why a custom lcd display price

Looking to take your project to the next level in terms of functionality and appearance? A custom LCD display might be the thing that gets you there, at least compared to the dot-matrix or seven-segment displays that anyone and their uncle can buy from the usual sources for pennies. But how does one create such a thing, and what are the costs involved? As is so often the case these days, it’s simpler and cheaper than you think, and [Dave Jones] has a great primer on designing and specifying custom LCDs.

The video below is part of an ongoing series; a previous video covered the design process, turning the design into a spec, and choosing a manufacturer; another discussed the manufacturer’s design document approval and developing a test plan for the module. This one shows the testing plan in action on the insanely cheap modules – [Dave] was able to have a small run of five modules made up for only $138, which included $33 shipping. The display is for a custom power supply and has over 200 segments, including four numeric sections, a clock display, a bar graph, and custom icons for volts, amps, millijoules, and watt-hours. It’s a big piece of glass and the quality is remarkable for the price. It’s not perfect – [Dave] noted a group of segments on the same common lines that were a bit dimmer than the rest, but was able to work around it by tweaking the supply voltage a bit.

We’re amazed at how low the barrier to entry into custom electronics has become, and even if you don’t need a custom LCD, at these prices it’s tempting to order one just because you can. Of course, you can also build your own LCD display completely from scratch too.

Low-cost custom LCDs come in many shapes and sizes, offering basic or complicated functionality. Not everyone is looking for a super bright, 1,000 nit, color TFT LCD Module with the ability to display 64,000 color shades.

Although TFT displays look very sharp, many consumer products require a lower cost solution similar to what is offered by a segmented custom LCD Display. This older technology has been in use for many years and not only offers a low unit cost in the sub-dollar to ten dollar range, but an ultra-low tooling fee with a very conservative power budget.

There is a newer custom color TN technology available that offers the same power saving as a custom monochrome TN display. The addition of color does not require any additional power.

A custom LCD segmented monochrome display contains a twisted nematic (TN) fluid sandwiched between two layers of Indium Tin Oxide (ITO) glass. The fluid rotates one direction to block light and rotates back to its original position to allow light to pass through.

These custom LCDs have a monochrome, single color, background with the segments being a different color than the background. A segmented custom LCD, may contain seven (7) segment, fourteen (14) segment characters and custom icons.

There are two methods to drive a segmented custom display. The first method static drive, or direct drive, connects one pin to every segment. The second method is multiplex drive, which connects one pin to every four segments; the advantage to this is that fewer pins are required, thereby reducing the unit cost.

Segment Custom LCDs have been in use for many years, and show no signs of going away anytime soon. Custom segmented monochrome displays can be custom manufactured for a low one-time tooling fee. The unit cost is much lower than a TFT or Field Sequential Color Liquid Crystal Display (FSC).

Although custom segmented LCD modules have been in use for many years, they don’t look to go away anytime soon. One primary reason for this is that low power consumption is always in style. Custom segment displays are the second lowest power consuming display compared to Bi-stable, or Cholesteric displays.

Once it’s recognized that a custom display will be a better design and lead to a lower overall system-level cost it’s time to dive into the actual tooling costs.

There are many factors that go into determining the upfront tooling. There’s also due diligence to be performed prior to making this commitment to ensure that this new custom display supplier will effectively support you over the long term.

Customization can either be semi-custom or fully custom. Semi-custom is where some attributes of a standard product are modified to fit the application. In contrast, fully custom is where the design is started from scratch and each component is designed from the ground up.

