cog lcd display quotation

The Displaytech 162GCOG series is a lineup of 16x2 character chip-on-glass LCD modules. These modules have an 65x27.7 mm outer dimension with 61x15.7 mm viewing area on the display. The 162GCOG 16x2 LCD display series has the controller mounted directly onto the LCD glass. The chip-on-glass (COG) technology allows for a cost-effective system build since the display does not require a PCB. Get a quote directly from Displaytech for the 16x2 COG character LCD display from the 162GCOG series.

Available in character and graphic formats, COG (Chip-On-Glass) LCD Displays are designed without a PCB. The LCD driver/controller is bonded directly to the glass of the display. This allows COG displays to be smaller in size, more cost effective and a highly customizable display solution compared to typical LCD modules with a board.

Dr Pan: Hello, Greg. COG is the abbreviation for chip on glass. It is a technology, which IC is bonded directly onto ITO glass. COG technology is usually used in small size dot matrix monochrome LCD module and TFT LCD module.

NO.1, it can greatly reduce the size of the LCD module because it doesn’t have PCB and it can be as thin as 2.0mm (maybe thinner). The thinner the more expensive.

NO.3, it is cost effective over COB LCD and can totally replace COB LCD in function, especially in graphic LCD modules, because it reduces the number of IC.

NO.4, for some dot matrix LCD modules, it is not possible to apply COB LCD technology because it is too crowded to place so many points on the view area. COG LCD is an economical and feasible solution because the pitch is smaller .

A wide variety of cog lcd options are available to you, such as original manufacturer, odm and agency.You can also choose from cog, tft and fstn/cstn cog lcd,

We have received calls to be a second source LCD display supplier for selected technologies of Densitron LCD Displays. This includes Monochrome Graphic and custom segmented TN, STN, and FSTN static displays. The majority of these monochrome displays are FSTN, but can also be built as a STN.

We offer standard LCD display modules that are an equivalent replacement to Densitron’s character LCD display modules. We also offer design assistance to design and build a custom LCD module and glass that will be an equivalent match to your current Densitron LCD module.

At Focus Display Solutions, when we are asked to quote on a “chip on glass” graphic LCD module, we find that many of the displays require a custom display solution and are not off-the-shelf.

If you find that you need a unique LCD design to match your current display requirements, please feel free to contact us. We offer design assistance with the initial prototype through final production.

Monochrome Graphic LCDs include TN, STN, FSTN, FFSTN technologies with polarizer in positive mode or negative mode options. COG (Chip on Glass) Constraction. Graphic LCD modules include different options of polarizer in reflective, transmissive or transflective types. LED backlights are available in various colors including yellow/green, white, blue, red, amber and RGB. Available sizes from 1.2’’ to 5.2’’ (128x32~256x128 pixels). Main features:

QS-9000, ISO-9001 & ISO-14001 certified manufacturer of chip-on-glass (COG) displays. Chip-on-glass displays are available in various models with specifications including character pattern ranging from 2 lines x 16 characters to 160 lines x 100 characters, module size ranging from 34 mm W x 28 mm H to 102 mm W x 70 mm H, viewing area ranging from 31 mm W x 19 mm H to 87 mm W x 43 mm H. Display available in white, yellow & gray LED colors with or without backlight. COG displays are suitable for a variety of markets including handhelds, industrial, irrigation, medical & scales. RoHS compliant.
