wxga tft display resolution supplier

This 14-inch LCD display is a ALL o’clock TFT LCD (Thin Film Transistor Liquid Crystal Display) module. This model is Composed of a TFT LCD panel, a driving circuit and a back-light, with a 14.1 inch diagonally measured active display area with WXVGA (1920horizontal by 1080 vertical pixel) resolution in a stripe arrangement. Display 16.7M colors by 6-bit R.G.B signal input. This TFT display is a landscape type 14” TFT LCD panel with 16:9 aspect ratio and with outline dimension 320.39x205.12x2.50mm and active area 309.312(H)x173.988(V)mm, it can be operated at temperature from 0 to 45 degree, stored at temperature from - 20 to 60 degree with typical 30,000 hours LED life time, mainly used for Laptop and TFT LCD Monitor applications.

A 10.1” TFT display module, featuring WUXGA (1920x1200px) resolution, has been introduced by KOE. The TX26D202VM0BAA has a pixel pitch of 0.11325x0.11325, which equates to a pixel density of 224ppi.

The 16:10 aspect ratio display features IPS technology and a 16.7m colour palette, which enables highly accurate representation of image detail such as colour gradients and authentic colour reproduction. Outstanding optical performance is maintained with a contrast ratio of 800:1 and a brightness specification of 800cd/m², enabling bright, sharp display images.

The compact 10.1” display has mechanical outline dimensions of 232.0x153.0x4.7mm and an active display area of 217.44x135.9mm. A 50-pin, 2-channel LVDS interface supports 8-bit RGB, which enables a colour palette of up to 16.7m colours. The LED backlight is specified at 40,000 hours to half brightness lifetime and features an integrated dimming function. The operating temperature range of the TX26D202VM0BAA module is -30 to +80°C.

Typical applications for the WUXGA display include diagnostic systems, compact broadcast and video monitors, medical imaging, and test and measurement instrumentation. The TX126D202VM0BAA TFT display module is available now.

Mark Stephenson, Technical Marketing Manager, KOE Europe, said "KOE are one of the first LCD manufacturers to introduce compact, high resolution display modules developed specifically for industrial and professional applications. This reflects the trend for higher pixel density and enhanced image clarity found in consumer devices such as monitors, tablets and smartphones. The use of higher resolution displays with greater pixel density enables accurate reproduction and representation of graphical information such as measurement and diagnostic images, and video reproduction."

A new high resolution, 8.0" Lite+ TFT display has been introduced by industrial LCD manufacturer, KOE. The TX20D201VM2BAB features WXGA resolution (1280x768px) with a 16:9 wide aspect ratio. The 8.0" display has a pixel pitch of 0.13575x0.13575mm, which equates to a pixel density of 187ppi (pixels per inch). The new TX20D201VM2BAB display module is mechanically compatible with existing KOE 8.0" WVGA (800x480px) TX20D33VM2BAA, TX20D34VM2BAA, and TX20D34VM2BAB display modules.

The high resolution WXGA (1280x768px) TFT display provides a significantly higher pixel density - an increase of 60% - when compared with industry standard 8.0" WVGA displays with 117ppi.

The display brightness is specified at 900cd/m², and combined with a contrast ratio of 500:1, the Lite+ display produces images that are bright, clear and concise. The white LED backlight, features a 50,000 hours to half brightness lifetime specification.

Jason Tsai, Marketing Manager, KOE, said: "Many infotainment and user interface applications are demanding higher resolution displays to enable accurate reproduction of images and video to be presented. The new 8.0" WXGA display allows KOE to embrace the increasing market demand for high performance, high resolution displays."

A 20 pin LVDS interface supports 6 or 8-bit RGB colour data which enables a colour palette of 262,000 or 16.7 million colours respectively. The 8.0" display module has mechanical outline dimensions of 189.0x120.0x7.5mm and an active LCD area of 173.76x104.26mm. The display has an operating and storage temperature range of -30 to 80°C. The module weighs 160g.

KOE"s Lite+ TFT modules offer cost effective LCD solutions that feature industry standard screen sizes, display resolutions and data interfaces but without any compromise in display optical performance. Lite+ display modules offer high brightness display characteristics and are suitable for use in bright ambient environments.

The new 8.0" WXGA display is suited for industrial user interface, security, medical, and infotainment applications where a high resolution display is required to accurately represent display images and information, and video reproduction. The new KOE TX20D201VM2BAB Lite+ display module is available immediately through KOE"s distribution sales channel partners.

