Add some dazzle to your project with this 1.45" diagonal graphic TFT LCD display module. You"ll often see this display advertised as a 1.44" Color TFT but we rounded up instead. This small display packs 128x128 full-color pixels into one square inch of active display area. It is a great choice when you need color and sharp detail while using minimal front panel space. At less than 5 grams, the display adds very little weight to handheld or wearable devices.

Thanks to the integrated Sitronix ST7735S or compatible controller, a single 3.3v source powers everything. The SPI host interface allows full read and write control of the display while using only 10 pins. The single bright white LED backlight has anode (A,+) and cathode (K, -) pins brought out on the Flexible Printed Circuit (FPC) tail. To connect, all you need is a single standard 10-conductor, 0.5 mm SMT ZIF connector.

While the SPI interface requires only a few lines to control this TFT LCD module, it is still possible to transfer data at a rate that supports 20 FPS (Frames Per Second) screen updates -- fast enough to play a full motion video.

To get started, download the datasheet and SPI sample code. And of course, Crystalfontz is always here to help you when you integrate this display into your application.

Mounting bezel for 20x4 displays made from textured black ABS. This kit includes all mounting hardware and easy to use mounting cutout template.Includes:1x BEZ-204A-V1

Mounting bezel for 20x2 displays made from textured black ABS. This kit includes all mounting hardware and easy to use mounting cutout template.Includes:1x BEZ-202C-V1

Choosing from material options such as soda lime, chemical and heat strengthened, tempered and toughened glass and PMMA, Polycarbonate and Optolite™ high scratch resistant plastics, our team can pinpoint the ideal solution. Our bespoke service also includes enhancement such as Anti-Glare (AG), Anti-Reflection (AR) and Anti-Smudge (AS) optical treatments. Finally, colour and graphic logo printing, circular, rectangular and free-form cut-out detailing can fully customise your monitors.

As the ultimate in sensory and intuitive user experience, delivering product differentiation from competitors, we offer integrated Haptic feedback technology to our TFT touch sensors. Users experience added satisfaction of a tactile sensation of simulating clicks and vibrations through the touch screen, giving the enhanced perception of using physical buttons and switches.

When clarity and functionality is essential to create the best end-user experience, Optical Bonding offers the perfect solution for increasing visibility and durability in light-challenging and harsh environments.

Specially designed embedded SBC solutions for our AMOLED displays, contain all the essential hardware, software, electronics and interface drivers to reduce your development cycle and speed up time to market.

When maintaining maximum performance, reliability and output efficiency is essential, our in house engineer designed and developed protective EMI shields and ground pads to limit Electromagnetic Interference (EMI) and provide noise immunity.

This reliable LCD monitor comes with a dimmer and 5-year warranty. Transduction already has hundreds of computers and monitors working on the ships for many years now.

The potentiometer adjustable dimmer allows for smooth adjustment of display from almost zero brightness to maximum. This is a very useful feature for reading maps, etc. when it is dark during the nights. Dimming feature also extends useful life of the monitor backlight.

This monitor is compliant with all requirements of safety for marine use but the only formal approval is electrical safety for the 120VAC version by CSA/UL, that is required by law.

Price of the TR-LCD1500-ITX is US $1575 for a complete system including 2GB of memory and 64GB Flash SATA SSD with optional CD-DVD/RW and resistive or capacitive touch screen.

TR-LCD1500-ITX is the most economical solution for a high quality industrial workstation. TR-LCD1500-ITX rack and panel computers are readily available from stock. Warranty is 3 years.

I"ve been working on a project that used a 16x2 LCD display and wanted a nice finish that also allowed me to seal against water and other liquids. I also needed impact resistance, low cost and the ability to be changed easily if worn or broken.

3) Looking for access to a laser cutter to make a profiled perspex window that sits through the enclosure hole to sit flush with surface. Difficult tolerances and no depth control with a laser.

