12.1-inch LCD with touch screen, frame bonding, 1024×768

Size: 12.1 inches

Bonding Type: Frame Bonding

Module: Original

Application: Industrial Control

Model: EV121X0M‑N10 + STC‑12186

Resolution: 1024×768

Outline Dimensions (mm): 260.5×204×8.7

LCM AA Area (mm): 245.76×184.32

Brightness: 500 cd/㎡

Interface: LVDS 20PIN + IIC/USB/RS232

Casing: Metal Frame

Viewing Angle: IPS

Operating Temperature: -20°C~+70°C

Storage Temperature: -30°C~+80°C
