Prosine POWERSAVE Mode Your Prosine Inverter has a function mode called POWERSAVE. This “sleep” mode shuts off much of the power control circuitry of the inverter as well as the display back-lighting, reducing the standby current draw considerably. With this mode enabled, the unit draws approx. 1.5 W while powered up but with no load on the inverter. The Prosine Inverter detects the presence of a load by sending out pulses approximately once every 2.5 seconds. Full output power is available with the detection of a load. The unit will remain in POWERSAVE mode if the load it detects is less than 10 W for the 1000 model and less than 20 W for the 1800 model. This is a factory set search mode setting and cannot be changed. You would want to enable POWERSAVE mode if the inverter is only being used periodically to power loads. This allows the inverter to draw less power from the batteries during non-use periods. If the inverter is being used frequently and your batteries are being recharged during inverter use (e.g. vehicle alternator), or soon after inverter use, you can leave POWERSAVE disabled.

Offering superior quality true sine wave output, the PROsineTM 1000and 1800 stand-alone inverters are ideally suited for electrical systems xantrex 1000 watt and 1800 watt power inverter that already have a quality multistage battery charger. Designed for recrestional and industrial applications, their 120-volt/230-volt, 60HZ/50HZ AC power output is capable of handing both heavy duty and smaller, multiple AC loads. PROsine best 12v pure sine wave inverter include a backlit LCD display panel, which can be mounted remotely.

With less than 3% total harmonic distortion, PROsine 1000 and 1800 inverters deliver true sine wave output that is identical to AC powersupplied by your utility. This clean output makes PROsine inverters ideal for handing sensitive loads and improves AC equipmentperformance. Expect trouble-free true sine wave electricity for televisions, audio systems, variable speed tools, and more.

PROsine inverters are lighter and more compact than other inverters with similar power ratings because they use high-frequency switching technology in the power conversion process.Electrical specifications

and inverter to ACMax 2 cycles(typically 1 cycle)＜2.5 seconds with Powersave “ON”Max 2 cycles(typically 1 cycle)＜2.5 seconds with Powersave “ON”

Materials List System / Installation Information Before you call Customer Service, please record the following information about your system. It will help our staff to give you better service. Serial Number (This is on the side of the Prosine). Type of installation (e.g., RV, Boat, Home).

Section 1: Features Over-Current Protection When the AC loads connected to the Prosine inverter/charger exceed 50 amps, the inverter will instantaneously reduce the output voltage until the loads on the inverter are reduced. If the overload continues, the inverter will shut down. The unit will automatically restart after a calculated recovery time.

ACS Configuration Considerations BATTERY INFO: BATTERY INFO: ENTER TYPE: FLOODED TYPE: GEL BATTERY INFO: BATTERY INFO: ENTER SIZE: 75Ah SIZE: 2000Ah Prosine 2.5/3.0 Installation & Operation Guide...

Installation Overview 4. Select an appropriate mounting location. The Prosine must be mounted vertically on a bulkhead or wall with the AC and DC connectors on the bottom. The Prosine is a solid- state electronic device and must be located in an appropriate environment. (Refer to “Where to Install the Prosine Inverter/Charger‚”...

Section 4: Inverter/Charger Installation PROsine Prosine Output Power De-rating at Elevated Temperature 4000 3000 PS 2.5 2000 2000 PS 3.0 1000 Am bient tem perature (deg. C) WARNING Explosion hazard: This equipment contains components which tend to produce arcs or sparks. To prevent fire or explosion do not install the Prosine inverter/charger in compartments containing batteries or flammable materials or in locations which require ignition protected equipment.

Section 5: Operation Input Voltage: The Prosine inverter/charger operates from an input voltage ranging from 10 volts to 16 volts, (20 to 32 volts on 24V models) and peak performance occurs when voltage is in the range of 12 volts to 13 volts (24 to 26 volts on 24V models) as shown in the following table. Prosine Operating Voltage Limits Operating Voltage Range...

Section 6: Multistage Charging Stow- Set to Battery is fully charged at a specific gravity of 1.285. This away FLOODED. is a calcium/lead type battery and requires a higher Set to Cold charging voltage than normal. If performance is poor, this for all battery will likely need to be equalized on every charge ambient...

