In the previous article, I described the steps needed to install an LCD touchscreen on the Raspberry Pi. In this article, I will show you how to adjust the screen rotation of the LCD to landscape mode, and will show you how to calibrate the touchscreen pointer for optimal accuracy. Just follow the steps below to compete the process of setting up your Raspberry Pi LCD touchscreen:
1. First we need to change the setting for screen rotation in the /boot/cmdline.txt file. This setting is called fbtft_device.rotate=X. By default, this is set to X=0, which results in a portrait mode screen orientation. In order to switch the orientation to landscape mode, change fbtft_device.rotate=0 to fbtft_device.rotate=90. Enter sudo nano /boot/cmdline.txt at the command prompt. There should only be one line in this file. Go to the end of it and you will find the fbtft_device.rotate=X setting. Change the value from 0 to 90:
After the Pi finishes rebooting, you should notice that when you move your finger across the touch screen, the pointer should follow correctly in both axes. If you are using the Raspberry Pi 2 Model B, you will need to complete the calibration steps below before the pointer follows your finger correctly (and make sure that you have enabled startx to load automatically – see step 6 in this article).
You can rotate the screen 90 degrees (as we did in this tutorial) and the power connector will be at the bottom of the screen, but you can also rotate it 270 degrees so that the power connector is at the top of the screen. To do this, simply enter fbtft_device.rotate=270 in the /boot/cmdline.txt file. Then change the DISPLAY=:0 xinput --set-prop "ADS7846 Touchscreen" "Evdev Axis Inversion" 0 1 line in the /etc/X11/xinit/xinitrc file to DISPLAY=:0 xinput --set-prop "ADS7846 Touchscreen" "Evdev Axis Inversion" 1 0. All you need to do is switch the values of the 0 and 1 at the end of this line.
4. Now we can use ts_calibrate. Enter ts_calibrate at the command prompt (make sure you are still in root mode) to run the ts_calibrate program. The program will consecutively display five crosses on different parts of the screen, which you need to touch with as much precision as possible:
A standard Raspberry Pi project that uses a typical HDMI monitor probably has a display with the correct orientation. But that’s not always the case. Perhaps you’ve installed an unusual monitor and need to flip things around.
After all, screen rotation is a feature most operating systems support for good reason. Word processing (reports, school assignments, even screenplays) benefit from a display rotated 90 degrees.
Your easiest option for rotating the display on a Raspberry Pi is via the operating system. In Raspberry Pi OS there is a specific menu command in the desktop environment. Make the right selection here, and you can rotate the display clockwise, anti-clockwise, or flip it entirely.
Ubuntu is an increasingly popular option for Raspberry Pi users as an alternative to Raspberry Pi OS. Steps for rotating the display in Ubuntu differ slightly.
Users with a Raspberry Pi 4 will find that computer has its own command line screen rotation instructions. These are an alternative to the steps outlined above.
To pre-configure the Raspberry Pi display settings, you can edit the config.txt file before the first boot. This can also be edited at any other time, although the changes will not be instantaneous.
If you’re using Windows, you’ll find config.txt in the Pi’s boot folder, the only part of the SD card that is readable. It can be edited in Windows Notepad or any other text editor.
On Linux (including Raspberry Pi OS), you can open config.txt in a desktop text editor or in the terminal. To edit config.txt in a tool like nano, which is preinstalled, use: sudo nano /boot/config.txt
Browse through the text file until you find a setting called display_hdmi_rotate. (If this doesn’t exist, you can add it on a new line at the bottom of the page).
For example, if you were using the official Raspberry Pi 7-inch Touchscreen Display and wanted to flip (or invert) the display, you would use: display_hdmi_rotate=2
Third party displays require slightly different instructions. For example, if you set up a Hyperpixel or other Raspberry Pi display HAT, the command required is the simpler display_rotate=x.As before, 0 resets the orientation, with 1, 2, and 3 available as rotation options.
The rest of this guide looks at settings and commands, but there is a chance you won’t need them. After all, there is a chance that your Raspberry Pi display doesn’t need rotating. Instead, you just need to rethink your project to ensure everything lines up the way you need it to.
So, consider the project, the cabling you’re using, and any chassis or case. Could a different cabling solution improve positioning of the display? Could you stick with the Pi’s default orientation if the cables were otherwise arranged?
There is no need to put up with upside-down or incorrect orientation from your Pi’s display. Simply use one of these options to rotate the display, using desktop menus, terminal commands, or configuration statements.
I think the touch part of the screen behaves as a different part (a input device) on top ot the display"s output device. So you have currently just rotate the latter not the input
This suggest a similar concept - except the screen is rotated by adding this to /boot/cmdline.txt (you may be able to stick with your existing rotation command, in which case some of these options may need to be different!):
You haven"t mentioned/linked to the library you are using which might help people answer. First of all, check if the library you are using has the ability to control display layout - it might already and you won"t need the following:
Somewhere in your library"s display initialisation function it will write the value 0x36 followed by another byte. The 0x36 is the MADCTL command and the following byte is the parameter that controls the display layout. You can change this value to get the effect you want. I"d suggest changing one bit at a time - it helps keep track of which bit has what effect.
The RPi LCD can be driven in two ways: Method 1. install driver to your Raspbian OS. Method 2. use the Ready-to-use image file of which LCD driver was pre-installed.
2) Connect the TF card to the PC, open the Win32DiskImager software, select the system image downloaded in step 1 and click‘Write’ to write the system image. ( How to write an image to a micro SD card for your Pi? See RPi Image Installation Guides for more details)
3) Connect the TF card to the Raspberry Pi, start the Raspberry Pi. The LCD will display after booting up, and then log in to the Raspberry Pi terminal,(You may need to connect a keyboard and HDMI LCD to Pi for driver installing, or log in remotely with SSH)
This LCD can be calibrated through the xinput-calibrator program. Note: The Raspberry Pi must be connected to the network, or else the program won"t be successfully installed.
The RPi LCD can be driven in two ways: Method 1. install a driver to your Raspbian OS. Method 2. use the Ready-to-use image file of which the LCD driver was pre-installed.
2) Connect the TF card to the PC, open the Win32DiskImager software, select the system image downloaded in step 1 and click‘Write’ to write the system image. ( How to write an image to a micro SD card for your Pi? See RPi Image Installation Guides for more details)
3) Connect the TF card to the Raspberry Pi, start the Raspberry Pi. The LCD will display after booting up, and then log in to the Raspberry Pi terminal,(You may need to connect a keyboard and HDMI LCD to Pi for driver installing, or log in remotely with SSH)
This LCD can be calibrated through the xinput-calibrator program. Note: The Raspberry Pi must be connected to the network, or else the program won"t be successfully installed.
Since the Raspberry Pi image and version are frequently updated, if you encounter a situation where the LCD cannot be used normally, please download the latest version of the image provided by us or from the official website of Raspberry Pi and install the latest driver provided by us.
When the Raspberry Pi starts normally, the PWR light is always on, and the ACT light is flashing. If it is found that both lights are always on, it may be that the TF card is not successfully programmed to the image or the TF card is in poor contact with the Raspberry Pi.
It is recommended to use a 5V 2.5A power adapter for the Raspberry Pi. If the Raspberry Pi is powered by the USB port of the PC, the Raspberry Pi may not be able to start normally due to an insufficient power supply.
