・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : APR 2012 Printed in Japan All rights reserved. F : JAN . 19, 2016 Pub. No. OME-44730-F (DAMI ) FMD-3200/3200BB/3300 0 0 0 1 7 6 1 2 5 1 5...

Do not place liquid filled containers Unit. Do not remove any label. If a label is on the top of the equipment. missing or damaged, contact a FURUNO agent or dealer about replacement. Fire or electrical shock can result if a Name: Warning Label (1) liquid spills into the equipment.

GPL or LGPL as published by the Free Software Foundation. Please access to the following URL if you need source codes: https://www.furuno.co.jp/cgi/cnt_oss_e01.cgi. This product uses the software module that was developed by the Independent JPEG Group.

MC-3030D optional or local supply equipment. Serial Analog Digital IN Digital OUT interface interface interface interface The following monitors are available for use with the FMD-3200 BB. Maker Model Viewing distance (m) FURUNO MU-190 1.0138 MU-231 1.0138 MU-201CE 1.0759 MU-231CE 1.0138...

Push: Confirms selection. ESC key: Goes back one step in the current operating se- quence on the InstantAccess bar. BRILL Rotate: Adjusts the brilliance of a FURUNO or Hatteland moni- tor. Push: Selects a color palette. A/C RAIN No use.

To emphasize this point these charts are called "Non-ENC" charts in this manual. Note that some eToken dongles from the FEA-2xx7 can be used. These are labeled “JeT FURUNO XXXXX”. This ECDIS accepts the following C-MAP chart types: CM-ENC, Professional, Profes- sional+ and Jeppesen Primary ECDIS Service.

NAV log (Voyage, Details, Chart Usage), Target log (Danger Target). *Voyage navigation and Voyage planning modes Selects a color palette, day, dusk or night. • Adjusts the brilliance of a FURUNO or Hatteland monitor unit. • Adjusts the backlighting of the control unit. Inscribes the MOB (ManOverBoard) mark.

2. OPERATIONAL OVERVIEW  Conditions for chart alerts during route monitoring, which includes safety contour and other chart alerts, on the [Alert Parameters] page of the [Route Plan] dialog box. Check Status: Checked  Name of the user chart to be used during route monitoring together with this planned route, on the [User Chart] page of the [Route Plan] dialog box.

2. OPERATIONAL OVERVIEW Select the user chart(s) to monitor A user chart can be monitored without linking it to a route. You can select a user chart two ways. • Click the [Voyage], [User Chart] and [Select/Unselect] buttons on the InstantAccess bar to open the [Select Monitor User Chart] dialog box.

8. CHART ALERTS Check Status: Checked 4. Click the [Check Route] button to generate a list of chart alerts. The results appear on the [Check Results] page. Route Bank The figure above shows the alerts to be monitored. If there are alerts included in the planned route, check alerts leg by leg, or check alerts by using category of alert.

11. HOW TO MONITOR ROUTES Method 2: Selection from the Route information box Right-click the route name location in the [Route Information] box then select [Select Route] to show the [Select Route] dialog box. Select a route then click the [Open] but- ton.

11. HOW TO MONITOR ROUTES To close the [Instant Track] dialog box, click the [Close] button. (The system continues monitoring the instant track route.) The following occurs when sensor data is lost while using the instant track function. Monitoring condition Result Instant track route monitor- •...

ECDIS via the Radar Connection Box. Note: For FURUNO radars, it is recommended to use the settings set on the radar in order to match the radar overlay picture with the radar picture.

Selects a display palette. See section 1.7. Adjusts the brilliance of a FURUNO or Hatteland monitor. See section 1.8. Takes a screenshot. See section 1.14. Displays system information and the Operator’s Manual. Conning informa- tion appears in the Version tab.

26. AUTOPILOT OPERATIONS Lost speed (IEC 62065 Ed. 1) Associated Expected system Operator alerts performance action • Speed log data, VTG • Acknowledge alerts. sentence lost. Alert • Monitor situation. "901 No FIlter Source of COG/SOG", Alert "902 No Filter Source of CTW/STW"...

26. AUTOPILOT OPERATIONS Low speed Associated Expected system Operator alerts performance action • Alert "159 Low Speed • Acknowledge alerts. Alarm". • Monitor situation. Lost communication between Autopilot and ECDIS and vice versa Associated Expected system Operator alerts performance action Within 15 •...

APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviation Meaning minute Minimum MMSI Maritime Mobile Service Identity Man Overboard Monitor Message North Navigation, Navigator Navtex Navigational Telex Nautical miles Number November NtoM Notice to Mariners October Operation Own Ship Personal Computer PERPENDIC Perpendicular Parallel Index (lines) POSN Position PRIM...

APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Routes - Monitor Monitored route leg lines are dashed. Leg lines may indicate planned speed and bearing. W05a Wheel over position 1115/20 Jan 15 deg 1213 Plotted positions Plotted position includes some labels. Type is DR, EP or Fix (Fix is without label).

APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Danger highlight Route Plan, Route Monitor and own ship Chart Alarm search area use danger highlight to indicate violation against user selected dangers. Danger bearing Also called by traditional name clearing line. User defined clearing line symbols are available as part of User Chart.

Symbol Meaning Symbol Meaning Minimize button Screenshot capture (on InstantAccess bar) Access AIS, Navtex Monitor brilliance (FURUNO message processing or Hatteland monitor only); control unit backlighting Access user profile, Color palette selection common settings Information (show program Activate weather display no., operator"s manual)

Warning Internal temperature ex- Please turn off monitor. Inside Monitor ceeds threshold. If the error frequently oc- Monitor: Connected to curs, contact FURUNO and COM2 (Sub Monitor). inform frequency of occur- rence. Fan1 No Warning For MU-190/231: Connect- If the error frequently Rotation ed to COM2 (Sub Monitor).

60 seconds. Sentence Syntax Caution For Sub monitor, connected If the error frequently Error to COM2, value of external- occurs, contact FURUNO ly input sentence is out of and inform frequency of range defined by sentence. occurrence. Main Monitor COM Caution...

FU- RUNO. EC-3000 CPU Fan Caution Rotation speed of CPU fan If the error frequently Rotation Speed in processor unit is below occurs, contact FURUNO Lowering threshold. and inform frequency of occurrence. EC-3000 Fan1 Caution Rotation speed of fan1 in...

Double Gyro Sta- Warning When connected with Dou- If the error frequently tus Conflict ble Gyro System, instru- occurs, contact FURUNO ment produced by and inform frequency of Yokogawa Electric, two occurrence. gyro has been displayed "Selected" status for 3 sec- onds.

RM Stop - Discon- Alarm Error occurs inside of route If the error frequently oc- nect Sensors monitoring function. curs, contact FURUNO and inform frequency of occur- rence. RM Stop - Other Alarm Required data for route Check the connection with...

However, if it"s continually removed, there is a possibility that correct data is not received from sensor. In this case, contact FURUNO. EPFS 2 Sensor Caution Own ship position data from Reset the filter to confirm Banned No.2 GPS is determined ab-...

However, if it"s continually removed, there is a possibility that correct data is not received from sensor. In this case, contact FURUNO. EPFS 7 Sensor Caution Own ship position data from Reset the filter to confirm Banned No.7 GPS is determined ab-...

However, if it"s continually removed, there is a possibility that correct data is not received from sensor. In this case, contact FURUNO. SDME 3 Sensor Caution Own ship speed data from Reset the filter to confirm Banned No.3 SDME is determined...

However, if it"s continually removed, there is a possibility that correct data is not received from sensor. In this case, contact FURUNO. ROT Gyro 1 Caution Heading data from No.1 Reset the filter to confirm Sensor Banned...

FURUNO FMD-3200/3300/3200-BB 2.16 Other functions Radar overlay, Playback log INTELLIGENT HUB (OPTION) Number of ports 8 ports (10/100/1000BASE-T) Swiching method Store and forward, non-blocking L2 switching Capacitance of switching 16 Gbps Flow Control Full-Duplex (IEEE802.3x flow-controlled at automatic mode) Ring aggregation 8 group max.

FURUNO FMD-3200/3300/3200-BB MC-3030D (digital-out) 8 ports: relay contact, normal open and normal close available Ethernet interface for IEC61162-450 (EC-3000) Port (LAN2) 1000Base-TX, IPv4, 8P8C connector Data sentences Input ABK, ACN, ALC, ALF, ALR, ARC, CUR, DBT, DPT, DTM, ETL, GGA, GLL, GNS, HBT, HDT, HTD, MTW, MWV, NRX, OSD, PRC,...

FURUNO FMD-3200/3300/3200-BB Radar connection box (option) 24 VDC: 0.6 A HUB (HUB-3000/ HUB-100, option) 100-230 VAC: 0.1 A, 1 phase, 50-60 Hz ENVIRONMENTAL CONDITION Ambient temperature -15°C to +55°C Relative humidity 95% or less at 40°C Degree of protection Monitor unit...

