t440s lcd panel quotation

Product delivered in 2 days with very good packaging. New screen was protected with adhesive sheet and all tools included. Replacement instructions can easily be found on Youtube and the whole process took around 30 minutes.My original 1600x900 screen was not working at all. First power up after replacement would see the Thinkpad opening screen and booted into Windows but no image on the new screen. Luckily I had the Lenovo connected to a second screen and upon reboot, voila, the new screen showing 1080p resolution in Windows. No dead pixel and the screen is very well made and definitely worth it. My T440s will live another 2-3 years (finger crossed)..

There are many LCD screen manufacturers for the Laptop Industry. LCD screens have different resolutions, size and type and these screens are compatible as long as the resolution and connections are the same.

For this listing, we will ship you a brand new OEM Compatible LCD screen manufactured either by Samsung, LG, Chi Mei, Chunghwa, Sharp, or AUOptronics. For more information about each LCD manufacture please click here.

If you wish to know the make of the actual LCD that will be shipped to you, please contact us by phone with your order information between 10AM - 8PM EST (Monday – Friday).

Laptop-LCD-Screen.co.uk guarantee you a working Ibm Lenovo Thinkpad T440s (FHD) screen replacement, or your money back. With our 17 years of trading experience, we can warrant that claim with real expertise. If you research our company, you will encounter our impressive accumulation of fantastic reviews on sites like Trustpilot and Google.

Thinkpad are notorious for fitting different types of screen to the Ibm Lenovo Thinkpad T440s (FHD) machine, and as such we ask you to please check the specifications of this screen match your original. To be 100% sure, it"s best to remove your old screen first, and make sure it looks similar to the photograph we provide, and that the resolution, connector type and connector position match as well. Other screens available...

We insist on higher grade Class I panels, (note that there is no such thing as a Grade A screen). We pay a little more to ensure our products impress and please every time, and give a long working lifetime. With more than a decade of experience our team will ensure your high quality replacement screen is as good - or better than your original display, and that the whole process from purchase, through the delivery and to installation, is seamless. And this promise is endorsed by our customers.

Buy Lenovo Thinkpad T440 T440S T450 T450S Non-touch FHD 30 Pin1080P IPS 14" LCD Screen 04X0436 Buy New Replacement LCD Panel for IBM-Lenovo Thinkpad T440S Series LCD ... ThinkPad T431 T431s T440 T440E T440p T440s T450 L440 Compatible with

LCD Screen Repair Replacement for 14” LCD LTN140HL05 LTN140HL05-401 for LENOVO T440 T440S T440P T450 T450S led screen 1920*1080 30pin eDP from Lenovo Service Center

Modernized classic. This year, with the ThinkPad T440s models, Lenovo takes on the legacy of the highly acclaimed T series and does not limit it to just updating the components. It is to be the ultimate in performance and to bring a range of practical updates. We have tested whether this is really the case.

Business notebooks with the name ThinkPad are indispensable in the modern computer world. These devices represent reliability, longevity, quality and ergonomic design. Both IBM and Lenovo have introduced new features with great care and only sparingly. The last big change took place in form of the keyboard area, the last big IBM sanctum. At first, this change was received with mistrust among the ThinkPad lovers, however, now much of the prejudice and doubt have disappeared and one gets to appreciate the advantages of the new input. The current ThinkPad T440s does not bring any such big changes, but it has a lot of minor changes. Whether these are all beneficial will be analyzed in our test.

Our LenovoThinkPad T440s 20AQS00500 is equipped with an Intel Core i5-4200U CPU, 4 GB RAM, a 500 GB hard drive and a 14-inch HD+ display. It is a model of the Lenovo education program, which should also be a reason for the relatively low price of 960 Euros (~$1298), in addition to the missing operation system.

The Lenovo ThinkPad T440s contains an Intel Wireless-N 7260 module. It can operate in the 2.4 GHz band and in the 5 GHz band. It is equipped with 2 antennas and can reach a theoretical transfer rate of a maximum of 300 Mbit/s. We observed usual signal strength and a normal connection response to our 802.11n router with a Ralink RT2860T chip. We measured the Wi-Fi performancewhile having the router in sight at distances of 2, 5 and 10 meters. Here, the results vary between 3.2 MB/s and 5.7 MB/s. External factors, such as overlapping Wi-Fi networks could possibly disturb the transfer rates, hence these values are only approximate. The Intel module also has an integrated Bluetooth 4.0 chip which can control smartphones, mice or speakers over short distances. There is also a 720p webcam from SunplusIT built in for video conferences and a Gigabit Ethernet port enables connecting to a wired network.

After the removal of 8 cross screws from the bottom of the device, one can remove the hatch and gain access to the important components. In addition to the screws, there are supporting clips in place here. Those have to be removed by applying a bit of pressure. We did not do this in the case of the brand-new test device out of respect for the lending provider. Lenovo"s Hardware Maintenance Manual for the ThinkPad T440s explains all the required steps in detail and with pictures. Here, one can also find helpful advice for which components can be exchanged by the user himself. The RAM modules, the mass storage, the fan and the built-in battery can be accessed among others. In the test device there is also an M.2 slot that is not being used. It could hold an M.2 SSD or an M.2 WLAN card.