Semi-custom is typically the preferred option to start with. And in the case of color TFT, it’s typically the only option, as the TFT panel comes with a significant tooling and minimum order quantity (MOQ) such that the customization costs outweigh the drawbacks of using the closest standard TFT glass platform available.

b) Custom color TFT displays— the bulk of this cost comes from the TFT glass cell at $70K–$200K depending on the type of TFT cell used (standard TN or IPS). The balance of the module is an additional $5,000 – $15,000.

f) Touch panels— resistive touch panels cost approximately $2,500, while capacitive touch panels can range between $4,000 and $10,000. If a standard capacitive touch sensor can be used, and only a custom top surface is customized, the tooling can be reduced to only $1,500.

g) Backlights— monochrome display backlights are less complex and cheaper to tool at $2,000 – $4,000. The color counterpart, due to its high brightness requirement, will run between $4,000 and $10,000.

i) Overlays— this can vary significantly depending on the complexity of the screen printing, as well as any additional features, such as button or LED indicators. The overlay will typically range from $1,500 - $4,500.

Now that we’ve reviewed some of the costs associated with custom displays, here are some tips you can use to make sure that you move forward with the right partner that will then support this custom display for the long term.

Many LCD display manufacturers try to accommodate all order volumes they receive. While this allows them to serve a wider range of customers, it makes them less specialized for serving certain types of customers. As a result, your specific production volumes may be prohibitively expensive.

Seek out a display manufacturer who is optimized to handle your specific production needs for LCD displays. This is necessary to get the display for the right cost and the appropriate level of support.

Always start with a semi-custom approach. Use the available standard products to base the new design on, and then keep modifying as needed. This results in the lowest tooling costs and an easier design process. And in the case of color TFT, unless you are developing the next iPhone, design your display based on one of the standard glass platforms readily available. Then from there, redesign the backlight and the mechanical and electrical interface for your specific application.

Behind every great company are happy customers. Find out whether your supplier has them. Make sure that when this experience is handed off from your supplier’s sales and design team, the production team is just as good and accommodating. This can be accomplished through references and audits.

Initiating a successful relationship for a new custom display is all about having an open and transparent relationship with the right partner. And by designing the ideal custom or semi-custom display with this partner, you can ensure you’re getting the best possible solution for your company.

There are three types of LCD Displays: Tint, MNF, glass 727 display, 16NF and 16NF. All types of color LCD Displays. Another type is a digital LCD display (T LCD) , which in a liquid crystal display (LCD) display, TL, TL, and 7LF display all types are available and a single color LCD display. This type is a digital L LCD display and it can be used in other formats like IPS, TN, and VLA. There are also three types of primary color LCD display. This type is a digital LCD display because it can be used in IPS, IPS, TN, and TN; as well, a types of liquid crystal display (LCD) display, which in a form of frame and glass 27 27 display display where they are used in IPS, TN, and TN.. type are a digital color LCD display technology.

You can use an LCD LCD sign for small companies. Ideally, you will need to have large electronic lcd signs signage for businesses, retail stores, and restaurants. They can also use custom projection display LCDs as a signage for businesses in retail stores, restaurants, bakeries, and many other areas.

Liquid Crystal Displays or more commonly known as LCDs are one of the most common electronic components which help us interact with an equipment or a device. Most personal portable equipment and even gigantic industrial equipment utilize a custom segment display to display data. For many portable consumer electronics, a segment LCD display is one of the biggest contributors to the overall cost of the device, hence designing a custom segment display can drive the cost down while also utilizing the display area in the most optimum manner. These displays have the lowest cost per piece, low power requirements, and a low tooling fee too.

At first thought, designing a custom segment LCD might look like a Herculean task, but trust me that it is easier than it seems. In this article, we have summarised and compared the display types and available technologies which are required to construct a custom segment LCD. We have also provided a flowchart that can act as a step-by-step guide while you design your own custom LCD. We have also provided the process we followed, a require gathering sheet we used for communicating our needs to the manufacturer, and a few other data and the quotation we received from the manufacturer.

Icons: A silhouette of any shape can be placed on the glass which enhances the ability to display data. For example, a symbol of a heart can be made to denote heart rate or an icon for a low battery to show that the battery needs to be charged. Icons are counted as a single pixel or segment and can give a lot more details than similar-sized text.

