A display system includes a projection screen and a projector. The projection screen includes a retarder plate between a polarizer and a transparent screen. The projector projects an image through the polarizer and the retarder plate onto the transparent screen. The image is visible from a first side of the transparent screen but invisible from a second side of the transparent screen because any light passing twice through the retarder plate is blocked by the polarizer.

This invention relates to displays, and specifically to transparent displays with an image that is visible from one side of the display but not the other. DESCRIPTION OF RELATED ART

Generally speaking, advertising is the paid promotion of goods, services, companies and ideas by an identified sponsor. Advertisements on the side of buildings were common in the early-20th century U.S. One modern example is the NASDAQ sign at the NASDAQ Market Site at 4 Times Square on 43rd Street. Unveiled in January 2000, it cost $37 million to build. The sign is 120 feet high and is the largest LED display in the world. NASDAQ pays over $2 million a year to lease the space for this sign. This is actually considered a good deal in advertising as the number of “impressions” the sign makes far exceeds those generated by other ad forms. However, advertisements on the side of a building cover up what otherwise would be space for windows in the building.

Thus, what is needed is an apparatus that would provide advertisements on the side of buildings while still allowing for windows in the advertisement space. SUMMARY

In one embodiment of the invention, a display system includes a projection screen and a projector. The projection screen includes a retarder plate between a polarizer and a transparent screen. The projector projects an image through the polarizer and the retarder plate onto the transparent screen. The image is visible from a first side of the transparent screen but invisible from a second side of the transparent screen because any light passing twice through the retarder plate is blocked by the polarizer. Thus, the projection screen frees a person on the second side of the transparent screen from any distraction caused by the image while still allowing the person to look out through the projection screen. BRIEF DESCRIPTION OF THE DRAWINGS

FIG. 1 illustrates a rear-projection transparent display system 100 in one embodiment of the invention. System 100 includes a projector 102 that generates an image “Q” toward a projection screen 104. Projector 102 can be a liquid crystal display (LCD) projector, a digital light processing (DLP) projector, a laser projector, or any other projection device. Depending on the application, image Q can be a still image, a slideshow of still images, or a video stream.

Projection screen 104 includes a polarizer 106, a retarder plate 108, and a transparent screen 110. Although shown spaced apart, polarizer 106, retarder plate 108, and transparent screen 110 may be directly mounted on each other. Image Q propagates from projector 102 through polarizer 106. After passing through polarizer 106, image Q only has polarized light. In one embodiment, polarizer 106 is a linear polarizer and image Q only has linearly polarized light aligned along a first direction 112. Polarizer 106 may polarize light by absorption, scattering, or refraction. In one embodiment, polarizer 106 is a glass panel with a linear polarizing film. Alternatively, polarizer 106 is made of a polarizing material.

Image Q then propagates through retarder plate 108 and strikes transparent screen 110. In one embodiment, retarder plate 108 is a quarter-wave plate. When image Q strikes transparent screen 110, it becomes visible on both sides of the screen. In one embodiment, transparent screen 110 is a transparent diffusion screen such as the HoloPro™ from G+B pronova GmbH of Germany, the Holo Screen from dnp Denmark of Denmark, or the TransScreen from Laser Magic of Los Angeles, Calif.

Any light that travels back from transparent screen 110 through retarder 108 becomes linearly polarized along a second direction orthogonal to the first direction and is therefore blocked by polarizer 106. Thus, image Q is visible from one side of projection screen 104 and invisible from the other side of projection screen 104.

In system 100, a small image Q may be visible on projection screen 104 to person 116. This occurs when projector 102 projects images with non-polarized light that is partly transmitted through polarizer 106 and partly reflected by polarizer 106. The small reflected image Q can be avoided by using an LCD projector 102 that produces images with light aligned along polarization direction 112. Alternatively, an additional polarizer 118 having polarization direction 112 can be placed before or on the lens of projector 102.

FIG. 2 illustrates a transparent display system 200 in one embodiment of the invention. Display system 200 includes a transparent display 202 and a polarizer 204. Although shown spaced apart, transparent display 202 and polarizer 204 may be mounted directly on each other.

Transparent display 202 has a transparent screen that generates an image “R” that is visible from both sides of the display. Image R consists of polarized light that propagates away from both sides of transparent display 202. Depending on the application, image R can be a still image, a slideshow of still images, or a video stream.

In one embodiment, transparent display 202 is a transparent organic light-emitting diode (OLED) display that emits linearly polarized light. FIG. 3 illustrates that OLED display 202 consists of an organic emissive layer 302 sandwiched between a transparent cathode 304 and a transparent anode 306 on a transparent substrate 308. An example of a transparent OLED display is the TOLEDO from Universal Display Corporation of Ewing, N.J. To emit linearly polarized light, an orientation layer 310 is formed on anode 306 and then emissive layer 302 is formed on orientation layer 310. An example of an organic OLED that emits polarized light is described in “Polarized Emission of PPV Oligomers” by Lauhof et al., 2005 Conference of German Liquid Crystal Society.

