CONRAC’s IP-TEC series of large-screen LCD / TFT displays has been specially designed for outdoor applications, as well as for indoor use with special requirements regarding the environmental conditions, e.g. where dust, moisture or immense variations in temperature are involved.

The main fields of application in airports are in baggage handling and loading areas, as well as car parks or other outside areas where a certain ruggedization of the displays is required. The displays are also ideal for railway, bus and subway

Similar to IP20 displays, customisation of IP54 displays is a major issue. All IP54 protected displays are based on a modular construction which allows various configurations. It is possible to combine a different number of integrated screens to

All displays can be supplied with or without an integrated controller which supports different software applications. The monitor-only versions can be connected to standard PC systems.

To offer maximum flexibility concerning the information to be displayed, the IP54 series can be used for operation in both landscape and portrait mode applications. All displays feature integrated display heating and ventilation, robust metal housing,

The IP54 series of displays uses the latest high-performance LCD / TFT displays. Screens are currently available in 32in, 40in, 46in and 57in. Conrac is also planning the launch of a series of IP65 protected units, with screen diagonals from 32in to

CONRAC"S 6018 ID is a high resolution, multi-frequency, industrial grade TFT flat panel monitor supplied in metal cabinet or rackmount configurations. The cabinet version is supplied with a bracket for wall or ceiling mounting or for use as a desk stand. Advanced signal image processing techniques allow for operation on video signal sources ranging from CGA up to 1280 x 1024 (SXGA) workstation resolutions as well as CVBS and Y/C (S-Video). Modular construction, robust aluminum casing and special laminated anti-glare safety glass panel ensure reliable around the clock operation in demanding applications.

CONRAC’s range of highly engineered Marine Grade LCD/TFT Displays is specifically designed to withstand the harsh maritime environment. The SD-Series (Ship Display-Series) meets the

stringent demands of the international standards for Maritime Navigation and Radio Communications Equipment & Systems and ECDIS (Electronic Chart Display Information System).

Used for ECDIS, Radar, ARPA (Automatic Radar Plotting Aid) or ship control, the displays’ superior performance provides very clear and readable images regardless of the ambient light

With the highly innovative wideECDIS® series of MultiTask Monittors, CONRAC introduces an entirely new generation of wide screen Radar and ECDIS displays. The new 16:10 widescreen

format allows to dramatically increase the amount of information displayed which is important for compliance with the new Radar standard. The superior picture performance of the

wideECDIS® monitors is achieved with high performance full HD (High Definition) panels in combination with CONRAC’s latest state-of-the-art electronics.

During night-time operations in bridge and wheelhouse environments it is vital to optimise the display brightness to the ambient light conditions for night vision capability. CONRAC offers fully

The use of laminated safety glass with high efficiency anti-glare treatment does not only maximise security and protect the display but also enhances image contrast.

CONRAC‘s COS (Customised Operation System) allows adjustment of brightness alternatively using the traditional potentiometer control, hot keys or the integrated intelligent ALC (Ambient

Approved/built to meet IEC 62288 as well as IEC 61174 (ECDIS), EN 62388 (Radar), EN 60945 (Navigation), CONRAC Ship Displays are the ideal solution for the use in Integrated Bridge

The use for ECDIS, radar and navigation makes high demands on the displays in integrated bridge systems. Displays, being a critical aspect of safe and efficient operations, have to meet

suppliers, CONRAC has implemented vital functions into their Ship Display Series to guarantee superior performance, both, during day and night operation.

Dimming of standard TFT widescreen displays does result in uneven brightness performance. Especially during night operation this effect is distracting and unacceptable for navigation

mode. To avoid this negative effect, CONRAC implemented high contrast dimming functions, allowing dimming at the full contrast level guaranteeing outstanding picture performance during

Other functions include for example: turn off the display or PC, adjust brightness/contrast, select different picture source, check the internal temperature/humidity of the device and analyze the statistics gathered by IDA. And all of this can also be done thru the Internet or LAN (Local Area Network).

The AP4200PRO/PC is a complete PC and a big display in one flat package! Slim and stylish design with a huge, bright 42� screen make it possible to use in a variety of applications.

Alpha Point Ltd. supplied new public transport information displays to Helsinki-Vantaa International airport in the spring of 2004. Whole system with software was fully functional in the summer 2004.

AP3000PRO/PIDS display device is our latest integrated panel-PC product, AP3000PRO/PC. The huge 30" TFT display, with high brightness and contrast fits great to the airports bright lighting conditions. Devices are equipped with Linux operating system and software which independently collects the passenger information data from various service providers via Internet.

The AP3000PRO/PC is a complete PC and a big display in one flat package! Slim and stylish design with a huge, bright 30� screen make it possible to use in a variety of applications.

AP3000 Multimedia is also a TV receiver and a computer monitor in the same device. Numerous connectors make it possible to use the monitor with many different devices. It represents the latest TFT technology which results in wide viewing angles and lightning fast display refresh rate.

