custom lcd display heater quotation

NHD-C12864A1Z-FSB-FBW-HTT | Monochrome Graphic COG | 128x64 Pixels | Transflective LCD | Side Blue Backlight | FSTN (+) Positive Display | Built-in 12V Heater & Temp Comp Circuit

Newhaven 128x64 graphic Chip-On-Glass (COG) Liquid Crystal Display shows dark pixels on a blue background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -40 to 70 degrees Celsius. This NHD-C12864A1Z-FSB-FBW-HTT display includes a built-in 12V heater, and temperature compensation circuit. It has an optimal view of 6:00, operates at 3V supply voltage and is RoHS compliant.

Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.

Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HDMI, USB, SPI, VGA and more into your display to achieve your design goals.

We encourage you to provide us with as much information as possible. It will help our engineers and design team to have a better understanding of your needs and requirements, and ensurequality and efficient customer service. If you are unsure about any of the above information, please feel free to contact us.

If you are not sure about any of the above information or have any difficulties designing a heater, please don’t hesitate to contact us. We are more than happy to help you from conceptualization to production.

Orient Display is a company that specializes in manufacturing LCD displays, touch panels, OLED displays with competitive prices. The company was founded in 1996 by specializing in fields of production, R&D, quality controls. Thanks for the management and employee’s continuous hardworking and enormous effort and shareholder continuous investment over years, Orient Display factory is now the world’s leading custom LCD manufacturer in flat panel industry and is listed as a public company in China stock market. Now, Orient Display factory has 2 production lines that can produce PMOLED and AMOLED custom display modules. Factories have complete quality and environment management system, ISO9001, ISO/IATF16949, ISO14001, IECQ QC080000. Orient Display takes around 18% market share in global automotive market and is No.1 in automotive capacitive touch screen.

Orient Display has supported customers with custom LCD displays for tens of thousands of types and models for automotive, appliances, medical, smart homes, point of sales, industrial advices, etc. Whether your design requires a small custom LCD display glass, or a fully customized LCD module, or custom monitors and displays equipped with complicated embedded control board with touch panels, our experienced engineers in North America, Europe or in China factory will assist you in designing your customized displays.

Orient Display customer service sends quotation to you (might come with technical suggestions according to your targeted applications). The time will depend on the complexity of the project and the time to source components, normally, it takes 1-3 days for custom LCD glass panels, 2-5 days for custom LCD display modules or touch panels.

Orient Display engineers provide custom LCD display counter-drawings for you to approve with your signature on the drawing. The drawings might be modified several times until the designs are fully achieved your technical requirements. There can be a lot of technical discussions at this stage. The time our engineers take to arrange drawings also depend on the complexity of the project. Normally, it takes 1-3 days for custom LCD glass panels, 2-5 days for custom LCD display modules or touch panels.

After your drawing approval, Orient Display will start to make samples or prototypes for you to test. The lead time also varies depending on the production complexity and component/material sourcing. Normally, it takes 4-6 weeks for custom LCD glass panels, 8-10 weeks for custom LCD display modules or touch panels.

After your sample / prototype approval, Orient Display is ready for production. Orient Display welcomes trial production between the prototypes to large scale production so that you have the opportunity to fully test the custom LCD display or touch panel to run well in your designed products.

Congratulations! You have accomplished the journey of the idea, design, prototype and production in the market. The journey can take from 3 months to 3 years. Whatever the voyage, Orient Display’s engineers, customer services are proud to be part of your design. Our happiness is based on your success.

Dimensions (Specification / Drawing / Sketch of the LCD, if available). If it is a drop-in replacement, it is great to provide files in dwg. or dxf. format.

LCD Mode Preference if you have an idea or let us to decide (TN Positive/Negative, STN Positive YG, STN Negative Blue, STN Positive Gray, FSTN Positive, FSTN Negative, FFSTN Negative);

Dimensions (Specification / Drawing / Sketch of the LCD module, if available). If it is a drop-in replacement, it is great to provide files in dwg. or dxf. format.

LCD Mode Preference if you have an idea or let us to decide (TN Positive/Negative, STN Positive YG, STN Negative Blue, STN Positive Gray, FSTN Positive, FSTN Negative, FFSTN Negative);

Fully custom made TFT LCD display module can be very expensive, the NRE ranges from $80,000 to $1M depending on the size and the resolution of the LCD display and the generation of the production line the LCD display to be produced. For over 99% of our projects, we are talking about the modifications of the standard TFT LCD display. There are a lot of standard color TFT displays available in the market. You are highly likely to find one matching your requirement. If you can’t find a suitable one on our website, please check with our engineers, we have a database in factory with much more types.

