There are various panel technologies. Each has its own specific features - viewing angles, color reproduction, response time, brightness/contrast, production cost, etc. The image quality depends directly on the type of the display panel used.VA

The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.10 bits

The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.1073741824 colors

The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.Direct LED (Full-Array Local Dimming)

3D TVs use either "Passive" or "Active" technology to present 3D. Passive type TVs typically have a brighter picture but reduced image resolution (except on UHD TVs). Active systems typically present 3D at full screen resolution but image brightness is lower than when viewing programs in regular 2D. Active 3D TVs now use very light weight 3D glasses, comparable to those for Passive TVs.

The number of special 3D eyeglasses included with the 3D TV. Some 3D TVs omit this item to control costs. Some 3D Blu-ray players may include these glasses. Retailers may offer a "3D TV + Blu-ray" bundle that also includes the glasses. All of the 3DTVs in our Ratings require the viewer to don special eyeglasses. So-called "active" 3D sets, which require "active" battery-powered LCD shutter glasses, may come with one or more pairs, or none. Additional pairs generally cost from $50 to $150 each. Most so-called "passive" 3D TVs come with four pairs of passive polarized glasses, much like the ones used in theaters, which don"t require batteries. Additional sets cost from $10 to $30 each. You cannot use passive glasses with 3DTV that requires active glasses, and vice-versa. You also generally cannot mix active 3D glasses from one brand of TV with another"s, though TVs made in 2012 and later may share glasses. (Passive 3D glasses can be used interchangeably with any passive 3D TVs.) There are some "universal" active 3D glasses you can buy as an after-market item .

The height of the TV in inches, rounded up to the nearest 0.25-inch. Dimensions include the base and detachable speakers, important if you plan to place the TV on a stand or in an entertainment center. See "Panel size without base" if you plan to wall-mount only the display.

The width of the TV in inches, rounded up to the nearest 0.25-inch. Dimensions include the base and detachable speakers, important if you plan to place the TV on a stand or in an entertainment center. See "Panel size without base" if you plan to wall-mount only the display.

The depth of the TV in inches, rounded up to the nearest 0.25-inch. Dimensions include the base and detachable speakers, important if you plan to place the TV on a stand or in an entertainment center. See "Panel size without base" if you plan to wall-mount only the display.

Dimensions of the display panel only, not including the base, rounded up to the nearest 0.25-inch. Also see "Overall height (in.)", "Overall width (in.)", and "Overall depth (in.)".

Fixed-pixel display types such as LCDs and OLEDs have a native resolution. It sets an upper limit of how sharp images may look. Native resolution is expressed in horizontal by vertical pixels (for example: 1920x1080 for an HD display, 3840x2160 for UHD).

Almost all UHD TVs can display a special kind of video content called High-Dynamic Range (HDR) video. There are several standard types of HDR signals, with "HDR10" being the most common.

The total number of HDMI inputs on the TV. HDMI (High-Definition Multimedia Interface) is a digital audio/video connection found on TVs, monitors, Blu-ray players, DVD players, receivers, computers, cameras and digital TV tuners. HDMI is the preferred type of A/V connection between TV and device, instead of the old analog methods (component, composite, or RF - all still found on many cable boxes).

Component/Composite-video shared inputs (total/aux). One of the three component video input RCA jacks doubles as a composite-video input. This means you can only plug in one type or the other at any given time.

VGA (Video Graphics Array) connector is essentially a standard connection for video on old computers and old monitors, and is rare on new TVs, in favor of an HDMI connection. This type of input is no longer available on most TVs.

That"s because the 43- and 50-inch sizes lack the local dimming that was so effective on the 65-inch size I tested. Meanwhile most of the smaller models use an IPS-based ("in-plane switching") LCD panel, and the IPS panel on the 50-incher I tested delivers inferior image quality. Only the 60-inch and larger sizes that have the winning combination of local dimming and VA (vertical alignment, and non-IPS) LCD panels.

