lcd screen temperature range brands
Modern LCD screens have a great many uses. Not only are they now the system of choice for our home TVs and computers but their use in digital signage has made them a common sight in many shopping malls, airports and other locations with high quantities of people.
Even outdoor locations are no barrier to the use of modern LCD screens with outdoor digital signage a rising medium now seen in many town centers, car parks, front of stores and train station platforms.
All this out of home use means many screens operate in locations test the temperature limits of LCD displays. While waterproof screens and LCD enclosures designed for rugged applications provide the ability of the screen to operate-even in outdoor locations, one consideration often overlooked, is that of temperature.
LCD screens have a limited temperature range. Not only will the electronics inside an TV screen overheat and cause failure if the screen gets too hot, but the liquid crystal itself will begin to deteriorate under hot conditions.
The same is true of environments where temperatures fall below zero, causing a screen to stop functioning. A typical LCD TV has an operating range between 0°C (32°F) and 32°C (90°F).
Of course, many indoor and outdoor locations don’t suffer temperatures outside of this range, but many locations do and placing screens in these areas can prove challenging.
One of the problems with using a screen in hot locations is that the screen itself produces quite a bit of heat. When housed in an outdoor enclosure, the heat has to be continuously removed. While cooling fans combined with an air-vent normally carry out this task on an LCD, the need to prevent moisture from getting to the screen makes the task more complicated.
To get around this problem, specially shaped vents provide an exit for hot air while preventing rainfall and other moisture from getting in. In some locations where ambient temperatures are extremely high, screens need air conditioning to ensure they don’t exceed the maximum operating temperature.
In cold climates the opposite problem occurs. The need to keep heat in often requires insulation of the screen enclosure. Often this can trap enough of the heat generated by the screen itself to keep the internal temperature above minimum, but in some locations, even this isn’t enough. Heaters, controlled by thermostats provide extra heat in these circumstances, which enables the use of LCD displays in extremely cold locations such as ski-resorts and in Arctic regions.
Liquid crystal displays (LCD) have become an essential component to the industry of display technology. Involved in a variety of contexts beyond the indoors like LCD TVs and home/office automation devices, the LCD has expanded its usage to many environments, such as cars and digital signage, and, thus, many temperature variations as well.
As with any substance that requires a specific molecular characteristic or behavior, LCDs have an operating temperature range in which the device, if within, can continue to function properly and well. In addition to that, there is also an ideal storage temperature range to preserve the device until used.
This operating temperature range affects the electronic portion within the device, seen as falling outside the range can cause LCD technology to overheat in hot temperatures or slow down in the cold. As for the liquid crystal layer, it can deteriorate if put in high heat, rendering it and the display itself defective.
In order for the LCD panel to avoid defects, a standard commercial LCD’s operation range and storage range should be kept in mind. Without adaptive features, a typical LCD TV has an operating range from its cold limit of 0°C (32°F) to its heat limit of 50°C (122°F) (other LCD devices’ ranges may vary a bit from these numbers).
The storage range is a bit wider, from -20°C (-4°F) to 60°C (140°F). Though these ranges are quite reasonable for many indoor and even outdoor areas, there are also quite a few regions where temperatures can drop below 0°C or rise above 32°C, and in these conditions, LCDs must be adapted to ensure functionality.
Heat, can greatly affect the electronics and liquid crystals under an LCD screen. In consideration of heat, both external heat and internally generated heat must be taken into consideration.
Seen as the liquid crystals are manipulated in a device by altering their orientations and alignments, heat can disrupt this by randomizing what is meant to be controlled. If this happens, the LCD electronics cannot command a certain formation of the liquid crystal layer under a pixel, and the LED backlighting will not pass through as expected, which can often lead to dark spots, if not an entirely dark image. This inevitably disrupts the display’s readability.