Dimensions (Specification / Drawing / Sketch of the LCD module, if available). If it is a drop replacement, it is great to provide files in dwg. or dxf. format.

The above information can be overwhelming. Actually, we design a lot of touch panel and LCD custom display projects without being provided detailed information. Our engineers and customer service can quickly decide the parameters based on the customer’s application. Please feel free to contact our engineers for details.

We use our expertise and technology to assist our customer to design the LCD into the specification at the most economical cost in the shortest amount of time.

SIMPLE can offer various options on backlight type, pin and connector, cable, touch panel, inverter, heater or even customized PCB which can be adopted to standard product and material as semi-custom solution for your product application.

Clearview™ transparent heating elements are an optically clear variation of our wire-wound heater that provides superior light transfer with higher durability than comparable technologies.

The wire-wound design brings high heating efficiency and quick thermal response with minimal power consumption. This makes Clearview LCD screen heaters ideal for applications such as computers, battery powered hand scanners, and touch screens.

Optically clear heaters are typically used in applications that require a high degree of light transmission. Clearview"s ultra-fine wire construction gives high optical clarity and ensures optimal light transmission for scanning and imaging applications.

Clearview provides controlled, direct heat to displays, lenses and clear panels, allowing continuous high definition operation of device monitors in low temperature environments. With an LCD screen heater, displays and touch screens remain usable in cold, high humidity/low dew point environments and locations where ambient temperature can change quickly.

Engineering services and consultation are available on every custom heating element order. Contact a specialist today for details about Clearview optically clear transparent LCD screen heaters.

Liquid Crystal Displays or more commonly known as LCDs are one of the most common electronic components which help us interact with an equipment or a device. Most personal portable equipment and even gigantic industrial equipment utilize a custom segment display to display data. For many portable consumer electronics, a segment LCD display is one of the biggest contributors to the overall cost of the device, hence designing a custom segment display can drive the cost down while also utilizing the display area in the most optimum manner. These displays have the lowest cost per piece, low power requirements, and a low tooling fee too.

At first thought, designing a custom segment LCD might look like a Herculean task, but trust me that it is easier than it seems. In this article, we have summarised and compared the display types and available technologies which are required to construct a custom segment LCD. We have also provided a flowchart that can act as a step-by-step guide while you design your own custom LCD. We have also provided the process we followed, a require gathering sheet we used for communicating our needs to the manufacturer, and a few other data and the quotation we received from the manufacturer.

Icons: A silhouette of any shape can be placed on the glass which enhances the ability to display data. For example, a symbol of a heart can be made to denote heart rate or an icon for a low battery to show that the battery needs to be charged. Icons are counted as a single pixel or segment and can give a lot more details than similar-sized text.

LCD Bias– It denotes the number of different voltage levels used in driving the segments, static drives (explained later in this article) only have 2 voltage levels or 2 bias voltage while multiplex drives have multiple voltage levels. For example, 1/3 will have 4 bias voltages.

LCDs utilizes the light modulating properties of liquid crystals which can be observed by using polarizing filters. Polarizing filters are special materials that have their molecules aligned in the same direction. If the light waves passing through polarisers have the same orientation as the filter, then the molecules of lights are absorbed by the filter, hence reducing the intensity of light passing through it, making it visible.

A custom LCD is important for maximizing the efficiency of the display area by adding custom symbols and characters. It also helps in reducing the cost and improving energy efficiency of the product. A higher number of custom symbols and specified placement of numerical and alphanumerical characters make the display more informative and readable for the user. This makes it look better than the plain old boring displays we get in the market. Furthermore, we can specify the viewing angle, contrast, and other specifications which can increase durability or give a better value for money for our intended usage.  A typical Custom Segment display is shown below, we will also show you how to design and fabricate the same further in the article.

The LCD display doesn’t emit any light of its own, therefore it requires an external source of illumination or reflector to be readable in dark environments.

While designing a custom segment LCD display, we have the leverage of choosing a lot of parameters that affect the final product. From the color of the display to the illumination technique and color of illumination as well as the type of input pins. Some important considerations we need to take while designing a custom 7 segment display are - the type of display, i.e. positive or negative, illumination method, driving technique, polarising type, and connection method. All these design criteria are explained below:

Positive and negative displays can be easily distinguished by the colour of the background and characters. Some common differences between the positive and negative displays are:

So, which one should you choose? When the displays are to be used in areas with higher ambient light, we should select positive segment LCD display as it has better visibility than negative segment LCD displays without using a backlight.

