When debugging whether the LCD screen can be used on the development board, we should first check if the line sequence used on the screen hardware can be consistent with the hardware line sequence on the development board; software debugging can only be performed if the hardware can be connected to the development board. Then, after the hardware is connected, check whether the LCD screen is lit. If the screen cannot be lit, first check the PWM backlight control; when the screen can be lit, we can debug the display, which is the main purpose of this article.

Modify linux-3.0.35/drivers/video/mxc/mxc_lcdif.c and add the red part to the following structure. The parameters in the red part are the same as those in UBOOT.

The modifications that we often involve in the LCD display part are mainly the parts mentioned above. After the modification, write the image file generated by recompilation to the development board, and connect it to the 10.4-inch LCD screen to see it. The screen can be displayed normally.

Some LCD manuals will directly give the values of these 6 parameters, then you can set them directly according to the values given in the hardware manual, and fine-tune them when debugging.

Most examples in the kernel are directly set to FB_VMODE_NONINTERLACED. Interlaced means interlaced scanning. In TV, a 2:1 interleaving rate is used, that is, each frame is divided into two fields, scanned twice vertically, one scans odd lines, and the other scans even lines. Obviously LCD is not this model.

The content of this article is only a preliminary introduction. Many parameters are not introduced in detail. The LCD driver and support are relatively extensive. If you are interested, you can consult the relevant content online.
