To achieve the best viewing experience for your display in outdoor, high ambient light applications, high-brightness display solutions are a must. Where brightness enhancement, anti-reflective and anti-glare films passively improve a display visibility in these scenarios, active high brightness display enhancements result in best screen visibility.

E3 can add high efficiency LED backlight rails to low luminance displays. This product line provides a simpler, less costly option of replacing lamps and power sources in an existing LCD panel.

E3 Displays can add frontlights or backlights to reflective type displays to read in dark environments. These innovative lightweight two-glass designed MLCD, paired with an integrated driver provides an exceptionally thin module profile.

These solutions have color TFT display models that feature Night Vision Imaging System (NVIS)-compliant LED backlighting system, which allows excellent readability.

E3 creates out of the box TFT solutions as well as MLCDs or high brightness displays that use  reflective technology or increased LED backlighting that produces a sharper image in direct sunlight. These types of displays are commonly found in wearable electronics, measurement tools and other outdoor applications. We work with you side by side to create your custom out of the box display solution that fits your unique goals and we can also work with you to add additional enhancements to maximize your display capabilities.

Reflective polarizers are the best option for direct sunlight displays but are not ideal for low light conditions. Since a reflective polarizer reflects back 100% of the light it takes in, the brighter the surrounding environment, the easier it will be to read the display. Because they are only reflecting light and not creating it, these polarizers are best suited for monochrome displays. Reflective polarizers will increase display contrast and have the minimum amount of power consumption and heat creation.

Note: It is possible to use a reflective polarizer with a side-lit LED Display, or edge-lit LED Display. A side-lit display positions the LEDs above the reflective polarizer. This is a popular option since it provides a sharp contrast with the added benefit of being thinner (in the Z axis) than a LCD with a backlight.

Transflective polarizers are a hybrid of reflective and transmissive. They use a combination of ambient light reflection and an internal backlight to create the display image. A display with a transflective polarizer can be used with or without the backlight being on and can also be used in low or high ambient light conditions. Combining a transflective polarizer with E3 optical bonding and contrast enhancement film lamination will create a superior all light readable display with extended battery life and reliability.

A Transflective polarizer allows the display to be read with or without the backlight on. If the Liquid Crystal Display is located in an area with good ambient light, the backlight can be turned off and the display is still readable. When the LCD is moved into poor ambient light, the backlight can be turned on and the display can still be read.

TFT stands for “Thin Film Transistor.” These transistors are used in high-quality flat panel liquid-crystal displays (LCDs). TFT-based displays have a transistor for each pixel on the screen. This allows the electrical current that illuminates the display to be turned on and off at a faster rate, which makes the display brighter and shows motion smoother. LCDs that use TFT technology are called “active-matrix” displays, which are higher-quality than older “passive-matrix” displays.

Sizes can range up to 86.0″.  Each pixel in a TFT LCD is controlled by one to four transistors which offers greater control over the images and colors that it renders. TFT technology provides up to 4K resolutions, sharp contrast and wide viewing cone options.

US Micro Products manufactures a wide selection of TFT LCD (Active Matrix LCDs) displays to accommodate the needs of OEMs across many different industries, including medical, industrial, gaming, military and many more.

An array of available interfaces, brightness levels, and temperature ranges ensure that our TFT LCDs work well with your design and in the environment of your choice

Our new line of 10.1” TFT displays with IPS technology are now available! These 10.1” IPS displays offer three interface options to choose from including RGB, LVDS, and HDMI interface, each with two touchscreen options as capacitive or without a touchscreen.

The new line of 3.5” TFT displays with IPS technology is now available! Three touchscreen options are available: capacitive, resistive, or without a touchscreen.

This 32” RLCD computer monitor is the first in the world of its kind! Made primarily for those who experience discomfort from backlit monitors, it combines familiarity with groundbreaking innovation. It has no backlight, using only the ambient light that is available in most indoor settings. At a 32" diagonal size, it the largest monitor on the reflective market. there"s no flashing or blue light emissions. It is extremely easy to use. Just connect via HDMI and go! Its thin, sleek design will look great on any desktop.

Backlights are a common source of discomfort for many people due to flashing, high brightness, and blue light emissions. We developed a fundamentally different solution that doesn’t use a backlight: A monitor featuringColor Reflective LCD (RLCD) Technology.