Vizio says the E55-E2 may use either an IPS or a VA panel. Here"s its statement: "[The E55-E2 will] start shipping with VA panels and then may move to IPS panel technology if demand increases. It is difficult to say when the IPS panels will cut in, but your readers can use the following serial number prefix on the box to identify models with IPS panels. If the fourth digit of the serial number is a "J" or "7," that unit uses an IPS panel. Ex. LWZJSEARxxxxxxx or LTM7SHARxxxxxxx. All other serial numbers will be units using VA panels."

Video processing:The E series handled 24-frame content properly, with the smooth but not too smooth look of film. Motion resolution was typical of a 60Hz TV, the panel"s native refresh rate, despite Vizio"s "120Hz effective" fake specification. The E65"s "Clear Action 180" improve motion performance to 600 lines, but it wasn"t worth the trade-off in brightness or flicker.

There are many types of vizio e series tv you can buy. Some are basic, while others are advanced. You need to determine what type of product you need and then buy one that fits your needs. For example, if you want a simple product, the best choice is a basic one. However, suppose you want something more advanced. In that case, it’s better to get an expensive one because it will have extra features.

So, why is this important? A monitor’s panel technology is important because it affects what the monitor can do and for which uses it is best suited. Each of the monitor panel types listed above offer their own distinctive benefits and drawbacks.

Choosing which type of monitor panel type to buy will depend largely on your intended usage and personal preference. After all, gamers, graphic designers, and office workers all have different requirements. Specific types of displays are best suited for different usage scenarios.

The reason for this is because none of the different monitor panel types as they are today can be classified as “outstanding” for all of the attributes mentioned above.

Below we’ll take a look at how IPS, TN, and VA monitors affect screen performance and do some handy summaries of strengths, weaknesses, and best-case uses for each type of panel technology.

IPS monitors or “In-Plane Switching” monitors, leverage liquid crystals aligned in parallel to produce rich colors. IPS panels are defined by the shifting patterns of their liquid crystals. These monitors were designed to overcome the limitations of TN panels. The liquid crystal’s ability to shift horizontally creates better viewing angles.

IPS monitor variations include S-IPS, H-IPS, e-IPS and P-IPS, and PLS (Plane-to-Line Switching), the latter being the latest iteration. Since these variations are all quite similar, they are all collectively referred to as “IPS-type” panels. They all claim to deliver the major benefits associated with IPS monitors – great color and ultra-wide viewing angles.

With regard to gaming, some criticisms IPS monitors include more visible motion blur coming as a result of slower response times, however the impact of motion blur will vary from user to user. In fact, mixed opinions about the “drawbacks” of IPS monitor for gaming can be found all across the web. Take this excerpt from one gaming technology writer for example: “As for pixel response, opinions vary. I personally think IPS panels are quick enough for almost all gaming. If your gaming life is absolutely and exclusively about hair-trigger shooters, OK, you’ll want the fastest response, lowest latency LCD monitor. And that means TN. For the rest of us, and certainly for those who place even a modicum of importance on the visual spectacle of games, I reckon IPS is clearly the best panel technology.” Read the full article here.

IPS monitors deliver ultra-wide 178-degree vertical and horizontal viewing angles. Graphic designers, CAD engineers, pro photographers, and video editors will benefit from using an IPS monitor. Many value the color benefits of IPS monitors and tech advances have improved IPS panel speed, contrast, and resolution. IPS monitors are more attractive than ever for general desktop work as well as many types of gaming. They’re even versatile enough to be used in different monitor styles, so if you’ve ever compared an ultrawide vs. dual monitor setup or considered the benefits of curved vs. flat monitors, chances are you’ve already come into contact with an IPS panel.

TN monitors, or “Twisted Nematic” monitors, are the oldest LCD panel types around. TN panels cost less than their IPS and VA counterparts and are a popular mainstream display technology for desktop and laptop displays.

Despite their lower perceived value, TN-based displays are the panel type preferred by competitive gamers. The reason for this is because TN panels can achieve a rapid response time and the fastest refresh rates on the market (like this 240Hz eSports monitor). To this effect, TN monitors are able to reduce blurring and screen tearing in fast-paced games when compared to an IPS or VA panel.