As we know that LED displays don’t emit any light, hence to illuminate it and make it visible in a dark environment, we can use different methods of illumination. The most common LCD Illumination methods are compared below:

For displays that need to be used for budget-friendly devices that should be small and rugged, LED lights are preferred for the displays due to the high durability and low cost of operations. For high brightness, CCFL and Incandescent lights can be used.

A polarizer film is the most important component of an LCD display, which makes it possible to display characters by controlling the light. There are 3 types of polarizers that can be used in the LCD display, the properties and difference are given below:

Displays can be categorized into two types, passive displays, and active display, passive displays are simpler to construct as they have 2 connections at each segment, the conductors comprise of an Indium Tin Oxide to create an image, whereas the active displays use thin-film transistors (TFT) arranged in a grid. The name is due to its ability to control each pixel individually.

If your displays have fewer segments, then static LCD drive is preferred as it is easier to control and cheaper to construct, and has a better contrast ratio. But let’s say that if the number of segments in the display are more than 30-40 then a multiplex LCD drive should be preferred as it has multiple common pins, hence reducing the total number of pins required to drive the display.

Choosing a connector type!!! For the prototyping phase or if you need to connect your LCD display on a Microcontroller directly, a pin type connector is the best and most economical option you have. If you need to connect your LCD display in a final product with a high volume of production which also requires to be extremely durable, but at the same time should not take up a lot of space, a Flex type LCD Connector will work best for you

LCDs have limited viewing angles and when seen from an angle they lose contrast and are difficult to be observed.  The viewing angle is defined by the angles perpendicular to the center of the display towards its right, left, up, and down which are denoted by the notations 3:00, 9:00, 12:00, and 6:00 respectively. The viewing angle of LCD can be defined as the angle w.r.t. to the bias angle at which the contrast of segments is legible.

To improve the viewing angle in an LCD, a Bias is incorporated in the design which shifts the nominal viewing angle with an offset. Another technique is to increase the Voltage, it affects the bias angle, making the display crisper when viewed from a direction.

For example, the viewing angle of a TN type TFT LCD is 45-65 degrees. Extra-wide polarising film (EWP) can increase the viewing angle by 10 degrees, using an O film polariser can make the viewing angles 75 degrees but these come at a cost of reduced contrast.

LCD Control chip or LCD driver chips can be mounted on the flex cable, display, or externally on a PCB. The placement of LCD control chip can affect the cost and size of the display. The 2 most common methods of chip placement are-Chip of Board (COB)and Chip on Glass(COG) which are described below:

We planned to design an air quality monitoring system for which we needed a custom segment LCD panel for an air quality monitoring device. Our product needs to display the following data: 2.5-micron and 10-micron particulate matter (PM) suspended in the air; the units should be in parts per million (PPM). CO2 in the air in PPM along with total volatile organic compounds present in the air in parts per billion (PPB). To make the product more usable, we included time in 24-hour format, Temperature in ºC, Battery status, loudspeaker status, Bluetooth status, and Wi-Fi status. And for some personal touch, we also added how good the air quality in the room is by using 3 different smileys.

We realized that it was impossible to provide all these data in a generic LCD available in the market, thus decided to build a custom LCD for our project.

A step-by-step flowchart is shown below to walk you through each and every step of selecting components and getting your custom segment LCD manufactured.

We started by listing down our requirements and drew a mock-up of the display on paper. After finalizing the placement of all the segments and icons on the prototype sketch of the display, we then decided which all icons and segments have to be kept on for the whole time and which needs to be driven. Realizing that there are too many segments, characters and icons, hence we selected a multiplex drive with 8 common pins which helped us bring down the total pins from an estimated 180 pins to less than 40 pins.

Since the device was meant to be used inside houses and offices, which are more often than not well lit and protected from environmental conditions, we opted for a positive mode display. For superior contrast ratio and better viewing angle, we chose a Film Super Twisted Nematic Display (FSTN) with a drive condition of 1/8 Duty and bias of 1/4.

Usually, the displays are mounted at a height of 4.5 feet from the ground, thus the viewing direction was selected to be 12"O clock with an operating frequency of 64Hz. We selected a Transmissive polarizer for the front glass and a reflective polarizer for the rear glass so that the natural light can pass through the front panel and the display can achieve the maximum contrast without the need for backlighting and we opted for the pin type connectors as they are easy for prototyping and are suitable for harsh environment with a lot of vibrations and shocks which best suited our purpose.