INDEX context-sensitive menu ......2-22 details ..........11-10 hiding............. 2-21 messages ..........11-9 measuring bearing with ......2-21 monitoring ........... 11-10 showing ..........2-21 parameters ..........21-4 EBL, VRM boxes........2-13 returning to monitored route ....11-12 ECDIS Control Unit ........1-3 safe off track..........

SAFETY INSTRUCTIONSThe user and installer must read the appropriate safety instructions before attempting to installor operate the equipment.DANGERWARNINGCAUTIONIndicates a hazardous situation which, if not avoided, will result indeath or serious injury.Indicates a potentially hazardous situation which, if not avoided,could result in death or serious injury.Indicates a potentially hazardous situation which, if not avoided,may result in minor or moderate injury.Warning, Caution Mandatory ActionProhibitive ActionDANGERNever touch the SSB antenna, antennacoupler or lead-in insulator when theSSB radiotelephone is transmitting.High voltage which will cause death orserious injury is present at the locationsshown in the illustration below when theSSB radiotelephone is transmitting.AntennaCouplerAntenna Wire(High Voltage)IndoorAntennaWireLead-inInsulator(HighVoltage)WARNINGDo not open the equipment.Only qualified personnel should workinside the equipment.Immediately turn off the power at theswitchboard if water leaks into theequipment or something is droppedinto the equipment.Continued use of the equipment can causefire or electrical shock. Contact a FURUNOagent for service.Do not disassemble or modify theequipment.Fire, electrical shock or serious injury canresult.WARNINGImmediately turn off the power at theswitchboard if the equipment is emittingsmoke or fire.Continued use of the equipment can causefire or electrical shock. Contact a FURUNOagent for service.Do not place liquid-filled containers onthe top of the equipment.Fire or electrical shock can result if a liquidspills into the equipment.Do not operate the equipment withwet hands.Electrical shock can result.Turn off the power immediatelyif you feel the equipment is behavingabnormally.Turn off the power at the switchboard ifthe equipment becomes abnormally warmor is emitting odd noises. Contact aFURUNO dealer or agent for advice.Make sure no rain or water splash leaksinto the equipment.Fire or electrical shock can result if waterleaks in the equipment.Use the proper fuse.Use of the wrong fuse can cause fireor electrical shock.ii

WARNINGDo not operate the [DISTRESS] buttonexcept in case of a life-endangeringsituation on your vessel.Operating the [DISTRESS] buttontransmits the distress alert. Accidentaltransmission may prevent search andrescue operations for actual emergency.If the distress alert is accidentallytransmitted, contact the nearest stationto cancel the alert.CAUTIONIf the distress alert is accidentallytransmitted, contact the nearest coaststation and inform them of the accidentaltransmission, providing the following data:a) Ship"s nameb) Ship"s call sign and DSC numberc) Position at time of transmissiond) Time of transmissionDo not apply strong pressure to theLCD, which is made of glass.Injury can result if the LCD breaks.WARNING LABEL(S)Do not remove any safety label.If a label is missing or damaged, contact a FURUNO agent or dealer about replacement.DANGERHazardous voltage.Can shock, burn,or cause death.Do not touch antennawire, insulator andterminal.Name: Danger LabelType: 05-062-0213-0Code No.: 100-199-230ANTENNACOUPLERWARNINGTo avoid electrical shock, do notremove cover. No user-serviceableparts inside.Name: Warning Label (1)Type: 86-003-1011Code No.: 100-236-231TRANSCEIVERUNITiii

FOREWORDThank you for purchasing the FS-1570/2570/5070 SSB Radiotelephone. We are confidentyou will discover why FURUNO has become synonymous with quality and reliability.Dedicated in the design and manufacture of marine electronics equipment for 60 years,FURUNO Electric Company has gained an unrivaled reputation as a world leader in theindustry. This is the result of our technical excellence as well as our worldwide distributionand service network.Please carefully read and follow the safety information and operating and maintenanceinstructions set forth in this manual before attempting to operate the equipment and conductany maintenance. Your unit will perform to the utmost of its ability only if it is operated andmaintained in accordance with the correct procedures.FeaturesThe FS-1570/2570/5070 is an MF/HF SSB Radiotelephone with a built-in DSC/WatchReceiver, all contained in a surprisingly compact cabinet. An NBDP (Narrow Band DirectPrinting) Terminal Unit is optionally available.Data is displayed on a large, easy-to-read backlit LCD. Operation is simplified by the use offew keys and easy-to-follow menus.The built-in DSC/watch receiver produces and receives digital selective calls for quick andefficient establishment of distress, urgency, safety and routine communications with otherships and coast stations that install any MF/HF DSC facilities.The main features areGeneralFully meets the following regulations: IMO A.806(19), IMO A.694(17), IMO A. 813(19), MSC68(68) Annex 3, IEC 61097-3 Annex A, IEC 61162-1 (2000), IEC 60945 (2002),EN 300 373-1 (2002), ETS 300 067A1(1998), EN 300 338(2004), EN 301 033 (2005),ITU-R M.493-11, M.541-9, M.476-5, M.491-1, M.492-6, M.625-3, M.1173-3.Automatic entry of position with manual overrideOptional printer can automatically print out DSC and NBDP received messages and testresults.SSB• Receiving voice communication, telex and AM.• Facsimile signal receiving• Simplified setting of channel and frequency.xii

FOREWORDDSC/watch receiver• Distress, urgency, safety and routine calling• Scanning of DSC frequencies for distress and general calls on MF/HF• File editing capability for readiness in case of emergency• PSTN (Public Switched Telephone Network) capability standard• Log stores 50 each of latest ordinary, distress and transmitted messages, in separatememory blocks.NBDP (with optional NBDP Terminal Unit IB-583)• Automatic error-free telex communications and distress message in compliance withGMDSS requirements• LCD monitor and keyboard comply with ITU regulations• Pop-up menus for user-friendly operation• Memory for 256 operator-customized channels• Real time message printing with Printer PP-510Program NumberFS-1570/2570/5070PC board Program No. Ver. No. RemarksMAIN 0550225 01 Main programPANEL 0550222 01 Program for the control displayDSP (DSC) 0550207 01 MODEM Program for DSCNBDP 0550208 01 MODEM Program for NBDPTerminal Unit IB-581 (optional unit, for FS-1570/2570 only)PC Board Program No. Ver. No RemarksTERMINAL 0550210 1.22Terminal Unit IB-583 (optional unit)Program Program No. Ver. No RemarksTERMINAL 0550209 1.22About the TFT LCD: The TFT LCD is constructed using the latest LCD techniques, anddisplays99.99% of its pixels. The remaining 0.01%of the pixels may drop out or blink,however this is not an indication of malfunction.xiii

SYSTEM CONFIGURATIONSFS-1570Standard configuration is shown with solid line.DSC DISTRESSSAFETY FREQUENCY# = 2.6 mwhipantenna#PREAMP UNITFAX-5ANTENNA COUPLERAT-1560-15EPFS (GNSS)LOUDSPEAKERSEM-21QINCOMINGINDICATORIC-303-DSCCONTROLLER 1CONTROLUNITFS-2571CHANDSETHS-2003PRINTERPP-510MIF EQUIPMENTDISTRESS ALERT UNITIC-302-DSCTRANSCEIVER UNITFS-1570TNBDPTERMINAL UNITIB-583/IB-58124VDCINTERFACEIF-8500*24VDC* = Required for NBDP Terminaland DSC to share printer.BK INTERFACEBK-300CONTROLLER 2CONTROL UNITFS-2571CHANDSETHS-2003AC/DC POWERSUPPLY UNITPR-300POWER STATUSMONITORPSM-0124VDC100-115/200-230VAC1φ, 50/60HzPreamp Unit Exposed to weatherAntenna Coupler Exposed to weatherOther Units Protected from weatherxiv

SYSTEM CONFIGURATIONSFS-2570Standard configuration is shown with solid line.DSC DISTRESSSAFETY FREQUENCYDSC ROUTINEFREQUENCY### = 2.6 mwhipantennaPREAMP UNITFAX-5PREAMP UNITFAX-5ANTENNA COUPLERAT-1560-25EPFS (GNSS)W/R BOARDLOUDSPEAKERSEM-21QINCOMINGINDICATORIC-303-DSCCONTROLLER 1CONTROLUNITFS-2571CHANDSETHS-2003PRINTERPP-510MIF EQUIPMENTDISTRESS ALERT UNITIC-302-DSCTRANSCEIVER UNITFS-2570TNBDPTERMINAL UNITIB-583/IB-581DC24VINTERFACEIF-8500*24VDC* = Required for NBDP Terminaland DSC to share printer.BK INTERFACEBK-300CONTROLLER 2CONTROL UNITFS-2571CHANDSETHS-2003AC/DC POWERSUPPLY UNITPR-850APOWER STATUSMONITORPSM-0124VDCUnit CategoryPreamp Unit Exposed to weatherAntenna Coupler Exposed to weatherOther Units Protected from weather100-115/200-230VAC1φ, 50/60Hzxv