LCD Bias– It denotes the number of different voltage levels used in driving the segments, static drives (explained later in this article) only have 2 voltage levels or 2 bias voltage while multiplex drives have multiple voltage levels. For example, 1/3 will have 4 bias voltages.

LCDs utilizes the light modulating properties of liquid crystals which can be observed by using polarizing filters. Polarizing filters are special materials that have their molecules aligned in the same direction. If the light waves passing through polarisers have the same orientation as the filter, then the molecules of lights are absorbed by the filter, hence reducing the intensity of light passing through it, making it visible.

In Layman’s language, when an electric current is applied to the electrodes, i.e. to the segment line and common line, it twists the Liquid Crystals w.r.t to the polarizing filter, obstructing the light in that particular area as shown in the figure below. Hence, that area becomes darker and prominent.

A custom LCD is important for maximizing the efficiency of the display area by adding custom symbols and characters. It also helps in reducing the cost and improving energy efficiency of the product. A higher number of custom symbols and specified placement of numerical and alphanumerical characters make the display more informative and readable for the user. This makes it look better than the plain old boring displays we get in the market. Furthermore, we can specify the viewing angle, contrast, and other specifications which can increase durability or give a better value for money for our intended usage.  A typical Custom Segment display is shown below, we will also show you how to design and fabricate the same further in the article.

The LCD display doesn’t emit any light of its own, therefore it requires an external source of illumination or reflector to be readable in dark environments.

While designing a custom segment LCD display, we have the leverage of choosing a lot of parameters that affect the final product. From the color of the display to the illumination technique and color of illumination as well as the type of input pins. Some important considerations we need to take while designing a custom 7 segment display are - the type of display, i.e. positive or negative, illumination method, driving technique, polarising type, and connection method. All these design criteria are explained below:

Positive and negative displays can be easily distinguished by the colour of the background and characters. Some common differences between the positive and negative displays are:

So, which one should you choose? When the displays are to be used in areas with higher ambient light, we should select positive segment LCD display as it has better visibility than negative segment LCD displays without using a backlight.

As we know that LED displays don’t emit any light, hence to illuminate it and make it visible in a dark environment, we can use different methods of illumination. The most common LCD Illumination methods are compared below:

For displays that need to be used for budget-friendly devices that should be small and rugged, LED lights are preferred for the displays due to the high durability and low cost of operations. For high brightness, CCFL and Incandescent lights can be used.

A polarizer film is the most important component of an LCD display, which makes it possible to display characters by controlling the light. There are 3 types of polarizers that can be used in the LCD display, the properties and difference are given below:

If your products need to be used with a switchable backlight, then trans-reflective reflectors are best to be used for front reflectors. If the device has to be used without backlight, then we can select a reflective polarizer for the back-panel as it gives the best contrast ratio.

Displays can be categorized into two types, passive displays, and active display, passive displays are simpler to construct as they have 2 connections at each segment, the conductors comprise of an Indium Tin Oxide to create an image, whereas the active displays use thin-film transistors (TFT) arranged in a grid. The name is due to its ability to control each pixel individually.

If your displays have fewer segments, then static LCD drive is preferred as it is easier to control and cheaper to construct, and has a better contrast ratio. But let’s say that if the number of segments in the display are more than 30-40 then a multiplex LCD drive should be preferred as it has multiple common pins, hence reducing the total number of pins required to drive the display.

Choosing a connector type!!! For the prototyping phase or if you need to connect your LCD display on a Microcontroller directly, a pin type connector is the best and most economical option you have. If you need to connect your LCD display in a final product with a high volume of production which also requires to be extremely durable, but at the same time should not take up a lot of space, a Flex type LCD Connector will work best for you

LCDs have limited viewing angles and when seen from an angle they lose contrast and are difficult to be observed.  The viewing angle is defined by the angles perpendicular to the center of the display towards its right, left, up, and down which are denoted by the notations 3:00, 9:00, 12:00, and 6:00 respectively. The viewing angle of LCD can be defined as the angle w.r.t. to the bias angle at which the contrast of segments is legible.