Distributor of component LCDs for equipment which provide high-contrast ratio, color saturation, luminance and performance enhancements such as advanced wide viewing (AWV) for true color fidelity, super-high brightness (SHB) and wide temperature range. Focus on industrial, instrumentation, hand-helds, medical and other low-to-medium volume markets. High-bright LED backlights for outdoor use. LVDS interfaces decrease EMI. Factory installed touch screen solutions. 3.5" to 12.1" QVGA, HVGA, VGA, WVGA, SVGA, XGA, WXGA. Also distributes other related products including LED drivers, lamps, indicators, LED assemblies, segment displays, LED mounts, LEDs, and light pipes. Distributor of electronic components, hardware and fasteners and provides design/value engineering support, fulfillment strategies, procurement services and transactional models to meet specific needs and priorities.

These wide viewing angle Small Format TFT LCDs with optional touch are industrial grade and cost competitive. Therefore these products are a popular display choice to integrate in many projects.

Using only high-tech factories that we partner with, we provide clients with the service of designing liquid crystal display panel (LCD) and liquid crystal display module(LCM), and is committed to the customized service, R&D, sales, after-sales service of display products. Our factories have hundreds of engineers focusing on creating the highest quality displays including monochrome LCD (TN, STN), colour LCD (CSTN and TFT), Custom LCD’s, LCD module (both COG* and COB*) which are widely used in mobile phones and many other applications.

Our state of the art factory produces High Resolution TFT glass panel cells, has TN, HTN, STN and TFT technologies for LCD panels. The Factory has class 1000 clean rooms, high accuracy bonding, pre bonding and heat seal machinery, many production lines specifically for TFT production, OCA and OCF bonding machines,  In-House LCD glass cleansing process, output thousands of pieces per month.

Touchscreen overlay cover glass only available (so you do not have to purchase the display)These displays can come with: touchscreen components, touchscreen overlays, industrial touch screen,Wide LCDs, LED TFTs, and TFT Colour displays.

Other options are: LCD drivers, LVDS Touchscreen displays, automotive LCD Display, TFT high resolution screens, TFT LCD capacitive touchscreens, TFT capacitive touchscreens, high brightness LCDs, Letterbox Displays, small VGA Displays, LCD panel without backlights,Variations of our Small Format TFT LCDs include: TFT Display touchscreens, TFT IPS Display, monochrome displays, TFT or LCD, embedded components, LCD components, TFT Drivers, industrial range of Displays,

CDS also offers industrial TFT LCDs,Our displays are used in: touch screen vending machines, automotive touch screen displays, vending machine display panel, Touch screen vending, TFT Automotive, LCD Dislay panel kits, Touch screen TFT monitors, LCD Display components, LCD Screen components,  and POS LCD Displays.As you can see from the tables above we have sizes including:  8.8 inches, 4.3 inch LCD Display, 10.1″ TFT LCD,  3.5 inch LCD Display, 4.3 inch display, 3.5 inch TFT LCD Display, 4.3″ screen, 7 inch LCD panel, 3 inch LCD Displays, and 4.3″ TFT LCDs as well as other small LCD Display screens.We have options on and equivalents to the following displays and TFT panel manufacturers:  Raystar, Kingtech LCD, Digital View, OLED modules, OLED products, Powertip LCD Displays, Data Vision LCD, LG TFT Display, Tianma NLT, Powertip Displays, Mitsubishi LCD Displays, DMC components, Kyocera LCDs, NLT Technologies Ltd, Sharp LCD TFT modules, LCD manufacturers in the USA, PMOLED Displays, innolux display corp, Industrial touchscreens, A Grade TFT LCD Displays, Panoramic TFT Displays, Samsung TFT Displays, Touchscreen components, Transparent TFT Displays, Touchscreen components,  TFT LCD controllers, as well as other TFT LCD manufacturers and Liquid crystal Display manufacturers.

CDS offers the widest range of displays and touchscreens including Abon touchscreens, Ampire LCD distributor, alternative Prisma interface baord supplier including Prisma iiia, Solomon Goldentek, Panasonic TFT, Winmate display, USB IO, and Apollo monitors

Our range includes AMOLED, circular displays, circular monitors, circular screens, circular TFT screens, round displays, Round TFT LCD displays, TFT AMOLEDs, TFT and IPS, TFT display interface microcontroller, TFT LCD or AMOLED, TFT LCD super AMOLED, WXGA TFT Displays, and WXGA TFT screens

As well as large format displays CDS also offers DSI TFT Display, large monochrome LCD displays, mono displays, mono OLEDC displays, mono TFT LCDs, monochrome displays, PCT Touchscreens, projected capacitive touch PCT technology, sq monitors and squid IDS.

