This panel meter features a 4½ digit LCD with 12.5mm (0.5") digit height and a low-profile bezel for mounting. With 200mV and 2V d.c. full scale readings, digital hold, auto-zero, and auto-polarity, this meter plugs directly into a single-in-line (SIL) socket or can be panel mounted using the snap-in bezel and window supplied.

This exceptionally low cost panel meter features a 3½ digit LCD with 6.3mm (0.25") digit height.  With 200mV full scale reading, auto-zero, auto-polarity and user selectable decimal points, this meter can be panel mounted using the snap-in bezel supplied. The V 1 is a popular part, normally stocked in high quantity and suitable for new designs and is also available in even lower cost packs of 10.

Last Sunday, while I was explaining the basics of electronics and Arduino to my roommate, she challenged me to understand how a voltmeter works and build one from scratch just using the stuff I own already. I accepted the challenge, started hacking, coding, testing, re-coding, and re-testing, and finally I had my voltmeter ready and working by dinner time!

I used Arduino Uno (to collect voltage in analog and to power the LCD), a small LCD screen that I got in my Arduino starter kit (to display the voltage), a breadboard (to connect everything), and jumper wires.

The code is pretty simple. We just want to collect the analog signal that the Arduino receives at Pin A5 (or any other analog pin) and convert it to digital. We then want to display the results on the LCD screen.

This is the code that you can copy-paste.#include int Vpin=A5;float voltage;float volts;LiquidCrystal lcd(12, 11, 5, 4, 3, 2);void setup() {Serial.begin(9600);lcd.begin(16,2);}void loop() {voltage = analogRead(Vpin); volts = voltage/1023*5.0; Serial.println(volts);lcd.print(“voltage = “);lcd.print(volts);delay(200);lcd.clear();}

So we’re first importing the LCD library, then creating a variable named Vpin (which will be the voltage collected from A5). Next, we create two more variables for the voltage, and then a variable of type LiquidCrystal. Finally, we do setup with the Serial monitor (which is a really useful tool in Arduino! Sort of like debug console), convert the analog voltage to digital voltage, and print (display) that value to the LCD screen.

Also, if you want to make the reading on the LCD more legible, put a 1k ohm resistor in the path to Pin 3 (which is for contrast adjustments). By limiting the electric current flowing to that pin, you’ll improve the contrast of the screen.

Also important note: In this voltmeter, whatever voltage you test will go as a direct input to the Arduino, so you should only test stuff that is in the range of volts that Arduino can safely handle (0–5V). Testing with a 9V battery will fry your Arduino.

The Lascar DPM 970 is a 3 1/2 digit LCD voltmeter with 19mm (0.75") digit height and LED backlighting. It features 500 V AC RMS full scale reading, auto-zero and auto-polarity. Connection is via screw terminals. The meter can be panel mounted using the bezel. DPM-970 has an optional IP67 / NEMA 4X bezel (BEZ 900-IP) is available for waterproof applications.

A multimeter is a measuring instrument that can measure multiple electrical properties. A typical multimeter can measure voltage, resistance, and current, in which case it is also known as a volt-ohm-milliammeter (VOM), as the unit is equipped with voltmeter, ammeter, and ohmmeter functionality, or volt-ohmmeter for short. Some feature the measurement of additional properties such as temperature and capacitance.

Vacuum tube voltmeters or valve voltmeters (VTVM, VVM) were used for voltage measurements in electronic circuits where high input impedance was necessary. The VTVM had a fixed input impedance of typically 1 MΩ or more, usually through use of a cathode follower input circuit, and thus did not significantly load the circuit being tested. VTVMs were used before the introduction of electronic high-impedance analog transistor and field effect transistor voltmeters (FETVOMs). Modern digital meters (DVMs) and some modern analog meters also use electronic input circuitry to achieve high input impedance—their voltage ranges are functionally equivalent to VTVMs. The input impedance of some poorly designed DVMs (especially some early designs) would vary over the course of a sample-and-hold internal measurement cycle, causing disturbances to some sensitive circuits under test.

A multimeter is the combination of a DC voltmeter, AC voltmeter, ammeter, and ohmmeter. An un-amplified analog multimeter combines a meter movement, range resistors and switches; VTVMs are amplified analog meters and contain active circuitry.

Resistance measurements on an analog meter, in particular, can be of low precision due to the typical resistance measurement circuit which compresses the scale heavily at the higher resistance values. Inexpensive analog meters may have only a single resistance scale, seriously restricting the range of precise measurements. Typically, an analog meter will have a panel adjustment to set the zero-ohms calibration of the meter, to compensate for the varying voltage of the meter battery, and the resistance of the meter"s test leads.

A multimeter may be implemented with a galvanometer meter movement, or less often with a bargraph or simulated pointer such as a liquid-crystal display (LCD) or vacuum fluorescent display.

To avoid the loading of the measured circuit by the current drawn by the meter movement, some analog multimeters use an amplifier inserted between the measured circuit and the meter movement. While this increases the expense and complexity of the meter, by use of vacuum tubes or field effect transistors the input resistance can be made very high and independent of the current required to operate the meter movement coil. Such amplified multimeters are called VTVMs (vacuum tube voltmeters),

Category IV: used on locations where fault current levels can be very high, such as supply service entrances, main panels, supply meters, and primary over-voltage protection equipment

A quality general-purpose electronics DMM is generally considered adequate for measurements at signal levels greater than 1 mV or 1 μA, or below about 100 MΩ; these values are far from the theoretical limits of sensitivity, and are of considerable interest in some circuit design situations. Other instruments—essentially similar, but with higher sensitivity—are used for accurate measurements of very small or very large quantities. These include nanovoltmeters, electrometers (for very low currents, and voltages with very high source resistance, such as 1 TΩ) and picoammeters. Accessories for more typical multimeters permit some of these measurements, as well. Such measurements are limited by available technology, and ultimately by inherent thermal noise.
