" mode discussed further below, Mac resolutions beyond 832×624 tended to fall into line with PC standards, using what were essentially rebadged PC monitors with a different cable connection. Mac models after the II (Power Mac, Quadra, etc.) also allowed at first 16-bit High Colour (65,536, or "Thousands of" colours), and then 24-bit True Colour (16.7M, or "Millions of" colours), but much like PC standards beyond XGA, the increase in colour depth past 8 bpp was not strictly tied to changing resolution standards.

The first PowerBook, released in 1991, replaced the original Mac Portable (basically an original Mac with an LCD, keyboard and trackball in a lunchbox-style shell), and introduced a new 640×400 greyscale screen. This was joined in 1993 with the PowerBook 165c, which kept the same resolution but added colour capability similar to that of Mac II (256 colours from a palette of 16.7 million).

A monochrome display capable of sharp text and graphics for its time. Very popular with the Lotus 1-2-3 spreadsheet application, which was one of PC"s first killer apps. Introduced in 1982.

Introduced in 1984 by IBM. A resolution of 640×350 pixels of 16 different colours in 4 bits per pixel (bpp), selectable from a 64-colour palette in 2 bits per each of red-green-blue (RGB) unit.DIP switch options; plus full EGA resolution (and CGA hi-res) in monochrome, if installed memory was insufficient for full colour at above 320×200.

With on-board 2D and 3D acceleration introduced in 1984 for the 8-bit PC-bus, intended for CAD applications, a triple-board display adapter with built-in processor, and displaying high-resolution, full-colour graphics at a 60 Hz frame rate.

Introduced on MCA-based PS/2 models in 1987, it replaced the digital TTL signaling of EGA and earlier standards with analog RGBHV signaling, using the synonymous VGA connector. As with EGA, the VGA standard actually encompasses a set of different resolutions; 640×480 is sometimes referred to as "VGA resolution" today, however as per the original standard this mode actually only supports 16 colours (4 bpp) at 60 Hz. Other common display modes also defined as VGA include 320×200 at 256 colours (8 bpp) (standard VGA resolution for DOS games that stems from halving the pixel rate of 640×400, but doubling color depth) and a text mode with 720×400 pixels; these modes run at 70 Hz and use non-square pixels, so 4:3 aspect correction is required for correct display.

Furthermore, VGA displays and adapters are generally capable of Mode X graphics, an undocumented mode to allow increased non-standard resolutions, most commonly 320×240 (with 8 bpp and square pixels) at 60 Hz.

Precursor to XGA and released shortly after VGA in 1987. 8514/A cards displayed interlaced video at 43.5 Hz in a 1024×768 resolution, and at 640×480, 60 Hz non-interlaced, both with up to 256 colours.

The high-resolution mode introduced by 8514/A became a de facto general standard in a succession of computing and digital-media fields for more than two decades, arguably more so than SVGA, with successive IBM and clone videocards and CRT monitors (a multisync monitor"s grade being broadly determinable by whether it could display 1024×768 at all, or show it interlaced, non-interlaced, or "flicker-free"), LCD panels (the standard resolution for 14" and 15" 4:3 desktop monitors, and a whole generation of 11–15" laptops), early plasma and HD ready LCD televisions (albeit at a stretched 16:9 aspect ratio, showing down-scaled material), professional video projectors, and most recently, tablet computers.

An extension to VGA defined by VESA for IBM PC-compatible computers in 1989 meant to take advantage of video cards that exceeded the minimum 256 kB defined in the VGA standard. For instance, one of the early supported modes was 800×600 in 16 colours at a slightly lower 56 Hz refresh rate, leading to 800×600 sometimes being referred to as "SVGA resolution" today.

Over the course of the early-to-mid-1990s, "SVGA" became a quasi-standard term in PC games, typically referring to a 640×480 resolution using 256 colours (8 bpp) at 60 Hz refresh rate. Many other higher and lower modes were standardized in the VESA BIOS Extensions, leading to the establishment of "SVGA" and "VESA" as catch-all terms encompassing output modes that surpassed the original VGA specifications.