CDS added a number of additional controller boards nd accessories which include TFT adaptor boards, TFT boards, TFT display controller boards, USB c LCD controller, USB touch kit, resistive touch screen, TFT accessories com, LCD controller board, LCD controller board USB c, LCD controller board, HDMI to MiPi DSI board, HDMI to MiPi DSI bridge, HDMI to MiPi LCD controller board, EDP adaptor bard, elite C microcontroller, Displaylink DL 3000 .

Whether it be bar type LCDs or any of CDS display solutions or many TFT displays we can help with comparing mipi dsi vs lvds interfces or mipi to edp wch can include use on pos shelf displays and rgb epaper for example.

Pixel, also called Picture Element, A pixel is the smallest unit of a digital image or graphic that can be displayed and represented on a digital display device. A pixel is the basic logical unit in digital graphics. Pixels are combined to form a complete image, video, text, or any visible thing on a computer display

LCD display doesn’t operate the same way as CRT displays , which fires electrons at a glass screen, a LCD display has individual pixels arranged in a rectangular grid. Each pixel has RGB(Red, Green, Blue) sub-pixel that can be turned on or off. When all of a pixel’s sub-pixels are turned off, it appears black. When all the sub-pixels are turned on 100%, it appears white. By adjusting the individual levels of red, green, and blue light, millions of color combinations are possible

The pixels of the LCD screen were made by circuitry and electrodes of the backplane. Each sub-pixel contains a TFT (Thin Film Transistor) element.  These structures are formed by depositing various materials (metals and silicon) on to the glass substrate that will become one part of the complete display “stack,” and then making them through photolithography. For more information about TFT LCDs, please refer to “

The etched pixels by photolith process are the Native Resolution. Actually, all the flat panel displays, LCD, OLED, Plasma etc.) have native resolution which are different from CRT monitors

HD TV has 1280×720 = 921,600 pixels; Full HD has 1920x 1080=2,073,600 pixels; 8K TV has 7,680×4,320=33,177,600 pixels. he “K” in 8K stands for Kilo (1000), meaning a TV that has achieved a horizonal resolution of about 8,000 pixels.

Although we can define a LCD display with resolution, a Full HD resolution on screen size of a 15” monitor or a 27” monitor will show different. The screen “fineness” is very important for some application, like medical, or even our cell phone. If the display “fineness” is not enough, the display will look “pixelized” which is unable to show details.

DPI stands for dots per inch and refers to the resolution of a printer. It describes the density of ink dots placed on a sheet of paper (or another photographic medium) by a printer to create a physical print.

PPI stands for number of pixels per inch. It is kind of pixel density. PPI describes the resolution of a digital image, not a print. PPI is used to resize images in preparation for printing

But you see other lower resolution available, that is because video cards are doing the trick. A video card can display a lower LCD screen resolution than the LCD’s built-in native resolution. The video cards can combine the pixels and turn a higher resolution into lower resolution, or just use part of the full screen. But video cards can’t do the magic to exceed the native resolution.

Special names by individual companies: Apple Macbook Pro Retina 6K display, Acer Nitro, ASUS Pro Art , ViewSonic Elite, ASUS TUF ,Samsung edge Infinity-O Display etc.

Apollo specializes in TFT-LCD flat panel technologies and supply chain solutions. We offer a huge selection of TFT-LCD monitors and touchscreens, as well as corresponding components. We also offer hardware and software solutions for all of our products and digital signage applications.

As a worldwide supplier of state-of-the-art TFT technologies and system solutions, Apollo Displays supports you in all project phases – 1 from construction of the metal housing and procurement of specific parts to in-house development of controller boards and touchscreen integration.

Two separate colors (yellow and sky blue), make this graphic OLED module easy-to-read, unique display. Less than an inch diagonal, this lightweight display uses super low power, making it great for handheld devices.

An ePD retains the content of your Display without applied power. Only for changing the display-content, a short supply with power is necessary. Microtips has partnered with an experienced E-paper manufacturer. We represent a full series of E-paper technology, including true color to meet your specific needs.

Thin Film Transistor or TFT screens are active-matrix LCDs capable of controlling individual pixels on the screen. Thus, they assure better visibility than other variants. These flat-panel displays are suitable for a variety of applications owing to their wide range of beneficial features.