SYSTEM CONFIGURATIONSFS-5070Standard configuration is shown with solid line.DSC DISTRESSSAFETY FREQUENCYDSC ROUTINEFREQUENCY# = 2.6 mwhipantenna#PREAMP UNITFAX-5#PREAMP UNITFAX-5ANTENNA COUPLERAT-5000EPFS (GNSS)W/R BOARDLOUDSPEAKERSEM-21QINCOMINGINDICATORIC-303-DSCCONTROLLER 1CONTROLUNITFS-2571CHANDSETHS-2003PRINTERPP-510MIF EQUIPMENTDISTRESS ALERT UNITIC-302-DSCTRANSCEIVER UNITFS-5070TNBDPTERMINAL UNITIB-58324VDCINTERFACEIF-8500*24VDC* = Required for NBDP Terminaland DSC to share printer.BK INTERFACEBK-300CONTROLLER 2CONTROL UNITFS-2571CHANDSETHS-2003AC/DC POWERSUPPLY UNITPR-850APOWER STATUSMONITORPSM-0124VDCUnit CategoryPreamp Unit Exposed to weatherAntenna Coupler Exposed to weatherOther Units Protected from weather100-115/200-230VAC1φ, 50/60Hzxvi

1. OPERATIONAL OVERVIEW7/ key Turns loudspeaker on/off.(Note that this key does not silence the distress or urgency alarm.)8/PRINT key Prints communications log files, current screen (except DSC standbyscreen and radiotelephone screen) and test results.9/ key Adjusts panel dimmer and LCD contrast.*/FILE/CURSORkey• Opens the send message file list from the DSC standby screen, to sendstored message.• Shifts cursor.0/LOG/TUNE key • Long press: Tunes antenna in radiotelephone operation.• Momentary press: Displays message logs.#/SETUP key Opens the main menu.ALARM lamp • Flashes in red for distress and urgency messages.• Flashes in green for safety and routine messages.OVEN lamp Lights (in green) when mains switchboard is on.1.2 Turning the Power On/OffTurn the PWR/VOL knob clockwise at the right-hand side of the control unit to power thesystem. The RT screen appears.Rotate the PWR/VOL knob counterclockwise to turn the system off.In the dual control unit system, the control unit connected to the CONTROLLER 1 port onthe transceiver unit has priority and it controls the power for both the No.1 and No. 2 controlunits. The power switch of the No. 2 control unit powers on/off the No. 2 control unit only.Note: Turn on power at switchboard more than five minutes before turning on thisequipment.1.3 Radiotelephone (RT) ScreenTurn the power on, or press the 1/ RT/CH key to show the radiotelephone screen. This iswhere you set up the transceiver unit, and communicate by voice or telex.CH: 200Tx: 2182.0 kHzRx: 2182.00 kHzSSB SIMP HIGH FAST NB SQSENSIA 10.0AMMSI xxxxxxxxxPOS 35 00.0000N135 00.0000EDRUTC 00:00EPFS 23:59Radiotelephone (RT) screen1-2

2. SSB RADIOTELEPHONEcompleted, TUNE: OK appears. If tuning fails, TUNE: NG appears.2. Hold the handset close to your mouth, press the PTT switch and speak clearly.Note: When tuning is initiated in the two control units system, the display of the idle controlunit shows “OCCUPIED(ANOTHER CONTROLLER).” In this case, only theDISTRESS button is operative on the idle control unit. Further, if a control unit is inuse when the other control is tuned, the display of the activated control unit shows“OCCUPIED” plus the reason why cannot use: ANOTHER CONTROLLER or NBDPto inform you that tuning is not operated.2.3.2 Reducing transmitter powerTo minimize possible interference to other stations, reduce the transmission power. Thisshould be done when using the transceiver in a harbor, near the shore or close tocommunication partner (other ship).1. Rotate the ENTER knob to choose HIGH, MID, LOW (1) or LOW2 (shown on FS-5070)in the equipment states area and then push the ENTER knob.2-4CH: 200Tx: 2182.0 kHzRx: 2182.00 kHzSSB SIMP HIGHFAST NB SQSEN MID SIALOW1 10.0AMMSI xxxxxxxxxPOS 35 00.0000N LOW2UTC 00:00135 00.0000EEPFS 23:59(The above figure shows FS-5070.)FS-1570 FS-2570 FS-5070HIGHMID150Wpep 250Wpep 500Wpep100Wpep 125Wpep 350WpepLOW1* 68Wpep 90Wpep 200WpepLOW2110Wpep*: For FS-1570/2570, "LOW"(Power: ITU401CH)2. Rotate the ENTER knob to choose a power as appropriate and then push the ENTERknob.Note: Power amplifier temperature is monitored, and when its temperature rises above acertain temperature output power is automatically reduced. For FS-5070, when theover current is detected, output power is automatically reduced.2.3.3 Condition of the transmitting unitWhile transmitting, you may display RF (PA output), IA (antenna current), IC (collectorcurrent) or VC (collector voltage), at the lower left-hand side of the radiotelephone screen.1. Rotate the ENTER knob to choose RF, IA, IC or VC (whichever is displayed) in theequipment states area, and push the ENTER knob.CH: 200Tx: 2182.0 kHzRx: 2182.00 kHzIASSB IC SIMP HIGH FAST NB SQSEN VCSSIA RF IA10.0AMMSI xxxxxxxxxPOS 35 00.0000NUTC 00:00135 00.0000EEPFS 23:59Equipment states area2. Rotate the ENTER knob to choose option desired and then push the ENTER knob.

2. SSB RADIOTELEPHONE2.6 User ChannelsThe USER CH menu provides for registration of user TX and RX channels, where permittedby the Authorities. The user channel in the System setup menu must be enabled in order toregister user channels. For further details, contact your dealer. See section 6.4 to register.NOTICEFURUNO will assume no responsibilityfor the disturbance caused by theunlawful or improper setting of userchannels.2-8

4. DISTRESS OPERATIONSThe display changes as below (example).Compose msg.MSG TYPE : DISTRESSNATURE : FLOODINGPOS: 35°00.0000N135°00.0000E AT 12:34COMM MODE : TELEPHONEDSC FREQ : 2187.5 kHzGO TO VIEW16. Press the DISTRESS button more than four seconds to send the distress alert.Distress alertmessage in progress!NATURE: FLOODINGPOS: 35°00.0000N135°00.0000E AT 12:34TELEPHONE 2182.0 kHzDSC FREQ : 2187.5 kHzTIME TO GO : 38S17. When the distress acknowledge call is received, use the telephone or telex tocommunicate.For telephone, follow step 3 on page 4-3. For NBDP, follow the procedure below.Communicating by NBDP Terminal UnitThe message “STATION ENTRY COMPLETED FROM DSC. Press any key to escape.”Appears on the NBDP’s display.1. Press any key on the NBDP Terminal Unit to erase the message.2. Press the function key F3 on the keyboard of the NBDP Terminal Unit to show theOperate menu.3. Choose “Call Station” and then press the Enter key.Call StationStation ListStation Set upDSCABC-6MABC-12MABC-8MFURUNOStation : DSCID Code :Mode : ARQ FECTx Freq : 2174.50Rx Freq : 2174.504. “DSC” is selected; press the Enter key to connect the communications line.“Connect” appears in reverse video.5. Type and transmit your message, giving the following information:• Ship’s name and call sign• Nature of distress and assistance needed• Description of your vessel6. Press the function key F10 (BREAK) to disconnect the line.For NBDP details, see Chapters 7 through 10.4-6

4. DISTRESS OPERATIONS4.4 Receiving Distress Relay from Coast StationYour ship receives the distress relay when:• the coast station sends the distress relay to your ship. (DISTRESS RELAY COAST)• the coast station sends the distress relay to the area where you are navigating.When you receive a distress relay message from a coast station, continue monitoringdistress and safety frequencies. The audio alarm sounds and the display looks like the onein the left-hand figure below when a distress relay is received from a coast station.1. Press the CANCEL key to silence the audio alarm, and the display changes as in theright-hand figure below.Distress relay coastmessage received.CANCEL: STOP ALARMNATURE: UNDESIGNATEDPOS: 12°34.000N DIST: 14nm123°45.0000E AT 12:34TELEPHONE 8291.5 kHzPress theCANCEL key.Received messageMAY-23-2006-23:59DISTRESS RELAY COASTSENDER ID: 001234567SHIP ID IN DIST: 123456789NATURE: UNDESIGNATEDPOS: 12°34.0000N DIST: 14nm123°45.0000E AT 12:34TELEPHONE 8291.5 kHz 10M10SGO TO VIEW2. Press the CANCEL key to go to the radiotelephone screen.3. Watch distress/safety frequency.4.5 Cancelling Distress CallYou can cancel the distress call while it is being sent or while waiting for itsacknowledgement as follows.1. Press the CANCEL key to show the following display.The following message appears.Distress Proc. isPaused.NATURE: UNDESIGNATEDPOS: RESUME 12 34.5678N RESEND CANCEL123 45.6789EDSC FREQ : 2187.5 kHzTIME TO GO : 0S4-21