An IBM display standard introduced in 1990. XGA built on 8514/A"s existing 1024×768 mode and added support for "high colour" (65,536 colours, 16 bpp) at 640×480. The second revision ("XGA-2") was a more thorough upgrade, offering higher refresh rates (75 Hz and up, non-interlaced, up to at least 1024×768), improved performance, and a fully programmable display engine capable of almost any resolution within its physical limits. For example, 1280×1024 (5:4) or 1360×1024 (4:3) in 16 colours at 60 Hz, 1056×400 [14h] Text Mode (132×50 characters); 800×600 in 256 or 64k colours; and even as high as 1600×1200 (at a reduced 50 Hz scan rate) with a high-quality multisync monitor (or an otherwise non-standard 960×720 at 60 Hz on a lower-end one capable of high refresh rates at 800×600, but only interlaced mode at 1024×768).I, 640×480×16 NI, high-res text) were commonly used outside Windows and other hardware-abstracting graphical environments.

Although not an official name, this term is now used to refer to 1152×864, which is the largest 4:3 array yielding less than a binary megapixel (2^20, 1048576 pixels, 1048 decimal kilopixels), thus allowing the greatest "normal" resolution at common colour depths with a standard amount of video memory (128 kB, 512 kB, 1 MB, 2 MB, etc.). Variants of this were used by Apple Computer (at 1152×870) and Sun Microsystems (at 1152×900) for 21" CRT displays.

A widely used aspect ratio of 5:4 (1.25:1) instead of the more common 4:3 (1.33:1), meaning that even 4:3 pictures and video will appear letterboxed on the narrower 5:4 screens. This is generally the native resolution—with, therefore, square pixels—of standard 17" and 19" LCD monitors. It was often a recommended resolution for 17" and 19" CRTs also, though as they were usually produced in a 4:3 aspect ratio, it either gave non-square pixels or required adjustment to show small vertical borders at each side of the image. Allows 24-bit colour in 4 MB of graphics memory, or 4-bit colour in 640 kB.

An enhanced version of the WXGA format. This display aspect ratio was common in widescreen notebook computers, and many 19" widescreen LCD monitors until ca. 2010.

A wide version of the SXGA+ format, the native resolution for many 22" widescreen LCD monitors, also used in larger, wide-screen notebook computers until ca. 2010.

This display aspect ratio is the native resolution for many 24" widescreen LCD monitors, and is expected to also become a standard resolution for smaller-to-medium-sized wide-aspect tablet computers in the near future (as of 2012).

A wide version of the UXGA format. This display aspect ratio was popular on high-end 15" and 17" widescreen notebook computers, as well as on many 23–27" widescreen LCD monitors, until ca. 2010. It is also a popular resolution for home cinema projectors, besides 1080p, in order to show non-widescreen material slightly taller than widescreen (and therefore also slightly wider than it might otherwise be), and is the highest resolution supported by single-link DVI at standard colour depth and scan rate (i.e., no less than 24 bpp and 60 Hz non-interlaced)

This is the highest resolution that generally can be displayed on analog computer monitors (most CRTs), and the highest resolution that most analogue video cards and other display transmission hardware (cables, switch boxes, signal boosters) are rated for (at 60 Hz refresh). 24-bit colour requires 9 MB of video memory (and transmission bandwidth) for a single frame. It is also the native resolution of medium-to-large latest-generation (2012) standard-aspect tablet computers.

A version of the XGA format, the native resolution for many 30" widescreen LCD monitors. Also, the highest resolution supported by dual-link DVI at a standard colour depth and non-interlaced refresh rate (i.e. at least 24 bpp and 60 Hz). Used on MacBook Pro with Retina display (13.3"). Requires 12 MB of memory/bandwidth for a single frame.

Four times the resolution of 1080p. Requires a dual-link DVI, category 2 (high-speed) HDMI, DisplayPort or a single Thunderbolt link, and a reduced scan rate (up to 30 Hz); a DisplayPort 1.2 connection can support this resolution at 60 Hz, or 30 Hz in stereoscopic 3D.