This RLCD monitor is the first of its kind. Compared to other reflective technologies, like E-ink,it features a full-color spectrum, high refresh rate (no ghosting), and a 32 inch screen — the largest RLCD on the market. It’s great for work, watching videos, gaming, and more!

While it’d be fun to say this was all our idea, it wouldn’t be accurate. Truth be told, this was largely inspired by people like you. Thanks to your feedback, we saw the value in moving some of our reflective tech indoors. With it, we’ve developed something unique. Introducing our all new 32” RLCD Computer Monitor. Our thanks go to you. You helped make it happen! Read Our Story

As a highly trusteddisplay manufacturerfor some of the world"s largest OEMs, we take great care in the quality of our products. That"s why each of our RLCD Monitors comes standard with a1-Year Manufacturer"s Warranty. It"s our promise to you that we will replace any defective item or part for FREE in cases where damage or defects were the result of our manufacturing.

Color TFT LCDs (Thin Film Transistor LCDs) give your product a beautiful appearance with high-resolution, full-color graphics. Our modern, automated LCD factories can create custom TFT displays for extreme temperature functionality, sunlight readability, shock and vibration durability, and more. Whether you need a stand-alone TFT LCD display or fully integrated assembly with touch and cover lens, custom FPC, or custom backlight, our experienced team can develop the right solution for your project.

With the growth of the LCD panel industry as a whole, it has become more important than ever to prevent the sun’s wash out of displays used outdoors, such as automobile displays, digital signage, and public kiosks. Hence, the sunlight readable display was invented.

One solution would be to increase the luminance of the TFT LCD monitor’s LED backlight to overpower the bright sunlight and eliminate glare. On average, TFT LCD screens have a brightness of about 250 to 450 Nits, but when this is increased to about 800 to 1000 (1000 is the most common) Nits, the device becomes a high bright LCDand a sunlight readable display.

Since many of today’s TFT LCD display devices have shifted to touchscreens, the touch panels on the surface of LCD screens already block a small percentage of backlighting, decreasing the surface brightness and making it so that the sunlight can even more easily wash out the display. Resistive touch panels use two transparent layers above the glass substrate, but the transparent layers can still block up to 5% of the light.

A recent technology falling into the sunlight readable display category is the transflective TFT LCD, coming from a combination of the word transmissive and reflective. By using a transflective polarizer, a significant percentage of sunlight is reflected away from the screen to aid in the reduction of wash out. This optical layer is known as the transflector.

In transflective TFT LCDs, sunlight can reflect off the display but can also pass through the TFT cell layer and be reflected back out off a somewhat transparent rear reflector in front of the backlight, illuminating the display without as much demand and power usage from the transmissive nature of the backlight. This addresses both the issues of wash out and the disadvantages of high brightness TFT LCDs in high ambient light environments. Because of its transmissive and reflective modes, this type of device is very useful for devices that will be used outdoors but also indoors.

While it does greatly reduce power consumption, transflective LCDs are much more expensive than high brightness LCDs. In recent years, the cost has decreased, but transflective LCDs continue to be more costly.

In addition to adjustments to the internal mechanics of LCDs, it is possible to make devices more sunlight-readable using surface treatments. The most common are anti-reflective (A/R) films/coatings and anti-glare processing.

Anti-reflective focuses on depositing multiple transparent thin film layers. With the thicknesses, structures, and properties of each individual layer composing the film, reflecting light wavelengths are changed, and thus less light is reflected.

Often paired with other methods of creating sunlight readable displays is optical bonding. By gluing the glass of a display to the TFT LCD cells beneath it, optical bonding eliminates the air gap that traditional LCD displays have in them using an optical grade adhesive.

This adhesive reduces the amount of reflection between the glass and LCD cell as well as the reflection of external ambient light. Doing this helps provide a clearer image with an increased contrast ratio, or the difference in the light intensity of the brightest white pixel color and darkest black pixel color.

With this contrast ratio improvement, optical bonding addresses the root issue with unreadable outdoor displays: the contrast. Though an increase in brightness can improve contrast, by fixing the contrast itself, LCD display images in outdoor environments will not be as washed out and will require less power consumption.

The optical bonding adhesive’s elimination of the air gap also protects the LCD from moisture/fogging and dust, as there is no space for impurities to penetrate and remain under the glass layer. This especially helps with maintaining the state of LCDs in transport, storage, and humid environments.