This new 6.4" TFT panel features an integrated touch screen overlay. Building a display device as a part of your own equipment is so one step easier. Bright and crisp picture, small and compact size and light weight makes it possible to use the display in many purposes.

These new products further enforce the product family and bring along them a new feature: XGA resolution (1024x768) on a 12.1" TFT panel. It is a welcomed feature since it is often usefull and required to display more accurate information on smaller displays as well.

Sync on Green option makes it possible to use a modern Alpha Point TFT monitor instead of an old and bulky industrial CRT monitor (for example Conrac, Alcont, Altim). Connection interface is three BNC connectors (RGB).

With its active display area the device is equivalent to a 23-24" large and heavy CRT monitor, which you can replace with the new and modern AP2000PRO as your PC systems monitor.

The display is bright, high resolution (1600x1200, UXGA) and it is easily viewed from multiple angles with its wide viewing angles. It also supports full color palette (16.7M colors).

All of the AP1200 series devicies can be equipped with integrated touch, membrane key mouse, standard or daylight TFT display, extended brightness control and a suitable monitor stand.

For industrial, mobile applications and navigation AP has developed new AP500PRO/PC. 15.1" bright and crisp TFT display (250 cd/m�, also 500 cd/m�-version) with touch screen and a fully equipped PC in one small package!. Shock resistant and splash water tight (IP65, option) housing enables it to be used even in harsh enviroments.

As a fore-runner of digital display technology Alpha Point offers a new effective cabling solution. Fully compliant with DVI standard, AP Opto Link accomplishes up to 500 meter cable lenghts with fibre optics, with SXGA resolution! DVI connectors at each end of the cable have integrated modulators that convert the (standard) electrical DVI signal to light and back to electrical signal at the receiving end. This enables the AP Opto Link to operate fully invisible between the PC and monitor: it fits to all standard DVI(-D) monitors/PC"s. Fiber optic cable is also 100% invisible to EMI.

Today, DATA MODUL AG is one of the world’s leading specialist providers of display, touch, embedded, signage, monitor and panel PC solutions and is celebrating its 50th anniversary this year.

June 29, 2022 - In an ever more interconnected world, displays are the most important interface for interaction, exchange and the operation of various applications. In this context, display technologies and the requirements for individual complete solutions are continuing to develop at a rapid pace. In 1972, the year of its foundation, DATA MODUL AG specialized in electro mechanics, but already in the early years recognised the potential of display technologies as a future market and positioned itself early on as a pioneer and competent partner for complex high-level display and system solutions. Today, DATA MODUL AG is one of the world’s leading specialist providers of display, touch, embedded, signage, monitor and panel PC solutions and is celebrating its 50th anniversary this year.

In 1972, Walter Eichner founded the company with 20,000 Deutsche Marks in equity capital and initially focused on electromechanical switches and components for his distribution business. Gradually, he added other product categories such as printers, scanners, cash register systems and LCD displays. Together with Peter Hecktor, who joined the company in 1976 and became Co-Managing Director of DATA MODUL, Walter Eichner laid the foundation for the company’s current financial stability and success. The sole proprietorship very soon developed into an established medium-sized company with a broad distribution product portfolio of displays.

The company’s initial public offering in 1988 was followed by a stronger international orientation and the addressing of global markets. The product portfolio now included displays and the associated system peripherals as well as electro mechanics, crystals and semiconductor sales. In 1994, the company was certified according to DIN EN ISO 9001, which stands for the continuous improvement of processes, products and services. The acquisition of DATAMEGA in 1997 added the distribution of printers, cash register systems and monitors to the existing portfolio. The founding of DATA MODUL Inc. in Hauppauge, New York and the associated expansion into the US market constituted another important step in the company"s internationalisation.

In 1998, this was followed by the acquisition of CONRAC GmbH in Weikersheim, which back then mainly produced display solutions for the digital signage sector. In the course of this, the warehouse was also relocated to Weikersheim. In the following years, DATA MODUL AG succeeded in continuously expanding its product portfolio and its expertise in the field of large-format LCD and TFT displays for industrial and information displays as well as in meeting the growing market requirements. In 2008, DATA MODUL AG started producing its own PCAP touch modules - a first important milestone in the company’s history for successfully establishing itself as a provider of state-of-the-art touch solutions. This was followed by implementing optical bonding in the company’s own production processes in 2011, which set new standards in terms of the quality, presentation and durability of the offered displays. In the years to come, DATA MODUL then continuously supplemented its own bonding competencies with further bonding technologies and thus developed into the leading provider of high-quality touch products. In 2012, production was expanded to include the LOCA process. Following the commissioning of several LOCA machines, the OCA process was also introduced at DATA MODUL for the first time in 2016. In 2019, the range of bonding processes was expanded to include hybrid bonding which combines the LOCA and OCA processes. In 2021, the gel bonding process was implemented adding the final touch to in-house bonding service spectrum of DATA MODUL AG.