Depending on the upper limit of the operation temperature range, LCD device can be permanently damaged by extreme heat. With long exposure to extreme heat, besides the destruction of the liquid crystals, battery life can shorten, hardware can crack or even melt, response time may slow to prevent even more heat generation from the device.
The LED backlight and the internal circuitry, typically TFT-based in the common TFT LCDs, are components that can generate heat that damages the device and its display. To address this concern with overheating, many devices use cooling fans paired with vents.
Some devices that are used in extremely high ambient temperatures may even require air conditioning. With air vents to carry the heat out, the device can expel it into the surroundings.
In the opposite direction is extreme cold. What typically occurs in the cold is “ghosting” (the burning of an image in the screen through discoloration) and the gradual slowing and lagging of response times. Like heat-affected LCD modules, the extreme temperature can affect the liquid crystals. This layer is a medium between the liquid and solid state, so it is still susceptible to freezing.
An LCD device can be left in freezing temperatures because it will likely not be permanently damaged like in the heat, but it is important to understand the device’s limits and how to take precautions when storing the device. The standard and most common lower-bound storage range limit is -20°C, below freezing, but if possible, it would be best to keep it above that limit, or else there is still a risk of permanent damage.
If the device is not adapted for the cold, it would be good to keep it bundled up, trapping the heat within layers. However, this is only a temporary solution. Adapted, rugged devices have advantages such as screen enclosure insulation for heat level preservation and, in more extreme cases, heaters to generate extra heat to raise the internal temperature to a level above the minimum.
When selecting the appropriate module, it is necessary to understand the device’s expected primary application. The application will decide factors such as display type, environmental conditions, whether or not power consumption is a factor, and the balance between performance and cost. These factors can have an effect on the operation and storage temperature ranges for the device.
Display types have a lot of variation. Choices like alphanumeric or graphic LCD, human-machine interactive LCD modules and touchscreen panels capabilities, the width of the viewing angle, level of contrast ratios, types of backlighting, and liquid crystal alignment methods are often considered. For example, the twisted nematic LCD provides for the fastest response time at the lowest cost, but cannot offer the highest contrast ratio or widest viewing angle.
Environment-based factors must consider things besides the obvious temperature like UV exposure and humidity/moisture, as they all are necessary in finding the perfect fit extreme temperature LCD module.
Besides the LCD modules, recent new products have opened doors in wide temperature range displays, such as OLED displays. OLED displays offer better displays in regard to contrast, brightness, response times, viewing angles, and even power consumption in comparison to traditional LCD displays.
These benefits, in addition to its ability to achieve a wide temperature range, provide more options for consumers in search of high quality displays for extreme climates.
The higher the mux rate, the less time a given group of segments is being addressed , and the worse the display will look. If you refer to our "Basic Operation of an LCD" page, it is easy to see that this is not a good situation.
To understand what happens to the LCD in cold temperatures, we"ll need to go back to the basics of LCD technology. Liquid crystal displays are just like their name suggests... they contain a liquid that is housed between two layers of glass. Liquids begin to freeze as the temperature drops. As the liquid in the display freezes the response time slows down. In other words, it takes longer for the numbers and letters on the display to change (Turn ON or Turn OFF).
The best way I can think to explain the response time of the LCD in cold temperatures is a ceiling fan. When you turn OFF the ceiling fan the blades continue to turn for a few minutes, even though the power if OFF. When you turn ON a ceiling fan the blades will be at full speed in a shorter period of time. At most the blades will be at their max speed within 30 seconds. When talking about an LCD, we talk about when the display is ON (the characters can be seen) or OFF (the characters cannot be seen).
We do not recommend operating our wide temperature (extended temperature) displays below -20°C (-4°F). This is true for all segment displays (static displays or glass displays), 7 (seven) segment, 14 (fourteen) segment, and 16 (sixteen) segment LCD’s.
Alphanumeric LCD displays such as: 8x1 LCD display, 8x2 LCD display, 16x1 LCD display, 16x2 LCD display, 16x4 LCD display, 20x2 LCD display, 20x4 LCD display, 24x2 LCD display, 40x1 LCD display, 40x2 LCD display, and 40x4 LCD display will react the same way.