To improve the viewing angle in an LCD, a Bias is incorporated in the design which shifts the nominal viewing angle with an offset. Another technique is to increase the Voltage, it affects the bias angle, making the display crisper when viewed from a direction.

For example, the viewing angle of a TN type TFT LCD is 45-65 degrees. Extra-wide polarising film (EWP) can increase the viewing angle by 10 degrees, using an O film polariser can make the viewing angles 75 degrees but these come at a cost of reduced contrast.

Anti-glare filters are bonded with the top polarising filters using adhesive. It improves the viewability by re-directing light waves so they don’t reflect back towards the viewer thus reducing glare. Newer materials are capable of reducing the front glare by up to less than 0.3%.

LCD Control chip or LCD driver chips can be mounted on the flex cable, display, or externally on a PCB. The placement of LCD control chip can affect the cost and size of the display. The 2 most common methods of chip placement are-Chip of Board (COB)and Chip on Glass(COG) which are described below:

COG can be used as it is cheaper and makes the assembly process simpler, but if the dimensions are a constraint, then the COB is also a viable option.

We planned to design an air quality monitoring system for which we needed a custom segment LCD panel for an air quality monitoring device. Our product needs to display the following data: 2.5-micron and 10-micron particulate matter (PM) suspended in the air; the units should be in parts per million (PPM). CO2 in the air in PPM along with total volatile organic compounds present in the air in parts per billion (PPB). To make the product more usable, we included time in 24-hour format, Temperature in ºC, Battery status, loudspeaker status, Bluetooth status, and Wi-Fi status. And for some personal touch, we also added how good the air quality in the room is by using 3 different smileys.

We realized that it was impossible to provide all these data in a generic LCD available in the market, thus decided to build a custom LCD for our project.

A step-by-step flowchart is shown below to walk you through each and every step of selecting components and getting your custom segment LCD manufactured.

We started by listing down our requirements and drew a mock-up of the display on paper. After finalizing the placement of all the segments and icons on the prototype sketch of the display, we then decided which all icons and segments have to be kept on for the whole time and which needs to be driven. Realizing that there are too many segments, characters and icons, hence we selected a multiplex drive with 8 common pins which helped us bring down the total pins from an estimated 180 pins to less than 40 pins.

Since the device was meant to be used inside houses and offices, which are more often than not well lit and protected from environmental conditions, we opted for a positive mode display. For superior contrast ratio and better viewing angle, we chose a Film Super Twisted Nematic Display (FSTN) with a drive condition of 1/8 Duty and bias of 1/4.

Usually, the displays are mounted at a height of 4.5 feet from the ground, thus the viewing direction was selected to be 12"O clock with an operating frequency of 64Hz. We selected a Transmissive polarizer for the front glass and a reflective polarizer for the rear glass so that the natural light can pass through the front panel and the display can achieve the maximum contrast without the need for backlighting and we opted for the pin type connectors as they are easy for prototyping and are suitable for harsh environment with a lot of vibrations and shocks which best suited our purpose.

In the above image of a custom display design, we sent to the manufacturer, the red lines over multiple characters indicate that all these are considered as a single segment. For the sake of simplicity, we added test like T, S, U, B to denote Text, Symbols, Units, and Battery respectively. These characters were followed by numbers to simplify communication between us and the manufacturer. For example, if we needed any particular text or symbol to remain on, we can easily specify that to the manufacturer by using the corresponding text for that segment.

We mailed our requirements to multiple LCD manufacturers, (you will find a lot of LCD manufacturers on the Internet). Most LCD manufacturers have competitive pricing, and reply within a week. A sample requirement sheet is shown above which a customer needs to fill to specify all the details to the manufacturer.