Round TFT LCDs are gaining popularity as they have become a perfect replacement for analog gauges, and they help make any application look versatile. Microtips Technology has introduced a new 3.4-inch round display, with a high resolution of 800 x 800 pixels.

High-definition Multimedia Interface (HDMI) is a proprietary technology used to transmit uncompressed audio and video data from an HDMI-compliant digital controller to a television, computer, video projector, or any other HDMI-compliant device. Microtips Technology has developed the 7" RFH70XB-1IW-LHS medium-sized HDMI display with an HDMI interface and a high resolution.

TFT (Thin Film Transistor) is a thin-film field-effect transistor display that is designed to visualize millions of clear, bright, and high-contrast color pixels. Over the years, this display has gained immense popularity owing to its several benefits.

The 7 inch low-cost color display is one of the most popular touch screen displays available for raspberry pi, HDMI display screen and other mini PCs. Featuring IPS screen with larger visible angle and more clear display effect, this 7 inch display with touch screen can be used in all environmental conditions because of its wide temperature liquid crystal fluid.

Microtips Technology has introduced a high brightness High-Definition Multimedia Interface (HDMI) interface IPS TFT LCD module. These modules are compatible and assure seamless interface with any version of Raspberry Pi Single Board Computers (SBCs), PCs, or devices such as HDTV, DVD player, or any device that is compatible with HDMI.

AMOLED (stands for Active Matrix Organic Light Emitting Diodes) display is one of the best screen technologies popularly used in today’s laptop screens and PC monitors and high-end smart phones.

The Thin-Film-Transistor display (TFT display) is an active matrix display where each pixel of the flat panel is illuminated individually. In recent times, TFT display is increasingly used in the electronics industry owing to its several benefits.

Microtips Technology, one of the leading 5-inch color TFT display module manufacturers, has introduced the new low-cost 5-inch color TFT display. The thin film transistor (TFT) technology is just another variant of the LCD technology.

Thin-film transistor (TFT) LCD displays assure improved image quality over traditional LCD displays. They offer more control over colors and images, and require less power than other technologies.

Microptips Technology has introduced a 3.9" bar type TFT display that has a high contrast ratio. This panoramic 3.9 inch RGB bar TFT LCD comes with a resolution of 480x128 pixels. This display is suitable for several modern electronic appliances like server and audio systems, auto/marine equipment, advertising displays, drone controls and many more.

Microtips Technology, one of the leading 4.3-inch TFT LCD module manufacturers, has introduced the new low-cost 4.3-inch TFT display. TFT or thin film transistor is primarily a variant of the LCD technology. TFTs are active matrix LCDs, which help improve contrast, color, and picture quality.

Thin-Film- Transistor displays or TFT displays are active matrix LCD displays that assure better color perception than regular Twisted Nematic LCDs. The demand for TFT displays has increased in recent years owing to several advantages they offer. These displays assure a clear view from any angle, and they can display millions of bright color pixels.

Microtips is proud to announce a new line of HDMI Displays designed to work seamlessly with development boards and computers like the Raspberry Pi. This video outlines our current options for these displays...

Microtips is excited to announce our 10.1”, high bright, TFT display with increased resolution and widened viewing angles. This 10.1”, WXGA 1280*800 TFT display is an IPS panel equipped with an HDMI signal input...

Simple monochrome displays, like 7 Segments & Icons, have been around for a very long time. These displays are still widely used by customers in wide variety of industries. But have you thought about Color TN Displays instead?

Microtips MTD0550AZOM-T is a 5.49 inch display module with a resolution of 1080(RGB) x 1920. This display is composed of an AMOLED panel, driver ICs, On-cell Touch Panel and FPC.

Regional Sales Manager, George, explains OLED Displays, their benefits, and other characteristics that make them better than standard Liquid Crystal Displays for some applications.

Raystar is a global leading LCD panel supplier and specialized in producing TFT LCD Panel, including Color TFT, Monochrome TFT Display and bar type TFT Display. Raystar Color TFT displays are available in various resolutions and offers a wide product range of small to medium-sized TFT-LCD modules from 0.96” to 12.3". The interface options are in MCU / RGB / SPI / UART / 8080 / LVDS. TFT Panel with control board or TFT LCD Panel with micro controller are also available.