Professional LCD displays are located in such industries as medical, industrial, theaters, airports, train stations, churches and even schools. They provide the ability to display information to a large body of people or are visible at a great distance. These displays produce large color images and characters that display information such as arrival and departure times and weather conditions. Information can be presented as precisely and attractively as possible.
TFT, OLEDs and Plasma can be customized to meet the needs of a customer, but the tooling cost is very prohibitive. Even if the customer is willing to invest into tooling, the MOQ (Minimum Order Quantity) requirements can reach as high as several thousand. These limitations force customers looking for a professional LCD display to design their product around the LCD. This is no longer true with the introduction of a new technology that offers the ability of low cost tooling and lower MOQ’s but also a wide operating temperature range and ultra-sharp contrast.
UWVDLCD displays are built with a stark black background. Unlike other technologies that use filters to create the black, UWVD LCD displays offer a true black background 100% of the time. There is no ‘dark grey’ or fading of colors that older displays suffered from.
In the past, product design engineers using a professional LCD display were required to design their product around the display module. UWVD now reverses this; the display can be designed and manufactured to meet the needs of the customer’s product.
Professional LCD displays incorporating UWVD technology offer a contrast ratio of greater than 200:1. This contrast can be seen when the display is located a long distance from the audience or end customer.
The operating temperature range of a TFT is at -20C to +70C and plasma displays are rated to at 0C to +40C. OLED displays can operate as low as -40C, but keep in mind that half-life of the blue color is rated at 14K hours (1.6 years on continuous use).
Product design engineers making use of professional LCD displays have many choices when choosing a display technology that would be perfect for their particular product. The UWVD technology may offer a competitive advantage over other competing LCD technology.
The thermoMETER CT is a cost-effective temperature sensor that is integrated with a measuring range of 50 to 600°C and -40 to 900°C. This device possesses a spectral rate ranging from 8 to 14 µm and is characterized by ...
... 8-14 µm.It features a broad measuring range of -50 to 600°C.Built in with one of the smallest IR sensors in the world, it displays extremely short measuring times and is most efficient for fast processes.It also showcases ...
The thermoMETER CT is a non-contact IR-temperature sensor that is ideal for use in a variety of applications including processing of clays, furnaces, plastic, and textile. The unit has the capacity to measure temperatures ...
... easy-to-use pistol grip IR thermometer (sometimes called laser thermometers or non-contact thermometers) for making surface temperature measurements. It has a built-in laser to assist ...
... radiation thermometer. It is a handy type, yet high performance with focusable type, large distance factor and wide temperature range up to a high temperature.
This thermometer is inexpensive easy to used handheld type radiation thermometer with measuring range -40 to 500°C and measuring wavelength 8 to 14μm. This general use thermometer is ...
IR-TE2 is water-proof handheld infrared thermometer with measuring temperature range -40 to 300°C. With its one button operation and laser pointer for measuring location checking, anybody can use the thermometer ...
HEITRONICS transfer radiation thermometers guarantee precise and long-term stable temperature measurements. They are used for calibrating cavity blackbodies and plate radiation sources, radiation thermometers ...
Modern intensity comparison pyrometer (successor of the disappearing filament pyrometer) for precise contol of temperatures ranging between 700 °C and 3500 °C. Target spots as small as 0.1 mm can be achieved. Mikro PV ...
The DTE is a battery powered LCD digital thermometer designed for use in a wide range of industrial and process applications. Similar to our standard DTB instrument, this latest development ...
Infrared thermometer with a built-in contact thermocouple probe. This dual-sensor thermometer is very useful and requires both non-contact and contact temperature measurement. This model has food-grade ...
... gun-type infrared thermometer with laser and backlight for easier targeting and operating. The good temperature range with real-time maximum reading makes the BT63 the ideal tool for various applications.