In the above image of a custom display design, we sent to the manufacturer, the red lines over multiple characters indicate that all these are considered as a single segment. For the sake of simplicity, we added test like T, S, U, B to denote Text, Symbols, Units, and Battery respectively. These characters were followed by numbers to simplify communication between us and the manufacturer. For example, if we needed any particular text or symbol to remain on, we can easily specify that to the manufacturer by using the corresponding text for that segment.

We mailed our requirements to multiple LCD manufacturers, (you will find a lot of LCD manufacturers on the Internet). Most LCD manufacturers have competitive pricing, and reply within a week. A sample requirement sheet is shown above which a customer needs to fill to specify all the details to the manufacturer.

This is a sample Custom Segment LCD quotation we got from one of the manufacturers. As you can see, the cost is based on the quantity. Higher the quantity, lower the cost. Apart from the cost per quantity, there is one more component called tooling fees. Tooling fee is a one-time fee charged by the manufacturer. It is for the technical design, support, and customization of the product. Customization of PCB or tooling of LCD can drive the tooling price higher or lower.

A custom segment LCD can help you personalize your product while also saving the overall cost of your product. The whole process will take you around 2-3 months, which will include the designing phase, prototyping phase, and getting your custom segment LCDs delivered to your doorstep. Higher ordering quantity will reduce the cost per piece of each unit, thus driving down the cost of your final product.

When a customer pays for the LCD tooling fee, they are not just paying for the option to buy a customized LCD display; they are investing in a LCD design of their own. It is their design and they control the rights to it.

The client receives a customized display that matches their exact requirements – everything from dimensions and functions down to the module colors, unique voltages, modified bezel, addition of headers or cables and any other desired components (resistors, potentiometers, heaters, etc.) to make this LCD unique.

One of the most important, yet overlooked, values that come with paying for the LCD tooling is longevity and peace of mind. Customized LCDs are much less likely to be discontinued or EOL (End Of Life) than a standard off-the-shelf LCD.

Custom displays tend to require a slightly higher MOQ (Minimum Order Quantity) than standard LCD’s modules. This is because the product is only being sold to one customer and many of the components on the display will be unique to that customer.

A common solution to high MOQs is to place a blanket order with Focus LCDs. We can provide Kanban releases which means the customer will only receive and pay for the number of LCDs that they need every month or even every week.

The current lead time for prototype samples after paying for LCD tooling is between five to seven weeks. This will increase by three to four additional weeks during Chinese New Year. We are able to offer a short lead time and fast turnaround since all our displays are shipped via FedEx air and not on boat.

The first step is to review the LCD displays that we keep in stock from our standard LCD supply and can ship out the same day you need them. If you find that you need a unique LCD solution, we can quote you a tooling fee within one or two working days.

ISO 9001:2015 certified stocking distributor of displays, lamps and LEDs. Sub-assembly such as wire leads with termination can be built into display and lighting assemblies per customer drawings and specifications. Capabilities include bin replenishment, just in time delivery, EDI, Kanban or pull systems, internet ordering, in-house stores and consignment inventory. Industries served include food and beverage service, transportation, medical, instrumentation and self service banking.

Distributor of ruggedized & custom liquid crystal (LCD) displays. Sunlight readable TFT, monochrome, chip on glass, LED and OLED displays are also available. Vendor managed inventory (VMI) programs and stock items available. Meets AS9100 Rev C standards. Kanban and JIT delivery.

Manufacturer of flat-panel industrial monitors and displays rated for Division 1 and Division 2 environments. Custom engineered, designed, and manufactured to handle the dust, dirt, debris and chemical exposure common to rugged and hazardous applications in the oil and gas, pharmaceutical and food processing, manufacturing and chemical industries. Types of monitors include military grade, LCD, rugged, washdown, high definition, wide screen, panel mount, rack mount, flush mount, gas purged, and more.

Manufacturer of custom rugged displays for military, marine, industrial, avionic, medical, transportation, commercial and other applications. Diverse engineering team is able to design to fit any enclosure. Features include sunlight readable, NVIS, waterproof, flip-up, flip-down, rack mount drawer, panel or rack mount, and much more. All sizes are available from small to large. Suitable for workstations, cockpits, medical devices and other safety- or mission-critical applications. Manufactured, serviced, and supported in the USA.

Manufacturer and distributor of high bright and ruggedized liquid crystal (LCD) displays. Various features include 4.3 in. LCD widescreen rear view mirrors, license plate, wide angle surface mount and flush mount cameras.