6. MENU OPERATION6.2 Noise BlankerThe noise blanker functions to remove pulse noise. You may turn it on or off as follows.Normally, use it with OFF (default setting).1. Press the SETUP key.2. Rotate the ENTER knob to choose NB.3. Push the ENTER knob.4. Rotate the ENTER knob to choose ON or OFF as appropriate, and then push theENTER knob.5. Press the CANCEL key.“NB” appears in the equipment states area when choosing ON at step 4.6.3 Squelch FrequencyIf you change the squelch frequency (ex. For high voice), do the following procedure.(default setting: 800Hz)1. Press the #/SETUP key.2. Rotate the ENTER knob to choose SQ.3. Push the ENTER knob.4. Enter frequency (range: 500-2000 Hz) with the numeric keys and then push the ENTERknob.5. Press the CANCEL key.6.4 User ChannelsThe USER CH menu allows registration and deleting of user TX and RX channels, wherepermitted by the Authorities. Maximum 256 channels can be registered.NOTICEFURUNO will assume no responsibilityfor the disturbance caused by theunlawful or improper setting of userchannels.6.4.1 Registering user channels1. Press the #/SETUP key.2. Rotate the ENTER knob to choose USER CH and then push the ENTER knob.*** User ch entry ** MODE: SSB CH: 2-0100201. TX: 2111.5 RX: 2111.500202. TX: 2222.0 RX: 2222.000203. TX: 2333.5 RX: 2333.500204. TX: 2444.0 RX: 2444.000205. TX: 2555.5 RX: 2555.56-2

6. MENU OPERATION13. Rotate the ENTER knob to choose appropriate DSC band and then push the ENTERknob.14. Rotate the ENTER knob to choose appropriate DSC frequency and then push theENTER knob.15. Enter file name and number as shown below.How to Enter File Name and Number1. Push the ENTER knob to open the file name entry window.*Message file entryFILE NAME: ----------------FILE NUMBER : ---FILE ENTRY2. Use the numeric keys and ENTER knob to enter file name (max. 16 characters). Forexample, enter FURUNO as the file name.Key and available character, symbol1 : 1→(blank)→12ABC : 2→A→B→C→23DEF : 3→D→E→F→34GHI : 4→G→H→I→45JKL : 5→J→K→L→56MNO : 6→M→N→O→67PQRS : 7→P→Q→R→S→78TUV : 8→T→U→V→89WXYZ : 9→W→X→Y→Z→90 : 0→_→ − →01. Rotate ENTER knob to select location.2. Press appropriate key.How to enter "FURUNO" as file name1. Press the 3 key to display F.2. Rotate ENTER knob to shift cursor.3. Press the 8 key to select U.4. Rotate ENTER knob to shift cursor.5. Press the 7 key to select R.6. Rotate ENTER knob to shift cursor.7. Press the 8 key to select U.8. Rotate ENTER knob to shift cursor.9. Press the 6 key to select N.10. Rotate ENTER knob to shift cursor.11. Press the 6 key to select O.12. Push the ENTER knob.3. Push the ENTER knob to open the file number entry window. Key in file number in threedigits with the numeric keys and then push the ENTER knob. For example, press 0, 0, 1,ENTER knob to enter file number 001.*Message file entryFILE NAME: FURUNO001FILE NUMBER : ---Note: The available file number is 001-799 and900-999.FILE ENTRY6-6

6. MENU OPERATION4. Push the ENTER knob. The display shows the name and file number entered.* Message file entry If the file name or number exists the message"Duplicate name (number) ! Overwrite OK?" appears.Push the ENTER knob to write over the name, orpress the CANCEL key to escape.FURUNONo.001 file enteredGo to next file?YES: [ENT] keyNO: [CANCEL] keyFILE ENTRY5. Push the ENTER knob to continue6.5.2 Preparing group callsTo receive the group calls, registering of the group ID is necessary as below.1. Press the #/SETUP key.2. Rotate the ENTER knob to choose MESSAGE.3. Push the ENTER knob.4. Push the ENTER knob to open the MSG TYPE menu.*Message file entryMSG TYPESTATION IDCOMM MODECOMM FREQDSC FREQINDIVIDUAL: PSTN : --------- MESSAGETEST MESSAGE: TELEPHONEGROUP MESSAGE: NO INFO: 2M-INTL5. Rotate the ENTER knob to choose GROUP MESSAGE and then push the ENTER knob.6. Push the ENTER knob to open the GROUP ID entry window.*Message file entryMSG TYPE:GROUP IDCOMM MODECOMM FREQDSC FREQGROUP MESSAGE: 0000000000--------: TELEPHONE: NO INFO: 2M-INTL7. Key in ID of group with the numeric keys and then push the ENTER knob.6-7

6. MENU OPERATION6.5.5 Sending prepared messagesSending without modification1. Press the FILE/CURSOR key at the DSC standby screen to show the send message filelist. Below is an example of the send message file list.Send message file001 : FURUNO JAPAN002 : FURUNO USA003 : FURUNO UK004 : FURUNO DENMARK005 : FURUNO NORWAY006 : FURUNO SPAINDOWN2. Rotate the ENTER knob to choose a file.3. Press the CALL key to send the message.Editing before sending1. Press the FILE/CURSOR key at the DSC standby screen to show the send message filelist.2. Rotate the ENTER knob to choose file desired and then push the ENTER knob.DETAILDELETE3. DETAIL is selected; push the ENTER knob. The message contents are shown on the“Compose msg.” Screen.4. Edit the message as necessary.5. Press the CALL key to send the message.6.5.6 Deleting send messageDeleting send messages individually1. Press the FILE/CURSOR key at the DSC standby screen to show the send message filelist.2. Rotate the ENTER knob to choose file desired and then push the ENTER knob.DETAILDELETE3. Rotate the ENTER knob to choose DELETE and then push the ENTER knob.6-11

6. MENU OPERATIONDeleting all messages1. Press the #/SETUP key.2. Rotate the ENTER knob to choose the MEM CLR.3. Rotate the ENTER knob to choose the MESSAGE FILES.4. Push the ENTER knob.5. Rotate the ENTER knob to choose YES.6. Push the ENTER knob.6.5.7 Printing List of Send Message FilesYou can print a list of send message files as follows:1. Press the FILE/CURSOR key to open the Send message file list.2. Press the 8/PRINT key.3. YES is selected; push the ENTER knob to print.********** Send message file **********001. FURUNO JAPAN INDIVIDUAL MESSAGE002. FURUNO USA INDIVIDUAL MESSAGE003. FURUNO UK PSTN MESSAGE004. FURUNO DENMARK GROUP MESSAGE005. FURUNO NORWAY INDIVIDUAL MESSAGE006. FURUNO SPAIN GROUP MESSAGE007. FURUNO FRANCE INDIVIDUAL MESSAGENote: Message not framed in actual printout.6.6 Manual Entry of Position and TimeIf there is no EPFS (Electronic Position-Fixing System) connected to this equipment or theEPFS connected is not working (EPFS error indication appears), manually enter positionand time as follows:1. Press the #/SETUP key.2. Rotate the ENTER knob to choose POSITION.3. Push the ENTER knob.** Position setup **Last updated: EPFSLAT : 34 41.0000 NLON : 135° 30.0000 ETIME: 09: 00 UTC“Last updated” shows the method used at the last time, EPFS, MANUAL or NO INFO(information).6-12

8.2 Station List8. NBDP PREPARATIONSThe station list provides for storage of up to 50 stations, one frequency pair (RX and TX) perstation. For stations which have more than one frequency pair, you might add a suffix to thestation name to denote multiple frequency pairs. For example, station name FURUNOfollowed by –1, -2, -3, etc. for each frequency pair required.8.2.1 Registering stations1. Press the function key F5 followed by the 1 key to show the Station Entry screen.Station EntryStation ListCreateChangeStation Set UpStation : _ID Code :Mode : ARQ FECCH/Table : Channel ScanTableNum/Table:Station entry screenOn the right-hand side of the screen, Create and Change are shown.2. Create should be underlined. If it is not, underline it by pressing →, ↑ and the Enter key.3. The cursor is now choosing Station. Enter station name, using up to 18 characters.4. Press the ↓ key to choose ID Code. Enter station ID code.5. Press the ↓ key to choose Mode. Choose communication mode with ← or → among thefollowing:ARQ: Automatic Retransmission RequestFEC: Forward Error Correction6. Press the ↓ key to choose CH/Table. Choose Channel or ScanTable as appropriate.7. Press the ↓ key to choose Num/Table.8-3