Compiling the various methods of improving LCD screens for sunlight readability, these devices can be optimized in high ambient light settings. An anti-glare coating is applied to the surface of the glass and anti-reflective coatings are applied to both the front and back. The transflector is also used in front of the backlight. These features can result in 1000 Nit or more display lighting, without the excessive power consumption and heat production through a high brightness backlight, consequently allowing for a longer lasting and better performing LCD

Unfortunately, the process of building a reflector inside TFT LCD is complicated and transflective TFT LCD is normally several times higher cost compared with normal transmissive TFT LCD.

To further improve and enhance the qualities of the LCD, LED and cold cathode fluorescent lamp (CCFL) backlights are used. Both these create bright displays, but the LED specifically can do so without as much power consumption and heat generation as compared to the CCFL option. Optical bonding is also applied in order to improve display contrast, leading to a more efficient and better quality sunlight readable display.

Super Mobile HR TFT LCDs provide brilliant, vivid images outdoors where it is bright, but their visibility is poor indoors, where ambient light levels are lower.

Thus, though the display panel is transflective, it provides high transmittance and excellent image quality on a par with conventional transmissive TFT-LCDs.

The High Transmission Advanced TFT-LCD is suitable for applications where indoor use is of primary importance but outdoor use is occasionally necessary.

There is rapidly increasing demand for wide viewing angle TFT display modules,at present,wide viewing angle TFT display modules include MVA(Multi-domain Vertical Alignment) and IPS(In-Plane Switching) and O-Film TFT,comparing with MVA and IPS TFT technology,O-Film TFT is the most cost-effective products,what’s more,MVA and IPS TFT is more popular for consumer products,such as tablet and smart phone,most of them are not good for industrial grade products.

Most of the TFT-LCD are used in industrial market.However, TN-LCD disadvantage is obvious grayscale reverse phenomenon,which means the display should be the higher the gray level the brighter in theory,from zero gray scale (black) to 255 gray scale (white).when the liquid crystal display is at a certain angle, it is possible to see the low gray level is brighter than the high gray level.This phenomenon is called grayscale reverse.

O Film TFT module can increase the viewing angle and improve the grayscale reverse.The image is a comparison of normal TFT and O Film TFT.Left is normal TFT module, when viewed over 6 o"clock direction-the optimal viewing angle,normal TFT will show the problem of grayscale reverse.However, when O Film TFT also exceeds the optimal viewing angle,the problem has been improved.Therefore, O Film TFT is one best choice for wide viewing angles in the industrial field.

Sunlight readable tft lcd display included color transflective tft lcd and high brightness tft lcd,both high brightness tft LCD (transmissive display) and transflective lcd are viewable under sunlight conditions, butwhich one would be the most suitable sunlight redable lcd display for your application? let"s see the comparison in the following article.

Compare to transmissive display, transflective TFT has a reflector layer inside tft lcd cell that is in front of the backlight. The incoming light is reflected and used to illuminate the TFT display. Transflective TFT have both "transmissive" and "reflective" modes.

Both display modes work together for enhanced performance, as a result, the performance of the display content in very bright light is perfect even without any backlight on the transmissive tft lcd. Customers using a transflective TFT LCD module can save power by reducing or turning the display"s backlight off during bright environments.

Transflective TFT become more popular since the demand of requiring good performance in bright environments and direct sunlight.so that the transflective TFT displays are perfectly readable under almost any ambient light conditions. In addition, they arevery energy efficient, making them ideal for battery powered devices and mobile applications.

In the following, we make a full comparison about the high brightness tft lcd vs transflective tft lcd display in the technical parameters, display performance, and cost evaluation. After read this article, you would get a deep comprehension about sunlight readable display tft, and how to select sunlight readable tft lcd display, to choose a most suitable transflective tft lcd or high brightness tft lcd (transmisive display) for your outdoor display.

ratio only about 2%, they are not a significant transflective tft lcd, it is the alternative transflective lcd solution that the reflective layer is located on the back polarizer, not in the color filter, the 2% reflective ratio is too low to say it is transflective

its cost around 18 USD,So transflective tft lcd is good, but are you ready to pay more cost about your sunlight readable tft lcd display, I hope you had a answer after read this article.