Typically referred to as Ultra HD (UHD) 5K in consumer displays. 21:9 aspect ratio version of UHD 4K, defined in CTA-861-G, or resulting from 3840x2160 with 4:3 pixel ratio in HDMI 2.0/2.1.

Kingtech is one of the leading TFT LCD display OEM/ODM manufacturers in China since 2003. Customization is allowed for projects such as industrial devices, medical, POS, logistics devices, smart home applications and etc.

To provide a one-stop LCD display solution. During the last 17 years, based on LCD manufacturing as our center, we gradually expand to the TFT capacitive touchscreen, driving board, software hardware design, and complete industrial computer solution.

As a professional LCD screen supplier/ LCD display supplier/ LCD panel company/ LCD module manufacturer, Kingtech LCD aims to provide a one-stop service and solve your problems. With a strong LCD Display module R & D team and strict quality management of IS09001, IS01400ATF16949 certificates.

It is such a waste to only use the LCD for desktop computers. Connecting it up with a laptop PC has many merits for the user and can also bring out the latent power of the laptop.

Note: Below is the translation from the Japanese of the ITmedia article "The dual display in Windows 7 is now even more convenient" published March 1, 2010. Copyright 2011 ITmedia Inc. All Rights Reserved.

Most laptops have a handy "external display output" port. It can be used in the home to transmit videos played on the laptop to a large screen TV or, in the office, to connect up with a projector for presentations. In fact, there must be many users who already use it like this. However, people tend to use just the laptop in their daily routine and there are probably not so many cases where they use the external display output.

A laptop can be put to more effective use if it is connected to an external LCD. The photograph shows an EIZO 23-inch wide-screen LCD connected by HDMI to a Sony VAIO C laptop (VPCCW28FJ/R).

This time we would like to suggest a style that can be used in both the home and the office, where a laptop and stand-alone LCD remain connected. A laptop already has an LCD, but using it with an additional stand-alone LCD offers various merits. Not only does it make the laptop environment more pleasant and convenient, it also expands the potential of the computer itself, for example by making it possible to use it for new purposes.

Even if the LCD is already connected to a desktop computer and being used for something other than the laptop, most monitors nowadays have two or more video inputs and they tend not to use this capability to the full. It is such a waste to let the laptop"s external display output function and the monitor"s video input function remain dormant, so we would like them to be put to effective use. Of course, we would also recommend the introduction of a new LCD to connect to your laptop.

The biggest merit of connecting a laptop with a stand-alone LCD is that it gives you a large screen and high resolution dual display environment. Standard laptop models usually come with a built-in 13-inch to 15-inch wide-screen LCD with a 1280 × 800 dot or 1366 × 768 dot resolution.

This level of resolution is good enough for basic Windows operations, but it goes without saying that a large, high-resolution computer screen is much more user-friendly. Combining a laptop with one of the latest wide-screen monitors enables you to easily construct a large-screen, high-resolution dual display environment. It is a real boon to dramatically boost the screen size and resolution while continuing to use your familiar laptop.

In particular, the increased vertical resolution makes applications such as web browsers and document display and editing far easier to use. For example, you can do things like check things with the web browser, refer to pdf files, organize data using word processing or presentation software, and create spread sheets and documents without having to change windows.

Another plus is that you can create the luxury of a "watching while" environment where you run the web browser, for instance, on the laptop"s built-in LCD and watch the video content on the large screen of the external monitor. This can be really useful for hobbies too. For example, while playing a game on the large external LCD screen you can check out strategies on websites, post information on a BBS or communicate with other users.

You can smoothly use multiple applications at the same time in the large workspace provided by a dual display. The photograph shows an EIZO 24.1-inch wide-screen LCD, the FlexScan SX2462W connected to a VAIO C. By supplementing the laptop"s built-in 1366 × 768 dot 14-inch wide-screen LCD with a 1920 × 1200 dot 24.1-inch wide-screen, it is possible to show more data at a time, a huge boost to work efficiency.

With two screens it"s easy to have full-screen display of the video content on one screen while you operate the computer on the other. The photograph shows an EIZO 23-inch wide-screen LCD monitor connected to a VAIO C. The VAIO C has HDMI output and the LCD monitor has HDMI input so visuals and sound can be transmitted by a single HDMI cable. The LCD monitor has full HD screen resolution (1920 × 1080 dot), making it the perfect match for HD video content.