9. NBDP FILE OPERATIONS9.5 Opening FilesTwo working areas (called working area 1 and working area 2) are provided to which youcan load a file, and one file may be displayed on the LCD.9.5.1 Opening a file1. Insert the floppy disk which contains the file you want to open.2. Press the function key F1 to display the File menu.3. Press the 2 key. A chronological list of files on the floppy disk appears.Open TextLoad/Merge(TAB:Change)[A:\TEST1. ]File name Size Date & TimeLOG File 52 02-10-15 17:25TEST1. 120 02-10-15 16:30TEST2. 151 02-10-15 9:25TEST3. 180 02-10-15 20:16NBDP 169 02-10-15 6:23[ End of Directory ]4 Files exist 1454000 bytes freeTo select : ENTER To view : SPACE To quit : ESC4. Use the ↑ or ↓ key to choose a file.5. Press the Enter key.The file appears and the title bar shows the file name. You may repeat this procedure toload another file into a working area.Note: When two working areas have been opened, the close confirmation window appears.In this case, choose Yes or No and press the Enter key to close an open file in orderto open another file.9.5.2 Switching between filesTwo files can be opened and one displayed on the LCD. To switch between files do thefollowing:1. Press the function key F2.2. Press the A key to switch between files.9.6 Renaming FilesTo rename a file, do the following:1. Press the function key F1.2. Press the 5 key.3. Use the ↑ or ↓ key to choose a file and press the Enter key.9-7

10.2 ARQ Mode Operation10. NBDP TRANSMITTING, RECEIVINGIn ARQ operation, one station (information sending station) sends data to another block byblock, then listens for the acknowledge signal between blocks from the informationreceiving station which requests either the next block or retransmission of the last block ifthere is error. The request may be repeated up to 32 times, until the complete block isreceived free of error.Establishing connection1. Press the function key F3 to display the Operate menu.1: Call Station2: Macro Operation3: File to Send4: Cancel Sending5: Scan (Start/Stop)6: Manual Reception7: Timer Operation8: Manual Calling9: Set FrequencyOperate2. Press the 1 key to choose Call Station.1:File 2:Edit 3:Operate 4:Window 5:Station 6:System 7:WRU 8:HR 9:Over 10:Break2002-01-15 14:41:09 UTC Caps-EngStation Name : CHOUSHI-8MFrequency (T/R) : 8765.00 / 8965.00(kHz) Call Station Comm Mode :AQWComm Status Station : Connect ListSend Lock Error Station Mark Space SetupSending Volume : 100(%) ARQ Error : 0 ARQ Time : 0(sec)ABC-4MStation : ABC-4MABC-6MID Code : 45678ABC-12MMode : ARQ FECABC-8MFURUNOCH/Table : Channel ScantableNum/Table:Call Station menu3. Choose a station. (Station must be registered for use in the ARQ mode). Press theEnter key. The message “Calling Station” appears. If the message shown belowappears, check both the power of the radiotelephone and the connections between theradiotelephone and the NBDP Terminal Unit.“Station calling suspended. Check interconnections between the terminal and main units.Press any key to escape.”4. When an acknowledge signal is detected, “Connect” appears in reverse video on thecommunication status display.10-3

10. NBDP TRANSMITTING, RECEIVING10.5 Communication ExampleCall the coast station following the procedure in paragraph 10.2. Then, communicate withthe coast station. Below is a communication example.Call completed,connected withcoast station12345 KOBE XTo send messageto shipOwn answerback codeIf this is your firstcommunications with aparticular coast station,the coast station asksfor you selcall no. shipname, call sign andAAIC (your enterprisesname for which tocharge to charge tollcall. That registers youwith the coast station.Thereafter, if youranswerback code iscorrect automatictransmission is possible.Selcall No. Ship name or call sign1480 HKRDO VRXMOMGA+?OPR+MOM1480 HKRDO VRX12345 KOBE XKOBE DE HKRDO GOOD MORNINGNW NIL QRV GA+?GM NWQRV KKKKK QSL +?End message.QTC1+?GA+?TOR Teleprinting Over Radio(Message TX starts.)NR 9004 Msg No.TO: TELEX 1234567 FURUNOJAPAN OFFICEINT. DEP. SEC-1 MANAGERFM: KOBE MARU/12345 KOBE XTEXT:Type message.Automatically sent from Coaststation (ex. Hong Kong)Type at your side within 30 s.(Call operator manually.)Message from coast station(Wait. From HKRDO to KOBE.Nothing to send. Do youhave anything to send?)Type at your side(GM=Good Morning. I havea message for you.)From coast station.(Send your message.)Type at your side(To send a message file, typeMOM before TOR and waitawhile.)Receiver: Telex no.1234567FURUNO ELEC. CO.Sende: KOBE MARUType messageMessage finished. Can youacknowledge receipt)Coast station disconnects the line.KOBE DE HKRDO QSL NR9004TKS NW NIL +?TKS NW NIL BIBI +?TKS SEE YOU LATERBIBIFrom coast stationFrom HKRD0 to KOBE.Received NR9004. Thank you.No more to send.Type at your ship(Thank you. I have nothing tosend. Bye Bye.From coast stationThank you. See you later.)Communications example10-6

10. NBDP TRANSMITTING, RECEIVING10.9.2 PreparationsTo use automatic telex, you will need to register three items:• Answerback code• Scan groups• Station namesRegistering answerback codeThe coast station assigns a Telex number. This number functions as an answerback code.An answerback code contains the following:OOOOO SHIP XOOOOO: Coast station-assigned five-digit telex codeSHIP: Ship nameX: For shipboard station, normally X is entered.The procedure for registering the answerback code is the same as which appears on page8-1. If an answerback code was registered before the commissioning of the coast station, anew answerback code must be entered. To enter a new answerback code, contactFURUNO or an authorized FURUNO agent or dealer.Registering scan groupsThe central system emits a free-signal to indicate a coast station radio channel is in idlecondition and available for ship-to-shore calls. The free-signal is detected and recognizedby the shipboard equipment as a permission to start the transmission. Then, the shipboardoperator initiates a call.You can scan search for the free-signal automatically by registering coast station radiochannels in scan group(s). The procedure for registering scan groups for coast station useis the same as that which appears on page 8-7.Registering stationsThe next step is to enter station name. The procedure is the same as that shown on page8-3.10-11

10. NBDP TRANSMITTING, RECEIVINGProcedure for DIRTLXNo.ProcedureDisplayRemarks1 Calla coast . station.2 Transmit WRU signal.3 Key in subscriber"s Telex number.Example: (Japan) 5644325CONNECT appearsin reverse video(and bell sounds).00190 TLG DK26 X X X SHIP XGA+?Free-signal found;radio circuit ready.Initial identityexchange between coaststation and shipboardstationDIRTLX725644325+4 Transmitfile.5 When transmission is completed,type KKKK.12:20MOM5644325 FURUNO JMSG+26 X X X SHIP X5644325 FURUNO J00190 TLG DKDURATION ...TIME ...GA+?Request to startmessage transmissionMessage transmissionTransmit youranswerback code.Receive other party"sanswerback code.6 Transmit BREAK command toclear radio circuit.10-16

11. MAINTENANCE & TROUBLESHOOTING11.2 MaintenanceRegular maintenance is vital for maintaining performance. Following the procedures belowwill help keep the equipment in top operating condition.Maintenance check pointsItem Check Point Remedy/RemarksAntenna Check for physical damage andcorrosion.Replace damaged parts.WireantennaInsulatorsfor antennaAntennacouplerControlunitTransceiverunitPower supplyCheck that the antenna is properlyspanned and separated sufficientlyfrom metallic structures.Check for salt water deposits oninsulators. Check that connection atthe lead-in insulator is tight andrust-free.• Check condition of antenna terminal,ground, coaxial cable and controlcable.• Check that coupler lid and cableglands are firmly secure.Check for physical damage, corrosionand salt water deposits.• Check ground connection, controlcable, and external equipment.Confirm that there are no objects onthe top of the control unit.• Remove dust from control unit withsoft cloth.Note: Do not use chemical cleaners toclean the control unit; they can removepaint or markings or deform theequipment.• Check connection at signal cable,coaxial cable, control cable, powercable, and navigator.• Confirm that there are no objects onthe top of the cabinet.• Check that the supply voltage attransmission is within the rated range(21.6 to 31.2 VDC at the powerconnector).If necessary, re-span antenna.Replace damage insulators. Removesalt water deposits. Clean with freshwater, then dry. Remove rust, thentighten bolts and lock nuts. Covermetallic surface with sealingcompound.• Tighten loosenedconnections.• Fasten lid firmly and evenly toprevent water leakage.• Replace if damaged.• Tighten loosenedconnections; remove foreignmaterial from connectors.• Remove any objects.• Wipe the LCD carefully toprevent scratching, usingtissue paper and an LCDcleaner. To remove dirt or saltdeposits, use an LCD cleaner,wiping slowly with tissuepaper so as to dissolve thedirt or salt. Change paperfrequently so the salt or dirtwill not scratch the LCD.• Tighten loosened connections;remove foreign material fromconnectors.• Remove any objects.• If not within the range, checkship’s mains or ship’s battery.Low voltage may causeerratic operation.11-2