For DATA MODUL, customers and their individual requirements are always top priority. That is why the Munich-based company dedicated itself to the production of customised special solutions in the field of industrial display systems at an early stage. With its modular product concept, DATA MODUL AG combines all of the company’s Technology Sectors within one system. Components from the fields of display, touch, embedded, system and housing technology can be combined and adapted as required. In addition, individual solutions suitable for a broad user market are not only developed for the areas of hardware and mechanics but also for the field of application software. The proprietary software products “maXcs” and “easyANALYZER”, for example, support the commissioning and use of modern hardware components. In addition, there is the possibility of developing customised application software tailored to the respective area of application.

As a leading provider in the field of modern display technologies for industry, DATA MODUL has geared its product and service portfolio to both current and future fields of application. Thus, the products of DATA MODUL AG are successfully used in a wide range of different applications and markets, such as medicine, industrial automation, the automotive industry as well as in mechanical engineering and in the areas of digital signage and eMobility. And innovative display solutions can also be found in building technology, in household and end-customer devices as well as in infotainment systems.

With its particularly extensive and sophisticated portfolio as well as state-of-the-art research and production sites, the company stands for innovative strength, excellent quality, high-performance products and sustainable growth today and in future. An open corporate culture, responsible management and trusting, long-term relationships with customers, suppliers, employees and shareholders make DATA MODUL AG a reliable and competent partner for modern display solutions - with more than 50 years of experience.

DATA MODUL AG is one of the world’s leading specialist providers of display, touch, embedded, monitor and panel PC solutions. Since it was established in 1972, it has consistently pursued the objective of providing its customers with state-of-the-art, tailor-made and individually customised complete solutions for display technologies.

Many years of experience in the field of display, touch, embedded and system technologies enable the company to produce customer-specific value-added services for a variety of industries at its 45,000 m2 production and logistics facilities. The extensive distribution portfolio of displays, touchscreens and embedded solutions and the increasingly innovative in-house developments complete the unique modular product portfolio

As an industry display technology partner, over the course of 45 years, DATA MODUL has established itself as the European market leader in the field of display distribution. Today, DATA MODUL is one of the world"s leading specialist suppliers of display and system solutions for industrial, professional applications in a wide range of sectors. Based on its extensive distribution portfolio, DATA MODUL focuses on the development of its own products, customer-specific solutions, and value-added services in the areas of display, touch, embedded, monitor, and panel PC solutions.

DATA MODUL"s brand CONRAC stands for high quality passenger information systems and professional signage solutions installed at airports, railway stations and in public transport systems. With more than 300 system installations in over 60 countries CONRAC display and software systems are among the world"s leading solutions for passenger information at travel hubs. Over decades, DATA MODUL"s brand CONRAC has established an excellent reputation in the industry for highest reliability and durability in demanding environments.

We are a market leader for the development and supply of special display solutions for mobile, military and marine applications. The product portfolio covers a wide range of rugged, specialised and customised LCD monitors, widescreen displays for ECDIS, RADAR, NAVIGATION and marine panel computers.

CONRAC GmbH – now renamed to DATA MODUL – CONRAC remaining as brand name, has always been a leader in providing innovative technology to the naval industry. Active in this industry, the company has at all times played a pioneering role in the display business. Thousands of installations worldwide speak for themselves.

Thanks to an advanced R&D department with unique expertise and a product management team with unbeatable global market knowledge, we always stay one step ahead. Committed to technologically advanced and cost-effective display solutions, special R&D teams create highly-engineered products of exceptional quality and reliability, using only the latest and most reliable technologies. Special developments like our cTEC features, guarantee trouble-free operation, prolong the product’s lifetime and reduce the cost of ownership.

CONRAC wide screen displays are the ideal solution for the display of electronic charts, tactical situation reports and automation control information. The displays are optionally available according to MIL-STD-167 (vibration), 810 (shock / temperature) and 461 (EMI) and withstand severe underwater explosions of up to 100g. The screen sizes offered range up to 55in, options available are touch screens and additional shock mounts.

The highly innovative wideECDIS series has been specially designed for a maritime environment, ECDIS, RADAR, navigation and ship control applications. The 16:10 wide screen format allows the user to dramatically increase the amount of information displayed which is important for compliance with the new radar standard. All marine grade displays are fully dimmable and compliant with the relevant standards.

Our modular concept ensures cost-effective solutions with very high quality standards, avoiding unnecessary over-engineering which contributes to a reduced cost of ownership. The displays can be customised to suit the user’s needs. Options for our ruggedised / customised marine grade displays include:Integrated controllers or industrial / marine grade / ruggedised PCs

Extended temperature range, climate control and display heating for operation under extreme temperatures and /or temperature variations and highest system availability

Our company philosophy is not to just offer state-of-the-art products, but to provide our customers with the best display or system solution for their projects.