When transflective LCD technology used in regular TFT LCD with a reflective function. via the imposed reflective function, the modified tft LCD can reflect the ambient light passing the LCD cell and utilize the reflected light beams as its illumination. The stronger the ambient light is, the brighter the LCD will be needed.Transflective LCD modules are with both transmissive and reflective properties, and the image display effect depends on the conditions of the ambient environment. for transflective tft lcd, the tft lcd display uses a backlight with a transmissive property in dark environments, and uses external light with a reflective property in bright environments. so the transflective lcd method allows for better color performance than transmissive tft lcd with same backlight brightness, then the transflective lcd provides similar color characteristics similar to the transmissive mode that indoor. The net Reflectance rate of regular Transflective LCD solution is from 0.9% to 8% varied from panels selected. For example, with 1.3% net reflectance rate and under 10,000 ambient sunlight conditions, the brightness gain is around 130 nits added to original backlight brightness.

You could also find more information about "what makes best sunlight readable lcd display" here :https://www.szmaclight.com/new/Sunlight-readable-display.html

Raystar is a global leading LCD panel supplier and specialized in producing TFT LCD Panel, including Color TFT, Monochrome TFT Display and bar type TFT Display. Raystar Color TFT displays are available in various resolutions and offers a wide product range of small to medium-sized TFT-LCD modules from 0.96” to 12.3". The interface options are in MCU / RGB / SPI / UART / 8080 / LVDS. TFT Panel with control board or TFT LCD Panel with micro controller are also available.

DS042BOE40N-001 is a 4.2inch normally black display mode,it applies to 4.2” color TFT-LCD panel.The 4.2inch color TFT-LCD panel is designed for electronic label,white house,smart home,intercome device,industrial equipment device and other electronic products which require high quality flat panel displays,excellent visual effect.This module follows RoHS.

6.Special share LCD can be customized,such as bar,square and round LCD display can be customized or any other special shaped display is available to custom.

Reshine Display HDMI TFT Display Modules allow developers and makers to quickly add a TFT LCD display to their designs. Rather than using a FPC (Flexible Printed Circuit) ribbon cable, users can connect a standard HDMI cable from their desired board or computer right into the TFT module.

The HDMI TFT Display Modules are available in 7", 10.1",11.6",13.3" and 15.6" versions. These LCD Display Modules all feature MVA (Multi-domain Vertical Alignment) technology and offer the choice of capacitive, resistive, or no touch panel. Standard, Premium, or Sunlight Readable TFT Display options are also available in selected sizes.

Extended Half-Life.TFT displays boast a much higher half-life than their LED counterparts and they also come in a variety of size configurations that can impact the device’s half-life depending on usage and other factors.

TFT displays can have either resistive or capacitive touch panels.Resistive is usually the standard because it comes at a lower price point, but you can also opt for capacitive which is compatible with most modern smartphones and other devices.

TFT displays offer exceptional aspect ratio control.Aspect ratio control contributes to better image clarity and quality by mapping out the number of pixels that are in the source image compared to the resolution pixels on the screen.

Monitor ghosting doesn’t occur on TFT displays.This is when a moving image or object has blurry pixels following it across the screen, resembling a ghost.

TFT displays are incredibly versatile.They offer a number of different interface options that are compatible with various devices and accommodate the technical capabilities of all users.

Medical devices should have high contrast, high resolution, wide viewing angles, and high-quality LCD screen image displays. LCD screens will also be required to have higher brightness when used in operating rooms, emergency rooms, ICUs, and other environments that use high-brightness lighting. A newer design trend is the use of low-voltage differential signal transmission LCD modules to ensure minimal electromagnetic interference to the equipment. The industrial control screens used in medicine are generally those of Mitsubishi and AUO. Industrial control panel stability, and high parameters, is the best choice for medical equipment.

Industrial screens are usually used in automatic control equipment, industrial sites, mines, oilfields, test equipment, etc. Most modules used in industrial integrated workstations range from 5.7 inches to 19 inches. The brightness of the LCD screen is usually required to be above 300, wide temperature, 4:3 thick LCD screen, industrial LCD screen, or desktop LCD screen is a better choice.

LCD provides a powerful information management platform for security monitoring. Through the integration of case high incidence areas, key protection units, police road information, monitoring information, police force configuration information, electronic maps, police identification symbols, etc., can achieve full-screen view, multi-screen browsing, touch head operation, and other functions can realize personnel, vehicles and other police resources simulation deployment. This display is also commonly used in industrial LCD screens, stable, high parameters, but in the military screen is usually equipped with a touch screen, do a full paste, to help explosion-proof, brighten.