11. MAINTENANCE & TROUBLESHOOTING* Received message *MAR-23-2006-23:59TEST ACKNOWLEDGEMENTSENDER ID : 001234567PRIORITY: SAFETY3M10SGO TO VIEWNo response! Try calling again?Re-send call: Push the ENTER knob and then press the CALL key.Cancel call: Press the CANCEL key to return to the previous screen.11.7 NBDP Terminal Unit MaintenanceRegular maintenance is important for good performance. A regular maintenance programshould be established and should at least include the items mentioned below.11.7.1 Cleaning the equipmentWipe off accumulated dust from the terminal unit with a soft cloth. Wipe the LCD carefully toprevent scratching, using tissue paper and an LCD cleaner. To remove dirt or salt deposits,use an LCD cleaner, wiping slowly with tissue paper so as to dissolve the dirt or salt.Change paper frequently so the salt or dirt will not scratch the surface of LCD. Do not usesolvents such as thinner, acetone or benzene for cleaning; they can remove paint andmarks or deform the equipment.11.7.2 Connectors and earth connectionPeriodically check the connectors for proper seating and the earth connection for rust.Remove rust to maintain a good ground system.11.7.3 Floppy disk driveForeign material on the floppy disk drive head can scratch the magnetic material in thefloppy, resulting in loss of data. Clean the floppy disk drive head regularly with a floppy diskdrive cleaning disk to prevent erasure of information stored on disks.11.7.4 DiagnosticsGeneral diagnostics1. Press the function key F6 to display the System menu.11-8

APPENDIXMF band working carrier frequencies (ref. US CFR 47 Part 80.371)RegionShip Transmit Ship ReceiveShip Transmit Ship ReceiveRegion(kHz)(kHz)(kHz)(kHz)EastCoast2031.52490.0 GulfCoast2009.02466. 02118.02514.02134.02530. 02126.02522.02142.02538. 02142.02538.012158.02550. 02166.02558.02166.02558. 02198.02590.02206.02598. 02366.02450.02366.02450. 02382.02482.02382.02482. 02390.02566.02430.02572. 02400.02400.02458.02506. 02406.02506.0 GreatLakes22118.02514. 0WestCoast2003.02450.02158.02550. 02009.02442.02206.02582. 02009.02566.0 Alaska2131.02309. 02031.52566.02134.02312. 02126.02522.02240.02400. 02206.02598.0 Hawaii2134.02530. 02382.02466.0 Caribbean2009.02506. 02430.02482.032086.02585. 02134.02530. 0Guam2009.02506. 0Above frequencies are not programmed. Contact a FURUNO representative.1 = Unlimited use December 15 to April 12 = 2206 kHz for distress only3 = Limited to pep of 150 W.AP-5

APPENDIXParts ListThis equipment contains complex modules in which fault diagnosis and repair down tocomponent level are not practical (IMO A.694(17)/8.3.1). Only some discrete componentsare used. FURUNO Electric Co., Ltd. Believes identifying these components is of no valuefor shipboard maintenance; therefore, they are not listed in this manual. Major modules canbe located on the parts location photos on pages AP-26 thru AP-30.Transceiver unit FS-1570TF U R U N O Model FS-1570TUnitTRANSCEIVER UNITELECTRICAL PARTS LISTAug-02 Blk.No.SYMBOL TYPE CODE No. REMARKS SHIPPABLEASSEMBLYPRINTED CIRCUIT BOARDB2 05P0731, T-I/F 005-963-050 XB3 05P0732B, T-CPU 001-033-810 XB4 05P0733, TX/RX 005-963-090 XB5 05P0734A, W/R 001-005-370 XB6 05P0735, PA 005-963-130 XB7 05P0736, TX-FIL 005-963-150 XB8 05P0737A, SW-REG 001-005-390 XB9 05P0742, MB 005-963-210 XB10 05P0746, PRESEL 005-963-250 XB11 05P0747, REF OSC 005-963-270 XB13 05P0751B, DSP (DSC) 001-010-380 XB14 05P0751A, DSP (NBDP) 005-963-310 XB17 05P0744, RELAY 005-963-230 XAP-22

FURUNOFS-1570/2570/5070SPECIFICATIONS OF SSB RADIOTELEPHONEFS-1570/2570/50701 MF/HF DIGITAL RADIOTELEPHONE1.1 GENERAL1.1.1 Communication system Full-duplex* 1 , semi-duplex or simplex1.1.2 Class of emission J3E: TelephoneJ2B (F1B): DSC and NBDPH3E: reception only1.1.3 Frequency range 100.00 kHz to 29,999.99 kHz1.1.4 Number of channel User programmable: 256 TX/RX pairsAll ITU channels incorporated (include DSC/NBDP channel)2182 kHz (single action)1.1.5 Display method Monochrome LCD (180 x 96 dots)1.1.6 Backlight 8 tones1.1.7 Contrast 64 steps1.1.8 Warming up 1 minute approx. (oven 20 minutes approx.)* 1 : Operating frequency should not be higher than 22 MHz for full-duplex communication,FS-5070 only1.2 TRANSMITTER1.2.1 Frequency range 1,606.5 kHz to 26.175 MHz (100 Hz step)1.2.2 RF output power FS-1570: 1.6 kHz-4 MHz: 75/100 Wpep (J3E, J2B (F1B))4.0-26.175 MHz, 150 Wpep (J3E, J2B (F1B))FS-2570: 1.6-4.00 MHz, 75/100/200 Wpep (J3E, J2B(F1B))WpepFS-5070: 1.6-4.0 MHz, 400 Wpep, 4kHz-26.175 MHz: 500Wpep* 21.2.3 Frequency error Within ±10 Hz1.2.4 Modulation AF response 350 Hz to 2.7 kHz (SSB)1.2.5 Modulation system Low power balanced modulation1.2.6 AF Input -46 dBm/600 ohm (Handset/Microphone)1.2.7 Line in 0 dBm/600 ohm* 2 : RF output power should be restricted to 400W on NBDP.1.3 RECEIVER1.3.1 Receiving system Double-conversion superheterodyne1.3.2 Frequency range 100 kHz-29,999.99 kHz (10 Hz step)SP - 1E5656S01A-M080414

FURUNOFS-1570/2570/50701.3.3 Sensitivity Input level at 10 ohm+250 pF (below 4 MHz) and 50 ohm(above 4MHz) to produce SINAD 20 dBFrequency Range J3E/H3E100 kHz to 300 kHz 35 dBµV300 kHz to 1.6 MHz 25 dBµV1.6 MHz to 4.0 MHz 13 dBµV4.0 MHz to 30 MHz 7 dBµV1.4 Intermediate frequency 1st: 72,455 kHz, 2nd: 455 kHz1.5 Selectivity J3E: 2.4kHz at -6dB, H3E: 6kHz at -6dB, J2B (F1B): 300Hz at –6dB1.6 Inter-modulation Better than 80 dBµV1.7 Spurious response Better than 70 dB1.8 AGC SLOW/FAST/OFF1.9 BFO frequency Telex/DSC: 1,700 Hz, Facsimile: 1,900 Hz1.10 Audio output power FS-1570/2570: Internal speaker: 3W/8 ohmExternal speaker: 4W/4 ohmFS-5070:Internal speaker: 1W/8 ohmExternal speaker: 3W/4 ohmHandset: 2.5mW/150 ohm, Line output: 0 dBm/600 ohm1.11 Standard features Noise Blanker, Voice-activated squelch, Pre-selector2 DSC/WATCH KEEPING RECEIVER2.1 DIGITAL SELECTIVE CALLING2.1.1 Frequency shift Space: 1785.0 ± 0.5 Hz, Mark: 1615.0 ± 0.5 Hz2.1.2 Baud rate 100 bps ± 30 x 10 -62.1.3 Protocol FS-1570/2570: ITU-R Rec.M493-10, M541-8, M1082-1FS-5070: ITU-R Rec.493-11, 541-92.1.4 Modulation AFSK2.1.5 Distress alarm 3.5 s to 4.5 s self-repetition2.1.6 Distress alarm memory 50 messages2.2 DSC/WATCH RECEIVER (FS-1570/2570)2.2.1 Frequency rangeDISTRESS2187.5/ 8414.5 and 4207.5/ 6312/12577/16804.5 kHzROUTINE2187.5 kHz2.2.2 Class of emission F1B, J2B2.2.3 Antenna impedance 50 ohm2.2.4 Local oscillator 1st: F+54,455 kHz, 2nd: 54,000 kHz, 3rd: 456.7 kHz2.2.5 Frequency stability ±10 Hz2.2.6 Intermediate frequency 1st: 54,455 kHz, 2nd: 455 kHzSP - 2E5656S01A-M080414