Robust, easy-to-use and compact, PN 6515 waterproof thermometer is dedicated to temperature control of perishable food and can be used within expertise campaigns in food industry.
... accuracy handheld temperature indicator with two platinum resistance thermometer inputs. The high precision makes the instrument particularly suitable as a portable reference thermometer to use alongside ...
... a mobile phone. It has a dual target laser for aiming at the measuring point. The emission factor can be adjusted. The LCD display is easy to read due to its size and the background lighting.
Microtips’s Automotive Grade LCD Modules are offered in sizes ranging from 3.5 to 12.1 in. with high-brightness backlights. The units are suitable for use in applications such as dials, gauges, clocks and audio/thermostat controls. The LCD modules can be operated in -30 to 85°C and can be either resistive or capacitive. The units use IPS technology for keeping colors accurately vibrant and viewing angles wide.
These LCD Modules, with a standard operating temperature of -30 to 85 degrees Celsius, will allow manufacturers to use these displays in any environment, no matter how harsh the conditions. With an emphasis on robust construction and extended temperature range, these displays are ready to use in automotive applications like dials, gauges, clocks, and audio/thermostat controls. They are available in a variety of sizes ranging from 3.5” to 12.1” with high resolution and can come with high-brightness backlights for sunlight readability. Most utilize the latest IPS technology to keep colors accurately vibrant and viewing angles wide. These displays are available with many different interface technologies such as LVDS and RGB to ensure that our display will work with most controllers. Touch Panels are available on some models which make them perfect for center infotainment consoles. They can be either resistive or capacitive and can be fine tuned to work with gloves if needed. They utilize SPI or I2C to communicate with the host device.
In low temperature environment, liquid crystals will be condensed and cause the screen blanked out. In order to prevent the problem, you may need to add a Glass Heater to your TFT LCD Module.
It can optimize the LCD visual clarity and operate normally by heating up to the right temperature. With Glass Heater, displays and touch screens remain usable in cold, high humidity/low dew point environments and locations where ambient temperature can change quickly.
LCD stands for “liquid crystal display,” but this is a bit of a misnomer. In reality, the technology has no liquid components, so it isn’t susceptible to freezing and expansion in extreme cold. (Remember, many vehicles nowadays have LCD displays on their in-dash radios and CD players, and these have not been known to crack in freezing climates.)
An LED (light-emitting diode) TV is nothing more than an LCD TV that uses LED backlighting. Compared to the LCD’s fluorescent-style backlighting, LEDs are more energy-efficient, but they don’t respond to cold temperatures much differently. One exception is that LED lights may actually shine brighter in cooler temperatures, as long as it is not too cold. But what is too cold?
When it comes to durability in cold temperatures, there is no real difference between LCD and LED TVs. An LCD or LED TV may not perform well under extreme temperature conditions. In the cold, the response time of an HDTV picture may lag. For this reason, many LCD and LED television manuals will specify a safe-operating-temperature range. In most HDTVs, this range is about 50–90°F.
The temperature range for safe storage is typically even wider. Most LCD and LED sets are rated for storage in temps as low as -4°F. Always refer to your television’s manual for actual safe-temperature ranges.
If your cabin gets colder than this in the winter, you may want to consider erring on the side of caution. Cover the set in a soft blanket to protect it from dust and direct sunlight, and then store it in a dry place with above-freezing temperatures for the season, or for however long you plan to be away.
If you decide to leave the TV at the cabin for impromptu winter visits, exercise caution when turning it on in a cold room. Allow time for the cabin to warm up before turning on the TV, otherwise the extreme change in temperature may result in condensation inside the set and subsequent damage to the screen.
So, when you arrive at the cottage and fire up the woodstove, fireplace or heater, wait at least an hour (longer is better) for the screen to reach a temperature within the safe operating range. Sounds like a long time to wait, we know. But just think – you’ll have more time for card games and conversation!