So, eventually I tried something else and ended up with what I think is a nice professional finish that is easy to do, cheap, and results in an iPhone type black glass frame style, with a clear window exactly the right size to show the display properly. It can also be easily adapted to any other type or size of display.

I took the original dimensions of the 16x2 LCD display I had and drew it up, including the stand-off holes. I then added an additional 5mm surround to give my bezel additional strength around the fixing holes, and also to make it look better since the holes wouldn"t be right on the edge.

A fine tip permanent pen like a Sharpie or Write-4-All works well on the acrylic. I used 1.5mm clear acrylic sheet for a glass-like finish. You could use different colour acrylic or thicker/thinner to suit your requirements.

For the 16x2 LCD the display area is approx 15mm x 65mm. I made my window 14mm x 64mm so there is a slight overlap to the display so no edges can be seen.

Remove the template and then peel the outer area of tape away and this will leave a nice clean cut 14mm x 64mm piece where our display will eventually show through.

We now want to spray paint the area that will be the bezel outer border. Choose your colour for this, although I used black and found it produced a lovely black glass type finish.

Mounting the piece is to make sure it doesn"t get blown around by the force of the spray can, as we don"t want overspray onto the other side of the acrylic.

EDIT: On making one for a 64x128 1.8" TFT display it occurred to me that we can simply mask the back side of the acrylic completely. This ensures 100% that you don"t get any overspray on what will become the top face. When everything is dry just peel off the masking on the other side too.

Take the piece into a well ventilated area before spraying. Outdoors is best, or a garage with open door. The paint has quite an odour until fully dry.

You can now mount the bezel to your enclosure, using the mounting holes and some 3mm bolts. The same bolts can be used to mount the LCD behind. I found 3mm x 20mm bolts are ideal. You can also use nylon ones that are used for PCB stand-offs.

If you need weather/water proofing then simply apply a thin layer of sealant under the black border outside of the stand-off hole line. When this dries in place it will form a watertight seal that can"t be seen.

Awesome idea! I"m just starting on an Arduino based chess timer project with a small VFD display and a couple of those big "arcade" style microswitch buttons for my son and was thinking about how to make a decent looking hole / bezel for the display. Your instructable solved my problem elegantly! Thanks and thumbs up for you!

The types of flathead countersunk hex head bolts in the attached picture are great for such projects, especially the black bolts. I"ve used them a lot for such panels and also for mounting black items like IEC mains input sockets. They provide a fantastic finish, you just have to be careful and precise with your countersinking. Available on eBay from various sources. I use the M3 type most often but other sizes are available. I"d avoid pan-heads of a different colour on the outside as they don"t look nearly as professional as the countersunk flatheads. If you don"t want to countersink then use the button head ones, they look much nicer than the pan heads.

I"ve used the milled edge rebate technique in the past to produce a flush finish and it works great ... IF you can get someone to do the milling for you. I was lucky, I did. You don"t NEED a CNC machine but a plain old milling machine IS required for a really good accurate finish. If you have a decent pillar drill, you can use a simple cross feed milling table to do the milling with your drill. eBay has a great one for under £50 that I"m planning on getting.

However, you CAN achieve the effect by taking advantage of the ability of true perspex to be acetone welded invisibly and you build the total from the top piece that fits exactly into the cutout hole (very accurate cutting, filing and trimming is needed. Then before black painting the reverse, acetone weld a complete piece over the top piece like a layer cake. the second layer is larger than the first so provides the rebate step. It"s tricky but can be very successful. You can then black mask the rear as before.

Another trick is to use stand-offs behind the front panel, bolted to the front panel via countersunk holes at the front with the relevant bolts, then mount the operstional display etc to the stand-offs. The front bezel can then be applied OVER the countersunk bolts using double-sided adhesive or using a silicone bead as it should never need to come off again. I am using this process currently for a frequency meter display.

Nice design. How did you get round the paint being peeling off when you remove the tape? I"d have thought you"d need to score exactly on the edge of the tape before you remove it!0