We measured the maximum display brightness via nine measurement points as usual. In the case of a homogeneous illumination of 91% the brightness values extend from a range of 211 cd/m² to 232 cd/m². With the Lenovo ThinkPad S440 Touch we may have found the same panel type, but that one has lit up much less with an average of 173 cd/m². This is presumably due to the additional touch surface. This is clearly sufficient for interiors and one can usually choose ergonomic brightness settings around 150 cd/m². We ran the Wi-Fi battery runtime test with a brightness level of 12 which delivers a brightness of 155 cd/m² in the center of the screen.

The ThinkPad T440s profits from a brightness that is not throttled in battery mode, for instance outdoors. The matte surface of the test device allows seeing the content outdoors clearly and without any disturbing reflections. One still has to avoid direct contact with direct sunlight as otherwise nothing can be recognized anymore.

The viewing-angle stability of the TN panel only reaches the standard notebook quality level. On the vertical axis the colors either fade quite quickly depending on the angle of the display, or it comes to an inversion. On the horizontal axis the representation is affected only by a little in case of a change of brightness and stays clearly recognizable.

One mostly has to expect a reduction of the computing power when the CPU and GPU are claimed simultaneously. When both Prime95 and Furmark are running simultaneously, then the CPU clock rate is reduced to 1000-1100 MHz according to our tools. When the graphics unit is not in use, then we can observe a constant 2300 MHz. In the case of the Dell Latitude E7240 with the same Intel Core i5-4200U CPU we saw a much lower maximum reduction to 1600 MHz. Presumably, Lenovo has taken further action in case of the ThinkPad T440s in order to limit the consumption and heat emission.

In practice,we converted video and audio files into other formats. We used either the pure CPU power or Intel"s Quick Sync Video for this. The audio conversion via iTunes can be done with up to 39.6 times the speed and the conversion via Cyberlink"s MediaEspresso is achieved much faster with Intel Quick Sync Video than in a pure CPU task (multi-thread). Have a look at the corresponding graphic chart for this as well. In comparison to the Dell Latitude E7240 the Lenovo ThinkPad T440s has some small advantages in the Quick Sync and the MP3 conversions, but is a bit worse in video conversion via CPU.

Lenovo is going to offer supplementary mass storage options as soon as the T440s series becomes available for the broader market in November. The model overview contains hard drives up to 1 TB as well as SSD-cache modules and Solid State Drives of up to 512 GB. Until then it would definitely have to be a do-it-yourself project in order to get such a change.

Lenovo is able to manage the noise emission very well in its current models. We have found notebooks that run at a very low noise with the ThinkPad S440 and the S531. The ThinkPad T440s is no different here and convinces with a low noise level of 29.8 dB(A) under low load, despite a conventional hard drive. One could decrease the noise level even further with a Solid State Drive, since then the little noise of the drive would be canceled out as well. The fan spins significantly faster only when the graphics chip or the CPU receive more demanding tasks.Then the sound pressure level reaches 34.8 dB(A) under a medium load. This increases only marginally to 35.4 dB(A) under full load and is a clear effect of the reduced CPU performance with a simultaneous graphics load.

One of the fundamental upgrades in the ThinkPad T440s is the new battery concept named Power Bridge. Lenovo combines a built-in battery with a capacity of 24 Wh together with a replaceable battery that can be removed from the bottom of the device just like in the predecessors. Our test model is equipped with another 24 Wh battery and, hence offers a total capacity of 48 Wh. Lenovo has also announced a 6-cell battery 68+ with a capacity of 72 Wh (0C52862). This one should double the possible runtimes, but it is also much bigger and weighs about 150 grams more. The advantage of this 2 battery concept is mostly in situations where the battery has to be exchanged a lot so that the system does not need to be shut down during this process. Moreover, one has a higher failure safety when one of the batteries is not working well anymore.

The low total consumption is the main factor why the comparably low battery capacity of 48 Wh can deliver great battery runtimes. In the Battery Eater Reader"s Test (maximum energy saving options, minimum display brightness, Wi-Fi off) the ThinkPad T440s reaches more than 11 hours of battery life with just the small extra battery. However, this brilliant result only shows what is theoretically possible and, hence has little to do with real work performance. Therefore, the battery runtime is much shorter if the Wi-Fi module is in use such as during web surfing (Energy saving profile, brightness level 12 (155 cd/m²), Wi-Fi modules on). Here, the increased display brightness and the Wi-Fi module cause a bigger consumption. In this case only 6 out of the 11 hours remain. The system profits from throttling the CPU performance under full load and still reaches a very good 109 minutes in the Battery Eater Classic Test (Highest performance profile, maximum brightness, Wi-Fi modules on).

Despite the use of Intel"s weaker ULV chips and the conventional hard drive, the application performance is very good. In contrast the noise emissions, heat emission and the battery runtime profit from the low consumption. The ThinkPad T440s always stays at a low noise, never gets uncomfortably warm and at the same time also delivers good battery runtimes.

All in all, Lenovo succeeds in delivering a convincing entry with the ThinkPad T440s. The minor issues can be solved through an alternative configuration and adjusted to the individual requirements.