This is a sample Custom Segment LCD quotation we got from one of the manufacturers. As you can see, the cost is based on the quantity. Higher the quantity, lower the cost. Apart from the cost per quantity, there is one more component called tooling fees. Tooling fee is a one-time fee charged by the manufacturer. It is for the technical design, support, and customization of the product. Customization of PCB or tooling of LCD can drive the tooling price higher or lower.

The tooling time and cost depend on how detailed and accurate designs you sent to the manufacturer. They then send the exact dimensions and technical details of the product they will be manufacturing. Once you confirm the design, they manufacture and ship the product which might take 4-8 weeks to arrive depending on the size of the order and mode of transportation selected.

A custom segment LCD can help you personalize your product while also saving the overall cost of your product. The whole process will take you around 2-3 months, which will include the designing phase, prototyping phase, and getting your custom segment LCDs delivered to your doorstep. Higher ordering quantity will reduce the cost per piece of each unit, thus driving down the cost of your final product.

New Vision Display is a custom LCD display manufacturer serving OEMs across diverse markets. One of the things that sets us apart from other LCD screen manufacturers is the diversity of products and customizations we offer. Our LCD portfolio ranges from low-cost monochrome LCDs to high-resolution, high-brightness color TFT LCDs – and pretty much everything in between. We also have extensive experience integrating LCD screen displays into complete assemblies with touch and cover lens.

Sunlight readable, ultra-low power, bistable (“paper-like”) LCDs. Automotive grade, wide operating/storage temperatures, and wide viewing angles. Low tooling costs.

Among the many advantages of working with NVD as your LCD screen manufacturer is the extensive technical expertise of our engineering team. From concept to product, our sales and technical staff provide expert recommendations and attentive support to ensure the right solution for your project.

In addition, our extensive technology portfolio and manufacturing capabilities enable us to deliver high-quality products that meet the unique specifications of any application. To learn more about what makes us the display manufacturer for your needs, get in touch with us today.

As a leading LCD panel manufacturer, NVD manufactures custom LCD display solutions for a variety of end-user applications: Medical devices, industrial equipment, household appliances, consumer electronics, and many others. Our state-of-the-art LCD factories are equipped to build custom LCDs for optimal performance in even the most challenging environments. Whether your product will be used in the great outdoors or a hospital operating room, we can build the right custom LCD solution for your needs. Learn more about the markets we serve below.

Ready to get started or learn more about how we can help your business? Call us at +1-855-848-1332 or fill out the form below and a company representative will be in touch within 1 business day.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

To resize a LCD is literally to cut the glass, polarizers, circuits and circuit boards to a new size. Years ago, it was thought impossible to preserve the original performance of a previously manufactured LCD once the glass circuits are cut. However, Litemax has done the impossible, over and over again, becoming the world"s leading pioneer and leader in LCD resizing solutions.

Squarepixel series is designed for high brightness with power efficiency LED backlight. It provides LCD panel with specific aspect ratios and sunlight readable for digital signage, public transportation, exhibition hall, department store, and the vending machines.

The spirit of Durapixel indeed lies with its name: durability. Why Durapixel? Commercial-grade LCD displays, due to the competitive pricing structure, are unable to offer more than MTBF of 30,000 hours, which will not be sufficient for any applications that require around-the-clock operations. System designers, integrators and users serious about rugged, industrial displays for demanding environments need to look no further – the unfailingly robust and high-quality Durapixel is the key to each of your success.

UbiPixel, industrial LCDs are used in many professional applications. High bright sunlight readable and low power consumption display technologies offer the highest quality LCDs for specific industrial applications. Our embedded LCD can be manufactured in an open frame, VESA mount, or fully enclosed housing for HMI display, KIOSK, Vending machine, home automation, point-of-sale terminals, digital signage and more. UbiPixel, industrial LCDs are used in many professional applications. High bright sunlight readable and low power consumption display technologies offer the highest quality LCD screen for specific industrial applications. Our embedded LCD can be manufactured in an open frame, VESA mount or fully enclosed housing for HMI display, KIOSK, Vending machine, home automation, point-of-sale terminals, digital signage and more.

