Many Apple products use liquid crystal displays (LCD). LCD technology uses rows and columns of addressable points (pixels) that render text and images on the screen. Each pixel has three separate subpixels—red, green and blue—that allow an image to render in full color. Each subpixel has a corresponding transistor responsible for turning that subpixel on and off.

Depending on the display size, there can be thousands or millions of subpixels on the LCD panel. For example, the LCD panel used in the iMac (Retina 5K, 27-inch, 2019) has a display resolution of 5120 x 2880, which means there are over 14.7 million pixels. Each pixel is made up of a red, a green, and a blue subpixel, resulting in over 44 million individual picture elements on the 27-inch display. Occasionally, a transistor may not work perfectly, which results in the affected subpixel remaining off (dark) or on (bright). With the millions of subpixels on a display, it is possible to have a low number of such transistors on an LCD. In some cases a small piece of dust or other foreign material may appear to be a pixel anomaly. Apple strives to use the highest quality LCD panels in its products, however pixel anomalies can occur in a small percentage of panels.

In many cases pixel anomalies are caused by a piece of foreign material that is trapped somewhere in the display or on the front surface of the glass panel. Foreign material is typically irregular in shape and is usually most noticeable when viewed against a white background. Foreign material that is on the front surface of the glass panel can be easily removed using a lint free cloth. Foreign material that is trapped within the screen must be removed by an Apple Authorized Service Provider or Apple Retail Store.

If you are concerned about pixel anomalies on your display, take your Apple product in for closer examination at an Apple Store, Apple Authorized Service Provider, or an Independent Repair Provider. There may be a charge for the evaluation. Genuine Apple parts are also available for out-of-warranty repairs through Self Service Repair.*

Accidental Damage is any damage due to an unintentional act that is not the direct result of a manufacturing defect or failure. Accidental damage is not covered under the standard warranty of the product. Such damage is often the result of a drop or an impact on the LCD screen or any other part of the product which may render the device non-functional. Such types of damage are only covered under an Accidental Damage service offering which is an optional add-on to the basic warranty of the product. Accidental Damage must not be confused with an occasional dead or stuck pixel on the LCD panel. For more information about dead or stuck pixels, see the Dell Display Pixel Guidelines.

For more information about Dell Limited Hardware Warranty and Dell"s Accidental Damage service offering, see the Dell Warranty & Support Services page.

NOTE: Other damages may be considered customer induced if determined by Dell Technical Support, an on-site field engineer, or at the mail-in repair center.

The LCD glass on the display is manufactured to rigorous specifications and standards and will not typically crack or break on its own under normal use. In general, cracked, or broken glass is considered accidental damage and is not covered under the standard warranty.

Internal cracks typically occur due to excessive force on the screen. This can be the result of some object hitting the screen, a drop, attempting to close the lid while an object is on the keypad area, or even holding the laptop by its screen.

Spots typically occur due to an external force hitting the screen causing damage to the LCD panel"s backlight assembly. While the top layer did not crack or break, the underlying area was compressed and damaged causing this effect.

If your Dell laptop LCD panel has any accidental damage but the laptop is not covered by the Accidental Damage service offering, contact Dell Technical Support for repair options.

This graphic LCD module acts as a shield for Arduino Uno-style microcontrollers. The pins on the carrier board match up to the Arduino Uno"s ports, so the module simply presses on and is fully and correctly connected. Plus, this carrier board is able to be connected to either a 3.3v logic level or a 5v logic level device. (Read our blog post if you have questions about logic level.)

The hardware design of this carrier board is open source. Under the Datasheets & Files tab is a downloadable zip file that contains everything you need to manufacture your own boards: Gerber files, PADs source schematic and layout, and full BOM. If you have any questions, please contact our knowledgeable and friendly support staff by email, phone, or chat.

Plasma TV production ended in 2015. However, they are still being used and sold in the secondary market. As a result, it"s helpful to understand how a Plasma TV works and how it compares to an LCD TV.

When a Plasma TV is in use, the gas is electrically charged at specific intervals. The charged gas then strikes red, green, and blue phosphors, creating an image on the screen.

Each group of red, green, and blue phosphors is called a pixel (picture element — the individual red, green, and blue phosphors are called sub-pixels). Since Plasma TV pixels generate their light, they are referred to as "emissive" displays.

Plasma TVs can be made thin. However, even though the need for the bulky picture tube and electron beam scanning of those older CRT TVs is not required, Plasma TVs still employ burning phosphors to generate an image. As a result, Plasma TVs suffer from some of the drawbacks of CRT TVs, such as heat generation and possible screen burn-in of static images.

LCD crystals do not produce light, so they need an external source, such as fluorescent (CCFL/​HCFL) or LEDs, for the picture created by the LCD to become visible to the viewer.

Unlike a Plasma TV, since there are no phosphors that light up, less power is needed for operation, and the light source in an LCD TV generates less heat than a Plasma TV. There is no radiation emitted from the screen.

Potentially shorter display lifespan. Early models had 30,000 hours or 8 hours of viewing a day for nine years, which was less than LCD. However, screen lifespan improved and 60,000-hour lifespan rating became the standard, with some sets rated as high as 100,000 hours, due to technology improvements.

Not as good at tracking motion (fast-moving objects may exhibit lag artifacts). However, this has with the implementation of 120Hz screen refresh rates and 240Hz processing in most LCD sets, but that can result in the "Soap Opera Effect," in which film-based content sources look more like a videotape than film.

Narrower effective side-to-side viewing angle than Plasma. On LCD TVs, it is common to notice color fading or color shifting as you move your viewing position further to either side of the center point.

Although LCD TVs do not suffer from burn-in susceptibility, single pixels can burn out, causing small but visible, black or white dots to appear on the screen. Individual pixels are not fixable. Replacing the whole screen is the sole option if the pixel burnout becomes unbearable.

An LCD TV was typically more expensive than an equivalent-sized (and equivalent featured) Plasma TV. However, that is no longer a factor, since companies have ceased manufacturing Plasma TVs.

Manufacturers chose to incorporate 4K resolution only in LCD TVs, using LED back and edge-lighting, and, in the case of LG and Sony, incorporating 4K into TVs using OLED technology.
