Abstract:A build-in power supply circuits IP core for TFT-LCD driver IC is designed using 0.25μm CMOS LV/MV/HV hybrid voltage process.It is composed by four sub-blocks such as LDO regulators,capacitor-switched charge-pump circuits,VCOM and Vgoff driving buffer circuits.Both power supply voltages for TFT-LCD driver IC and driving voltages for TFT-LCD panel can be provided by this IP core.The temperature coefficients of voltages generated by LDO regulators are less than 13.7ppm/℃.A new topology of charge pump which generates the highest voltage VGH and the lowest voltage VGL is proposed,and the settling time of VGH and VGL is reduced to less than 100ms.The voltages generated by VCOM and Vgoff driving buffer circuits can be adjusted by programmable register.All generated voltages are with their stable values in 200ms when power is on.The static power dissipation of this IP core is less than 2mW.

The XC9516 series can offer three different power supplies to TFT-LCD panels. These power supplies consist of a step-up DC/DC converter for a source driver, positive and negative charge pumps for a gate driver.

This IC has power-on sequences to keep inrush current as small when output voltage rises. The step-up DC/DC output can be used as power-on sequences with adding a P-channel FET as external component. Also, the FET can shut down a path to the power input line when CE pin is low.

An IC for which any output voltage can be set by the reference voltage of the FB pins and the external dividing resistor. The output voltage is determined by the RFB1 and RFB2 values, using the following formula: VOUT = Vref × (RFB1 + RFB2)/RFB2

This circuit forcibly turns off the driver transistor when VIN drops below the UVLO voltage. If the input voltage recovers to the value which is equal to the specified value or more, UVLO will be released to resume the switching operation. It is resumed by the soft-start function. The paused state by UVLO is not the shutdown. The pulse output is stopped, but the internal circuit is operating.

The programmable Linear DC Power Supply SPD1168X has a 2.8 inch TFT-LCD display, features remote computer control capability, ity and real time wave display, to deliver high performance and ease-of-use. The SPD1168X features a high precision programmable output capable of delivering up to 16 V and also includes a 4-wire sense function for more accurate voltage sourcing, especially for long leads or high resistance connections. There are additional output short and overload protect functions to assist in production and development applications.

You will find the specifications of the SPD1168X series here. Quick comparision SPD1168X SPD3303C SPD3303X-E SPD3303X Voltage / Current CH1 0 - +16 V / 0 - 8 A 0 - +32 V / 0 - 3.2 A 0 - +32 V / 0 - 3.2 A 0 - +32 V / 0 - 3.2 A

Transform your design into an innovative product with our electronics manufacturing services. Scale your product with the help of a reliable manufacturing partner.

Since the reference voltages are connected to all channels, many DACs may use the same reference voltage. The more DACs there are connected to a single reference voltage, the larger the required C-DAC settling time. This study simulates the settling time for different numbers of connected DACs using a 0.35-μm 5-V CMOS model. Figure 11 shows the simulated results where the settling time is measured at 99.9% of its final voltage for a full swing (0.266 V ~ 4.75 V). The settling time is 5.2 μs when 200 DACs are connected to a single reference voltage. Although a column driver IC contains several hundreds or even up to a thousand DACs, these DACs are distributed to 256 (28) reference voltages. This means that not all the DACs are connected to a single reference voltage. A typical UXGA (1600×1200) display has a pixel clock frequency of 162 MHz and a horizontal scanning time of 9.877 μs [4]. Hence, the proposed column driver is suitable for UXGA displays.

Due to the limited silicon area, the proposed LCD column driver has only four channels. The 10-bit LCD column driver with R-DAC and C-DAC was fabricated using a 0.35-μm 5-V CMOS technology. Table I shows the device sizes used in the proposed column driver, where Rtop, Rmid, Rbot, and Ri are designated in Figure 7. Figure 12 is a photograph of the die. Except for the resistor string of the R-DAC, the die area is 0.2×1.26 mm2 for four channels. Each RGB digital input code is 10-bits wide.

The Differential Nonlinearity (DNL) and Integral Nonlinearity (INL) are typically measured for a DAC. However, it is difficult to determine these two specifications for a nonlinear DAC. To demonstrate the performance of the proposed circuit, the nonlinear gamma voltages are not applied to the R-string and the resistor values of the resistor string are made equal. Since an LCD panel needs several column drivers, the uniformity of different drivers is very important. Figure 13 shows the measured transfer curves of a DAC for eight off-chip column drivers. To show the deviation between different chips, Figure 14 provides an

enlarged view of the transfer curves, where the maximum deviation is 3.5 mV from the mean. This deviation is mainly due to process variations. The approach in this study uses no error correction. Hence, the deviation can be reduced by applying an offset canceling technique to the buffer amplifier. Figures 15(a) and (b) show the DNL values for positive and negative polarities, respectively. Figures 16(a) and (b) show the INL values for positive and negative polarities, respectively. The combination of R-DACs and C-DACs creates two groups of DNL values. The maximum DNL and INL values are 3.83 and 3.84 LSB, respectively. This study uses a 1-LSB voltage of 2.44mV to calculate the INL and DNL values. The linearity, however, is less important than the deviations between off-chip drivers for LCD drivers [2].

Figure 17 shows the measured output waveforms of two neighboring channels under dot inversion for the RGB digital inputs of ‘1111111111.’ Here, the voltage levels for negative and positive polarities are 0.266 V and 4.75 V, respectively. A load resistor of 5 kΩ and a capacitor of 90 pF were used. Figure 18 shows a similar waveform for ‘0000000000’ inputs, where the corresponding voltage levels for negative and positive polarities are 2.425 V and 2.598 V, respectively. These two figures show that the settling time is within 3 μs, which is smaller than that of previously published work [2] and standard UXGA displays [5]. Table II summarizes the performance of the proposed column driver IC. The average area per channel is 0.063 mm2, which is smaller than the reported areas of fully R-DAC-based column drivers [5, 8]. These experimental results show that the proposed column driver is suitable for UXGA LCD-TV applications.