Marine displays from Litemax are internationally recognized and certified with a proven track record of satisfying all types of scenarios, applications and environments for maritime professionals and organizations. Whether the project involves system building, maintenance, repair or equipment upgrade of a yacht, a submarine or any relevant maritime structure, Litemax"s marine displays guarantee high quality and performance from the dock to the engine room.

Litemax"s 2.5” Pico-ITX boards feature fanless operation, low power, compact designed for space-limited embedded applications. With built-in AMIO expansion interface to develop high flexibility and scalable capabilities.

Litemax"s 3.5" SBCs feature rich I/O ports, wide-temperature support, and wide input voltage range and low-power to robust high -performance computing modules designed for outdoor applications or harsh environmental requirements.

Litemax"s Mini-ITX embedded board provides the performance, expansibility, and durability to meet needs across a wide variety of applications, such as industrial control, industrial IOT, gaming, smart healthcare, and digital signage.

This high performance series supports Intel, AMD, Nvidia processor with multi I/O expansions, mini PCIe/M.2 expansion cards, and wide temperature range, being ideal for automation system, machine automation, factory automation, and IoT platforms.

Featuring a modular designed, this series can be fitted with a number of modules to expand its base capabilities. On-site maintenance and future upgradability are easier than ever by deploying our panel PCs and monitors.

Litemax rugged panel PCs go beyond that of the standard industrial panel computes with elegant, full IP68/65-rated construction, powerful performance and flexible mounting options making it ideal for harsh environments and demanding applications, such as machine controller, command centers, and fast, efficient computing.

The Litemax ITRP series is fanless Passenger Information System, It features stretched LCD display, with high brightness to ensure easy readability even in light-insufficient environments. It serves as a reliable platform to provide passenger information on wide versatility of vehicles, such as bus and trams.

Litemax develops an embedded artificial intelligence application platform for AI edge computing to meet client vertical market applications and various needs and solve the changing challenges of the operating environment. In response to the increasing demand for AI computing, computer vision, deep learning, edge computing, etc., Litemax offers a series of fanless BOX PC with Intel Edge Computing and NVIDIA® Jetson Nano™ to effectively improve the cooling performance of fanless systems. Field applications can smoothly provide powerful computing performance, support high-level AI computing chips, and provide a solution platform for a variety of application scenarios to integrate software and hardware to create more flexible and better vertical functions. Simplify the manpower required for the client to invest in AI system integration.

Intel® offers the Intel® Smart Display Module (Intel® SDM) specification and reference design that can be integrated into the sleekest all-in-one designs. Intel® SDM delivers the same level of intelligence and interoperability as the Open Pluggable Specification, but in our smallest form factor yet eliminates the housing and advances the thinnest integrated displays.

The new Intel® Smart Kiosk Module (Intel® SKM) is a revolutionary solution that makes it easier to scale and maintain interactive kiosks, which are increasingly being used by businesses and governments worldwide to offer customers around-the-clock access to information and services.As the market for interactive kiosks increases, so does the demand for smarter multi-function kiosks with advanced capabilities such as workload consolidation, artificial intelligence, smartphone and social media integration, 5G connectivity, telepresence, remote manageability, and data analytics.

LITEMAX AD Board is with high speed Analog/ Digital conversion and minimal programming. A wide variety of computer interfaces are available in your choice.

LITEMAX power board provides maximum output from 60W to 100W, it is an intelligent vehicle power converter with wide input voltage range from 9V to 16V DC.

Through intelligent thermal management technologies, Litemax is enabling smarter platforms for various vertical markets deploying display systems. Through the intelligent thermal control board, Litemax helps system integrators and engineers around the world improve efficiency and reliability.

We encourage you to provide us with as much information as possible. It will help our engineers and design team to have a better understanding of your needs and requirements, and ensure quality and efficient customer service. If you are unsure about any of the above information, please feel free to contact us.

