SainSmart 3.5 inch TFT LCD module is a special design for Raspberry Pi for portable application. It features a 3.5 "display with 320x480 16bit color pixels and resistive touch screen. The LCD is well mated with Pi board and interface with Pi via the high speed SPI port, and support console, X windows, displaying images or video etc. It therefore Provides 4 press buttons for user defined functions.

RPi LCD needs to use a SPI interface, but in the original image file of Raspberry Pi, the displayer is driven via a HDMI port. So the original image is not applicable for RPi LCD, and you should install the LCD driver to your Pi or use the Ready-to-use image file provided by Sainsmart,click here.

Download the LCD driver and extract it to your Raspbian OS (e.g. copy the driver to your Pi by sftpor using U disk). Then run the following command via putty:

This LCD can be calibrated using a program called xinput_calibrator which is pre-installed on the offer image. However, it was not pre-installed on original Raspbian OS. So in this case, you should get and install the program manually with

After running these commands, there will be a prompt for four-point calibration shown in the LCD screen. Click the points one by one to finish the touch calibration. Then, the new calibration data will be displayed in the terminal, as shows below. Please get these data for future use.

3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying.

Key information: This device"s controller is an ILI9486, which is compatible with ILI9481. The driver for ILI9481 was already in my Raspberry Pi. Here"s what I did to make it work:

The second command sets the console (tty1) to map its output to the framebuffer (buffer 1). That"s why the parameters are 1 1. You can map any tty to the LCD.

I don"t care about the touch-screen, so I didn"t set it up. All I need this is to show me the IP address of the Raspberry Pi so I can connect through SSH. (This is an issue you may encounter only if you find your RPi connecting to WiFi where you cannot control the IP address assignments and with ridiculously short lease times.)

3.5inch RPi LCD (A) and 3.5inch RPi LCD (B) are hardware compatible with each other (uses different driver), and can be mutually substituted in most cases. (A) for low cost ver. while (B) for IPS ver. with better displaying.

Why the LCD doesn"t work with my Raspbian?To use the LCD with the Raspberry Pi official image, driver (SPI touch interface only) should be installed first. Please refer to the user manual.

However, for the first testing, you may want to use our image directly (if provided).Why the LCD still doesn"t work with the Waveshare provided image?Make sure the hardware connection is correct and connects fine.

The PWR will keep on and the ACT will keep blinking when the Raspberry Pi starts up successfully, in case both of the two LEDs keep on, it is possible that the image was burnt incorrectly OR the TF card was in bad contact.Which power supply should I use?It is recommended to use a 5V/3A power adapter for the Raspberry Pi other than USB connection, otherwise the Pi may failed to start up because the PC"s USB port might have not enough power.