At the office, it is very helpful for presentations to use "clone view" for the laptop"s built-in LCD and the external LCD screen. Clone view means showing exactly the same content on two display screens. It is normally set by a graphics driver function.

When holding small meetings it is certainly very convenient to be able to offer simple explanations of the presentation materials displayed on the external LCD, rather than having to ready a projector. Being able to explain about what is displayed on the screen means fewer documents to distribute, helping your office to "go paperless", which can only be a good thing.

We would like to point out here that you should check in advance the maximum resolution that the laptop"s external display output can handle. This can be found in documents such as the laptop"s specifications chart and support information. This is because, although most laptops can handle output up to 1920 × 1080 dots or 1920 × 1200 dots, some slightly older computers have an upper limit of 1680 × 1050 dots or 1600 × 1200 dots.

Even if the upper limit is 1680 × 1050 dots, the LCD can still display the data if its own resolution is 1680 × 1050 dots or higher. In such cases, it is better to use a monitor that offers dot-by-dot display, which displays the input resolution as it is, or enlarged display, which maintains the screen"s aspect ratio as it is. You do not need to worry because EIZO wide-screen LCDs can handle such display methods (although in some cases they do not function properly depending on the laptop computer or input resolution).

This is an example of a low-resolution display on the 1920 × 1200 dot display SX2462W. Since dot-by-dot display outputs the physical "1 dot" of the LCD and the input resolution "1 dot" without enlargement or reduction, it is shown small in the center of the screen (photo on the left). The display is a little blurred if it is enlarged while maintaining the aspect ratio, but this method is suitable for displaying images as they are shown large with low resolution to make the most of the screen size (photo on the right). Many monitors that cannot handle such display methods enlarge the display to full screen regardless of the input resolution. In such cases you have to be careful as the aspect ratio of the image is altered (for example, people appear to be thinner or fatter).

It is easy to set up a dual display in Windows 7. A menu is displayed when you right-click on the desktop. From "Screen resolution" it is possible to detect and align the external LCD, and set details such as resolution, display method and which will be the main display screen.

The "Screen resolution" menu. If the external LCD is not automatically recognized, click on "Detect". After the monitor has been recognized, you can select the display mode from the "Multiple displays" drop-down menu. Select "Extend display screen" to make the laptop screen and the external LCD into a single display screen (dual display).

Select "Duplicate display screen" from the "Multiple displays" drop-down menu to display the same content on the laptop screen and the external LCD screen (clone view). With this drop-down menu you can also set it to display video on one of the LCDs.

You can also call up a settings menu to decide the display method for a projector or external display by pressing the "Windows" and "P" keys. This is a tip worth remembering as selecting "Extension" for dual display or "Duplicate" for clone view here allows you to switch swiftly between them as necessary.

The menu launched by simultaneously pressing the "Windows" and "P" keys. You can easily switch between display methods such as dual display or clone view.

It is also worth noting that Windows 7 has added functions so that dual display can be used more effectively. An active window can be moved to the screen of another LCD by simultaneously pushing "Windows" + "Shift" + "→" (or "←"). It is also possible to maximize the window by pressing "Windows" + "↑", minimize it by pressing "Windows" + "↓", and shift it to the left or right of each screen by pressing "Windows" + "→" (or "←"). Making good use of these shortcuts should enable the efficient placing of windows in the two screens.

We would recommend a wide-screen model with a screen resolution of 1920 × 1080 dots (Full HD) or 1920 × 1200 dots (WUXGA) as the LCD to connect to a laptop, so that you can make full use of the advantages of dual display. EIZO has an extensive line up of wide-screen LCDs which can offer many benefits, in addition to the merits of a large screen and high resolution, when used with a laptop for dual display.

The SX2462W is also equipped with vertical display function, turning the screen through 90 degrees. Vertical display is really handy when viewing elongated documents, graphics or web pages. In addition, when used as a standard horizontal screen, a 24.1 wide-screen, with its 518.4 × 324.0 mm display area, can display two A4 sheets, in other words one A3 (420 × 297 mm) in actual size. As well as being very useful in areas such as graphics or desk top publishing, this is also bound to come in handy when checking large business or accounting documents.