Orient Display LCD displays are the general category that includes LCD display glass panels, character LCD modules, graphic lcd modules, Arduino LCD displays, and our featured JAZZ series graphic LCD displays.

Graphic LCD Displays: Our standard LCD Graphic display products range from 122 x 32 pixels to 320 x 240-pixel resolution. These displays are available in positive or negative STN, blue STN, FSTN, or FFSTN with multiple backlight color options. They can be either traditional Chip-On-Board (COB) LCDs or Chip-On-Glass (COG) LCDs for displays with a smaller footprint and lower power consumption. COGs come in the same display types and colors as our other LCD modules but are designed without a PCB to allow for a slimmer profile.

JAZZ Graphic LCD Displays: The series are exclusive for Orient Display 128 x 64 pixels with the selection of yellow green STN, blue STN, positive or negative FSTN display, with the options of yellow green, green amber, blue, red or RGB tricolor backlights, with or without resistive touch panels. JAZZ series have two sizes: 1.0” and 2.7”.

VTN Character LCD Displays: Orient Display VTN is vertical alignment LCDs which provide superior black background and then great contrast with the options of yellow green, green amber, blue, red or RGB tricolor backlights.

LCD Glass Screens (Panels): Orient Display LCD display panels include different options of polarizer in reflective (saving power), transmissive (better contrast) or transflective (sunlight readable and battery powered) types. Orient LCD glass panels include 1; 2; 2.1/2; 3; 3.1/2; 3.3/4; 4; 4.1/2; 5; 6; 8; and 24 digits. Orient LCD glass panels also include 7 , 14 or 16 segments to display digits and alphanumeric letters. The temperature ranges are from room temperature to wide temperature applications. Orient LCD glass panels can have metal pin or zebra connections.

ARDUINO LCD Displays: Orient Display creates special character LCD displays with SPI interface which is easily hooked up with Arduino, which has been widely acceptable in the electronic design. The series includes 8 x 2 characters, 16 x 2 characters, 20 x 2 characters and 20 x 4 characters with either yellow green STN with yellow green LED backlight or blue STN with white LED backlight.

Although Orient Display provides many standard small size OLED, TN or IPS Arduino TFT displays, custom made solutions are provided with larger size displays or even with capacitive touch panel.

If you have any questions about Orient Display TFT LCD displays or if you can’t find a suitable product on our website. Please feel free to contact our engineers for details.

Many Size Options – Flexible design requirements allow for a wide range of size options for custom glass LCD. Designs can be as small as 1.5″ and as large as 10″.

Very Fast Tooling Process – Concept to Production as fast as 12 weeks – Tooled samples delivered in as little as 4 weeks. Once customer provides drawing to sales@azdisplays.com , we can have a proposed design within in 1-2 days.Proposal Design

If you don’t have a drawing already, you can download the Design Sheet and return to sales@azdisplays.com or contact an engineer for technical support at 949.360.5830

IDISPLAYS is specialised in designing the customised LCD displays as per the customer requirement, has supported customers with Custom LCD display for medical and test equipment to industrial applications. Whether your design need is a small LCD Glass display, or a fully customized LCD Module, our experienced technical customer support can assist you in designing your custom LCD display.

The process begins with you providing your dimensions and segment content. We will then advise on the most cost-effective overall size and design. Our team will work with you to design the optimum custom LCD displays for your projects. Design considerations for your customized LCD display will include the type of interface, backlight options, space constraints, touch panel options..

Why settle for an off-the-shelf LCD monitor that’s almost “good enough”? Let TRU-Vu provide a custom LCD monitor, modified LCD display, or design a custom OEM monitor to meet your needs. Above all, we can customize nearly aspect of your display, from the inputs and electronics, to screen treatments and enclosures. Custom options for embedding your own devices inside our enclosures and even private labeling it with your own name/logo and corporate identity are available.

Certainly, your customized LCD display will receive a unique model number, to identify it as your exclusive custom LCD monitor. Most importantly, no one else can order this model. If they try,  they will be referred back to you. Our OEM customers love this! For example, this protects your intellectual property, and ensures your return on investment.