FURUNOFS-1570/2570/50702.2.7 Selectivity -6 dB: 270 Hz to 300 Hz, -30 dB: within ± 380 Hz,-60 dB: within ± 550 Hz2.2.8 Receiving system Double-conversion superheterodyne2.2.9 Radiation within 4 nW2.2.10 RX error rate 1 % or less at 1 µV input voltage2.2.11 Spurious response 31.6mV non-modulated at 10µV input voltage,at error rate within 1%2.2.12 Scanning reception max. 6 frequencies within 2 s (MF/HF)2.2.13 Diagnosis Transmit high frequency signal of DSC2.3 DSC/WATCH RECEIVER (FS-5070)2.3.1 Frequency rangeDISTRESS2187.5/ 8414.5 and 4207.5/ 6312/12577/16804.5 kHzROUTINE1,606.5 kHz to 27.5 MHz2.3.2 Class of emission F1B, J2B2.3.3 Antenna impedance 50 ohm2.3.4 Local oscillator 1st: F+54,455 kHz, 2nd: 54,000 kHz, 3rd: 456.7 kHz2.3.5 Frequency stability ±10 Hz2.3.6 Intermediate frequency 1st: 54,455 kHz, 2nd: 455 kHz2.3.7 Selectivity -6 dB: 270 Hz to 300 Hz, -30 dB: within ± 380 Hz,-60 dB: within ± 550 Hz2.3.8 Receiving system Double-conversion superheterodyne2.3.9 Radiation within 2 nW2.3.10 RX error rate 1 % or less at 1 µV input voltage2.3.11 Spurious response 31.6mV non-modulated at 10µV input voltage,at error rate within 1%2.3.12 Scanning reception max. 6 frequencies within 2 s (MF/HF)2.3.13 Diagnosis Transmit high frequency signal of DSC2.4 GENERAL Watch KEEPING receiver (FS-2570, option)2.4.1 Frequency Range 1,606.5 kHz to 27.5 MHz2.4.2 Class of Emission J2B, F1B2.4.3 Antenna Impedance 50 ohms2.4.4 Local Oscillator 1st: F+54,455 kHz, 2nd: 54,000 kHz, 3rd: 456.7 kHz2.4.5 Frequency Stability within ±10 Hz2.4.6 Intermediate Frequency 1st: 54,455 kHz, 2nd: 455 kHz2.4.7 Selectivity -6 dB: 270 Hz to 300 Hz,-30 dB: within ± 380 Hz,SP - 3E5656S01A-M080414

FURUNOFS-1570/2570/5070-60 dB: within ±550 Hz2.4.8 Receiving System Double-conversion superheterodyne2.4.9 Radiation within 2 nW2.4.10 RX Error Rate 1 % or less at 1 μV input voltage2.4.11 Spurious Response 31.6 mV non-modulated at 10μV input voltage,at error rate within 1%2.4.12 Scanning Reception max. 6 frequencies within 2 s (MF/HF)2.4.13 Diagnosis Transmit high frequency signal of DSC3 NBDP FUNCTION (OPTION)3.1 GENERAL3.1.1 Communication mode ARQ, FEC, DIRC (FSK)3.1.2 Protocol ITU-R M625-3, M476-5, M490, M491-1, M492-6ID code4, 5, 9 columnLine cord4B/3Y (Intl.)ModulationAFSKTone frequency 1615/1785Hz ± 0.5 Hz (mark/space)Tracking range ±80 Hz3.1.3 ApplicationsAuto-reception Setting timer and frequency (max. 10 settings available)Frequency scanning 10 group max., 20 station as each groupUser-channels 100 channels max.3.2 TERMINAL UNIT IB-581 (FS-1570/2570)3.2.1 Display 9.5” monochrome LCD, 680 x 480 dots3.2.2 CPU ALI M6117 (33 MHz)3.2.3 Memory Flash ROM 2 MB, DRAM 2 MB3.2.4 FD Drive 1.44MB 3.5”3.2.5 Keyboard 82 keys, IBM PS/23.3 TERMINAL UNIT IB-5833.3.1 Display 10.4” color TFT LCD, 640 x 480 dots3.3.2 CPU HD6417615 (15.5 MHz)3.3.3 Memory Flash ROM: 1 MB, S-RAM: 256 KB3.3.4 FD drive 1.44MB 3.5”3.3.5 Keyboard 82 keys, IBM PS/23.3.6 Other functions Text editor, FD control, Printer, Remote control for Transceiver,DiagnosisSP - 4E5656S01A-M080414

FURUNOFS-1570/2570/50704 ANTENNA COUPLER (FS-1570/2570)4.1 Tuning System CPU controlled fully automatic tuning system4.2 Frequency Range 1.6 MHz to 27.5Hz4.3 Input Impedance 50 ohms4.4 Antenna 7m to 18m wire or whip antenna4.5 Power Capability 150 W (FS-1570), 250 W (FS-2570)4.6 VSWR 1.5 max4.7 Tuning Speed Within 15 s4.8 Dummy Load FS-1570: 10 ohms+250 pF/100WFS-2570: 10 ohms+250 pF/200W5 ANTENNA COUPLER (FS-5070)5.1 Tuning system CPU controlled fully automatic tuning system5.2 Frequency range 1.6MHz to 29.9 MHz5.3 Input impedance 50 ohm (viewed from transceiver)5.4 Antenna 10 m to 18 m wire or whip antenna + wire5.5 Pre-tuning power 10 W5.6 VSWR less than 1.55.7 Tuning time 0.2 to 2 seconds typical (within 2 to 15 seconds)5.8 Antenna BK relay Internal, optional supply6 INTERFACE6.1 Input data sentences IEC 61162-1 (NMEA 0183-3)Ship’s Position (L/L) GGA>RMC>GLLTimeZDA7 POWER SUPPLY7.1 Transceiver/control unit FS-1570: 24 VDC, 0.8 A, max. 20A (TX)FS-2570: 24 VDC, 1.5 A, max. 35A (TX)FS-5070: 24 VDC, 3 A (RX), max. 35 A (TX)7.2 Terminal unit IB-581: 24VDC, 0.8 AIB-583: 24 VDC: 0.6 A7.3 Printer (PP-510) 24 VDC: 1.5 A7.4 AC/DC power supply unit 100/110/115/220/230 VAC, 1Ø, 50/60Hz8 ENVIRONMENTAL CONDITION8.1 Ambient temperatureIndoor units-15°C to +55°CAntenna coupler -25°C to +55°C8.2 Relative humidity 93% or less at 40°CSP - 5E5656S01A-M080414

FURUNOFS-1570/2570/50708.3 Degree of protectionControl unitIPX2 (panel), IPX0 (chassis)Transceiver/terminal unit IPX0Antenna coupler IPX5 (FS-1570/2570), IPX6 (FS-5070)8.4 Bearing vibration 2 Hz-5Hz to 13.2 Hz: Amplitude: ±1 mm±10%13.2 Hz to 100 Hz: Max. acceleration 7m/s 2 , fixed9 COATING COLOR9.1 Control/terminal unit N3.0 (panel), 2.5GY5/1.5 (chassis)9.2 Transceiver unit 2.5GY5/1.59.3 Antenna coupler N9.5 (white)SP - 6E5656S01A-M080414

