cog meter lcd module factory free sample

NHD-C12864A1Z-FSR-FBW-HTT | Monochrome Graphic COG | 128x64 Pixels | Transflective LCD | Side Red Backlight | FSTN (+) Positive Display | Built-in 12V Heater & Temp Comp Circuit

Newhaven 128x64 graphic Chip-On-Glass (COG) Liquid Crystal Display shows dark pixels on a red background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -40 to 70 degrees Celsius. This NHD-C12864A1Z-FSR-FBW-HTT display includes a built-in 12V heater, and temperature compensation circuit. It has an optimal view of 6:00, operates at 3V supply voltage and is RoHS compliant.

This Chip-On-Glass (COG) 20x2 character Liquid Crystal Display shows characters with dark pixels on a white background when powered on. This FSTN positive display can achieve higher contrast and is visible with ambient light or a backlight. As a COG display, there"s no PCB and the controller/driver is directly bonded to the glass of the display. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-C0220BA-FSW-FTW display has an optimal view of 12:00. This display operates at 5V supply voltage and is RoHS compliant.

Dr Pan: Hello, Greg. STN is the abbreviation for Super Twisted Nematic. The main difference between TN, HTN, STN and FSTN LCD is the view angle. From the definition, the maximum view angle of STN LCD is 210~255 degree. Take this STN positive LCD for example. The view angle is 12 o’clock direction and it can be seen very clearly in the full view angle: 12 o’clock direction, 3 o’clock direction, 6 o’clock direction, 9 o’clock direction and the front side.

128X64 (S) COG White Display Small SizeDisplay is professional Monochrome LCD display for Industry application, include digital panel meter, UPS, inverter, multi-function meter, POS machines, Fuel Dispenser, Oil Dispenser, Gas Dispenser, Flow Meter, KWH Meter, Energy Meter, Water Meter, Gas Meter, Smart Meter, Clock. Our COG Graphic LCD Module 128*64 has various different models on shelf and accept custom develop to meet your special requirement. We can develop different interface like I2C, Serial, and we also have different font available.

This Chip-On-Glass (COG) 20x2 character Liquid Crystal Display shows characters with dark pixels on a white background when powered on. This FSTN positive display can achieve higher contrast and is visible with ambient light or a backlight. As a COG display, there"s no PCB and the controller/driver is directly bonded to the glass of the display. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-C0220BA-FSW-FTW-3V3 display has an optimal view of 12:00. This display operates at 3.3V supply voltage and is RoHS compliant.

A very unique 16×2 dot matrix Character LCD Module display in FSTN Positive LCD Mode, Six O’clock viewing direction, Wide Temperature Range (Operating Temp: -20°C to 70°C, Storage Temp: -30°C to 80°C), and White LED Backlight. It has a transflective polarizer, recommended for applications that will be used both indoor and outdoor. This product is assembled Chip On Glass with 1/16 Duty and a Controller IC NT7603 or equivalent. The interface type is Parallel. This is an ROHS Compliant product manufactured with ISO standards and procedures.

You don"t know which module is right for you? Contact us, we will be happy to advise you more about our products and will surely find the right product together with you.

TSG094B-F-T isreflectiveTN positive 7 segment monochrome LCD display. This monochrome display is best for gas pump and water meter. Thins COG display do not have backlight, the chip is on the glass. What"s more, we also support custom monochrome display, you can customize the characters showed on the screen, this segment LCD display for you reference only. If this mono LCD display is not suitable for your project, you can send us your drawings, datasheet, ortell us your requirements, we can customize one for you based on the information you provided.

We also support custom LCD displays, if you did not find the LCM that you want from our shop, please feel free to contact us. Color display, monochrome display, segment LCD display, graphic display, COB, COG, touch screen, etc, all can be customized by send our drawings, datasheets or tell us your requirements.

We have developed thousands of LCD display products for automotive products, consumer electronics, smart wearable device, POS, PDA, medical equipment, IOT products, smart home application, white goods, industrial and integration equipment, communication device, fiscal products, meter and measuring device, etc.

We usually arrange the shipment of samples in 3 working days after received the payment if there are some LCD display samples in stock. The out of stock samples and batch production should be negotiated with us.

Of course! TSD was established in 2004, we are a professional LCD display manufacturer from China with ISO13485,IATF16949,ISO9001 and other certificates. At present, we have thousands of standard LCD modules for customer choosing, and special customization is welcome too.