Lastly, we will guarantee long-term availability of your custom OEM monitor design. Subsequently, we can ensure your custom LCD monitor is available for 3 – 5 (or many more) years. On the other hand, retail,  consumer-grade or commercial-grade monitors  typically have a 3 to 12 month life cycle.

Contrary to popular belief, custom LCD monitors do not need to be expensive. At least not the custom screens from TRU-Vu. We modify, customize or custom-build monitors and touch screens that are usually in the same price range as off-the-shelf monitors. Give us a call and learn for yourself how affordable a custom solution can be. Unlike our competitors, we can build these for very low minimum order quantities. So why settle for off-the-shelf?

Optical Bonding: Ideal for use in bright, indirect light. A optical-grade resin is injected into the space between the LCD panel and the outer glass, filling the gap. This eliminates internal reflections and condensation. Similarly, it also increases contrast ratio, and thereby improves image quality.

We can embed some of your own devices inside your custom lcd monitors and touch screens. Subsequently, we then also provide you with external connections to other products or systems.

TRU-Vu monitors can be configured to accept a wide range of video input signals. For instance, the letter at the end of each monitor model number designates the video input board:

To sum up, our standard, modified and custom LCD displays and touch screens can be private-labeled to your specifications. Likewise, this includes your silk-screened logo/company name, custom enclosure colors and your own unique model number. See our Private Label Monitors page for more information.

For over 20 years we"ve been helping clients worldwide by designing, developing, & manufacturing custom LCD displays, screens, and panels across all industries.

Newhaven Display has extensive experience manufacturing a wide array of digital display products, including TFT, IPS, character displays, graphic displays, LCD modules, COG displays, and LCD panels. Along with these products, we specialize in creating high-quality and affordable custom LCD solutions. While our focus is on high-quality LCD products, we also have a variety of graphic and character OLED displays we manufacture.

As a longtime leader in LCD manufacturing, producing top-quality LCD modules and panels is our highest priority. At Newhaven Display, we’re also incredibly proud to uphold our reputation as a trusted and friendly custom LCD manufacturing company.

As a custom LCD manufacturing company, we ensure complete control of our custom displays" reliability by providing the industry"s highest quality standards. Our design, development, production, and quality engineers work closely to help our clients bring their products to life with a fully custom display solution.

Our excellent in-house support sets Newhaven Display apart from other display manufacturers. Modifications in the customization process are completed at our Illinois facility, allowing us to provide an exceptionally fast turnaround time.

Customer support requests sent by phone, email, or on our support forum will typically receive a response within 24 hours. For custom LCD project inquiries, our response time can take a few days or weeks, depending on the complexity of your display customization requirements. With different production facilities and a robust supply chain, we are able to deliver thefastest turnaround times for display customizations.

We work hard to ensure that personalized support is available and highly reliable. Our extended support center is available through our website, including example codes, IC datasheets, font tables, engineering changes, a video library, and answers to frequently asked questions. You can visit our knowledge center and community forum, where you can find answers, browse topics, and talk to other engineers in the display and electronics field.

Our excellent in-house support and custom display modifications set Newhaven Display apart from other LCD display manufacturers. From TFTs, IPS, sunlight readable displays, HDMI modules, EVE2 modules, to COG, character, and graphic LCDs, our modifications in the customization process are completed at our Illinois facility, allowing us to provide quality and fast turnaround times.

As a display manufacturer, distributor, and wholesaler, we are able to deliver the best quality displays at the best prices. Design, manufacturing, and product assembly are completed at our headquarters in Elgin, Illinois. Newhaven Display International ensures the best quality LCD products in the industry in this newly expanded facility with a renovated production and manufacturing space.

With assembly facilities in the US, manufacturing facilities in China, and distribution channels worldwide, we pride ourselves on delivering high-quality custom display solutions quickly to locations worldwide.