Setting the connected monitor into a vertical position is very convenient when displaying elongated web pages and documents or photographs that were taken vertically

With a 24.1 inch wide-screen like the SX2462W, an A3 sheet (two A4 sheets side by side) can be viewed in actual size, particularly effective for paper-based creative work ITmedia LCD Course II, Lesson 3: Which is better, 16:10 or 16:9 ? – "Screen size / resolution / aspect ratio"

We must not forget that EIZO"s wide-screen LCDs have non-glare screens (processed to reduce ambient light reflection). Nowadays the trend is for laptops to have an LCD with glare (glossy) surface treatment. While these can display images in bright color, reflected ambient light can sometimes be distracting.

A laptop screen is not so large and adjusting its angle can avoid the reflection of lights and so on, however it is not so easy with the large screen of an external LCD. When it comes to the large screen of an LCD in habitual use, a non-glare type that is not reflective is probably easier to see, as well as being kinder on the eyes. A large screen, high resolution and non-glare ensure that you can comfortably continue viewing over a prolonged period of time.

The surface treatment of an LCD makes a difference to the background reflection. Glare panels do not diffuse background light, making it easier to achieve high color purity, but easily reflect the user or lights (photo on the left). If the lights are similarly trained on a non-glare panel they do not have much effect, only appearing as a fuzzy brightness (photo on the right).

Another distinctive feature of EIZO wide-screen LCDs is a commitment to energy saving. They incorporate various power saving features that support "EcoView". A pivotal feature is the "EcoView Sense" adopted in the FlexScan EV series, such as the EV2333W.

This is the motion sensor on the front of the LCD. It constantly monitors the user"s movements to automatically take finely-tuned power saving measures. To be more precise, if the user"s presence is not detected for a specified period of time, for example if he leaves his seat, the monitor automatically switches to power save mode, and then automatically switches back when the user"s presence is detected again.

Other features include "Auto EcoView", which automatically optimizes the brightness of the LCD based on ambient lighting, and "EcoView Index", which displays a meter on the screen showing how much power is being saved. All these features can be expected to have a strong energy saving effect and to boost the user"s awareness of power saving, making them particularly useful in the office.

A standard laptop computer switches to sleep mode if the built-in LCD is closed while it is running but, if this function is turned off, a laptop can be treated as a "small desktop computer."

It can be set to use only the connected external LCD and not to react when the laptop"s built-in LCD is closed. The transformation into a small desktop PC is complete if you add a keyboard and mouse connected to the laptop via USB ports, for example. The OS is still running even though the laptop"s built-in LCD is closed, so you can carry out normal operations using the external keyboard and mouse, and also use the laptop"s built-in optical drives.

The idea is to use a large screen, high resolution external LCD at home or in the office, and to use the laptop"s built-in LCD as usual for mobile purposes. This helps to boost the longevity of the laptop"s built-in LCD and many people do use their laptop in this way. If you feel reluctant to use a dual display environment, where the screen is split in two, why not give this a try?

Select "Only show the desktop on 2" from the "Multiple displays" list in the "Screen resolution" menu. The laptop"s built-in LCD will be switched off and the external LCD will become the main display.

By making this simple setting your laptop can be used as a space saving desktop computer. Another plus is that the laptop"s built-in LCD will last longer.

Recently some high-end laptop computers, such as the Sony VAIO F, are insisting on good display quality for their LCDs. However, a typical laptop"s built-in LCD does not have as good image quality as a stand-alone LCD. This is only natural since the costs allowed for display quality are completely different for an LCD incorporated into the PC as one of its parts and a specialized LCD.

However, by using an EIZO wide-screen LCD a laptop user can still fully enjoy such benefits of a stand-alone high-quality LCD as excellent color reproduction, a wide viewing angle, more even display and a wealth of items that can be adjusted to improve image quality. This is a crucial point for people who use their computer for photographs and videos in particular.