Declaration of Conformity9-52 Ashihara-cho, Nishinomiya, 662-8580, JapanTel: +81 (798) 65-2111 Fax: +81 (798) 65-4200www.furuno.co.jpPublication No. DOC-1027WeFURUNO ELECTRIC CO., LTD.-----------------------------------------------------------------------------------------------------------------------------------------------(Manufacturer)9-52 Ashihara-Cho, Nishinomiya City, 662-8580, Hyogo, Japan-----------------------------------------------------------------------------------------------------------------------------------------------(Address)declare under our sole responsibility that the productMF/HF SSB Radiotelephone Type FS-1570 consisting of Control unit FS-2570C/FS-2571C, Transceiver unit FS-1570T, Handset/Bracket HS-2001/HS-2003/HCS701K-B20, Antenna coupler AT-1560-15, Incoming call indicator IC-303-DSC, Telex distress alert button IC-302-DSC, Alarm unit IC-350, NBDP-controller monochrome display IB-581, NBDPcontrollercolor display IB-582/IB-583, Printer PP-510, Printer switch box IF-8500, Distress message controller DMC-5, 2.6m active whip antenna for WKR FAX-5, External loudspeaker SEM-21Q and AC power supply PR-300/PR-850A-----------------------------------------------------------------------------------------------------------------------------------------------(Model name, type number)to which this declaration relates conforms to the following standard(s) or normative document(s)StandardsTest standardsIMO Resolutions MSC.36(63), A.694(17) ETS 300 338: 1995-11, ETS 300 373: 1995-08,IMO Resolutions MSC.68(68), A.806(19) ETS 300 067 A1: 1998-11, EN 301 033 V1.1.1: 1998-08IMO MSC Circular MSC/Circ.862 EN 60945: 1997-01, EN 61162-1: 2000-07ITU-R Recommendations M.1173, M.1082-1, M.821-1, M.493-10, M.493-11, M.493-12, M.541-8, M.541-9,M.476-5, M491-1. M.492-6, M.625-3-----------------------------------------------------------------------------------------------------------------------------------------------(title and/or number and date of issue of the standard(s) or other normative document(s))For assessment, see• EC type-examination (Module B) certificate N o : 02212010/AA/04 of 02 July 2008 issued by Telefication, TheNetherlands• Product Quality System (Module D) certificate No. P 112 of 20 May 2005 issued by Telefication, The Netherlands• Test report 98752230, 98752232 and 98752234 of 17 June 2002 issued by Telefication, The Netherlands• Test reports FLI 12-02-019 of 20 May 2002, FLI 12-02-036 of 30 August 2002, FLI 12-08-014/Rev.A/FLI 12-08-024/Rev.A of 11 June 2008 and FLI 12-08-028/FLI 12-08-030 of 30 June 2008 issued by Furuno LabotechInternational Co., Ltd.This declaration is issued according to the provisions of European Council Directive 96/98/EC on marineequipment modified by Commission Directive 2002/75/EC.On behalf of Furuno Electric Co., Ltd.0560Nishinomiya City, JapanJuly 9.2008------------------------------------------------------(Place and date of issue)Hiroaki KomatsuManager,International Rules and Regulations----------------------------------------------------------------------------------(name and signature or equivalent marking of authorized person)

Declaration of Conformity9-52 Ashihara-cho, Nishinomiya, 662-8580, JapanTel: +81 (798) 65-2111 Fax: +81 (798) 65-4200www.furuno.co.jpPublication No. DOC-1028WeFURUNO ELECTRIC CO., LTD.-----------------------------------------------------------------------------------------------------------------------------------------------(Manufacturer)9-52 Ashihara-Cho, Nishinomiya City, 662-8580, Hyogo, Japan-----------------------------------------------------------------------------------------------------------------------------------------------(Address)declare under our sole responsibility that the productMF/HF SSB Radiotelephone Type FS-2570 consisting of Control unit FS-2570C/FS-2571C, Transceiver unit FS-2570T, Handset/Bracket HS-2001/HS-2003/HCS701K-B20, Antenna coupler AT-1560-25, Incoming call indicator IC-303-DSC, Telex distress alert button IC-302-DSC, Alarm unit IC-350, NBDP-controller monochrome display IB-581, NBDPcontrollercolor display IB-582/583, Printer PP-510, Printer switch box IF-8500, Distress message controller DMC-5, 2.6 mactive whip antenna for WKR FAX-5, External loudspeaker SEM-21Q and AC power supply PR-850A-----------------------------------------------------------------------------------------------------------------------------------------------(Model name, type number)to which this declaration relates conforms to the following standard(s) or normative document(s)StandardsTest standardsIMO Resolutions MSC.36(63), A.694(17) ETS 300 338: 1995-11, ETS 300 373: 1995-08,IMO Resolutions MSC.68(68), A.806(19) ETS 300 067 A1: 1998-11, EN 301 033 V1.1.1: 1998-08IMO MSC Circular MSC/Circ.862 EN 60945: 1997-01, EN 61162-1: 2000-07ITU-R Recommendations M.1173, M.1082-1, M.821-1, M.493-10, M.493-11, M.493-12, M.541-8, M.541-9,M.476-5, M491-1. M.492-6, M.625-3-----------------------------------------------------------------------------------------------------------------------------------------------(title and/or number and date of issue of the standard(s) or other normative document(s))For assessment, see• EC type-examination (Module B) certificate N o : 02212010/AA/04 of 02 July 2008 issued by Telefication, TheNetherlands• Product Quality System (Module D) certificate No. P 112 of 20 May 2005 issued by Telefication, The Netherlands• Test report 98752231, 98752233 and 98752235 of 17 June 2002 issued by Telefication, The Netherlands• Test reports FLI 12-02-019 of 20 May 2002 and FLI 12-02-036 of 30 August 2002, FLI 12-08-014/Rev.A/FLI 12-08-024/Rev.A of 11 June 2008 and FLI 12-08-028/FLI 12-08-030 of 30 June 2008 issued by Furuno LabotechInternational Co., Ltd.This declaration is issued according to the provisions of European Council Directive 96/98/EC on marineequipment modified by Commission Directive 2002/75/EC.On behalf of Furuno Electric Co., Ltd.0560Nishinomiya City, JapanJuly 9, 2008------------------------------------------------------(Place and date of issue)Hiroaki KomatsuManager,International Rules and Regulations----------------------------------------------------------------------------------(name and signature or equivalent marking of authorized person)

Declaration of Conformity9-52 Ashihara-cho, Nishinomiya, 662-8580, JapanTel: +81 (798) 65-2111 Fax: +81 (798) 65-4200www.furuno.co.jpPublication No.DOC-1029WeFURUNO ELECTRIC CO., LTD.-----------------------------------------------------------------------------------------------------------------------------------------------(Manufacturer)9-52 Ashihara-Cho, Nishinomiya City, 662-8580, Hyogo, Japan-----------------------------------------------------------------------------------------------------------------------------------------------(Address)declare under our sole responsibility that the productHF/MF SSB Radiotelephone with integrated DSC and NBDP Type:FS-5070 consisting ofTransceiverunitFS-5070T,ControlunitFS-2571C ,Antenna couplerAT-5000,Handset/BracketHS-2003,Distress alertunitIC-302-DSC,Receiving ca lunitIC-303-DSC,Alarm unitIC-350,TerminalunitIB-583,Keyboard BTC-5100C ,Interface IF-8500,Pre-am plifierFAX-5,ExternalloudspeakerSEM 21Q,BK interface BK-300,PrinterPP-510,AC pow ersupply PR-850A and Powerstatus m onitorPSM -01-----------------------------------------------------------------------------------------------------------------------------------------------(Model name, type number)to which this declaration relates conforms to the following standard(s) or normative document(s)StandardsTest standardsIMO Resolutions MSC.36(63), A.694(17) EN 300 338 V1.2.1: 1999-04, EN 300 373-1 V1.2.1: 2002-10IMO Resolutions MSC.68(68), A.806(19) ETS 300 067: 1990-11, ETS 300 067/A1: 1993-11IMO MSC Circular MSC/Circ.862 EN 301 033 V1.1.1: 1998-08EN 60945: 2002-10, EN 61162-1: 2000-07ITU-R Recommendations M.1173, M.1082-1, M.821-1, M.493-10, M.493-11, M.493-12, M.541-8, M.541-9,M.476-5, M491-1. M.492-6, M.625-3-----------------------------------------------------------------------------------------------------------------------------------------------(title and/or number and date of issue of the standard(s) or other normative document(s))For assessment, see• EC type-examination (Module B) certificate N o : 06212004/AA/01 of 02 July 2008 issued by Telefication, TheNetherlands• Product Quality System (Module D) certificate No. P 112 of 20 May 2005 issued by Telefication, The Netherlands• Test report 98752231, 98752233 and 98752235 of 17 June 2002 issued by Telefication, The Netherlands• Test reports FLI 12-02-019 of 20 May 2002 and FLI 12-02-036 of 30 August 2002, FLI 12-08-014/Rev.A/FLI 12-08-024/Rev.A of 11 June 2008 and FLI 12-08-028/FLI 12-08-030 of 30 June 2008 issued by Furuno LabotechInternational Co., Ltd.This declaration is issued according to the provisions of European Council Directive 96/98/EC on marineequipment modified by Commission Directive 2002/75/EC.On behalf of Furuno Electric Co., Ltd.0560Nishinomiya City, JapanJuly 9, 2008------------------------------------------------------(Place and date of issue)Hiroaki KomatsuManager,International Rules and Regulations----------------------------------------------------------------------------------(name and signature or equivalent marking of authorized person)