Appendix A: Specifications Prosine 2.5 Efficiency Curve Prosine 2.5 Efficiency 120Vac, 12Vdc model 90.0 89.0 88.0 Eff. @10.5 V 87.0 Eff. @11.5 V Eff. @ 13.0V 86.0 Eff. @ 12.0 V 85.0 Eff. @ 12.5V Eff. @12.5 V 84.0 Eff. @ 12.0V Eff.

Appendix C: Troubleshooting Error Description of Fault Possible Cause Solution Code AC Output voltage too high 1. Some loads, like motors, 1. Try resetting the unit and can feed power back into running the load again. the output of the Prosine. Contact Xantrex if you This may result in a tempo- find consistent incompati-...

Index battery Amp-hour capacity charging profile battery bank sizing charging times battery capacity calculating battery configuration chassis ground battery current indicator chassis ground lug Battery Information menu described battery requirements, estimating illustrated battery reserve capacity circuit breakers battery size minimum setting cleaning batteries Battery status display (ACS control panel)

Offering superior quality ture sine wave output, the PROsineTM 1000and 1800 stand-alone inverters are ideally suited for electrical systems that already have a quality multistage battery charger. Designed for recrestional and industrial applications, their 120-volt/230-volt, 60HZ/50HZ AC power output is capable of handing both heavy duty and smaller, multiple AC loads. PROsine inverters include a backlit LCD display panel, which can be mounted remotely.

With less than 3% total harmonic distortion, PROsine 1000 and 1800 inverters deliver true sine wave output that is identical to AC power supplied by your utility. This clean output makes PROsine inverters ideal for handing sensitive loads and improves AC equipment performance. Expect trouble-free true sine wave electricity for televisions, audio systems, variable speed tools, and more.

PROsine inverters are lighter and more compact than other inverters with similar power ratings because they use high-frequency switching technology in the power conversion process.

Transfer time AC to inverterand inverter to ACMax 2 cycles(typically 1 cycle)<2.5 seconds with Powersave "ON"Max 2 cycles(typically 1 cycle)<2.5 seconds with Powersave "ON"

With less than 3% total harmonic distortion, PROsine 1000 and 1800 inverters deliver true sine wave output that is identical to AC power supplied by your utility. This clean output makes PROsine inverters ideal for handing sensitive loads and improves AC equipment performance. Expect trouble-free true sine wave electricity for televisions, audio systems, variable speed tools, and more.

PROsine inverters are lighter and more compact than other inverters with similar power ratings because they use high-frequency switching technology in the power conversion process.

Theres a wide variety of inverters on the market. Here, we look at some of the higher-output models-from 1,000 to 2,500 watts-that can be used to power major appliances.

True sine wave versions are generally 5% to 10% percent less efficient than modified sine wave models, and most have a substantially higher standby current while idle, which can be particularly important on smaller boats with limited 12-volt reserves (unless you can remember to shut it off when not in use). The biggest advantage to line-frequency models is the built-in high-capacity battery charger, worth at least $300 if purchased separately, and found in most models. The PROsine we tested is an exception because it is a high-frequency model with a sophisticated four-stage charger.

Trace has a similar remote controller unit called the RC-5 ($200 discount). The difference is that the inverter essentially has all the adjustments built into the basic unit and the RC-5 is an extension of that capability to a remote LCD, two-line display that adds a few extra adjustments. The RC-5 is much easier to install, requiring only the connection of a phone-type cable to the inverter.

We saved the best for last. This unit is nothing less than phenomenal. The exterior case is all aluminum, with all mounting hardware made of stainless steel. The powder-coated side panels are 1/8″ thick aluminum for extreme ruggedness. While the price sounds high at first, looking at what you get actually makes it an outstanding value. Included is an external remote controller that is worth $200 to $300 dollars. This unit looks like Statpower took a clean sheet of paper and decided to include every good feature from of all of the other inverters.

We were most impressed by the state-of-the-art PROsine inverter from Statpower, and highly recommend it as the best, most complete true sine wave version we have seen. A modified sine wave model of equal power with all the options (if you could find one) would be nearly as expensive. Put PROsine on your short list.