Manufacturer"s representative of liquid crystal displays (LCDs) for electronics, telecommunications, military, automotive and medical industries. LCDs are ruggedized, have high brightness, wide view angle, wide range temperature, advanced LED technology, touch or high resolution panels and environmental protection. Thin film transistor LCDs are used in marine, transportation, financial, marketing and hospitality applications. RoHS compliant.

Precision CNC machining services. Capabilities include vertical and horizontal milling, turning, forming, welding, grinding, sawing, printed circuit board(PCB) assembly, electronic manufacturing and sheet metal fabrication. Prototype available. Also, a manufacturer of liquid crystal displays (LCD) for the medical, aviation, aerospace, marine, automotive, industrial controls and defense industries. Types of displays are bezel, graphic, character module and ruggedized. Secondary services such as integration, engineering and testing are also provided.

Precision CNC machining, sheet metal fabrication and assembly services. Repair services are also provided. Fiber optic junction boxes, converters, latches and switches are offered. Uninterruptible power supplies (UPS), liquid crystal displays (LCD), racks, consoles, multiplexers, control panels and quad-core processors and servers are also available. Serves aerospace and defense industries.

Manufacturer of organic light emitting diode displays (OLED). Supplier of LCD, TFT, OLED, VFD displays and development tools. Products include IPS, sunlight readable, premium MVA, HDMI modules, EVE2 modules, graphic and character LCD or OLED modules, COG displays, full color OLED, dot matrix, 7-segment, shields for hardware & software, breakout boards, accessories and custom display designs.

Manufacturer’s representative of embedded computer systems and RF products. Products include rugged servers and LCD displays, Ethernet switches, media converters, UPS power systems, frequency synthesizers, RF amplifiers and phase noise analyzers.

ISO 9001:2000 & ISO 13485:2003 certified manufacturer of ruggedized & custom liquid crystal (LCD) displays. Options include graphics, installation of touch sensors, color ink printing for icons & symbols or for changing viewing modes or connection methods, drive electronics & LED backlights. Films & enhancement options include anti-glare, anti-reflective, vandal glass & optical glass bonding. Custom enclosures & brackets include bezels, mounts, chassis & stands. Extended temperature options include cooling kit & heaters. Applications include transportation, military, public safety, outdoor kiosks, medical & industrial. FDA approved.

Distributor of equipment for the retail petroleum industry. Product selection includes bulbs, decals, overlays, LCDs, fuel filters, gasoline and diesel pump hose, nozzles, breakaways, air compressors, vacuum machines, shampoo and water machines, UPSs, surge suppressors, power conditioners, and isolation transformers. Also offers parts for petroleum pump and car wash controllers, as well as intercoms and vehicle detectors. Serves oil, travel plaza, convenience store, casino/gaming, and related markets.

Manufacturer of ruggedized & custom liquid crystal (LCD"s) displays. Models available in 17, 19, 20 & 24 in. Up to 1280 x 1024 pixel resolution. Contrast 500:1 through 1500:1. Integrated power supply. Premium models with DDC CI interface.

Distributor of liquid crystal ruggedized & custom LCD displays for industrial applications. Displays are available in 15 in. to 20 in. sizes. Desktop LCD, large format, touch CRT, panel mount LCD & NEMA-rated displays & flat panel monitors are also available.

Manufacturer of transflective glass and module LCD displays. Glass LCD displays are available with -40 degrees C to +105 degrees C operating temperature. Module LCD displays are available with -40 degrees C to +85 degrees C operating temperature. Medical, transportation, industrial, security and consumer industries served. LCDs can be customized. Stock items available. RoHS compliant. CE certified.

Manufacturer and distributor of standard and custom LCD displays for commercial, retail and industrial applications. LCD displays are commercially rated and available in stand alone or kiosk configurations in a wide variety of sizes. Also features a turn-key solution with hardware and software, intuitive content manager, analytical data reporting, dashboard accessible from anywhere, modular designs, flexible development, single source support, ADA compliancy features and a safe and secure design.

Custom manufacturer of electronic displays for the automotive, avionics, commercial, digital signage, gaming, marine, medical, military and retail industries. Specializes in thin-film transistor (TFT) displays, memory liquid crystal displays (MLCDs), organic light-emitting diode (OLED) displays, touchscreen displays, large format displays, wide viewing cone displays and specialty format displays. Display design services also offered.