On the flip side, however, TN panel technology tends to be ill-suited for applications that benefit from wider viewing angles, higher contrast ratios, and better color accuracy. That being said, LED technology has helped shift the perspective and today’s LED-backlit TN models offer higher brightness along with better blacks and higher contrast ratios.

The greatest constraint of TN panel technology, however, is a narrower viewing angle as TN monitors experience more color shifting than other types of panels when being viewed at an angle.

Today’s maximum possible viewing angles are 178 degrees both horizontally and vertically (178º/178º), yet TN panels are limited to viewing angles of approximately 170 degrees horizontal and 160 degrees vertical (170º /160º).

TN monitors are the least expensive panel technology, making them ideal for cost-conscious businesses and consumers. In addition, TN monitors enjoy unmatched popularity with competitive gamers and other users who seek rapid graphics display.

Vertical alignment (VA) panel technology was developed to improve upon the drawbacks of TN. Current VA-based monitors offer muchhigher contrast, better color reproduction, and wider viewing angles than TN panels. Variations you may see include P-MVA, S-MVA, and AMVA (Advanced MVA).

These high-end VA-type monitors rival IPS monitors as the best panel technology for professional-level color-critical applications. One of the standout features of VA technology is that it is particularly good at blocking light from the backlight when it’s not needed. This enables VA panels to display deeper blacks and static contrast ratios of up to several times higher than the other LCD technologies. The benefit of this is that VA monitors with high contrast ratios can deliver intense blacks and richer colors.

MVA and other recent VA technologies offer the highest static contrast ratios of any panel technology. This allows for an outstanding visual experience for movie enthusiasts and other users seeking depth of detail. Higher-end, feature-rich MVA displays offer the consistent, authentic color representation needed by graphic designers and other pro users.

There is another type of panel technology that differs from the monitor types discussed above and that is OLED or “Organic Light Emitting Diode” technology. OLEDs differ from LCDs because they use positively/negatively charged ions to light up every pixel individually, while LCDs use a backlight, which can create an unwanted glow. OLEDs avoid screen glow (and create darker blacks) by not using a backlight. One of the drawbacks of OLED technology is that it is usually pricier than any of the other types of technology explained.

When it comes to choosing the right LCD panel technology, there is no single right answer. Each of the three primary technologies offers distinct strengths and weaknesses. Looking at different features and specs helps you identify which monitor best fits your needs.

LCD or “Liquid Crystal Display” is a type of monitor panel that embraces thin layers of liquid crystals sandwiched between two layers of filters and electrodes.

While CRT monitors used to fire electrons against glass surfaces, LCD monitors operate using backlights and liquid crystals. The LCD panel is a flat sheet of material that contains layers of filters, glass, electrodes, liquid crystals, and a backlight. Polarized light (meaning only half of it shines through) is directed towards a rectangular grid of liquid crystals and beamed through.

Note: When searching for monitors you can be sure to come across the term “LED Panel” at some point or another. An LED panel is an LCD screen with an LED – (Light Emitting Diode) – backlight. LEDs provide a brighter light source while using much less energy. They also have the ability to produce white color, in addition to traditional RGB color, and are the panel type used in HDR monitors.

Early LCD panels used passive-matrix technology and were criticized for blurry imagery. The reason for this is because quick image changes require liquid crystals to change phase quickly and passive matrix technology was limited in terms of how quickly liquid crystals could change phase.

Thanks to active-matrix technology, LCD monitor panels were able to change images very quickly and the technology began being used by newer LCD panels.

Ultimately, budget and feature preferences will determine the best fit for each user. Among the available monitors of each panel type there will also be a range of price points and feature sets. Additionally, overall quality may vary among manufacturers due to factors related to a display’s components, manufacturing, and design.

Alternatively, if you’re into gaming and are in the market for TN panel these gaming monitor options may be along the lines of what you’re looking for.