EIZO"s wide-screen LCDs emphasize color reproduction, and the coloration in sRGB mode has a high degree of accuracy. The standard color gamut used in PC environments and Internet content is sRGB, so you need have no worries about viewing or editing videos and photographs. They can also display images on web pages, such as products in online shops or goods for sale in online auctions, in colors that are very close to the real thing. (This is also influenced by how the seller took the photographs and processed the images, so we cannot say that the colors will always be accurate.)

Furthermore, in addition to sRGB color gamut accuracy, the high resolution-oriented FlexScan SX has the added benefit of covering more than 95% of Adobe RGB. Adobe RGB is a color gamut whose definitions encompass more highly-saturated colors than sRGB. In other words, it can represent a larger number of colors and brighter hues than sRGB.

An example of sRGB color gamut image data displayed on a standard laptop and on the SX2462W. The SX2462W"s reproducibility of sRGB mode is of a considerably high standard but the color balance on the laptop has been lost. This would make it difficult to perform rigorous photo retouching.

In this case, if the image is edited on the external LCD with its high color reproducibility and the many tool palettes in the application are grouped in the laptop"s built-in LCD, there is less need to display or hide the tool palettes or to switch back and forth, and the image data to be edited can be displayed in a large form, making for more efficient work.

In this case, if the image is edited on the external LCD with its high color reproducibility and the many tool palettes in the application are grouped in the laptop"s built-in LCD, there is less need to display or hide the tool palettes or to switch back and forth, and the image data to be edited can be displayed in a large form, making for more efficient work.

When doing things like photo retouching, using software where there is a lot of switching between tool palettes it is very handy to display the image data to be edited on the external LCD with its high color reproducibility, and to gather the palette tools to be used on the laptop"s built-in LCD.

Going back to the subject of laptop computers, it is not going too far to say that applications and functions are being spoiled in laptops whose built-in LCD"s image quality is not too good. Connecting a laptop to a monitor with high image quality dispels any concerns about work that deals with colors and also helps to bring out the laptop"s potential.

Combining an EIZO wide-screen LCD with a laptop computer makes viewing videos and images even more fun. Just being able to see them on a large screen is a pleasure, but what makes it even better is that our LCDs are equipped with Fine Contrast, the optimum image quality mode for video and visuals. You can also use the Custom mode to create the image quality you prefer.

We expect that you now understand how displaying screens from a laptop computer on a stand-alone LCD can create a very pleasant environment. It feels as if your everyday laptop has been transformed into a completely different desktop machine. Even if you only use laptop computers, it is definitely worthwhile to add a stand-alone LCD.

When choosing the type of LCD the most important consideration is to choose one with overall high quality. When it comes to that, we can recommend EIZO wide-screen LCDs to a broad range of laptop users. In addition to their high image quality, EIZO wide-screen LCD are built with careful attention to detail, including non-glare screens, versatile stand features, dot-by-dot capability, abundant image quality modes, and our proprietary eco-functions. We want you to make full use of your beloved laptop computer along with an EIZO wide-screen LCD.

This time we have spoken about how an external LCD can be connected to a laptop computer, but if your main machine is a desktop computer then you probably already have a LCD.

In which case, why not consider adding a full HD (1920 × 1080 dot) or WUXGA (1920 × 1200 dot) wide-screen LCD and creating a more advanced dual display environment to further enhance your computer"s usability.

Recently many computers can handle dual display output with their chipset integrated graphics function, and nearly all of them are capable of dual display output with a stand-alone graphics card.

The dual display environment of a desktop PC has a wider range of options than a laptop computer, which is already installed with an LCD. Depending on the combination of products used you can seek for a larger screen, higher resolution and better image quality.

The photograph below shows two EIZO 24.1-inch WUXGA (1920 × 1200 dot) models being used side by side for an overwhelming super high resolution of 3840 × 1200 dots in total.

You can get a super high resolution of 3840 × 1200 dots in total by putting two 24.1-inch 1920 × 1200 dot wide-screen LCDs side by side. The advantage in this is that a larger screen and higher resolution are achieved at a lower cost than buying a single 30-inch high resolution model
