5.7 inch tft lcd free sample

This 320x240 resolution LCD TFT is a standard display with 16-bit parallel interface and a 12:00 optimal view. This Liquid Crystal Display has a built-in SSD1963 controller. It is RoHS compliant and has a 4-wire resistive touchscreen.

This 640x480 resolution LCD TFT is a standard display with 8-bit parallel interface and a 6:00 optimal view. This Liquid Crystal Display has a built-in SSD1963 controller and a 4-wire resistive touchscreen. The TFT is RoHS compliant and has been discontinued. Purchase now while stock is still available!

EVERVISION’s new 5.7” TFT VGA (VGG644804-6UFLWU) display features 640 x 480 resolution and LVDS 6 bit interface. Designed with a high-efficiency power LED backlight, the display achieves a super high brightness of 1300cd/m², which makes it easily readable

EVERVISION’s new TFT-LCD offers a wide operating temperature range of - 30° / 80°C. Together with the long-term availability, the display is ideal for industrial

Evervision’s super high brightness TFT display is optimal for daylight applications like parking pay station, E-Car charging point, automatic car wash POS, outdoor terminals, payment kiosk and more.

In this category, we’d like to introduce our product line of TFT LCD Display Modules. We offer a wide array of products for customers to choose from, including all-in-one TFT with built-in control board, monochrome TFT, high brightness TFT, wide temperature TFT, and TFT supporting HDMI signal, etc. In addition, you can also find your favorite modules with CTP or RTP feature. On top of that, we provide TFT modules with various options of resolution, including 320x240 , 480x128, 640x480, 720x1280, 800x480 and so on. There are many more options in our product line with different Controller IC/Interface/Brightness/Temperature...etc. You can use the filter below to find the module that best suits your project. If you would like to learn more about product details of 5" TFT LCD, 5.2" TFT LCD, 5.6" TFT LCD and 5.7" TFT LCD please browse through the following models and feel free to send us inquiries.

If you want to buy a new monitor, you might wonder what kind of display technologies I should choose. In today’s market, there are two main types of computer monitors: TFT LCD monitors & IPS monitors.

The word TFT means Thin Film Transistor. It is the technology that is used in LCD displays.  We have additional resources if you would like to learn more about what is a TFT Display. This type of LCDs is also categorically referred to as an active-matrix LCD.

These LCDs can hold back some pixels while using other pixels so the LCD screen will be using a very minimum amount of energy to function (to modify the liquid crystal molecules between two electrodes). TFT LCDs have capacitors and transistors. These two elements play a key part in ensuring that the TFT display monitor functions by using a very small amount of energy while still generating vibrant, consistent images.

Industry nomenclature: TFT LCD panels or TFT screens can also be referred to as TN (Twisted Nematic) Type TFT displays or TN panels, or TN screen technology.

IPS (in-plane-switching) technology is like an improvement on the traditional TFT LCD display module in the sense that it has the same basic structure, but has more enhanced features and more widespread usability.

These LCD screens offer vibrant color, high contrast, and clear images at wide viewing angles. At a premium price. This technology is often used in high definition screens such as in gaming or entertainment.

Both TFT display and IPS display are active-matrix displays, neither can’t emit light on their own like OLED displays and have to be used with a back-light of white bright light to generate the picture. Newer panels utilize LED backlight (light-emitting diodes) to generate their light hence utilizing less power and requiring less depth by design. Neither TFT display nor IPS display can produce color, there is a layer of RGB (red, green, blue) color filter in each LCD pixels to produce the color consumers see. If you use a magnifier to inspect your monitor, you will see RGB color in each pixel. With an on/off switch and different level of brightness RGB, we can get many colors.

Winner. IPS TFT screens have around 0.3 milliseconds response time while TN TFT screens responds around 10 milliseconds which makes the latter unsuitable for gaming

Winner. the images that IPS displays create are much more pristine and original than that of the TFT screen. IPS displays do this by making the pixels function in a parallel way. Because of such placing, the pixels can reflect light in a better way, and because of that, you get a better image within the display.

Winner. While the TFT LCD has around 15% more power consumption vs IPS LCD, IPS has a lower transmittance which forces IPS displays to consume more power via backlights. TFT LCD helps battery life.

Normally, high-end products, such as Apple Mac computer monitors and Samsung mobile phones, generally use IPS panels. Some high-end TV and mobile phones even use AMOLED (Active Matrix Organic Light Emitting Diodes) displays. This cutting edge technology provides even better color reproduction, clear image quality, better color gamut, less power consumption when compared to LCD technology.

This kind of touch technology was first introduced by Steve Jobs in the first-generation iPhone. Of course, a TFT LCD display can always meet the basic needs at the most efficient price. An IPS display can make your monitor standing out.