EVERVISION is a professional and experienced manufacturer of TFT LCD module. Our displays are full color LCDs available in industry standard sizes ranging from 3.5", 4.3", 7.0", 10.1" to 15.6 inch TFT display and resolutions from QVGA(320x240), WQVGA(480x272), VGA(640x480), XGA(1024x768) to WXGA(1280x800).

EVERVISION Standard TFT LCD Displays,TFT Color LCD Display Module, also offer a variety of interface options including MCU, TTL RGB, eDP, LVDS, MIPI and more, as well as a line of modules that support touch panels in resistive and capacitive technology. We have many customized TFT LCD modules as well as system solution fulfilling any demand. Controller board or special sizes can be available depend on customer"s requirement.

Applications are mainly found on industrial equipment, medical products, white goods, POS system, Kiosk, and so on. Please use the product filter below to help you find the display monitor that is suitable for your application.

Winstar standard TFT-LCD display modules are available in various sizes from 1.77" to 10.4" TFT LCD, such as 2.4" TFT display, 2.8", 3.5" TFT display, 4.3" TFT display, 5 inch display, 7" LCD display. These TFT LCD modules are including options of TFT panel, TFT LCM with controller board, industry standard mono TFT LCM, TFT color display, and wide operating temperatures of -20°C to +70°C or -30°C to +80°C.

Winstar TFT displays are available in various graphic display resolutions including QVGA (320 x 240), WQVGA (480x272), VGA (640x480), WVGA (800x480), 640x320, 1024x600, XGA (1024x768) and WXGA(1280x800). Many of Winstar TFT display modules have more than one interface available including MCU, RGB, TTL and LVDS as well as two touch panels optional in resistive and capacitive technology.

The list below is our standard offering. However, Winstar Displays has many more customized solution and special sizes available as options. Please contact us online for more information.

Take your design to the next level with our range of TFT Displays including latest IPS TFT, circular and bar shape as well as large size TFT. With or without touch, these are fully customisable to your system requirements.

TFT-LCD technology is now fairly mature. As a result, manufacturing processes are efficient and production yields are high, leading to very competitive unit prices. Upgrading from a monochrome display to a TFT is now an affordable way to give your product an uplift.

Users of industrial display devices are wanting the same experience they have come to expect from a consumer device with all-round viewing angles. Switching to a superior IPS TFT display has become very cost effective as production increases and unit prices decrease.

Choosing a circular display for your next product design could really set you apart from your competition. Models are available from 1" to 4.2"in TFT, PMOLED and AMOLED, we have something to suit every application.

It is now possible to transform from a monochrome display to a colour display in space constrained systemsby using a letterbox shaped display. These ultra-wide displays are ideal for applications with restricted build height such as rack mount systems or landscape format front panels.

Large TFT display systems are increasingly being used for transportation information, retail signage and vending machines and kiosks. We can supply a large range of TFT solutions up to 65" diameter and in bar-style, square or rectangular configurations.

We are now offering increasing cover lens customisation options and processes to make your TFT LCD user interface truly stand out! Anders’ experienced marketers and engineers work with our manufacturing partners around the world to keep informed of the latest innovations, including mirrored glass,tinted glass, spot-facing, three dimension glass, and many more!

Here at Anders we don"t just strive to design a best in class display solution for your product, but we also want to make sure the display is driven with the right embedded system. We can help achieve a hardware solution that ensures your display works perfectly within your application. Hardware solutions include:

Get started quickly on your new user interface with our HMI development kits. The display, the processor and the OS work together out of the box with optimised QT GUI images. We"ll then optimise the kit to meet exactly your system requirements with our design services.

At Anders we understand that no two customers are the same, which is why we specialise in custom display solutionsand offer unique productstailored to your end application.

See below our range of TFT Displayswith sizes ranging from0.96" to 64.5" and including circular and bar type shape. All our displays can be tailored to suit your application antimicrobial coating technology,

We aim to offer reliable and long-term solutions to our B2B customers. If you are a business and would like to discuss your display and/or embedded system requirements please contact us below

A TFT display is a form of Liquid Crystal Display with thin film transistors for controlling the image formation. The TFT technology works by controlling brightness in red, green and blue sub-pixels through transistors for each pixel on the screen.

There are many display technologies, but do you know which one would be better for your application? Particularly when considering optimum viewing angle and contrast. We discuss 2 of the best options.

Compare IPS vs TFT displays - the TFT display is the display of choice for industrial designs, but it can have its limitations. A newer technology called IPS (in plane switching) offers better viewing angles and colours, but is it really the best choice - we discuss benefits and negatives of both types of TFT display.