ISO 9001 manufacturer of custom displays including ruggedized, high bright & transflective liquid crystal (LCD) displays. Suitable for hotels, public spaces, live theater, trade shows, sporting events, casinos, airport, rail station, retail & shopping centers. RoHS compliant.

Manufacturer of handheld products for vehicular, marine, military, railway, educational and oil, gas and energy industries. Products include embedded panel personal and single board computers, displays, tablets and touch screens.

Manufacturer of custom liquid crystal (LCD) displays. Features include active and passive backlight enhancements, ruggedization, enclosures, heaters, open frame solutions, custom electronics and circuits, gaskets and optical bonding.

Manufacturer of ruggedized and custom liquid crystal displays (LCD). VGA, SVGA, XGA, SXGA, and FHD liquid crystal displays (LCD) are available with sizes ranging from 6.5" to 24" and up to 1300 cd/sq. m luminance. Computer accessories are also offered such as cables, CPU coolers, drive bays, and flash disk drives. Secondary services are also provided including design and prototyping services. Suitable for automotive, aerospace, medical, and military applications. RoHS compliant.

Manufacturer Of LCD Standard & Custom LCD Character & Graphic Modules & LCD Panels; Printed Circuit Board Assemblies; Electronic Assemblies; Power Supplies; Wall Plug-In Adaptors, Transformers & Offshore Production Facilities

Manufacturer of ruggedized & custom liquid crystal (LCD) displays. Features include 15 in. to 23 in. TFC analog & digital LCD displays, 16.7 million display true colors, maximum resolution range from 1280 x 1024 pixels to 1920 x 1200 pixels, articulating arm mount, optional touch screens, 8U rack mount, weight range from 13 lbs. to 24 lbs. Liquid crystal (LCD) displays are used for rack, wall, panel or kiosk installations. One year limited warranty. RoHS compliant. Meet UL & MilitarySpec.

Manufacturer"s representative of electronic and semiconductor components and solutions. Products represented include cards, processors, sensors, memory, transistors, connectivity items, liquid crystal displays and monitors, modules, ocsillators, clock generators, and filters. Also represents manufacturers of relays, LED lighting, electronics cooling solutions, DC-DC converters, magnetics, capacitors, slip rings, resistors, quartz crystals, and PCBs. Other companies represented include electronics and semiconductor designers and engineering services, as well as electronics contract manufacturing services.

Distributor of display products including touch screen integration, sunlight readable & high bright displays, LCD kits, LCD open frames, controller boards & LCD screens. Distributor of mass storage products including hard drives & CD/DVD drives.

All of our Military COTS displays are flight certified or have been air qualified by our customers and are currently deployed on a variety of military aircraft. They are built to meet aerospace MIL Standard requirements for durability and reliability. Our aircraft LCD displays accept pressure gradients from sea level to 40,000 ft. LCD heaters permit reliable operation from -50C up to 70C. They have a compact, light design to minimize payload size and weight. All displays are tailored to meet shock and vibration profiles for large jets, small turboprops, and helicopters.

LED segment display is one of the commonly used display screens. By inputting the corresponding current to its different pins, it will light up, so as to display the number, date, temperature, and so on.

Because of its relatively low cost and simple use, it is widely used in the fields of electrical appliances, especially household, such as air conditioners, water heaters, refrigerators, and so on.

LED segment displays are composed of many SMD LEDs mounted on the circuit board and plastic shell to display fixed and simple numbers and other information patterns. The most common forms are the numbers 0 to 9, one or two decimal points, alphabet, marks, and symbols.

The shell is made of flame retardant PC plastic, with high strength, impact resistance, aging resistance, UV protection, dust prevention, and moisture resistance. LED segment displays have the advantages of low power consumption, low heat, impact resistance, and long serving time. With the help of a controller, it can realize the effects of running water, gradual change, jump, and chase, etc. It can be divided into common cathode and common anode according to the attribution. A wide range of colors are available: white, red, green, blue, orange, etc.

With the development of technology, it is supposed to be replaced by segment LCD display in some areas. If we compare it with segment LCD display, it is much cheaper and much brighter, suitable for industrial illumination and indication, but low class and much thicker.

The all new TEC Temperature Controllers are packed with new features at a competitive price, bringing you unparalleled value from the company that does it best. These high-performance controllers are easy-to-use, feature a compact design and bright LCD display. They can also be used for pressure, flow, and humidity control.

Tempco is your ISO 9001:2015 Certified custom manufacturer of electric heating elements, temperature sensors, temperature controllers & process heating systems.