Referring back to FIG. 2, some of the linearly polarized light of image R propagates from transparent display 202 to polarizer 204, which blocks the linearly polarized light from traveling any further. Thus, image R is visible from one side of display system 200 and invisible from the other side of display system 200. Polarizer 204 may polarize light by absorption, scattering, and refraction. In one embodiment, polarizer 204 is a glass panel with a linear polarizing film. Alternatively, polarizer 204 is made of a polarizing material.

In one embodiment, a one-way vision film 210 is inserted between transparent display 202 and polarizer 204. One-way vision film 210 allows person 208 to look out through display system 200 but does not allow person 206 to look through display system 200 and into the building. In one embodiment, one-way vision film 210 is a perforated film having a light color (e.g., white) on the side facing transparent display 202 and a dark color (e.g., black) on the side facing polarizer 204.

FIG. 4 illustrates a transparent display system 400 in one embodiment of the invention. System 400 includes a screen 402 with an alternating pattern of nontransparent light-emitting pixels 404 and transparent non-emitting pixels 406. Thus, screen 402 appears at least semi-transparent as light can pass through transparent non-emitting pixels 406.

The pattern of nontransparent light-emitting pixels 404 and transparent non-emitting pixels 406 can be varied as long as they are evenly distributed so screen 402 appears semi-transparent. In one embodiment, the pattern consists of alternating lines of nontransparent light-emitting pixels 404 and transparent non-emitting pixels 406. Alternatively, as illustrated in FIG. 5, the pattern consists of nontransparent light-emitting pixels 404 interspersed with transparent non-emitting pixels 406.

In one embodiment, nontransparent light-emitting pixels 404 are OLED pixels with transparent cathodes and anodes, and opaque substrates. Transparent cathodes and anodes are necessary so these conductive lines can run across the transparent non-emitting pixels without obscuring their transparency. Opaque substrates are necessary so that the OLED pixels only transmit light on one side of screen 402. In one embodiment, transparent non-emitting pixels 406 are simply dummy OLED pixels with transparent substrate and devoid of an emissive layer.

a projector for projecting an image through the polarizer and the retarder plate onto the transparent screen, wherein the image is visible from a first side of the transparent screen and invisible from a second side of the transparent screen.

7. The system of claim 1, wherein the polarizer comprises a linear polarizing film, the retarder plate is a quarter-wave plate, and the transparent screen is a transparent diffusion screen.

8. The system of claim 1, wherein the projector is selected from the group consisting of a liquid crystal display (LCD) projector, a digital light processing (DLP) projector, a laser projector.

9. The system of claim 1, further comprising another polarizer between the projector and the projection screen, the another polarizer and the polarizer having the same polarizing direction.

10. A method for projecting an image on a transparent screen so the image is visible from a first side of the transparent screen but invisible from a second side of the transparent screen, the method comprising:

projecting the image through a polarizer and then a retarder plate onto the transparent screen, wherein any light traveling back from the transparent screen through the retarder plate a second time is blocked by the polarizer.

14. The method of claim 10, wherein the polarizer comprises a linear polarizing film, the retarder plate is a quarter-wave plate, and the transparent screen is a transparent diffusion screen.

15. The method of claim 10, wherein the projector is selected from the group consisting of a liquid crystal display (LCD) projector, a digital light processing (DLP) projector, a laser projector.

16. The method of claim 10, further comprising projecting the image through another polarizer before the polarizer, wherein the another polarizer and the polarizer have the same polarizing direction.

22. The system of claim 17, wherein the transparent display is a transparent organic light-emitting diode display and the polarizer comprises a polarizing film.

23. The system of claim 17, further comprising a one-way vision film between the transparent display and the polarizer, wherein the one-way vision film allows a person on the side of the polarizer to look through the display system but does not allow another person on the side of the transparent display to look through the display system.

24. The system of claim 23, wherein the one-way vision film comprises a perforated film comprising a light side facing the transparent display and a dark side facing the polarizer.

25. A method for displaying an image on a transparent display so the image is visible from a first side of the transparent display but invisible from a second side of the transparent display, the method comprising:

generating the image on the transparent display, wherein the image comprises polarized light propagating from the first and the second sides of the transparent display;

28. The method of claim 25, wherein the transparent display is a transparent organic light-emitting diode display and the polarizer comprises a polarizing film.

30. The method of claim 29, wherein the one-way vision film comprises a perforated film with a light side facing the transparent display and a dark side facing the polarizer.

34. The system of claim 31, wherein the nontransparent light-emitting pixels comprises organic light-emitting diodes with opaque substrates and transparent cathodes and anodes.

35. The system of claim 31, wherein the transparent non-emitting pixels comprises dummy organic light-emitting diodes with transparent substrates and devoid of an emissive layer.
